CNB MPC1070PN Bedienungsanleitung

iCanView361MP-PM

Owner’s Manual

MPC1070PN

5M Pixel Panoramic IP Camera

Rev.1.4

The lightning flash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of uninsulated “dangerous voltage"

within the product's enclosure that may be of sufficient magnitude to constitute

a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

THE GRAPHIC SYMBOLS WITH SUPPLEMENTAL MARKING ARE ON THE BOTTOM OF THE SYSTEM.

"WARNING-TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE"

Directions

Be careful not to cause any physical damage by dropping or throwing IP Camera. Especially keep

the device away from children.

Do not disassemble IP Camera. No After Service is assumed when disassembled.

Use only the power adapter provided with IP Camera.

Be careful to prevent moisture or water penetration into the unit. Particular attention is needed

when installing IP Camera. The screw holes for the installation screws and pipes should be

maintained tight during the whole life time of the product.

All the electrical connection wires plugging in the unit should be prepared so that water from the

outside cannot flow into the unit through the surface of the wires. Penetration of the moisture

through the wire for extended period can cause malfunction of the unit or deteriorated image.

CAUTION!

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

Rev.1.4

CAUTION!

Changes or modifications not expressly approved by the manufacturer could void the user's

authority to operate the equipment.

Regulatory Notice

This equipment has been tested and found to comply with limits for a class of digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at their own

expense.

Rev.1.4

Contents

1. Introduction....................................................................................................................................................5

1.1. Overview...................................................................................................................................................5

1.2. Features & Specification...........................................................................................................................6

1.2.1.

.......................................................................................................................................6

...............................................................................................................................6

1.3. Applications of IP Camera ........................................................................................................................9

2. Product Description ....................................................................................................................................10

2.1. Contents .................................................................................................................................................10

2.2. Product Preview......................................................................................................................................10

2.3. Physical description................................................................................................................................11

2.3.1. External View...........................................................................................................................11

2.3.2. Dimension ................................................................................................................................11

2.3.3. External Connector.................................................................................................................12

2.3.4. Factory Default Switch...........................................................................................................12

2.4. Functional Description............................................................................................................................13

3. On Site Installation ......................................................................................................................................15

4. Getting Started.............................................................................................................................................17

4.1. PC Requirement.....................................................................................................................................17

4.2. Quick Installation Guide..........................................................................................................................17

4.2.1. Connect PC and IP Camera to network. ............................................................................17

4.2.2.Install IP installer and set IP parameters on IP Camera.................................................18

4.2.3.Remote video connection to IP Camera..............................................................................21

4.2.4.Additional settings through connection to the Admin Page ...........................................22

5. Trouble Shooting.........................................................................................................................................23

5.1. No power is applied................................................................................................................................23

5.2. Cannot connect to the Video ..................................................................................................................23

5.3. Windows 7 ..............................................................................................................................................24

5.4. Technical Assistance...............................................................................................................................25

AppendixA–ImportantNoticeinExchangingSD Card(Micro SD).........................................................................26

Rev.1.4

1. Introduction

1.1. Overview

The Product is panoramic IP camera offering panoramic view of 360or 180for covering entire surveillance

area with a single IP camera. 5 Mega Pixel image from Panomorph camera module can replace up to 4 PTZ

cameras and 5 fixed cameras. It enables real time transmission of synchronized video of up to

2,592x1,944(10fps) video and audio data. Remote clients can connect to MPC1070PN for the real time

video/audio data through various client solutions running on PC or smart device. Real time 2-way

communication is available through bidirectional audio communication feature.

Designed to be a stand-alone streaming audio & video transmission device, MPC1070PN can be applied to

various application area such as video security, remote video monitoring, distance education, video conference

or internet broadcasting system.

Vandal proof and weather proof housing will extend the application area to harsh environment of wide

temperature range. Embedded PoE (Power over Ethernet, IEEE 802.3af) will enable the owner to reduce TCO

(Total Cost of Ownership) by reducing on-site wiring works for the installation.

Original Video

PTZ mode

Pan/Tilt/Zoom Control

Quad mode

Each sub-screen with independent

Pan/Tilt/Zoom replaces 4 independent

PTZ cameras.

Perimeter mode

2 x180views with panning control for

ceiling mount. One 180views for wall

mount. Replaces two 180cameras..

Up to 5 crop windows of 320 x 240.

Replaces up to 5 fixed cameras.

