User’s Guide
Compaq P1610 Color Monitor
Fourth Edition (December 1997)
Third Edition (September 1997)
Part Number 305706-004
Compaq Computer Corporation
Notice
English
1-1
Writer: M. Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:55 PM
Pages: 31 Words: 6042 Template: c:\msoffice\templates\normal.dot
File Name Bk1a_en.doc Part Number 305706-004
book 1
E
NGLISH
Introduction The Compaq P1610 Color Monitor is a high-resolution, wide
screen display intended for use with high-end graphics
controller boards capable of high definition television (HDTV)
format. The wide screen is recommended for video animation;
advanced graphics user interfaces (GUIs); high performance
graphics and digital video applications such as computer-aided
design, computer-aided engineering, desktop publishing and
document image processing; and Windows 95 and Windows
NT applications.
1-2 English
Writer: M. Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:55 PM
Pages: 31 Words: 6042 Template: c:\msoffice\templates\normal.dot
File Name Bk1a_en.doc Part Number 305706-004
Product Features The monitor features include the following:
■ 24-inch (22.5-inch/57.15 cm viewable) aperture grille CRT
for superior brightness and uniformity.
■ On-screen display (OSD) for adjusting the monitor screen
in six different languages: English, Dutch, French, German,
Spanish, and Japanese.
■ Plug and play capability if supported by your system.
■■ AssetControl that provides detailed inventory information
including manufacturer, model, and serial number of
Compaq monitors.
■ Multisync capabilities for compatibility with a wide range
of computers and graphics adapters.
■ Ten preset and 15 user-defined display resolutions with a
maximum resolution of 1920 × 1200 at 76 Hz.
■ Signal cable connectors on the rear panel for connecting
two computers; one for the standard 15-pin signal cable,
and one for a set of five BNC connectors.
■ Energy Saver feature
■ Compliant with the following regulatory specifications:
❏ EPA Energy Star
❏ European Union CE Directives
❏ Swedish MPR II 1990
❏ Swedish TCO 1995
Graphics Adapter
To be able to view the higher resolutions this monitor displays,
a special graphics adapter for your computer is required. It must
be capable of resolutions at 1920 × 1035 to 1920 × 1200 with
varying horizontal and vertical frequencies. For information on
where to obtain a graphics adapter that supports these
resolutions, refer to your Compaq authorized reseller or dealer.
English
1-3
Writer: M. Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:55 PM
Pages: 31 Words: 6042 Template: c:\msoffice\templates\normal.dot
File Name Bk1a_en.doc Part Number 305706-004
Graphics Driver
This monitor's higher resolutions may also require a special
graphics driver that is compatible with your computer's graphics
adapter. If your Compaq computer has a graphics card installed
that supports the higher resolutions, 1920 × 1035 to 1920 ×
1200, these resolutions will display on this monitor. If your
computer has the proper hardware, but lacks the driver software,
you can access the Compaq World Wide Web site and
download the latest drivers. If your Compaq computer hardware
does not support the higher resolutions, contact your Compaq
authorized dealer or reseller for information on upgrades. If you
do not have a Compaq computer, contact the dealer that
represents your computer’s brand name for this information.
Compaq has created a Universal Driver Manager (UDM)
release that supports all Compaq QVision graphics controllers
and most graphics controllers found on Compaq Deskpro
products. The UDM eases graphics driver deployment across all
Compaq Deskpro platforms ensuring cross-compatibility and
backward-compatibility. The resulting solution enables
customers to manage and control ongoing software maintenance
costs. The UDM is available on the Support Software CD for
Compaq Desktop, Portable, and Workstation Products and the
Compaq World Wide Web site (www.compaq.com).
✎If the updated Universal Driver Manager that supports the
Compaq P1610 Monitor is not available on the Web site,
contact your authorized Compaq dealer or reseller.
■ You can order the Support Software CD for Compaq
Desktop, Portable, and Workstation Products. This compact
disc contains the latest device drivers, utilities, and
flashable ROM images needed to run MS-DOS, Microsoft
Windows 3.1, Windows 95, Windows NT Workstation, and
IBM OS/2 on your Compaq commercial Desktop, Portable,
or Workstation product.
■ You can download the Support software from the Compaq
World Wide Web site (www.compaq.com).
