Compaq StorageWorks S1000 - NAS Bedienungsanleitung

Part Number: 000001768 Version 1.0

Compaq, the Compaq logo and StorageWorks are trademarks of Compaq Information

Technologies Group, LP.

All other product names mentioned herein may be trademarks of their respective

companies.

Compaq shall not be liable for technical or editorial errors or omissions contained herein.

The information in this document is provided “as is” without warranty of any kind and is

subject to change without notice. The warranties for Compaq products are set forth in the

express limited warranty statements accompanying such products. Nothing herein should

be construed as constituting an additional warranty.

Printed in the U.S.A.

Published by Compaq Computer Corporation under license from Maxtor Corporation.

Technical Assistance

Refer to Compaq WorldWide Telephone Numbers booklet for technical support in your

country.

StorageWorks NAS S1000

Table of Contents

Preface: About This Guide .................................................... i

Who Should Use This Guide - - - - - - - - - - - - - - - - - - - - - - - - - - i

Box Contents - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - i

Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - i

System Information - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ii

Typographical Conventions - - - - - - - - - - - - - - - - - - - - - - - - - - ii

Related Documents - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ii

Compliance Statements - - - - - - - - - - - - - - - - - - - - - - - - - - - - iii

1 Pre-Installation Planning ............................................................... 1

Equipment Required for Installation- - - - - - - - - - - - - - - - - - - 1

Site Planning - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1

About Your StorageWorks NAS S1000 - - - - - - - - - - - - - - - - - 3

2 Installing Your StorageWorks NAS S1000 .................................. 4

Connecting StorageWorks NAS S1000 to Your Network- - - - 4

Turning on the Power- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

Installing StorageWorks NAS S1000 Setup and Discovery

Utility Software - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5

Completing StorageWorks NAS S1000 Setup and Discovery

Utility Installation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6

3 Configuring Your StorageWorks NAS S1000 ............................. 9

First Login- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9

Welcome To StorageWorks NAS S1000

First Time Setup Wizard - - - - - - - - - - - - - - - - - - - - - - - - - - - 11

Setting the Date and Time - - - - - - - - - - - - - - - - - - - - - - - - - 12

Setting the Administrator Password- - - - - - - - - - - - - - - - - - 12

Setting E-mail Alerts- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13

Setting Server Appliance Identity - - - - - - - - - - - - - - - - - - - - 14

Finish the Wizard - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15

Ready for use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16

Normal Power-Down - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 17

Index ................................................................................... 18

About This Guide i

About This Guide

Who Should Use This Guide

This Installation Guide is intended to help setup and configure your StorageWorks™

NAS S1000by Compaq. Itassumes that you are somewhat familiar with networking and

system administration basics.

Box Contents

Compaq StorageWorks NAS S1000 system

Quick Start Card

Compaq StorageWorks NAS S1000 End User License Agreement

Power Cord

CAT-5 Ethernet Cables (2)

Mounting ears (pre-installed)

Rubber feet (4)

StorageWorksNAS S1000 CD containing:

•StorageWorks NAS S1000 Setup and Discovery Utility

•StorageWorks NAS S1000 documentation

Worldwide Telephone Numbers booklet

Limited Warranty Statement

Important Safety Information book

Overview

Your StorageWorks NAS S1000 comes ready to install with all the required software. It works in

a 10/100 Mbps Ethernet network (or Gigabit Ethernet network when so equipped), and is

administered using an Internet Explorer web browser. It includes StorageWorks NAS S1000

Setup and Discovery Utility, Compaq’s software utility that helps you locate the unit on your

network, configure StorageWorks NAS S1000 network settings, and launch the web user

interface.

NOTE: Should you encounter any difficulties during the installation

and configuration process outlined in this guide, please refer

to the On-Line Help File also found on the StorageWorks NAS

S1000 CD.

About This Guide ii

System Information

Please record the following information from the label on the side panel:

Model Number: __________________________________________

Serial Number: ___________________________________________

Assembly Number: ________________________________________

These numbers will be needed by support personnel if you should contact them.

Typographical Conventions

The following typographical conventions are used in this guide to help you locate and

identify information:

Related Documents

Following is a list of related publications for background and additional information:

StorageWorks NAS S1000 On-Line Help File

Quick Start Card

StorageWorks NAS S1000 End User License Agreement (EULA)

Warranty Statement

Also see our Web site at: www.compaq.com/storage/nas for the latest Release Notes

Table P-1. Typographical Conventions

Item Symbol Description

Italic text is used for emphasis and book titles.

Bold text identifies menu names, menu options, items you can click

on the screen, and keyboard keys.

Courier

font

identifies file names, folder names, and text

that either appears on the screen or that you

are required to type in.