Rev.1.4

1.2. Features & Specification

1.2.1.

•Max. 5MP(2592x1944) up to 10FPS

•Focal Length: 0.98mm (Short axis) 1.12mm (Long axis)

•Built-in Panomorph Lens (Immervision360˚)

•1/2.5” Progressive CMOS Sensor

•Super Wide Angle of 182˚x 360˚FOV

•View Modes : Single PTZ View, 4 PTZ View in 1 Window,

Perimeter View in One Window(2x180˚)

•5 Simultaneous Multi-Profile Video Streams

•Support SD card

•Analog Video Output(CVBS) & Alarm I/O

•Onvif Profile S and 2.2x, Two-way Audio (ADPCM)

•Ethernet 10/100 Base-T (PoE)

[CAMERA]

Image Sensor

1/2.5” Progressive CMOS Sensor

Scanning System

16:9 Progressive

Sync. System

Internal

Effective Pixels

2,592 (H) x 1,994 (V) 5.0 Mega

Video Output Level

Select NTSC/PAL 1.0Vp-p (BNC 75Ω, composite)

Lens

Built-in Panomorph Lens (Immervision 360), 0.98mm : Short axis / 1.12mm : Long axis

Min. Illumination

0.12 Lux (Color)

White Balance

Auto

[VIDEO]

Compression

H.264 / MJPEG

Resolution

2,592 x 1,944 @ 10fps

Multi-Profile Streaming

* 5 Simultaneous video profiles / * Select the codec type, resolution and frame rates for each profile

Intelligent Bit-rate Control

Hybrid Bit rate control (VBR+CBR)

PTZ

Digital PTZ & Video Crop

Image setting

Text overlay, Privacy mask, De-interlace filter

Rev.1.4

Motion detection

3 regions

[AUDIO]

Mono Upstream

32Kbps G.726 ADPCM, 64Kbps 16bit μ-law PCM (Line-in / Mic-in)

Mono Downstream

64Kbps 16bit μ-law PCM , Line-out(1.0Vp-p)

[NETWORK]

Protocol

IPv4/6, TCP/IP, UDP, IGMP, ICMP, ARP, RARP, PPPoE, RTCP, RTP, RTSP, SDP, HTTP,

HTTPS, SMTP, FTP, DHCP, UPnPP, NTP, DNS, DynDNS, Socks

Supported DDNS

Supported (CNB DDNS)

Security

User ID & Password protection, IP address filtering, HTTPS encryption, Digest Authentication,

User Access Log

[EXTERNAL

TERMINALS]

LAN

10/100 Base-T LAN (auto MDIX)

Analog Output

1 Channel D1 CVBS Output of the encoding video

Alarm

Alarm I/O (1 Sensor input & 1 Relay output)

Other

Mic, Line in / Line Out / 12VDC

[SYSTEM

INTEGGRATION]

Intelligent Video

Motion Detection

Alarm Triggers

Sensor Input

Alarm Events

Video file upload(FTP), Still image(Email), Relay output

Video Buffer

Pre & Post alarm

[APPLICATIONS]

Browser

Internet Explorer 8 or Higher

Monitoring Application

XNET NVR 2, and Utility (IP-Installer)

[MAINTENANCE]

System Upgrade

Firmware upgrade over HTTP

[MECHANICAL]

Standard PoE

Standard IEEE 802.3af supported

Power

DC 12V Max. 1A

Dimensions

122(W) x 55(H) mm

Operating Temperature

-10℃~ 50℃

Rev.1.4

Weight

Approx. 400g

Rev.1.4

1.3. Applications of IP Camera

Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities,

military, etc.)

Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)

eleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting

Weather and environmental observation

Rev.1.4

2. Product Description

2.1. Contents

The product package contains followings :

Contents

Description

Remarks

IP Camera

IP camera MPC1070PN main unit

Accessories

CVBS Cable 1EA,

Screws (4 pieces of 1 type),

Anchors (4 pieces of 1 type),

L-type wrench with six angles 1EA

Software & User’s Guide

Power Adaptor

Default built in standard PoE module

(IEEE802.3af)

12V DC Adaptor

(Optional item)

2.2. Product Preview

IP Camera

IP-Installer

CMS Software (NVR)

MPC1070PN

PC software to allocate an IP

address to the IP Camera

PC software to view and record the

A/V streaming data transmitted from

IP camera.

(Simultaneous support of up to 64

IP cameras)
