ASSEMBLY INSTRUCTION
CONVERTIBLE MOBILE STAND
WITH ANTI-COLLISION
www.getcleartouch.com | Technical Support: (864) 643-5045 | Sales: (864) 973-7973
CTI-STAND-CONM-V3
AI-CT-03-19
2
A B C
1
2
3
5
4
7
6
DB
3
7
4
5
2
1
6
Mobile base
Center column
Tilt frame
Remote control
Display brackets
Anti-Collision unit
(not illustrated –
pre-assembled)
IEC (power) connector
8 x M8 x 40
Lenshead Allen
screw with ange
4 x M6 x 16
Lenshead Allen
screw with ange
2 x M6 x 70
Lenshead Allen screw
1 x Cable tie
Depending on the display
4 x M8 x 16
Lenshead Allen
screw with ange
PACKAGE CONTENTS
www.getcleartouch.com | Technical Support: (864) 643-5045 | Sales: (864) 973-7973
3
1 2
2
1
A
A2
3A
3 4
4
B
B
4
C
C
5 6
7
MOUNTING INSTRUCTIONS
RJ plug (frame)
Display
Molex plug (frame)
Molex plug (column)
www.getcleartouch.com | Technical Support: (864) 643-5045 | Sales: (864) 973-7973
4
7 8
5
9
D
B
D
A
C
INSTRUCTION REMOTE CONTROL
For moving the unit up or down just press and hold the buttons on the control
unit. Releasing the button will immediately stop the movement. So in case of
emergency just unhand the control unit (watchdog switch).
Height adjustable Tiltable
AUp
CVertical position
BDown
DHorizontal position
6
MOUNTING INSTRUCTIONS
Click
www.getcleartouch.com | Technical Support: (864) 643-5045 | Sales: (864) 973-7973
5
11
5
10
5
7
!System is pre-calibrated. PLEASE RECALIBRATE ONLY IN CASE OF ERROR.
7
12
13 Now repeat the points 5 6 89of the mounting instructions.
TROUBLE SHOOTING
Calibration:
1
Press key and simultaneously until you hear 1 x audio signal
2
Press key until you hear 3 x audio signal
3
Press key and hold on until the column reached the maximum position and
you can hear 2 x audio signal.
www.getcleartouch.com | Technical Support: (864) 643-5045 | Sales: (864) 973-7973