NOTE: Notes provide extra information, tips, and hints regarding

the topic.

CAUTION: Cautions identify important information about actions

that could result in damage to or loss of data or could

cause the system to behave in unexpected ways.

WARNING: Warnings identify critical information about actions that

could result in unexpected equipment failure, loss of

critical operating system files or potential bodily injury.

About This Guideiii

Compliance Statements

This Class B digital apparatus meets all requirements of the Canadian Interference Causing

Equipment regulations.

Cet appareil numerique de la classe B respecte toutes les exigences du Reglement sur la

materiel brouilleur du canada.

This device complies with Part 15 of the FCCrules. Operation is subjectto the following

conditions: (1) This device may not cause harmful interference, and (2) This device must

accept any interference thatmay cause undesired operation.

European Community Compliance Statement

This product is in conformity with the protection requirements of EC Council Directive

89/336/EEC on the approximation of the lawsof the Member States relating to

electromagnetic compatibility.Compaq cannotaccept responsibility for any failure to

satisfy the protection requirements resulting from a non-recommended modification of

the product.

Korean Government Ministry of Communication (MOC) Statement

Please note that this device has been approved for business purposes with regard to

electromagnetic interference. If you find this is not suitable for your use, you may

exchange it for one with a non-business purpose.

StorageWorks NAS S1000 1

1 Pre-Installation Planning

Equipment Required for Installation

To connect, install and administer your StorageWorksNAS S1000, you will need an

available 10/100 Ethernet network hub or switch port. It will be necessary for your

workstation to have the following capabilities:

• Windows 95/98/Me/NT (SP5)/2000/XP

• Internet Explorer v5.01 or newer - support for Netscape is not currently available.

• Client for Microsoft Networks enabled over TCP/IP

• Ethernet Connection

• DVD/CD-ROM Drive

Site Planning

When planning a site to house your StorageWorks NAS S1000, you will want to consider

requirements for power and network availability, as well as a space with well regulated

temperature and humidity that is relatively free of dust and other airborne contaminants.

If your installation calls for placement on a table top, apply the enclosed rubber feet to the

bottom of the chassis.

The following tables are designed to help you plan your StorageWorks NAS S1000

Installation.

NOTE:

If a secure browser session is necessary, then Internet Explorer

v5.5 with Active X installed is the required browser.

Table 1-1. Size & Weight

Item Quantity

Weight 27 pounds (12.3 kg)

Size 17 x 20 x 1.75 inches (43.2 x 50.8 x 4.5 cm)

NAS S10002

Pre-Installation Planning

Table 1-2. Electrical Requirements

Item Quantity

Voltage Range 90 ~ 135 VAC or 180 ~ 265 VAC

Frequency 47 ~ 63 Hz

WARNING: Make sure your site has the necessary capacity to

handle your StorageWorks NAS S1000 unit(s).

Overloading electrical supply circuits is extremely

hazardous. Care should also be taken to properly ground

all rack mounted equipment.

Table 1-3. Operating Environment Requirements

Item Quantity

Temperature - Operating

Temperature - Non-Operating

41º to 104º F (5ºC to 40º C)

external operating temperature range

-4º to 140º F (-20ºC to +60ºC)

Humidity - Operating

Humidity - Non-Operating

5% to 85% humidity non-condensing

5% to 95% humidity non-condensing

CAUTION: When mounting your StorageWorks NAS S1000 in a rack system,

make sure that the air vents do not become blocked. Also, care

must be taken to ensure that StorageWorks NAS S1000 is

installed in an environment compatible with the ambient

temperatures stated in the table above. Maximum of 40º C.

StorageWorks NAS S10003

Pre-Installation Planning

About Your StorageWorks NAS S1000

Front Panel

The StorageWorks NAS S1000 front panel has four LEDs. Three are grouped together on the

right side, one on the left. The LEDs indicate the following:

• Far left LED (soft power button). Solid LED indicates power on. This LED will blink

during boot-up, and will also blink to indicate error conditions (See StorageWorks NAS

S1000 On-Line Help File for alert codes).

• Network Link 1 for LAN 1. Flashing indicates network activity.

• Network Link 2 for LAN 2. Flashing indicates network activity.

• Hard disk drive LED indicates read/write activity.

Back Panel

Shown below is the view of the StorageWorks NAS S1000 back panel.