■ You can purchase backup diskettes.
1-4 English
Writer: M. Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:55 PM
Pages: 31 Words: 6042 Template: c:\msoffice\templates\normal.dot
File Name Bk1a_en.doc Part Number 305706-004
If you choose to purchase the Support Software CD, you have
two options:
■ You can purchase a single CD-ROM that gives you one-
time access to the latest support software (North America
only, Compaq part number 272505-001).
■ You can purchase a yearly subscription that delivers up to
12 monthly CD-ROMs (Compaq part number 183426-xxx).
The annual subscription ensures your continuous access to the
latest developments.
For help and service outside of the U.S. and Canada or to order
the CD or backup diskettes, contact your Compaq authorized
reseller, dealer, or service provider.
Setting Up the
Monitor To set up the monitor, ensure that the power is turned off to the
monitor, computer system, and other attached devices, then
follow these steps:
1. Place the monitor in a convenient, well-ventilated location
near, but not on top of, your computer.
!WARNING: To reduce the risk of possible injury, do not
attempt to lift the monitor by yourself. This monitor weighs
approximately 90 pounds and is not intended to be placed on
top of a computer. Place the monitor directly on a desktop or
other work surface.
English
1-5
Writer: M. Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:55 PM
Pages: 31 Words: 6042 Template: c:\msoffice\templates\normal.dot
File Name Bk1a_en.doc Part Number 305706-004
2. Connect one end of the standard monitor signal cable 1to
the monitor, and the other end to the 15-pin connector on
the rear panel of the computer and tighten the screws.
✎Be sure the signal cable aligns with the 15-pin connector. Do not
force the cable onto the connector or you may damage the signal
cable.
3. Connect the monitor power cord 2to the rear panel of the
monitor, then plug the other end into an electrical outlet
that is easily accessible and close to the monitor.
!WARNING: To reduce the risk of electric shock or damage to your
equipment, do not disable the power cord grounding feature. This
equipment is designed to be connected to a grounded (earthed)
power outlet that is easily accessible to the operator. The grounding
plug is an important safety feature.
CAUTION: Be sure that the power outlet you plug your power cord
into is easily accessible and located as close to the monitor as
possible. When you need to disconnect power to the equipment, be
sure to unplug the power cord from the power outlet.
1-6 English
Writer: M. Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:55 PM
Pages: 31 Words: 6042 Template: c:\msoffice\templates\normal.dot
File Name Bk1a_en.doc Part Number 305706-004
Signal Warning Function
If something is wrong with the input signal, one of the
following messages will display for 30 seconds when the
monitor is turned on and off, or when the computer select
switch is operated (refer to page 1-9 for an explanation of the
computer select switch):
■ Please check the signal (indicates the cable is not
connected)
Input: 1 (shows computer select switch setting)
FH:84.4kHz (indicates the horizontal sync signal)
FV: - Hz (indicates no vertical sync signal)
■ Out of Scan Range (indicates the input signal is not
supported by the monitor's specifications)
Using BNC Connectors
A signal cable with BNC connectors may be used in place of or
in addition to the 15-pin signal cable. To connect two computers
to the monitor, a BNC connector may be used together with the
15-pin signal cable. If you have separately purchased a signal
cable with BNC connectors, use the following instructions to
connect the signal cable to the monitor.
✎AssetControl is not supported by the monitor when BNC
connectors are used.
1. Connect the five BNC connectors to the monitor. Push in
and twist the connectors clockwise until they are locked
into place. The color of the wires may vary, so refer to the
manufacturer's instructions included with the BNC
connectors. Usually, the connectors are color coded from
left to right in the following order:
English
1-7
Writer: M. Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:55 PM
Pages: 31 Words: 6042 Template: c:\msoffice\templates\normal.dot
File Name Bk1a_en.doc Part Number 305706-004
1Red (R) for the red video connector
2Green (G) for the green video connector
3Blue (B) for the blue video connector
4White for horizontal sync (H)
5Black for vertical sync (V)
2. Connect the other end of the signal cable to the 15-pin
graphics connector on the back of your computer.
3. Connect the power cord as previously illustrated.
!WARNING: To reduce the risk of electric shock or damage to
your equipment, do not disable the power cord grounding
feature. This equipment is designed to be connected to a
grounded (earthed) power outlet that is easily accessible to the
operator. The grounding plug is an important safety feature.
