MicroRouter 900i
Installation Guide
Compatible Systems Corporation
4730 Walnut Street
Suite 102
Boulder, Colorado 80301
303-444-9532
800-356-0283
http://www.compatible.com
MicroRouter 900i Installation Guide, Version 3.0
Copyright© 1999, Compatible Systems Corporation
All rights reserved. RISC Router and CompatiView are trademarks of
Compatible Systems Corporation. Other trademarks are the property of
their respective holders.
Part number: A00-1095
FCC Notice: This product has been certified to comply with the limits
for a Class A computing device, pursuant to Subpart J of Part 15 of FCC
Rules. It is designed to provide reasonable protection against radio or
television communication interference in a commercial environment.
Operation of this equipment in a residential area could cause interfer-
ence with radio or television communication.
iii
Chapter 1 - Introduction 1
ABOUT THE MICROROUTER 900I1
A NOTE ABOUT ON-DEMAND INTERNETWORKING 1
MICROROUTER 900IINSTALLATION OVERVIEW 1
Chapter 2 - Getting Started 2
Chapter 3 - NetworkInstallation 2
Chapter 4 - CompatiView Software Installation 2
Chapter 5 - Command Line Preparation 2
Chapter 6 - Basic Configuration Guide 2
Appendices 3
Chapter 2 - Getting Started 5
A FEW NOTES 5
Please Read The Manuals 5
Warranty and Service 5
Getting Help With the MicroRouter 900i 5
WHAT YOU WILL NEED TOGET STARTED 6
Supplied withthe MicroRouter 900i 6
Needed For Installation 6
Ethernet Connection Requirements 6
Thick Ethernet 7
Thin Ethernet 7
10Base-T Twisted-Pair Ethernet 7
Telco Line Connection Requirements 7
RS-232 Port 7
Chapter 3 - Network Installation 9
Mounting the Router 9
Connecting the Router to the Ethernet 10
Connecting to Thick Ethernet 10
Connecting to Thin Ethernet 10
Connectingto Twisted-Pair Ethernet 10
Connecting a Line Device to the MicroRouter 900i 10
ConnectingDevices to the RS-232C Port 10
iv
Connecting an Out-of-Band Management Console 11
Powering Up the Router 11
Chapter 4 - CompatiView Software Installation 13
CompatiView for Windows 13
System Requirements 13
Installing and Running CompatiView for Windows 13
Transport Protocols and CompatiView 14
Chapter 5 - Setting Up Command Line Management 15
Out-of-Band Command Line Management 15
TemporarilyReconfiguringaHostforCommandLineManagement
15
Setting Up Telnet Operation 16
Chapter 6 - Basic Configuration Guide 19
ETHERNET INTERFACE CONFIGURATION 19
IP Protocol 20
Required for IP 20
Suggested for IP 20
WAN INTERFACE CONFIGURATION 20
Physical Communications Settings 20
Link Configuration 21
Required for Dedicated/Leased Line Operation 21
Suggested for Dedicated/Leased Line Operation 21
Required for Dial-On-Demand Operation 21
Suggested for Dial-On-DemandOperation 22
IP Protocol 22
Required for IP 22
Suggested for IP 22
Link Configuration 23
Suggested for Dedicated/Leased Line Operation 23
Frame Relay DLCI Mappings 23
v
IP Protocol 24
Required for IP 24
Required for IP Numbered Interface 24
Required for IP Unnumbered Interface 24
Suggested for IP 24
SAVING ACONFIGURATION FILE TO FLASH ROM 25
Appendix A - Shipping Defaults 27
Default Password 27
Ethernet Port 27
IP Defaults 27
WAN Port 27
IP Defaults 27
Link & Physical Defaults 27
Appendix B - Connector and Cable Pin Outs 29
Pin Outs for DIN-8 to RS-232 Data Cable (DCE/Male) 29
Pin Outs for DIN-8 to RS-232 Console Cable (DTE/Female) 29
Appendix C - Light Patterns and Test Switch Settings31
MicroRouter 900i Light Patterns 31
Traffic Indicators 31
Other Indicators 31
Level 1 Panic Indicators 31
MicroRouter 900i Switch Settings 32
Appendix D - Downloading Software From Compatible
Systems 33
Appendix E - Terms and Conditions 35
vi
Chapter 1 - Introduction 1
Chapter 1 - Introduction
About the MicroRouter 900i
Congratulations on your purchase of the MicroRouter 900i Ethernet to
Internet router. The MicroRouter 900i supports the IP protocol, with
dial-on-demand or dedicated operation over voice, leased/switched 56,
or ISDN lines, using the PPP or the Frame Relay wide area protocols.
