LQ™ Quick Start Guide

The following Quick Start Guide provides basic installation and configuration instructions for your LQ system. LQ is a

new IP interface for Clear-Com audio products. It offers Internet, LAN and WAN connectivity for multi-linking audio.

•LQ-2W2 provides connection for two 2-wire analog partyline channels (XLR connectors)

•LQ-4W2 provides connection for two 4-wire channels (RJ45 etherCON connectors)

1.1 Powering and connecting the LQ units

1) Connect the LQ unit to a network using standard Ethernet cable

and power it on (use either the DC power supply cable provided or

PoE).

2) Connect the audio cables.

3) Open a Web-browser on a device connected to the same network

as the LQ device.

4) Input the IP address shown on the LQ device’s display into the

address field of the browser.

5) Enter the default login credentials for the Core Configuration

Manager: Username – admin, Password – admin.

Core Configuration Manager (CCM)

The CCM has three main pages:

•Home - Settings for the host device (the device whose IP address

the browser is connected to).

•Devices - Settings for all devices in a Link-Group.

•Audio Assignments – Configuration of audio routes between LQ

devices.

Note: If your network does not serve

DHCP you will need to assign a static IP

address to the LQ device:

1) Connect a standard (straight)

Ethernet cable from a computer

to either LAN port on the device.

2) Ensure the computer is in DHCP

mode.

3) Open a web browser and input

the device’s IP address in the

address field.

4) Navigate to the device’s network

screen within the home page

and allocate a static IP address.

2-wire 2-wire

4-wire

1 399G117 Rev: B 11/12/14

1.2 Linking the devices

Each device’s role is set as Link-Master by default.

1) Select one device in the group to be designated as the Link-Master, connect it to the network and

power it on.

2) Connect another LQ device to the same network and power it on.

3) Enter the IP address shown on the display of the Link-Member device into the address field of your

Web-browser to connect to that device’s Core Configuration Manager.

1.3 Audio port settings

From the Core Configuration Manager (CCM) go to Devices >2-Wire/4-Wire (depending on device type).

The LQ devices arrive with the following default settings:

Power

Disabled

Mode

Clear-Com

Input/Output gain

0dB

Termination

Disabled

Network Quality

High

Input/Output gain

0dB

Network Quality

High

Pin Polarity To

Matrix

Note: When connecting any 2-

wire device to an LQ-2W2 port,

please auto-null each port.

1.4 Connecting and configuring audio channels

Once an LQ device is connected to a Link-Master, click on the Audio Assignments button within the

navigation bar to configure channel connections.

See the LQ System User Guide on the Clear-Com website for more information.

Navigate to Home >

Linking.

Click Change Role to

Link-Member.

Enter IP address of Link-Master. Click on

blue check mark or press <ENTER> key

to submit.

Select an available

device ID (highlighted in

blue).

8) Click Apply changes.

9) Repeat linking process for each device.

2 399G117 Rev: B 11/12/14
