CITROEN DS3 Cabrio Bedienungsanleitung

OWNER'S HANDBOOK - SUPPLEMENT

Welcome

This document describes the special

features relating to the presentation and

use of your DS3 CABRIO.

Refer to the DS3 owner's handbook for all

other descriptions and specifications, and

also to maintenance and warranty guide for

servicing information for your vehicle.

Contents

ACCESS

2Soft top

11 Boot

004

004 PRACTICAL

INFORMATION

14 Rear shelf

012

011

TECHNICAL DATA

15 Changing a bulb

16 Changing a fuse

17 Recommendations on care

18 Petrol engines

19 Petrol weights

20 Diesel engine

21 Diesel weights

22 Dimensions

Key

safety warning

additional information

contributes to the protection of

the environment

refer to the page indicated FITTINGS

006

Access

Soft top

Your vehicle is fitted with an electric soft top roof.

The roof is opened and closed by pressing

the control at the interior lamp, in the opening

direction 1and in the closing direction 2.

Electric opening and

closing

Access

In order to maintain the state of charge of

the battery, it is recommended that the roof

be operated with the engine running.

Operation of the roof is possible:

- engine running, or

- ignition on.

During operation of the roof with just

the ignition on, starting the engine may

cause the roof to stop, depending on

the state of charge of the battery. To

have the roof continue the operation,

operate the control again after the

engine has started.

Operating zones

There are two operating zones:

Zone A: horizontal operating zone, in manual

or automatic mode.

Zone B: vertical operating zone, in automatic

mode only.

Before operating the roof, ensure that no occupant of the vehicle or person outside the

vehicle could be subject to any risk related to the movement of the roof or the rear screen

and that no object could interfere with the operation.

Roof positions

Position 0: Roof completely closed.

Position 1: Stop position for automatic roof

closing.

Position 2: Roof open horizontally.

Position 3: Roof completely open.

Access

Opening

Manual mode

Opening of the roof in zone Bcan only be done in automatic mode.

)In zone A, press and hold the control

without passing the point of resistance to

open the roof.

)The roof stops as soon as you release the

control.

Access

Automatic mode

During automatic operation of the roof

in zone A, pressing the control stops

the roof.

During complete opening of the roof,

the rear screen comes down onto the

rear shelf. Ensure that no object is left

on the shelf which might damage the

rear screen or the roof.

Automatic opening of the roof in zone B

is not possible if the boot is open.

In the event of a problem, check that

the boot is fully closed

During an operation in zone B, an

instruction to stop the roof is not

possible.

Pressing the control reverses the

direction of movement of the roof,

whichever direction the control is

pressed.

This "anti-panic" function allows a quick

change in direction of movement of the

roof if suddenly required.

)Release the control: opening of the roof

continues up to the maximum horizontal

position (position 2).

)In zone B, a press on the control opens the

roof completely (position 3).

)In zone A, press the control beyond the

point of resistance to begin opening the

roof.

Access

Closing

Manual mode

)In zone A, press and hold the control

without passing the point of resistance to

close the roof.

Closing the roof in zone Bcan only be done in automatic mode.

If the roof does not lock correctly, it

opens again by a few centimetres. With

the engine running, operate the control

again.

If the problem persists, contact a

CITROËN dealer or a qualified workshop.

)The roof stops as soon as you release the

control.

)To close the roof completely, press and

hold the control until the the roof is heard to

lock.

Access

Automatic mode

)In position 3, press the control to begin

closing the roof.

When the roof is completely open, the

rear screen rests on the rear shelf.

Do not place any object on the rear

screen.

During automatic closing of the roof

in zone A(position 2to position 1),

pressing the control stops the roof.

Complete closing of the roof between 1

and 0can only be done in manual mode.

Press and hold the control until the roof

is heard to lock.

If the roof does not lock correctly, it

opens again by a few centimetres. With

the engine running, operate the control

again.

If the problem persists, contact a

CITROËN dealer or a qualified workshop.

)Release the control: closing of the roof

continues up to position 2.

)Between positions 2and 1, pressing the

control beyond the point of resistance

allows automatic closing of the roof to

position 1.

)Between positions 1and 0, press and hold

the control until the roof closes fully.

During an operation in zone B, an

instruction to stop the roof is not

possible.

Pressing the control reverses the

direction of movement of the roof,

whichever direction the control is

pressed.

This "anti-panic" function allows a quick

change in direction of movement of the

roof in the event if suddenly required.

Access

Aero-acoustic deflector Operating the roof when

driving

If a roof operation is started before the vehicle's

speed is above about 70 mph (120 km/h),

exceeding this speed limitation leads to the

following situations, depending on the type of

roof operation in progress:

- an operation in progress in zone Ais

stopped,

The roof opening and closing control

operates up to about 70 mph (120 km/h).

Above this speed, a message in the

screen informs you that operation of the

roof is not possible (speed too high).

An aero-acoustic deflector is available to

improve the acoustic comfort of occupants of

the vehicle in certain driving conditions (high

speed), by reducing the turbulence in the

passenger compartment resulting from the

displacement of air.

On opening the roof, the aero-acoustic

deflector may be deployed if it is not secured.

On closing the roof, the deflector folds away

automatically.

)With the roof open, this deflector can be

folded away manually and secured at its

centre : press vertically down on the cross

member near the paddle at the top of the

deflector and clip this paddle in the cut-out.

)To release and deploy the deflector

manually, press vertically down on the

cross member near the paddle to unclip it

from the cut-out and pull it gently towards

you.