A Note About On-Demand Internetworking
The MicrRouter 900i can be configured to provide cost effective
on-demand connections over a wide area communications link (typi-
cally a voice phone line, a switched 56 line, or an ISDN line). Your
network traffic and the configuration you place in the router will deter-
mine how often and for how long such a link is connected.
THE SHIPPING CONFIGURATION IN YOUR MICROROUTER
900i DOES NOT PROVIDE AUTOMATIC ON-DEMAND INTER-
NETWORKING. YOU MUST FIRST PROGRAM YOUR ROUTER
TO WORK IN THIS ROLE ON YOUR NETWORK.
YOU SHOULD CAREFULLY MONITOR PHONE LINE USAGE TO
BE SURE THAT YOUR ROUTER CONFIGURATION IS
ALLOWING THE ROUTER TO DROP THE COMMUNICATIONS
LINK WHEN IT ISN’T NEEDED.
MicroRouter 900i Installation Overview
This manual will help you install the MicroRouter 900i to a local
Ethernet to a remote network and/or PPP client computer. This connec-
tion can be made to other Compatible Systems routers, routers from
other vendors, or PPP compliant dial-in software packages running on a
variety of computers. The wide-area interface on the MicroRouter 900i
may be used to interconnect your network with other corporate
networks, and to make your network’s resources available to dial-in
clients. You can also use the MicroRouter 900i as an IP only router in
non-Internet applications.
2Chapter 1 - Introduction
In short, the installation steps are:
1. Install the MicroRouter hardware and connect it to a line commu-
nication device (including a modem, 56K CSU/DSU, or ISDN Ter-
minal Adapter).
2. Select the management method you wish to use with the router. If
you want to use the CompatiView management software, you must
install the software on a Windows PC which is connected to your
network.
3. Configure the MicroRouter LAN and WAN parameters using the
management method you have chosen.
The manual is divided into several sections that should provide you
with the basic information you will need to use the MicroRouter 900i on
your network. For the latest documentation on Compatible Systems
products, including the most current version of this manual, visit the
Technical Support section of our Web site at:
http://www.compatible.com.
Chapter 2 - Getting Started
This part of the manual describes the contents of the MicroRouter 900i
package and emphasizes the preparation and equipment you will need
to install the router.
Chapter 3 - Network Installation
This part of the manual includes step-by-step instructions on how to
physically install the MicroRouter 900i and connect it to your local
Ethernet and your wide area network. Instructions are included for
thick, thin, and twisted-pair Ethernet environments as well as modems,
56K CSU/DSUs, and ISDN terminal adapters.
Chapter 4 - CompatiView Software Installation
This part of the manual describes how to install CompatiView, Compat-
ible Systems’GUI (Graphical User Interface) management software
which is included with your router.
Chapter 5 - CommandLine Preparation
This part of the manual provides basic instructions on setting up
command line management and text-based configuration.
Chapter 6 - Basic Configuration Guide
This part of the manual provides a list of parameters that must be
entered into a router for proper operation.
Chapter 1 - Introduction 3
Appendices
This part of the manual includes additional information that might be of
interest to you such as technical specifications, default settings
(including the default factory password) and instructions for down-
loading current software.
