Clover HDC041 Bedienungsanleitung

INSTRUCTION

MANUAL

3D-DNR DAY/NIGHT

MINIATURE COLOR CAMERA

MODEL HDC041

•To prevent fire or shock hazard, do not expose the product to rain or moisture.

•To avoid electrical shock, do not open the case of this product.

•Operate this product using only the recommended AC Power supply.

•Do not overload electrical outlets or extension cords; this can result in fire or electric

shock.

•Keep this product away from strong magnetic fields.

•Do not expose this product in direct sunlight or strong reflected rays.

•Refer servicing to qualified personnel only.

•Do not change or modify this product, the warranty will be voided.

•1/3” Sony Super HAD CCD

•High Resolution 550 TV Lines (Color), 600 TV Lines (B/W)

•Day/Night Camera

•OSD (On Screen Display)

•3D DNR (Digital Noise Reduction) with 3D filter

•D-WDR (Digital Wide Dynamic Range)

•DC 12V Power Source

1. Attach the mounting bracket①to the wall or ceiling, wherever you want to install the

camera. Locate a wall stud or ceiling joist and secure the mounting bracket using the

supplied screws②.

2. Fix the mounting bracket①to the camera body④with the provided screws③.

3. If necessary, change the settings to get the best images depending on your application

by using the buttons on the rear of the camera (refer to the included instruction

manual for OSD).

4. Connect the one end of BNC cable (not supplied) to the BNC (F) of 2’ cable attached

to the camera and the other end (BNC) of cable to the video devices such as DVR,

monitor/TV. Plug an AC power supply (not supplied) to the DC jack (red) on the

camera.

PRECAUTIONS

FEATURES

INSTALLATION

If the camera does not function properly, check the following points before contacting the

service center.

Troubles Remedies

No video Check the AC adapter and video cable

between the camera and a monitor

The image on the screen is dark Check the brightness control on the

monitor

The image on the screen is dim Check if the lens is stained. If dirty,

clean it with soft and clean cloth

The camera is not working properly, and

the surface of the camera case is hot Check if you have connected the

provided AC adapter

The contrast on the screen is too weak Adjust the contrast feature of the

monitor. If the camera is exposed under

too strong light, change the position

The image on the screen flickers Does the camera face to directly to the

sunlight or fluorescent light? Change the

camera position

Picture rolls and jumps, scrambled

picture Improper V-hold control. Setting on your

monitor

Picture smaller than screen House current may be too low

•Image sensor 1/3” SONY Super HAD CCD

•Total pixels 811(H) x 508(V)

•Effective Pixels 768(H) x 494(V)

•Scanning system 2:1 Interlace

•O.S.D Available

•Backlight Off / HSBLC / BLC selectable

•Resolution 550TV Lines(color),600TV Lines(B/W)

•S/N (Y signal) 52dB (AGC Off, Weight On)

Note:

▪ Apply DC12V 250 mA regulated power supply (not included).

▪ To avoid fire or shock hazard, use a UL listed power supply.

TROUBLE SHOOTING

SPECIFICATIONS

•Min.illumination 0.00001Lux(sense-up x258)

•White Balance ATW / AWB / Manual / AWC→SET

•Sense-up Off / Auto / (Selectable limit x2 ~ x258)

•3 DNR Off / On (1~50 level adjustable)

•D-WDR Indoor / Outdoor / Off

•D&N selection Color / BW / Auto

•Digital zoom On(x32) / Off

•Voltage DC12V

•Current consumption 130 mA @DC12V

•Lens

3.6mm fixed board lens

•Operating temperature/Humidity -10°C ~ +50°C. RH 95% Max.

•Storage temperature/Humidity -20°C ~ +60°C. RH 95% Max.

•Dimensions 34 (W) x 34 (H) x 30 (D) mm

•Weight 60g

This warranty gives the original purchaser specific legal rights and you may also have

other rights, which vary from state to state. If our products do not function because of any

defect in material or workmanship, we will repair free of charges for 2 years on parts and

labor from the date of original purchase. This warranty does not cover modification,

abuse, incidental or consequential damages unless the state of owner’s residence specially

prohibits limitations on incidental or consequential damages.

1. Original purchaser must fill out a warranty card and mail it to the factory with model

number, serial number and the date of purchase.

2. We will repair or replace, and return to the owner the system under this limited

warranty.

3. Please pack the system carefully and securely using the original packing materials,

and send it prepaid and insured to: 13073 E. 166th St, Cerritos, CA 90703.

4. Please include a check for $15.00 to cover the cost of return postage and handling. If

the system is returned within the warranty period, please include a proof of purchase.

If the system is out of warranty, you will receive an estimate of the repair cost for

your approval before repair work will be begun.

LIMITED 2 YEAR WARRANTY

HOW TO OBTAIN FACTORY SERVICE

CDR0460 Stand-alone 4 CH Digital Video Recorder (DVR).

CDR4450 Stand-alone 4 CH Digital Video Recorder (DVR).

CDR0860 Stand-alone 8 CH Digital Video Recorder (DVR).

CDR1660 Stand-alone 16 CH Digital Video Recorder (DVR).

CDR0850 Stand-alone 8 CH Digital Video Recorder (DVR).

CDR1650 Stand-alone 16 CH Digital Video Recorder (DVR).

CA100BP 100’ BNC/Power to BNC/Power Extension cable and coupler

ADT120250 AC Power Supply DC12V 250 mA Regulated

1-Day & Night Miniature Color Camera

1-Hardware Accessories Kit

1-Instruction Manual

1-Instruction Manual for OSD Control

1-Warranty Registration Card

AVAILABLE ACCESSORIES

PACKAGE INCLUDES
