BUF-PCI(PC), BUF-PCI(98)
Bus Expansion
User’s Guide
BUF-PCI(PC), BUF-PCI(98) i
Copyright
Copyright 1998 CONTEC CO., LTD. ALL RIGHTS RESERVED
No part of this document may be copied or reproduced in any form by
any means without prior written consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current
the information contained in this document. The information in this
document is subject to change without notice.
All relevant issues have been considered in the preparation of this
document. Should you notice an omission or any questionable item in
this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no
responsibility for any errors that may appear in this document nor for
results obtained by the user as a result of using this product.
Trademarks
MS, Microsoft, MS-DOS and Windows are trademarks of Microsoft
Corporation. Other brand and product names are trademarks of their
respective holder.
BUF-PCI(PC), BUF-PCI(98)ii
Product Configuration
-BUS-PCI(PCI) Board ... 1
-BUS-PCI(PC) Board or BUS-PCI(98) Board ... 1
-Connecting Cable …1
-BUF-PCI Driver Install Disk (3.5 inch / 1.44MB) ... 2
-User's Guide (this booklet) ... 1
Unpacking:
This board is specially packed in an anti-static bag to prevent damage in
shipping.
Check the contents to make sure that you have everything listed above.
If you do not have all the items, contact your distributor or CONTEC
group office where you purchased.
Note! Do not remove the board from its protective packaging until the
computer case is open and ready for installation. Electrical static can
cause damage to electrical components.
BUF-PCI(PC), BUF-PCI(98) iii
Table of Contents
Copyright............................................................................i
Trademarks ........................................................................i
Product Configuration...................................................... ii
1. Introduction .............................................................1
About the BUF-PCI(PC) or BUF-PCI(98)....................1
Features.........................................................................2
Functions.......................................................................2
Limited Three-Year Warranty......................................3
How to Obtain Service..................................................3
Liability.........................................................................3
Restrictions....................................................................4
Handling Precautions...................................................5
About the Manual.........................................................6
2. Setup .......................................................................7
Setup Procedure................................................................7
Setting Up and Mounting the BUS-PCI(PCI) Board.......8
Setting Whether or not to Use Interrupt Resources ...8
Setting the Board ID.....................................................9
Mounting the BUS-PCI(PCI) Board.............................9
Setting Up and Mounting the BUS-PCI(PC) or
BUS-PCI(98) Board............................................10
Setting Up I/O Expansion Unit Power Control .........10
Mounting the BUS-PCI(PC) or BUS-PCI(98) Board.11
Connecting the PC to the I/O Expansion Unit...............12
Turning Power On...........................................................13
Installing the BUF-PCI Driver Software.......................14
Installing for Windows XP..........................................14
Installing for Windows 2000.......................................18
Installing for Windows NT .........................................22
Installing for Windows Me .........................................24
Installing for Windows 98...........................................28
Installing for Windows 95...........................................32
Installing for MS-DOS................................................39
BUF-PCI(PC), BUF-PCI(98)iv
Mounting Boards for Use in the I/O Expansion Unit....40
Verifying Restrictions and Specifications..................40
Setting I/O Port Addresses .........................................41
Setting Interrupt Request Levels...............................41
Mounting and Turning the Power On........................42
3. Programming.......................................................... 43
Programming with Windows..........................................44
About the BUF-PCI Driver Software.........................44
Function List...............................................................44
Programming Input and Output to and
from I/O Ports.....................................................45
Programming Interruption.........................................46
Programming Self-testing ..........................................48
Function Reference.....................................................48
BufPciOpen......................................................................49
BufPciClose......................................................................51
BufPciSetBusSignal........................................................52
BufPciInPortB.................................................................54
BufPciInPortW................................................................55
BufPciOutPortB ..............................................................57
BufPciOutPortW..............................................................58
BufPciSetIrqEvent..........................................................60
BufPciStopEvent.............................................................62
BufPciRestartEvent........................................................64
BufPciGetIrqStatus.........................................................65
BufPciSetProgramWait...................................................67
BufPciSelfTest .................................................................68
