C002332_02_CR3 User Manual - 1
Save Settings
This version of the manual supports firmware 3000 and greater.
User Manual
C002332_02_CR3 User Manual - i
Save Settings
Statement of Agency Compliance
The CR3 can be set to use targeting lasers. If the targeting lasers are
activated, do not stare into the beams. The CR3’s targeting lasers have
been rated as Class IIa Lasers by IEC 60825-1.
The CR3 has been tested by an independent electromagnetic compatibility
laboratory in accordance with the applicable specifications and instructions.
The CR3 has been tested for compliance with FCC regulations and was
found to be compliant with all applicable FCC Rules and Regulations.
IMPORTANT NOTE: To comply with FCC RF exposure compliance
requirements, this device must not be co-located or operate in conjunction
with any other antenna or transmitter.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
The CR3 has been tested for compliance to CE standards and guidelines
and was found to conform to applicable CE standards, specifically the
EMC requirements EN 55024, ESD EN 61000-4-2, Radiated RF Immunity
EN 61000-4-3, ENV 50204, EFT EN 61000-4-4, Conducted RF Immunity
EN 61000-4-6, EN 55022, Class B Radiated Emissions, and Class B
Conducted Emissions.
C002332_02_CR3 User Manual - ii
Save Settings
Code Reader 3.0 User Manual
Copyright © 2005 Code Corporation.
All Rights Reserved.
The software described in this manual may only be used in accordance with the terms of its license
agreement.
No part of this publication may be reproduced in any form or by any means without written permission from
Code Corporation. This includes electronic or mechanical means such as photocopying or recording in
information storage and retrieval systems.
NO WARRANTY. This technical documentation is provided AS-IS. Further, the documentation does not
represent a commitment on the part of Code Corporation. Code Corporation does not warrant that it is
accurate, complete or error free. Any use of the technical documentation is at the risk of the user. Code
Corporation reserves the right to make changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases consult Code Corporation to determine
whether any such changes have been made. Code Corporation shall not be liable for technical or editorial
errors or omissions contained herein; nor for incidental or consequential damages resulting from the
furnishing, performance, or use of this material. Code Corporation does not assume any product liability
arising out of or in connection with the application or use of any product or application described herein.
NO LICENSE. No license is granted, either by implication, estoppel, or otherwise under any intellectual
property rights of Code Corporation. Any use of hardware, software and/or technology of Code Corporation
is governed by its own agreement.
The following are trademarks or registered trademarks of Code Corporation:
CodeXML, Maker, QuickMaker, CodeXML Maker, CodeXML Maker Pro, CodeXML Router, CodeXML
Client SDK, CodeXML Filter, HyperPage, CodeTrack, GoCard, GoWeb, ShortCode, GoCode, Code Router,
QuickConnect Codes, Rule Runner
All other product names mentioned in this manual may be trademarks of their respective companies and
are hereby acknowledged.
The software and/or products of Code Corporation include inventions that are patented or that are the
subject of patents pending.
Code Corporation, 11814 S. Election Road, Suite 200, Draper, UT 84020
www.codecorp.com
C002332_02_CR3 User Manual - iii
Save Settings
Table of Contents
Chapter 1 - Getting Started ............................................................................................................... 1
1.1 - Introduction ............................................................................................................................ 2
1.2 - Unpacking .............................................................................................................................. 3
1.4 - Keypad/Icon Overview ........................................................................................................... 4
1.5 - Batch Operation ..................................................................................................................... 6
1.6 - Cabled Operation ................................................................................................................... 7
1.6.1 - Introduction .................................................................................................................. 7
1.6.2 - USB Cable Installation Guide ....................................................................................... 8
1.6.2.1 - USB Communication Settings ............................................................................ 9
1.6.3 - PS2 Cable Installation Guide ..................................................................................... 10
1.6.3.1 - PS2 Communication Settings .......................................................................... 10
1.6.4 - RS232 Cable Installation Guide ..................................................................................11
1.6.4.1 - RS232 Communication Data Bit Settings ........................................................ 12
1.6.4.2 - RS232 Communication Stop Bit Settings ........................................................ 12
1.6.4.3 - RS232 Communication Baud Rate Settings .................................................... 12
1.6.4.4 - RS232 Communication Parity Settings ............................................................ 12
1.6.5 - Cabled Reader - Time Out Settings ........................................................................... 13
1.7 - Bluetooth Radio Operation ................................................................................................... 14
1.7.1 - Introduction ................................................................................................................ 14
1.7.2 - Bluetooth Radio Auto Connect ................................................................................... 16
1.7.3 - Bluetooth Radio Auto Disconnect ............................................................................... 17
1.7.4 - Bluetooth Radio Time Out Settings (Uncabled Operations) ....................................... 17
1.7.5 - Bluetooth Radio Out of Range Notification Settings .................................................. 17
1.8 - Reader Feedback Guide ...................................................................................................... 18
1.9 - Targeting and Reading Techniques ...................................................................................... 19
1.10 - Imager Field of View and Resolution ................................................................................. 20
1.11 - Decode Zone ...................................................................................................................... 21
1.12 - Attaching Handle ................................................................................................................ 22
1.13 - Reader Battery Installation ................................................................................................. 23
Chapter 2 - Optimization and Trigger Programming .................................................................... 24
2.1 - Introduction .......................................................................................................................... 25
2.2 - Global Trigger Optimization Matrix ....................................................................................... 26
2.3 - Left Trigger Optimization Matrix ........................................................................................... 27
2.4 - Left Trigger Programming .................................................................................................... 27
2.5 - Right Trigger Optimization Matrix ......................................................................................... 28
2.6 - Right Trigger Programming .................................................................................................. 28
2.7 - Handle Trigger Optimization Matrix ...................................................................................... 29
2.8 - Right Trigger Programming .................................................................................................. 29
