Commell FS-979 Bedienungsanleitung

FS-979

Full-size PICMG CPU Card

User’s Manual

Edition: 1.11

2004/12/24

FS-979 User’s Manual

reserved. The information in this document is subject to change without prior notice to make

improvements to the products.

This document contains proprietary information and protected by copyright. No part of this

document may be reproduced, copied, or translated in any form or any means without prior

written permission of the manufacturer.

All trademarks and/or registered trademarks contains in this document are property of their

respective owners. Disclaimer

The company shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

The company does not issue a warranty of any kind, express or implied, including without

limitation implied warranties of merchantability or fitness for a particular purpose.

The company has the right to revise the manual or include changes in the specifications of

the product described within it at any time without notice and without obligation to notify any

person of such revision or changes.

Trademark

All trademarks are the property of their respective holders.

Any questions please visit our website at http://www.commell.com.tw.

FS-979 User’s Manual Packing List

Packing List:

Please check the packing list before you start to apply this production.

Hardware:

FS-979 Full-size PICMG CPU Card x 1

Cable Kit:

Floppy flat cable x 1

40-pin ATA100 IDE flat cable x 1

DB25 & DB9 cable with bracket x 1

(FS-979VDL only) Dual DB9 cable with bracket x 1

(FS-979VDG3 only)

DB25 cable with bracket x 1

(FS-979VDG3 only) Dual USB cable with bracket x 2

Serial ATA ribbon cable x 2

FS-979 User’s Manual Packing List

DVI module with bracket x 1

Audio cable with bracket x 1

4-pin to 3-pin ATX cable x 1

RAID drivers Disc for Windows 2000,

Windows XP and Windows Server 2003

PS/2 Keyboard & Mouse Cable x 1

Audio & VGA cable with bracket x 1 (FS-979VDG3 only)

CD Content:

Drivers

User’s Manual

FS-979 User’s Manual Packing List

Index

Chapter 1 <Introduction>.....................................................................................7

1.1 <Product Overview>.................................................................................7

1.2 <Product Specification> ...........................................................................8

1.3 <Component Placement> ......................................................................10

1.4 <Block Diagram>.................................................................................... 11

Chapter 2 <Hardware Setup>.............................................................................13

2.1 <Connector Location>............................................................................13

2.2 <Connector Reference>.........................................................................14

2.2.1 <Internal Connector>..................................................................14

2.2.2 <External Connector>.................................................................14

2.3 <Jumper Reference> .............................................................................15

2.4 <CPU and Memory installation> ............................................................16

2.4.1 <CPU Installation>......................................................................16

2.4.2 <Memory Installation>................................................................17

2.5 <CMOS Setup>......................................................................................18

2.6 <Enhanced IDE Interface>.....................................................................19

2.7 <Serial ATA interface>............................................................................20

2.8 <LAN Interface>.....................................................................................21

2.9 <Audio Interface>...................................................................................22

2.10 <Display Interface> ..............................................................................23

2.11 <Compact Flash Interface>..................................................................25

2.12 <USB2.0 Interface>..............................................................................26

2.13 <Power and Fan Installation> ..............................................................27

2.13.1 <Power connectors>.................................................................27

2.13.2 <Fan Connectors>....................................................................28

2.14 <Serial Port Configuration>..................................................................29

2.15 <GPIO Interface>.................................................................................30

2.16 <Switch and Indicator>.........................................................................31

FS-979 User’s Manual Index

Chapter 3 <System Configuration>...................................................................33

3.1 <SATA Configuration>............................................................................33

3.2 <SATA RAID Configuration>..................................................................36

3.3 <Video Memory Setup> .........................................................................39

3.4 <Display Properties Setting>..................................................................41

Chapter 4 <BIOS Setup> ....................................................................................43

Appendix A <I/O Port Pin Assignment>............................................................45

A.1 IDE Port .................................................................................................45

A.2 <Serial ATA Port>...................................................................................45

A.3 < Floppy Port > ......................................................................................46

A.4 <IrDA Port>............................................................................................46

A.5 < Parallel Port>......................................................................................47

A.6 <Serial Port>..........................................................................................47

A.6.1 <External DB9 serial port>.........................................................47

A.6.2 <Internal serial port>..................................................................47