List of Return Values..................................................70
Sample Program for Windows....................................73
Programming in an OS other than Windows.................74
I/O Port Input/Output Procedure...............................74
Interrupt Procedure....................................................75
Details of I/O Port Addresses..........................................77
List of Output Ports....................................................77
List of Input Ports.......................................................78
Detailed Description...................................................79
BUF-PCI(PC), BUF-PCI(98) v
Sample Programs for MS-DOS...................................83
4. System Reference.................................................... 85
Hardware Specifications.................................................85
System Specifications.................................................85
Specifications of Each Board......................................85
Cable Specifications....................................................86
List of BUF-PCI(PC) I/O Expansion Slot Signals......87
List of BUF-PCI(98) I/O Expansion Slot Signals ......88
Software (BUF-PCI Driver) Specifications....................89
5. Troubleshooting ...................................................... 91
The Product cannot be Set Up Properly.........................91
The PC and/or the I/O Expansion Unit does not
Start Up ..............................................................91
The BUF-PCI Driver cannot be Installed..................91
Self-testing does not Result in OK.............................91
Board Mounted in the I/O Expansion Unit cannot be
Accessed..............................................................92
No Input or Output can be Performed on I/O Ports..92
No Interruption can be Performed.............................93
6. Index ..................................................................... 95
BUF-PCI(PC), BUF-PCI(98)vi
List of Figures
Figure 2.1. DIP Switch SW1....................................................... 8
Figure 2.2. Mounting Diagrams................................................ 10
Figure 2.3. Connection Diagram............................................... 12
Figure 3.1. Programming I/O Port Input and Output Processes .45
Figure 3.2. Main Routine Programming Procedure................... 46
Figure 3.3. Programming Procedure for Message Processing by
Event...................................................................... 47
Figure 3.4. Main Routine Programming Procedure................... 47
Figure 3.5. Timer Process Programming Procedure.................. 48
List of Table
Table 2.1. Specifying Whether or not to Use Interrupt Resources... 8
Table 2.2. Setting Board IDs.......................................................... 9
Table 3.1. List of Functions.......................................................... 44
Table 4.1. BUF-PCI(PC) System Specifications........................... 85
Table 4.2. BUF-PCI(98) System Specifications............................ 85
Table 4.3. BUS-PCI(PCI) Board Specifications ........................... 85
Table 4.4. BUS-PCI(PC) Board Specifications............................. 86
Table 4.5. BUS-PC(98) Board Specifications............................... 86
Table 4.6. Cable Specifications.................................................... 86
Table 4.7. List of BUF-PCI(PC) I/O Expansion Slot Signals........ 87
Table 4.8. List of BUF-PCI(98) I/O Expansion Slot Signals......... 88
Table 4.9. Software Specifications............................................... 89
Introduction
BUF-PCI(PC), BUF-PCI(98) 1
1. Introduction
About the BUF-PCI(PC) or BUF-PCI(98)
Thank you for purchasing the BUF-PCI(PC) or BUF-PCI(98).
The product is a bus conversion adapter that allows you to add ISA or C
bus-equivalent expansion slots by connecting the PCI bus expansion
slot in the PC with the CONTEC I/O expansion unit.
Please read this document thoroughly before starting building a system,
including creating application programs and connecting with external
devices.
This product consists of the following
-BUS-PCI(PCI) board (to be mounted in the PCI bus expansion slot in
the PC)
-BUS-PCI(PC) board or BUS-PCI(98) board (to be mounted in
CONTEC's I/O expansion unit)
-Cable for connecting the above two products
In order to use the adapter, you need an I/O expansion unit FA-PAC
series, which is sold separately, in addition to the above.
Introduction
BUF-PCI(PC), BUF-PCI(98)2
Features
-The BUS-PCI(PCI) board is a PCI bus-compliant interface board
which can be used with the IBM PC-AT compatibles, NEC
PC98-NX series, and PC-9800 series in which a PCI bus expansion
slot is available.
-Allows you to add I/O-accessible ISA or C bus-equivalent expansion
slots.
-Verifies an interrupt request from the interface board mounted in the
I/O expansion unit to accomplish the interrupt process.
-Driver software for control of the interface board mounted in the I/O
expansion unit is available for Windows XP, Windows 2000,
Windows NT, Windows Me, Windows 98 and Windows 95.
-The I/O access wait and the refresh signal for the I/O expansion unit
can be enabled or disabled.
-Comes with a self-diagnostic feature.
Functions
General-purpose I/O accessing
Allows you to access an added expansion slot for I/O. The I/O wait can
be specified with software.
Interruption
An interrupt can be generated with an interrupt request signal from the
added expansion slot. The status of the interrupt request signal can also
be verified.
Control of the refresh signal
Enabling or disabling of the refresh signal for the added expansion slot
can be specified with software.
Self-testing
Allows self-testing using a dedicated register mounted on the board.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Contec Adapter Handbücher
