QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 1

Overview

What’s New

•Intel Mobile Pentium



III 800MHz

with Speedstep™ technology or

Intel Celeron 700MHz processor

•14.1-inch TFT XGA DisplayPanel

•10GB or 15GB Hard Drive

•Four Easy Access Internet

Buttons

At A Glance

•Intel Mobile Pentium



III 800MHz

with Speedstep™ technology

processor or Celeron 700MHz

processor

•14.1-inch TFT XGA DisplayPanel

•Configurations as light as

5.9 lbs/2.7 kg weight

•1.3 in/3.4 cm thin

•64MB SDRAM (100MHz),

Upgradeable to320 MB

•10GB or 15GB User Removable

Hard Drives

•Integrated Mini PCI modem/NIC

combo

•Full sized keyboard

•Windows Millennium

•2 USB port expansionoptions

available

•Lightweight/ExtendedCapacity

Lithium Ion batteryavailable

•Protected by a one-year,

worldwide limited warranty —

Certain restrictions and

exclusionsapply. Consult the

CompaqCustomerSupport

Center for details.

QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 2

Standard Features

Processor 800 MHz on Intel



Mobile Pentium



III processor with SpeedStep™ technology

700 MHz on Intel



Celeron™ processor

Note: Mobile Pentium

III processors feature 256-KB integrated cache and Mobile Celeron Processors feature

128KB integrated cache.

Memory Standard

Maximum 64-MB 100 MHz SDRAM

320-MB 100 MHz SDRAM

Communications Type III Mini PCI

Compaq Global Mini PCI 56K (V.90) Modem or

Compaq 56K (V.90) Modem plus Intel PRO/100+ NIC

Note: Designed only to allow faster downloads from V.90 compliant sources. Maximum achievable download

transmission rates currently do not reach 56 KB/s, and will vary with line conditions.

Note: Modem availability is subject to country regulatory approval.

PC Card Slots Two Type I, II or one type III PC Card Slot which supports both 32-bit CardBus (Full support in Windows 9.x) and

16-bit PC Cards

Storage Hard Drives 10 GB (9.5 mm height)

15 GB

Multimedia Integrated 16-bit Sound Blaster Pro-compatible stereo audio

Integrated speakers and microphone

Software volume control

Headphone-out Jack

Microphone-in Jack

Hardware assisted MPEG2 support

Interfaces PC Card Slot Two Type I, II or one type III

Enhanced Parallel Port 1

PS/2 1 (Y-cable compatible)

Serial Port 1

External Monitor Port 1

Speaker Out (Headphone) Jack 1

Microphone In Jack 1

AC Power Connector 1

RJ-45 1 (with Mini PCI Nic option only)

RJ-11 Jack 1 (with Mini PCI modem option only)

Infrared Port 1 (”Fast IR” compliant, IR performance will vary

depending on performance of IR peripherals and

application used)

USB Port 2

Graphics Integrated Trident CyberBlade i1 with AGP 2X support

14.1-inch color TFT XGA with 1024 x 768 resolution up to 16.7M colors internalDisplay (Internal)-One of the

following:

16 Million colors supported

Display (External) 640x480, 800x600, 1024x768 or 1280x1024 up to 60,75,85 Hz refresh rate

Operating System Windows Millennium

Windows 98SE or Windows 2000 in select countries

QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 3

Standard Features

Software Microsoft Office Small Business available on select models

Online Safety and Comfort Guide

Online Reference Guide

Norton AntiVirus 2000 available on select models

Security Cable lock support

Supervisor password

Boot password

Ability to disable serial port, parallel port

Power Supply External AC Adapter; 6-foot power cord included

Battery An 8-cell Lithium-Ion battery is standard

Note: Actual results may vary with individual usage. Standard configuration at time of announce is considered to be

one battery, a 1024x768 (High color – 16-bit color) panel set at 50percent brightness, 64 MB RAM, and no

drives other than the hard drive active.

Power Conservation Hibernation

Service and Support Compaq Services includes a one-year limited warranty, whole-unit replacement via second business day, pick-up

and delivery. (Eligibility depends on geographic location.) Optional services include a one-year warranty extension

CarePaq (FM-AMMAI-36 or 400514-002).

Note: Certain restrictions and exclusions apply. See the Limited Warranty Statement for details.

QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 4

Standard Features

Naming Convention The Etymology of a Model name:

QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 5

Standard Features

UNITED STATES Display 14.1-inch color TFT XGA

Processor Intel Pentium III 800 MHz

Cache Memory 256KB, L2 Cache

N15P800T4X15VC648LME

470013-661

720591808648

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 8X DVD-ROM

Hard Drive 15 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

Display 14.1-inch color TFT XGA

Processor Intel Celeron 700 MHz

Cache Memory 128KB, L2 Cache

N15C700T4X10DC648LME

470013-617

720591808099

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 24X CD-ROM

Hard Drive 15 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

Display 14.1-inch color TFT XGA

Processor Intel Celeron 700 MHz

Cache Memory 128KB, L2 Cache

N15C700T4X10DC648LME

GEM/NAFTA

470013-660

720591808631 Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 24X CD-ROM

Hard Drive 10 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 6

Standard Features

UNITED STATES (continued) Display 14.1-inchcolor TFT XGA

Processor Intel Pentium III 800 MHz

Cache Memory 256KB, L2 Cache

N15P800T4X15VC648LME

470013-726

720591810566

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 8X DVD-ROM

Hard Drive 15 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium + MS office SB

Battery 8 cell Lithium-Ion

Display 14.1-inch color TFT XGA

Processor Intel Celeron 700 MHz

Cache Memory 128KB, L2 Cache

N15C700T4X10DC648LME

470013-730

720591810412

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 24X CD-ROM

Hard Drive 10 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium + MS Office SB