A.7 <VGA Port>............................................................................................48

A.8 <LAN Port>............................................................................................48

A.8.1 < Fast Ethernet> ........................................................................48

A.8.2 <Gigabit Ethernet >....................................................................48

A.9 <AT Keyboard Port> ..............................................................................49

A.10 <PS/2 Keyboard & Mouse Port>..........................................................49

Appendix B <Flash BIOS>..................................................................................51

B.1 BIOS Auto Flash Tool......................................................................51

B.2 Flash Method...................................................................................51

FS-979 User’s Manual Introduction

Product Overview 7

Chapter 1 <Introduction>

1.1 <Product Overview>

FS-979 is the Full-size single board computer with last Intel desktop technology with

PICMG form factor. Based on Intel®915GV and ICH6R, the board integrates a new

Pentium 4 processor 775-pin socket, DDR2 memory socket, and Intel®Graphic Media

Accelerator 900 technology, LAN, AC97 audio, USB2.0 and Serial ATA with RAID function

for a powerful rack-mount/wall-mount system.

Intel®LGA775 processor

The Intel®Pentium 4 processor now comes with a new form factor with 775-pin PLGA

package, for 800MHz front-side-bus, 1MB L2 cache, and for 90nm manufacturing

technology, the PLGA processor without pin header on solder side can make user installing

the processor on the socket easier.

Intel®915GV and ICH6R chipset

The Intel® 915GV integrates DDR2 400/533MHz for memory, and Graphic Media

Accelerator (GMA) 900 technology for new graphic engine. It can provide up to 224MB of

frame buffer when you install over 256MB of system memory. The ICH6R integrates with up

to 8 USB2.0 interfaces (4 ports for FS-979), and serial ATA interface with RAID function.

Dual Display Supported

Based on Intel® 915G GMA900 technology, the board supports dual display function with

CRT and DVI display interfaces. You can take this advantage for gaming, security

monitoring or other demonstration applications.

Multimedia interfaces

FS-979 also integrates AC97 audio, Compact Flash and DVI interface, for these flexible

functions, system integrator can built more powerful systems for many field applications.

Max up to 3 Gigabit Intel®LAN

With up to 3 PCI-Express 1x with Marvell Gigabit LAN controllers, the board comes with the

powerful network function for Server or Workstation.

FS-979 User’s Manual Introduction

Product Specification 8

1.2 <Product Specification>

General Specification

Form Factor Full-size PICMG Single Board Computer

PICMG version 1.0 (Rev. 2.0), PCI version 2.0 compliant

CPU Intel®Pentium 4 processor with LGA775 socket

Package type: 775 pin PLGA

L2 Cache: 1MB / Front side bus: 800MHz (200MHz x 4)

Intel®Hyper-Threading Technology supported

Memory 4 x 240-pin DDR2 400/533MHz SDRAM

Maximum DRAM address decode space is 4GB.

Up to 8GB/s of bandwidth with dual-channel interleaved mode

Dual-Channel technology supported

Unbufferred, none-ECC memory supported only

Chipset Intel®915GV (Northbridge) and ICH6R (Southbridge)

BIOS Phoenix-Award v6.00PG 4Mb PnP flash BIOS

Green Function Power saving mode includes doze, standby and suspend modes.

ACPI version 1.0 and APM version 1.2 compliant

Watchdog Timer System reset programmable watchdog timer with 1 ~ 255

sec./min. of timeout value

Real Time Clock Intel®ICH6R built-in RTC with lithium battery

Enhanced IDE Enhanced IDE interface supports dual channels and up to 2

ATAPI devices at Ultra DMA100 with

One 40-pin IDE port onboard

Serial ATA Intel®ICH6R integrates 4 Serial ATA interface

RAID 0, 1, Intel Matrix Storage Technology supported

Multi-I/O Port

Chipset Intel®82801FR ICH6R with Winbond®W83627THF controller

Serial Port One RS232 and one jumper selectable RS232/422/485

USB Port 4 x Hi-Speed USB 2.0 ports with 480Mbps of transfer rate

Parallel Port One internal bi-direction parallel port with SPP/ECP/EPP mode

Floppy Port One internal Floppy port

IrDA Port One IrDA compliant Infrared interface supports SIR

K/B & Mouse External PS/2 keyboard and mouse ports on rear I/O panel

GPIO One 12-pin Digital I/O connector with 8-bit programmable

Smart Fan One CPU fan connectors for fan speed controllable

VGA Display Interface

Chipset Intel®915GV GMCH (Graphic Memory Controller Hub)