2.9 - Continous Trigger Optimization Matrix ................................................................................. 30
2.10 - Continous Scan .................................................................................................................. 30
C002332_02_CR3 User Manual - iv
Save Settings
2.11 - Continous Scan Settings .................................................................................................. 31
2.11.1 - Continous Scan - Sleep Time Out ............................................................................ 31
2.11.2 - Continous Scan - Trigger Delays .............................................................................. 31
2.11.3 - Continous Scan - Duplicate Scan Delay .................................................................. 31
2.12 - Motion Detection Scan Settings ....................................................................................... 31
Chapter 3 - CR3 Programming: Symbology Settings ................................................................... 32
3.1 - Introduction .......................................................................................................................... 33
3.2 - Aztec Symbology .................................................................................................................. 33
3.3 - Codabar Symbology ............................................................................................................. 33
3.4 - Codablock F Symbology ...................................................................................................... 34
3.5 - Code 11 Symbology ............................................................................................................. 34
3.6 - Code 39 Symbology ............................................................................................................. 34
3.7 - Code 93 Symbology ............................................................................................................. 35
3.8 - Code 128 Symbology ........................................................................................................... 35
3.9 - Composite Symbologies ...................................................................................................... 36
3.10 - Data Matrix Symbology ...................................................................................................... 36
3.11 - GoCode Symbology .......................................................................................................... 36
3.12 - Interleaved 2 of 5 Symbology ............................................................................................ 37
3.13 - Maxicode Symbology ......................................................................................................... 37
3.14 - Matrix 2 of 5 Symbology ..................................................................................................... 38
3.15 - Micro PDF417 Symbology ................................................................................................. 38
3.16 - MSI Plessy Symbology ...................................................................................................... 38
3.17 - NEC 2 of 5 Symbology ....................................................................................................... 39
3.18 - PDF 417 Symbology .......................................................................................................... 39
3.19 - Pharmacode ....................................................................................................................... 40
3.20 - Postal Symbologies ............................................................................................................ 40
3.21 - QR Code Symbology ......................................................................................................... 41
3.22 - RSS Symbology ................................................................................................................. 41
3.23 - Telepen Symbology ............................................................................................................ 42
3.24 - UPC/EAN/JAN ................................................................................................................... 42
Chapter 4 - Reader Feedback and Special Settings ..................................................................... 43
4.1 - Volume and Vibration Settings ............................................................................................. 44
4.2 - Code Readability Index ........................................................................................................ 44
4.3 - Backlight Intensity Settings .................................................................................................. 45
4.4 - Backlight Timeout Settings ................................................................................................... 46
4.5 - Laser Settings ...................................................................................................................... 46
4.6 - Reader Power Off Settings .................................................................................................. 46
4.7 - Reader ID and Firmware Version ......................................................................................... 47
4.8 - Reader Settings Lock ........................................................................................................... 47
4.9 - Keyboard Support ................................................................................................................ 48
Chapter 5 - Advanced Decode Performance ................................................................................. 49
C002332_02_CR3 User Manual - v
Save Settings
5.1 - Continous Illumination .......................................................................................................... 50
5.2 - Set Targeting Zone Tolerances ............................................................................................. 50
5.3 - Windowing ............................................................................................................................ 51
5.4 - VGA & Megapixel Settings ................................................................................................... 53
5.5 - Mirror Decoding .................................................................................................................... 53
Chapter 6 - Adding a Prefix or Suffix and Reader Text Commands ............................................ 54
6.1 - Prefix Settings ...................................................................................................................... 55
6.2 - Suffix Settings ...................................................................................................................... 55
6.3 - Reader Text Commands ...................................................................................................... 56
6.4 - Erase Prefix and Suffix Settings ........................................................................................... 56
Chapter 7 - CR3: Maintenance and Troubleshooting ................................................................... 57
7.1 - Reset Reader to Factory Defaults ........................................................................................ 58
7.2 - General Safety Information .................................................................................................. 58
7.3 - Warranty ............................................................................................................................... 59
7.4 - CR3 Accessories .................................................................................................................. 60
7.5 - Frequently Asked Questions ................................................................................................ 61
7.6 - CR3 Maintenance ................................................................................................................ 61
C002332_02_CR3 User Manual - 1
Save Settings
Chapter 1 - Getting Started
C002332_02_CR3 User Manual - 2
Save Settings
1.1 - Introduction
The CR3 establishes a new benchmark for Portable Data
Terminals and Hand Held Computers by combining the
industry’s best imaging technology with a graphic display
and rugged keyboard to create the smallest and lightest
full-featured bar code reading terminal on the market.
