Compex WPP54 Bedienungsanleitung

Quick Install Guide

Wireless 54Mbps

Outdoor Access Point

WPP54

Table of Contents

1: Introduction......................................................................................1

Introduction to WPP54G multi-SSID firmware version.......................... 1

Introduction to WPP54AG multi-SSID firmware version ....................... 2

Introduction to WPP54G non multi-SSID firmware version.................. 3

Introduction to WPP54AG non multi-SSID firmware version ............... 4

Packaging Content.................................................................................. 5

Network Application................................................................................ 6

2: Let’s Get Going-Hardware Setup ................................................7

Overall Setup of Compex WPP54 .......................................................... 8

Method 1: Mounting on the Wall........................................................... 9

Method 2: Mounting on the Pole......................................................... 12

3: Access to Web-based Interface................................................15

Method 1: Access to the Web interface with uConfig..................... 15

Method 2: Access to the Web interface manually........................... 19

4: TCP/IP Configuration....................................................................20

For Windows 95/98/98SE/ME/NT...........................................................20

For Windows XP/2000.............................................................................22

5: Panel Views and Descriptions.....................................................25

6: Technical Specifications..............................................................27

WARRANTY REGISTRATION CARD.......................................................33

Chapter 1 Introduction

1: Introduction

Introduction to WPP54G multi-SSID firmware version

The WPP54AG Wireless-AG 54Mbps XR™Outdoor Access Point is a high-

performance AP designed for enterprise and outdoor users. WPP54AG is

compatible with IEEE 802.11a/b/g and supports high-speed data transmission of

up to 54Mbps at in both the 2.4GHz and the 5GHz frequency bands. The in-built

Atheros®Super-AG technology provides higher throughput in the 802.11a 5GHz

band versus 802.11g’s congested 2.4GHz band and the ability to operate in at

least 19 non-overlapping channels as compared to the 3 non-overlapping

channels on 802.11g standard. This equips WPP54AG with network robustness,

stability and wider network coverage. Housed in a weatherproof casing,

WPP54AG is designed to withstand any outdoor climatic conditions, making it

the ideal solution for outdoor applications.

Designed with an external SMA connector and the ability to operate in 6

different modes, the WPP54AG can be used for a wide variety of wireless

applications. The integrated WDS (Wireless Distribution System) feature creates

a virtually larger wireless network infrastructure by linking up other access points.

WPP54AG also includes a DHCP server that automatically assigns IP addresses

to wireless clients. For the ultimate multimedia experience, WPP54AG includes

the WMM™(QOS) feature which allows media files to be delivered over the

network more efficiently,

Connecting to a wireless LAN without adequate security measures generally

opens up your network to any casual snoopers. To protect your privacy,

WPP54AG is armed with many enhanced wireless security features such as Wi-Fi

Protected Access (WPA), MAC Address Filtering, IEEE 802.1x Authentication,

64/128-bit WEP (Wired Equivalent Privacy) and Advanced Encryption Standard

(AES) encryption feature to ensure privacy for the heterogeneous mix of users

within the same wireless LAN, while maintaining full access to the

establishment’s resources.

WPP54AG also incorporates unique features from Compex such as – the Parallel

Broadband feature that allows bandwidth aggregation and fail-over

redundancy capability. It uses Spanning Tree Protocol (STP) that provides the

wireless network with extra redundancy and reliability. The network will auto-

reconfigure when there are changes to the network connections and the

Pseudo VLAN feature that enables the creation of wireless isolated nodes or

workgroups of wireless clients to increase network privacy in a public access

wireless LAN.

Chapter 1 Introduction

Introduction to WPP54AG multi-SSID firmware version