SOFT POWER BUTTON

LAN 1 LAN 2 HARD DISK DRIVE

(FRONT PANEL)

POWER

CONNECTION

FAN

CONNECTIONS FOR FIELD SERVICE PERSONNEL ONLY

UPS

CONNECTION LAN 1 LAN 2 GIGABIT OPTION SCSI PORT

(BACK PANEL)

StorageWorks NAS S1000 4

2 Installing Your StorageWorks NAS S1000

Connecting StorageWorks NAS S1000 to Your Network

To connect the StorageWorks NAS S1000 to your network, insert one or both of the

included Ethernet cables into either StorageWorks NAS S1000 10/100 Ethernet port (LAN 1

or LAN 2), located on the rear panel. Insert the other end of this cable into network hub or

switch. If your StorageWorks NAS S1000 is equipped with a Gigabit Ethernet option, you

may connect it to a 10/100/1000 network hub or switch, using a CAT-6 cable (not

supplied).

NOTE: The two 10/100 Ethernet ports found on StorageWorks NAS S1000 are

pre-configured to provide load balancing and fail-over capability.

Although not necessary for a successful installation, this feature does

enhance system performance, and allows for redundancy in the event

of a cable or component failure. To use this function, connect the

second included Ethernet cable to your StorageWorks NAS S1000 and

the other end to another open port on your network hub or switch.

Load balancing and fail-over will automatically be enabled with no

special configuration required for your switch.

LAN 1

LAN 2

StorageWorks NAS S1000 5

Installing Your StorageWorks NAS S1000

Turning on the Power

1Connect one end of the enclosed power cord to a power source. Plug the other end into the

power receptacle on the back panel shown in the figure below.

2Toggle the main power switch on the back panel to the “ON” position ( I).

3Press the soft power button on the front panel (shown below), to turn on the unit.

The LED in the power button will come on. After a few moments it will begin blinking, and

continue to blink for several minutes during the power-up cycle. When the power light

stops blinking and disk activity stops, your StorageWorks NAS S1000 is ready to configure.

Installing StorageWorks NAS S1000 Setup and Discovery Utility Software

StorageWorks NAS S1000 Setup and Discovery Utility software is Compaq’s software utility

that helps you locate the unit of your network, configure StorageWorks NAS S1000 network

settings, and launch the web user interface.

Use a workstation that is logged onto the network where the StorageWorks NAS S1000

unit is connected. Insert the StorageWorks NAS S1000 Installation and Documentation CD

into your CD-ROM drive. If the initial installation screen does not appear, use Windows

Explorer to launch the setup program from the CD.

Click on StorageWorks NAS S1000 Setup and Discovery Utility to begin your installation.

NOTE:

The “ON” position ( I) and “OFF” position (O) are displayed on the

main power switch on the back panel.

(BACK PANEL) POWER

RECEPTACLE

MAIN POWER SWITCH

(FRONT PANEL)

SOFT POWER BUTTON

Andere Handbücher für StorageWorks S1000 - NAS

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Compaq Server Handbücher

Compaq

Compaq ML350 - ProLiant - G2 Bedienungsanleitung

Compaq

Compaq AlphaServer DS10 Produktinformationsblatt

Compaq

Compaq 112726-001 - ProLiant - 6500 Kurzanleitung

Compaq

Compaq ProLiant 8000 Bedienungsanleitung

Compaq

Compaq 195294-001 - ProLiant - ML370R Bedienungsanleitung

Compaq

Compaq AlphaServer 4100 s Bedienungsanleitung

Compaq

Compaq ProLiant 6000 Series Bedienungs- und Sicherheitshinweise

Compaq

Compaq ProLiant ML350 (G2) Installationsanleitung

Compaq

Compaq 195294-001 - ProLiant - ML370R Bedienungs- und Sicherheitshinweise

Compaq

Compaq 221050-001 - ProLiant - 5000R Bedienungsanleitung

Compaq

Compaq AlphaServer GS80 Betriebsanleitung

Compaq

Compaq SCSI Bedienungsanleitung

Compaq

Compaq 6400R - ProLiant - 1 GB RAM Bedienungs- und Sicherheitshinweise

Compaq

Compaq DL320 - ProLiant - G3 Bedienungs- und Sicherheitshinweise

Compaq

Compaq 108164-003 - ProLiant - 800 Kurzanleitung

Compaq

Compaq 195294-001 - ProLiant - ML370R Bedienungsanleitung

Compaq

Compaq 1850R - ProLiant - 128 MB RAM Bedienungs- und Sicherheitshinweise

Compaq

Compaq ProLiant 5500 Bedienungs- und Sicherheitshinweise

Compaq

Compaq 1850R - ProLiant - 128 MB RAM Kurzanleitung

Compaq

Compaq 108164-003 - ProLiant - 800 Kurzanleitung

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Bedienungsanleitung

Compaq

Compaq ProLiant 400 Kurzanleitung

Compaq

Compaq ProLiant 4500 Bedienungsanleitung

Compaq

Compaq ProSignia 500 Handbuch

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung

Planet

Planet NAS-7410 Bedienungsanleitung