Using the same ergonomic platform as the highly
successful Code Reader 2.0, the CR3 extends mobile
all-symbology bar code reading to include information
display and keyboard entry.
The CR3 instantly reads large linear as well as high density matrix symbols due to Code Corporation’s
unique Dynamic Optimization Technology (DOT), which continuously adapts the resolution, illumination,
and image field for the fastest automatic symbology identification and decoding over the widest range of
symbology types, sizes, recording surfaces and ambient lighting. With DOT, the CR3 achieves matrix
symbol decoding at speeds that are similar to linear bar code decoding, while preserving battery energy.
By monitoring each user’s reading patterns, DOT reduces training time and eliminates the need for manual
configuration optimization through parameter settings.
Code eliminates the need for costly, high-overhead operating systems by providing an open platform
JavaScript development environment within its CodeXML Applications Development Suite. With CodeXML
and JavaScript, Developers and Information Technology organizations no longer need to worry about ex-
pensive porting of applications between Windows, Windows Pocket PC, Windows CE.Net, et.al.. A unique
feature of the Applications Development Suite is the ability to protect both development investment and
data security by a customer-unique key encryption, which allows the developer to control the distribution
and modification of applications to specific serial-numbered CR3 units.
The CR3 features a 1.3 MegaPixel dual-field
image collection engine, a 400MHz AMD Al-
chemy au1100 CPU, and 4MB of non-volatile
memory. Portable operations are supported
by a 1950 mAH Lithium Ion Battery and a Real
Time Clock with its own battery backup sys-
tem. For wireless communications, a 2.4 GHz
radio system is available and compatible with
a wide range of Bluetooth™ systems, as well
as the CodeXML Modem, with a unique data
and pairing encryption system for unsurpassed
wireless data security.
featuring
The CR3 will instantly decode all bar and 2D codes
C002332_02_CR3 User Manual - 3
Save Settings
1.2 - Unpacking
1.3 - Powering On/Off Reader
Figure 1.1
Remove the imager from its packing and inspect it for damage. If the scanner was damaged during
shipping, please call Code at (801) 495-2200.
The standard CR3 unit is shipped with a USB cable interface. The unit also features a 1950 mAH battery
that must be installed in the unit at all times.
Various accessories are available for the CR3.
• 3 cable options (USB, RS232 or PS/2)
• Class 1 Bluetooth radio with 300 foot operating range
• Clip-on pistol grip handle
• External battery charger
• CodeXML Bluetooth modem
Please keep your packing materials. The CR3 is shipped in an approved shipping container and should be
used if you ever need to return your equipment for servicing.
To power up the reader, press and hold (for 1 second) any of the red trigger buttons (Figure 1.1).
The reader will power down after 2 hours of non-use. To change the default settings, please see Section
4.7 - Reader Sleep/Time Out settings.
C002332_02_CR3 User Manual - 4
Save Settings
1.4 - Keypad/Icon Overview
The chart below shows key/button functions.
Description of Button Function
Key Numeric Mode Upper Case Text
Mode
Lower Case Text
Mode
Symbol Mode
Toggles between
numeric characters,
upper case text, lower
case text, and symbol
character input
Toggles between
numeric characters,
upper case text, lower
case text, and symbol
character input
Toggles between
numeric characters,
upper case text, lower
case text, and symbol
character input
Toggles between
numeric characters,
upper case text, lower
case text, and symbol
character input
1 Space, 1 Space, 1 Space ‘ ; (
2 A, B, C, 2 a, b, c, 2 . “ \ )
3 D, E, F, 3 d, e, f, 3 @ + < ^
4 G, H, I, 4 g, h, i, 4 ? = > Space
5 J, K, L, 5 j, k, l, 5 ! / { Space
6 M, N, O, 6 m, n, o, 6 - $ } Space
7 P, Q, R, S, 7 p, q, r, s, 7 , * [ Space
8 T, U, V, 8 t, u, v, 8 & # ] Space
9 W, X, Y, Z, 9 w, x, y, z, 9 : % _ Space
0 0 0 Toggles between
4 sets of symbols
– when pressed,
each symbol set is
displayed
Backspace and clear
messages
Backspace and clear
messages
Backspace and clear
messages
Backspace and clear
messages
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Code Corporation Barcode-Lesegerät Handbücher
Beliebte Barcode-Lesegerät Handbücher anderer Marken
POSMicro
POSMicro Datalogic PowerScan D7100 Bedienungsanleitung
Marson
Marson MT780 Kurzanleitung zur Einrichtung
NCR
NCR RealPOS Bedienungsanleitung
Motorola
Motorola SE3300 Kurzanleitung zur Einrichtung
Element
Element P130BT Bedienungsanleitung
Motorola
Motorola Symbol LS3008 Installations- und Betriebshandbuch