Memory Intel®DVMT 3.0 with up to 224MB shared with system memory

Display Type CRT, LCD monitor with DB15 or DVI interface

Connector External DB15 female connector on rear I/O panel

Internal header connector for DVI interface

FS-979 User’s Manual Introduction

Product Specification 9

Ethernet Interface

Chipset Intel®PRO/100 LAN interface with 82562EZ PHY

Or Marvell®Gigabit LAN interface with E8053 PCIE controller

82562EZ 10Base-T / 100Base-TX

auto-switching Fast Ethernet

Full duplex, IEEE802.3U compliant

Type

E8053 10Base-T / 100Base-TX/1000Base-T

auto-switching Gigabit Ethernet

Full duplex, IEEE802.3U compliant

Connector External RJ45 connectors with LED on rear I/O panel

Solid State Disk Interface

Flash Type Compact Flash Type-I/II for Compact Flash Card or Micro Drive

Capacity Up to 1GB flash memory

ISA Interface

ISA Bridge Winbond W83628F & W83629D

Function I/O & IRQ supported only, no support DMA & bus mastering

Audio Interface

Chipset Intel®ICH6R with Realtek®ALC201A AC97 3D audio codec

Interface 2 channel 3D audio with Line-in, Line-out and MIC-in

Connector Internal header for Line-out, Line-in and MIC-in

Internal CD audio connector

Power and Environment

Power

Requirement Standard AT 4-pin power supply

Additional +12V 4-pin power connector

3-pin ATX function connector

Dimension 338 (L) x 122 (H) mm

Temperature Operating within 0 ~ 60oC (32 ~ 140oF)

Storage within -20 ~ 85oC (-4 ~ 185oF)

Ordering Code

FS-979VDL Full-size Intel®Pentium 4 PICMG single board computer with

LGA775, DDR2, AC97 Audio, CF, USB2.0, DVI, 10/100Mbps LAN

FS-979VDG3 Same with above but with 3 x Gigabit LAN

The specifications may be different as the actual board.

For further product information please visit the website at http://www.commell.com.tw

FS-979 User’s Manual Introduction

Component Placement 10

1.3 <Component Placement>

Intel 82562EZ (LAN) Winbond W83627THF

(Super I/O)

SATA

ISA Bridge

USB2.0 Compact Flash

ICH6R

(Southbridge)

ALC201A

(

Audio

)

915G

(Northbridge)

CH7307B-DE

(DVI)

DDR2

(Memory)

LGA775

(CPU)

Inhaltsverzeichnis

Andere Commell Computerhardware Handbücher

Commell

Commell MPX-8188 Bedienungsanleitung

Commell

Commell HS-870P Bedienungsanleitung

Commell

Commell FS-A79 Bedienungsanleitung

Commell

Commell HS-B70 Bedienungsanleitung

Commell

Commell LE-376 Series Bedienungsanleitung

Commell

Commell MP-954GPS Bedienungsanleitung

Commell

Commell LS-574 Bedienungsanleitung

Commell

Commell HE-772 Bedienungsanleitung

Commell

Commell FS-A74 Bedienungsanleitung

Commell

Commell CMB-170 Bedienungsanleitung

Commell

Commell HE-B71 Bedienungsanleitung

Commell

Commell CBPE-1X2P Bedienungsanleitung

Commell

Commell CMB-67H-02 Bedienungsanleitung

Commell

Commell FS-975M Bedienungsanleitung

Commell

Commell MP-954 Bedienungsanleitung

Commell

Commell HS-871P Bedienungsanleitung

Commell

Commell SP-501 Bedienungsanleitung

Commell

Commell LS-571 Bedienungsanleitung

Commell

Commell MPX-225 Bedienungsanleitung

Commell

Commell FS-97E Bedienungsanleitung

Commell

Commell FS-97B Bedienungsanleitung

Commell

Commell MPX-885 Bedienungsanleitung

Commell

Commell FS-A78 Bedienungsanleitung

Commell

Commell HE-B73 Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
