QuickSpecs
Compaq M720 CRT Monitor
DA-10999 World Wide — Version 1 — October 15, 2001
1
M
ODELS
M720 CRT Monitor
238994-xxx Carbon/Silver Multimedia
240759-xxx Opal Multimedia
Note: Asset Control monitor. Asset Control features are accessible with Compaq desktops featuring Intelligent Manageability.
S
PECIFICATIONS
Picture Tube (diagonal) 43.18 cm (17-inch) FST
Viewable (diagonal) 40.6 cm (16-inch)
Horizontal Dot Pitch 0.24 mm (0.01 in)
Trio Dot Pitch 0.28 mm (0.011 in)
Max Refresh/Preset Graphic Modes 1600 x 1200 1280 x 1024
N/A 64 Hz/60 Hz
1024 x 768 800 x 600 720 x 400 640 x 480
85 Hz/75, 85 Hz 109 Hz/75, 85 Hz 120 Hz/70 Hz 137 Hz/60,75, 85 Hz
Note: All modes are non-interlaced unless specified otherwise.
Text Mode 720 x 400
70 Hz
Preset Graphic/ Modes User-Programmable 10/8
Anti-Glare/Anti-Static Yes/Yes
Plug and Play Yes
Approvals/Certifications UL Approval Yes
ISO9241-3, -7, -8 VDT Guidelines Approval Yes
MPR-II Compliant Yes
FCC Approval Yes
Energy Star Compliant Yes
TCO 99 Compliant (Select Models) Yes
CE Marking Yes
GS Marking Yes
Energy 2000 Compliant Yes
On-Screen Controls Yes
Language Selection German Yes
English Yes
Spanish Yes
Italian Yes
Swedish Yes
Portuguese Yes
French Yes
Russian Yes
Korean Yes
QuickSpecs
Compaq M720 CRT Monitor
DA-10999 World Wide — Version 1 — October 15, 2001
2
S
PECIFICATIONS
(continued)
Tilt Base (up/down) 13°up/5°down
Swivel ±45°left/right
User Controls Brightness, Contrast Yes
Size and Positioning Yes
Pincushion (barrel) Yes
Trapezoid Yes
Tilt (rotation) Yes
Color temperature (6500K/9300K) Yes
Parallelogram No
Pincushion Balance No
Pinbalance No
Individual color control No
Moiré Cancellation Yes
Convergence No
Vertical Linearity Yes
Display Timing Yes
OSD Lock/Unlock Yes
Serial Number Display No
Degauss Yes
Factory Reset/Recall Yes
AssetControl Yes
Note: When used with Compaq Intelligent Manageability CPUs and appropriate network software.
Pixel Clock Speed 110 MHz
Input Impedance 75 ohms
Horizontal Frequency 30 to 70 KHz
Vertical Frequency 50 to 160 Hz
Power Supply 90 to 132 & 195 to 265 VAC, 47.5 to 63 Hz Universal Auto-Sensing
Maximum Power Rating 90 Watts
Power Saver State < 3W
Synch Input TTL separate synch
Signal Cable Captive 15-pin D-sub video cable
Dimensions (Wx Dx H) 398 x 412 x 400 mm (15.6 x 16.2 x 15.7 in)
Weight (Packaged/Unpackaged) 17.5 kg/15 kg (38.6 lbs/33.1 lbs)
Operating Temperature 10°to 35°C (50°to 95°F)
Operating Humidity (non-condensing) 10% to 80%
QuickSpecs
Compaq M720 CRT Monitor
DA-10999 World Wide — Version 1 — October 15, 2001
3
S
PECIFICATIONS
(continued)
48 Hour Direct Replacement
If this monitor fails during the parts warranty, Compaq guarantees that a new, or like-new monitor
replacement will be delivered within 48 hours.
Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Service Support Center
for details.
Limited Warranty Three-year parts, first-year labor on-site
Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Service Support Center
for details.
C
OMPATIBILITY
Graphics Controllers ATI RAGE Mobility
ATI RAGE LT Pro
S3 Virge max
NVIDIA Quadro2 MXR
NVIDIA Quadro2 EX
NVIDIA Quadro2 Pro
Sonic Blue FireGL2
3Dlabs Wildcat 5110
NVIDIA TNT2 Vanta
G400 Dual Head
G200 Quad MMS
NVIDIA NV10
NVIDIA TNT2 Model 64
RAGE Pro Turbo 2x
RAGE Pro Turbo 2X
Viper V730
Viper V770 Ultra
Millennium II
G200SG
G400SD
G450 Dual Head AGP
G400 Toucan
TNT2 Pro
NVIDIA NV11 (AGP)
NVIDIA NV11 Dual Head (AGP)
NVIDIA NV11 Dual Head (PCI)
NVIDIA TNT2 (AGP)
Elsa Synergy III
NVIDIA TNT2 Pro
Matrox 450 Dual Head PCI
NV15 Sapphire
M64 8 MB PCI
M64 16MB
Chipsets Intel 810
Intel 810e
Intel 815
C
OMPAQ
M720 S
PEAKER
S
PECIFICATIONS
Sound Output 3.0 Watts per channel 4.3 Watts maximum @10% THD
Signal to Noise Ratio 50 dB
Speaker Impedance 4 ohm
Frequency Response 180Hz to 20,000Hz
Power DC 12V Cord (12V / 1A max)
Compaq, registered United States Patent and Trademark Office.
Other product names mentioned herein may be trademarks and/or registered trademarks of their respective companies.
©2001 Compaq Computer Corporation.
