Continental Refrigerator DL2RF-SS Bedienungsanleitung

SIDE BY SIDE

DUAL TEMPS

Utilizing Environmentally Safe, CFC-free R-134a & R-404A Refrigerant

Standard Features

• Modern, State-of-the-Art Styling

• Performance Rate “Plug” Refrigeration

Systems

• 3" Non-CFC Polyurethane Foam Insulation

• Chrome-Plated Flow Line Handles

• Cam-Action Lift-Off Hinges

• Self-Closing Doors

• Magnetic Snap-In Gaskets

• Cylinder Lock In Each Door

• Automatic Hot Gas Condensate Evaporator

• Adjustable 6" Stainless Steel Legs

• External Digital Thermometers

• Automatic Electric Defrost on Freezer System

• Automatic Interior Lighting

Optional Features & Accessories

• Half-Door • Pass-Thru

• Remote • Casters

• Stainless Steel • Pan Slides

Shelves • Correctional Facility

• Consult Factory Package

Standard (S/S Front, Aluminum Ends & Interior)

Suffix SA (S/S Exterior, Aluminum Interior)

Suffix SS (S/S Exterior & Interior)

REFRIGERATION SYSTEM

Two “performance rated”, air cooled hermetically sealed,

capillary type refrigeration systems are installed on top of

each dual temp. Plasticized fin coil and air circulating fans

are contained within each concealed “plug” type insulated

housing, readily accessible on the top of the cabinet and

separate from each food zone to increase food storage

capacity. Both “plug” systems are fully charged with refrig-

erant and mounted on a sturdy steel, rail-type base which

can be easily removed. Refrigerator sections are designed

to maintain 38 to 40 degrees Fahrenheit (3 to 5 degrees

Centigrade), and Freezer sections 0 degrees Fahrenheit (-

18 degrees Centigrade) while operating with an unrestricted

air supply in a maximum ambient temperature of 100

degrees Fahrenheit. Freezer “Plug” systems have an auto-

matic electric defrost timer which initiates defrost cycles at

predetermined intervals. All condensate water is evaporat-

ed by an automatic, non-electric, corrosion-resistant con-

densate evaporator. A strict quality-assurance team

inspects all materials and components to certify that each

model conforms to the most exacting standards. All models

are factory performance tested for a minimum of 16 hours

prior to crating.

CABINET CONSTRUCTION

All materials are of top quality, assembled to conform

with strict quality-assurance requirements. The cabi-

net front and doors are constructed of heavy-gauge

polished stainless steel for durability. All cabinet

joints and seams are sealed vapor tight. Case is of

all metal, welded construction and internally support-

ed and braced for a rigid unit construction. Cabinet

design eliminates overlapping panels with raw edges.

Cabinet body, doors and plug are insulated with non-

CFC, foamed-in-place polyurethane foam with an

average thickness of 3 inches to ensure increased

energy efficiency. Full-length louvered air grille locat-

ed above the doors allows equal air circulation to the

condensing unit. Easily removable, low-wattage,

anti-sweat door heaters concealed by a non-metallic,

non-conductive, high-impact thermal breaker strip

eliminate condensate build-up on th cabinet front.

Automatic interior lighting is controlled by door open-

ings. Cabinets are equipped with 6-inch adjustable

stainless steel legs.

SHELVING

Shelves are designed for heavy-duty use with

.306" diameter frame and brace members and

.140" diameter fill wires spaced 3/4" apart.

Shelves are welded steel and epoxy-coated for a

durable, long, rust-free service life. Adjustments

are in 1/2 increments and a wide door opening

allows the use of a variety of optional pan and tray

slide types.

DOOR CONSTRUCTION

Door shells are constructed of heavy gauge stain-

less steel and are internally braced and urethane-

foamed-insulated for rigidity. Door corners are of

welded construction and polished. REplaceable

snap-in gaskets are self-adjusting, heavy-duty,

magnetic type. Door handles and hinges are

chrome-plated and non-corrosive. Doors are pro-

vided with built-in cylinder locks which are keyed

alike. Hinges are cam action, lift-off type featuring

positive safety stop at 120 degrees.

DL2RF-SS

DL3RRF-SS

DL23RF305

DUAL TEMPS

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

CHARACTERISTICS DL2RF-SS DL3RRF-SS DL3RFF-SS

DIMENSIONAL DATA

Net Capacity (cu. ft.) 21/21 50/21 21/50

Width, Overall (in.) 52 78 78

Depth, Overall (Incl. Hdls.) (in.) 351/2351/2351/2

Depth (Less Door(s)) (in.) 32 32 32

Depth (Doors(s) Open 90°) (in.) 551/2551/2551/2

Clear Door Width (in.) 193/8193/8193/8

Clear Full-Door Height (in.) 585/8585/8585/8

Clear Half-Door Height (in.) 271/2271/2271/2

Height, Overall (Inc. 6" Legs)(in.) 831/4831/4831/4

No. of Full Door(s) 2 3 3

No. of Half Door(s) 4 6 6

No. of Shelves 6 9 9

Shelf Area (sq. ft.) 20.4/20.4 40.8/20.4 20.4/40.8

Tray Slide Capacity (Half) 12 ea. 12 ea. 12 ea.

Tray Slide Capacity (Full) 25 ea. 25 ea. 25 ea

REFRIGERATION DATA

Condensing Unit Size (H.P.) 1/4,1/31/3,1/31/4,1/2

Capacity (BTU/hr)** 1940/1590 2560/1590 1940,2470

ELECTRICAL DATA

Cabinet Specifications

115/60/1 115/60/1 115/60/1

Feed Wires (Incl. Ground) 3/3 3/3 3/3

Condensing Unit Specs.

115/60/1 115/60/1 115/60/1

Total Amperes 6.9/7.6 9.1/7.6 6.9/9.8

Defrost Amperes 4.3 4.3 9.6

Power Supply Cord yes yes yes

SHIPPING DATA

Height – crated (in.) 82 82 82

Width – crated (in.) 55 81 81

Depth – crated (in.) 37 37 37

Volume – crated (cu.ft.) 97 142 142

Weight Std – crated (lbs.) 630 835 835

Weight SS – crated (lbs.) 710 950 950

Weight Std – uncrated (lbs.) 460 625 625

Weight SS – uncrated (lbs.) 380 740 740

*Rating @ +25°F Evaporator, 90° Ambient (Refrigerator)

*Rating @ -15°F Evaporator, 90° Ambient (Freezer)

Note: All Specifications subject to change without notice.

Note: If the cabinet is located directly against wall and/or under low ceiling, a mini-

mum clearance of 2" required.

Cabinet upper side panels and refrigeration plug systems can be easily removed and

reinstalled at installation site where space limitations are confining.

52"

78"

DL2RF

DL3RRF/DL3FFR

SIDE VIEW