CAUTION: Be sure that the power outlet you plug your power
cord into is easily accessible and located as close to the monitor
as possible. When you need to disconnect power to the
equipment, be sure to unplug the power cord from the power
outlet.
1-8 English
Writer: M. Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:55 PM
Pages: 31 Words: 6042 Template: c:\msoffice\templates\normal.dot
File Name Bk1a_en.doc Part Number 305706-004
Operating the Monitor
Front Control Panel
Icon Control Function
1
1 2
Computer Signal
Switch Selects which computer signal to input when two
computers are connected to the monitor at the same
time.
2Reset Button Resets operating on-screen display (OSD)
adjustments to factory preset levels.
3Option Button Displays adjustments to:
1. Select an OSD language.
2. Move the OSD menu around on the screen.
3. Select between a normal or expert OSD menu.
4. Lock and unlock or disable all the buttons on the
front panel except the power switch, option button,
and the computer signal switch.
4Color Button Displays adjustments for screen color temperature.
5Screen Button Displays adjustments for vertical and horizontal
convergence, moire, landing, and degauss.
6Geometry Button Displays adjustments for picture rotation and
pincushion.
Continued
English
1-9
Writer: M. Silvetti Saved by: Marianne Silvetti Saved date: 03/03/98 2:55 PM
Pages: 31 Words: 6042 Template: c:\msoffice\templates\normal.dot
File Name Bk1a_en.doc Part Number 305706-004
Front Control Panel
(Continued)
Icon Control Function
7Size Button Displays adjustments for picture sizing.
8Center Button Displays adjustments for picture position.
9Brightness
Buttons 1. Adjusts Brightness.
2. The −/+ ( ) buttons also make adjustments
to OSD screens.
:Contrast Buttons 1. Adjusts Contrast.
2. The −/+ ( ) buttons also make adjustments
to OSD screens.
;Power Saving LED 1. Green indicates monitor is turned on.
2. Yellow indicates suspend mode.
3. Amber indicates sleep mode.
<Power Switch Turns the monitor on and off.
Computer Select Signal
This monitor has two signal connectors on the rear panel which
make it capable of connecting two computers to the monitor at
the same time. When two computers are connected to the
monitor and both are turned on, select the computer signal you
want to use by doing the following:
■ On the front control panel, set the computer select switch 1
to 1 for the computer connected with a 15-pin connector.
■ Set the computer select switch to 2 for the computer
connected with five BNC connectors.
If only one computer is connected or turned on, set the computer
select switch to the center position. The input signal is auto-
matically determined.
Andere Handbücher für Compaq P1610
1
Inhaltsverzeichnis
Andere Compaq Monitor Handbücher
Compaq
Compaq V70 Bedienungsanleitung
Compaq
Compaq S900 Gebrauchsanweisung
Compaq
Compaq CPQ-C1786FNSL Bedienungsanleitung
Compaq
Compaq Compaq S710 Bedienungsanleitung
Compaq
Compaq FP745A Bedienungsanleitung
Compaq
Compaq 307713-001 - V 75 - 17" CRT Display Bedienungsanleitung
Compaq
Compaq V1000 Bedienungsanleitung
Compaq
Compaq CV7500 Bedienungsanleitung
Compaq
Compaq TFT5030 Bedienungsanleitung
Compaq
Compaq 7500 Series Bedienungsanleitung
Compaq
Compaq 8000 - Elite Convertible Minitower PC Bedienungsanleitung
Compaq
Compaq TFT500 Bedienungsanleitung
Compaq
Compaq Q2009 - Compaq - Widescreen LCD Monitor Anleitung zur Verwendung
Compaq
Compaq TFT5000 Bedienungsanleitung
Compaq
Compaq W19Q Bedienungsanleitung
Compaq
Compaq 5017 - TFT - 15" LCD Monitor Bedienungsanleitung
Compaq
Compaq S920 Gebrauchsanweisung
Compaq
Compaq P1210 Bedienungsanleitung
Compaq
Compaq S500 Bedienungsanleitung
Compaq
Compaq TFT5010R Gebrauchsanweisung