Battery 8 cell Lithium-Ion

QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 7

Standard Features

FRENCH CANADA Display 14.1-inch color TFT XGA

Processor Intel Pentium III 800 MHz

Cache Memory 256KB, L2 Cache

N15P800T4X15VC648LME

470013-662

720591808655

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 8X DVD-ROM

Hard Drive 15 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

Display 14.1-inch color TFT XGA

Processor Intel Celeron 700 MHz

Cache Memory 128KB, L2 Cache

N15C700T4X10DC649HME

470013-618

720591808105

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 24X CD-ROM

Hard Drive 10 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 8

Standard Features

EURO Display 14.1-inch color TFT XGA

Processor Intel Pentium III 800 MHz

Cache Memory 256KB, L2 Cache

N15P800T4X15V648LME

470013-728

720591810689

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 8X DVD-ROM

Hard Drive 15 GB

Modem No Modem

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

Display 14.1-inch color TFT XGA

Processor Intel Celeron 700 MHz

Cache Memory 128KB, L2 Cache

N15C700T4X10D649HME

470013-724

720591810542

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 24X CD-ROM

Hard Drive 10 GB

Modem No Modem

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 9

Standard Features

ARABIA Display 14.1-inch color TFT XGA

Processor Intel Pentium III 800 MHz

Cache Memory 256KB, L2 Cache

N15P800T4X15VC648LME

470013-734

720591810436

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 8X DVD-ROM

Hard Drive 15 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

Display 14.1-inch color TFT XGA

Processor Intel Celeron 700 MHz

Cache Memory 128KB, L2 Cache

N15C700T4X10DC649HME

470013-700

720591810276

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 24X CD-ROM

Hard Drive 10 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

QuickSpecs

Compaq Evo Notebook N150

DA-10837 World Wide — Version 4 — June 12,2001 10

Standard Features

BELGIUM Display 14.1-inch color TFT XGA

Processor Intel Pentium III 800 MHz

Cache Memory 256KB, L2 Cache

N15P800T4X15VC648LME

470013-663

720591808662

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 8X DVD-ROM

Hard Drive 15 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

Display 14.1-inch color TFT XGA

Processor Intel Celeron 700 MHz

Cache Memory 128KB, L2 Cache

N15C700T4X10DC648LME

470013-619

720591808112

Memory Standard 64 MB SDRAM

Maximum 320 MB SDRAM

Optical Drive 24X CD-ROM

Hard Drive 10 GB

Modem Mini-PCI V.90 modem/10/100 TX NIC Combo

Graphics Trident CB i1 8-MB UMA RAM (Shared RAM)

Audio 16-bit SoundBlaster Pro compatible

Software Windows Millennium

Battery 8 cell Lithium-Ion

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Compaq Laptop Handbücher

Compaq

Compaq ARMADA 3500 3500 Bedienungsanleitung

Compaq

Compaq Armada E700 Series Gebrauchsanweisung

Compaq

Compaq Evo Notebook N400c Series Bedienungsanleitung

Compaq

Compaq Presario R3000 - Notebook PC Bedienungsanleitung

Compaq

Compaq Armada 7800 Bedienungsanleitung

Compaq

Compaq Compaq Presario Montage- und Wartungsanleitung

Compaq

Compaq 800 Series Bedienungsanleitung

Compaq

Compaq Notebook 100 Series Bedienungsanleitung

Compaq

Compaq EVO NOTEBOOK N410C Bedienungsanleitung

Compaq

Compaq Armada E500 Series Handbuch

Compaq

Compaq Armada 110 Kurzanleitung

Compaq

Compaq nw9440 - Mobile Workstation Bedienungsanleitung

Compaq

Compaq Armada 1100 Kurzanleitung

Compaq

Compaq Evo Notebook N200 Series Gebrauchsanweisung

Compaq

Compaq EVO M800c Handbuch

Compaq

Compaq PRESARIO Presario 1800 Bedienungsanleitung

Compaq

Compaq Evo N600c Handbuch

Compaq

Compaq Armada 1500 Handbuch

Compaq

Compaq Compaq Presario Handbuch

Compaq

Compaq Armada E500 Series Installationsanleitung

Compaq

Compaq Compaq Presario Handbuch

Compaq

Compaq Series 400 Handbuch

Compaq

Compaq Evo D500 - Convertible Minitower Kurzanleitung

Compaq

Compaq Presario V3000 - Notebook PC Bedienungsanleitung

Beliebte Laptop Handbücher anderer Marken

HP ze2401xt - Pavilion Notebook PC Bedienungsanleitung

Velocity

Velocity NoteMagix M10 Bedienungsanleitung

Dell

Dell Alienware 17 R2 Bedienungsanleitung

Toshiba

Toshiba A105-S2236 Bedienungsanleitung

HP ENVY 17 Handbuch

Winbook

Winbook LM Bedienungsanleitung

Dell

Dell Inspiron 1464 Bedienungsanleitung

Dell

Dell Inspiron 15R 5537 Bedienungsanleitung

HP PROBOOK 4520S Handbuch

Dell

Dell Latitude ATG D620 Bedienungsanleitung

Sony

Sony VAIO PCG-FX270 Bedienungsanleitung

Dell

Dell Latitude 7310 Bedienungsanleitung

Dell

Dell Precision GU806 Bedienungsanleitung

Sony

Sony VAIO PCG-R505JLK Bedienungsanleitung

Lenovo

Lenovo THINKPAD X32 Bedienungsanleitung

HP Compaq tc4200 Kurzanleitung

Toshiba

Toshiba mini NB300 Bedienungsanleitung

Lenovo

Lenovo ThinkPad X201 Tablet Handbuch
