CoolGear CG-U31iS4PH Bedienungsanleitung

4 Port USB 3.1 Gen1

Isolated Hub with 15KV

ESD Surge Protection

Product Manual

Coolgear, Inc.

Version 1.1

September 2017

Model Number: CG-U31iS4PH

www.coolgear.com

2 CG-U31iS4PH – Product Manual

www.coolgear.com

Revision History

Revision Date Author Comments

1.0 3/20/2017 Coolgear Original format

1.1 10/9/2017 Coolgear New Manual Format

About this document

This product manual outlines installation and features of the 4 Port USB 3.1 Gen1

Isolated Hub with 15KV ESD Surge Protection.

Scope

The scope of this manual is to give the user of the product an understanding of its use

with detailed diagrams and verbiage. The manual allows the users to apply the product

to their application.

Intended Audience

This product is intended for use in numerous industries including but not limited to

applications such as; Automotive, Machine Equipment, Kiosk, Office, and others.

Product Support

[email protected]

CG-U31iS4PH – Product Manual 3

www.coolgear.com

Table of Contents

1. Introduction.........................................................................................................4

1.1 Features .................................................................................................................. 4

1.2 Connector Layout.................................................................................................... 5

1.3 Supported USB Devices........................................................................................... 5

1.4 I/O Hardware .......................................................................................................... 6

1.5 Environmental Specifications ................................................................................. 6

2. Notes, Tips, Warnings, and Safety.........................................................................7

3. Supporting References .........................................................................................8

Table of Figures

Figure 1 – Connector Layout…………………………………………………………………………………………..5

Figure 2 – Supported Devices.............................................................................................6

4 CG-U31iS4PH – Product Manual

www.coolgear.com

1. Introduction

The new CG-U31iS4PH USB 3.1 4 port hub isolates the four downstream ports from the

upstream host port giving you valued circuit protection. With a small footprint, the hub

supports 5Gbps super-speed data and backwards compatibility down to USB 1.0

1.5Mbps. With its DIN RAIL mounting plate, it’s an ideal hub mountable hub with

protection. The hub provides an external 5V AC/DC power adapter for its downstream

ports. It supports USB charging specifications by turning its downstream ports from a

Standard Downstream Port (SDP) into Charging Downstream Port (CDP) or Dedicated

Charging Ports (DCP).

WEIGHT .7 lbs

DIMENSIONS 5.95”(L) x 2.44”(W) x 1.33”(H) (151.1 x 62.0 x 34.0 mm)

UPC 045079159969

WARRANTY 1 year from date of purchase

COLOR White

DOWNSTREAM PORTS 4 USB 3.1 Gen1 Type-A Ports

UPSTREAM PORTS 1 USB 3.1 Gen1 Type-B Port

1.1 Features

•Compliant with USB 3.1 Gen 1

Specifications

•1 USB-B Upstream and 4 USB-A

Downstream USB 3.1 Gen1 Facing

Ports

•Up to 3KV AC Isolation Between

Upstream and Downstream Ports

•Supports up to 15KV ESD Surge

Protection for Each Port

•Built-in RISC-like USB3.1 Gen 1 Hub

Controller

•Charges all 4 USB Ports up to1.5A Each

Simultaneously

•Supports 5Gbps (Super-Speed),

480Mbps (high-Speed), 12Mbpd (Full-

Speed), and 1.5Mbps (Low-Speed)

Speeds

•Multi Transaction Translators (TT) per

Hub

•Supports USB Battery Charging BC 1.2

CDP and DCP modes

•Plastic Case with DIN RAIL Mounting

Option and Wall Mounting Bracket for

Critical Applications

•Supports USB Screw-Lock Cable

Mechanism

CG-U31iS4PH – Product Manual 5

www.coolgear.com

1.2 Connector Layout

Figure 1

USB A Downstream Port USB B Upstream Port 5V DC Power Input

3KVrms isolated

Downstream Port Domain

for the 4 downstream USB

3.1 Type-A ports with 15KV

ESD surge protection per

port.

3KVrms isolated Upstream

Port for USB 3.1 Type-B to

A host port with 15KV ESD

surge protection.

5V AC/DC power adapter

for downstream ports. It

supports USB charging

specifications by turning its

downstream ports from a

Standard Port (SDP) into

Charging Downstream Port

(CDP) or Dedicated

Charging Ports (DCP).

1.3 Supported USB Devices

•Supports keyboard, mouse, monitor, scanner, printer, PC Camera, telephone,

DVD drive, joystick, virtual reality helmet, modem, PBX and many more USB

devices.

6 CG-U31iS4PH – Product Manual

www.coolgear.com

Figure 2

1.4 I/O Hardware

•Supports 4 external USB3.1 Gen 1 Type-A connectors and 1 USB3.1 Gen 1 Type-B

Upstream connector.

•Supports a DC-Jack Connector (on the Downstream Port Domain) for external

power input from AC/DC power adapter.

1.5 Environmental Specifications

Specification Data

Operating Temperature: 0-70°C (32 to 158°F)

Operating Temperature: -20 to 85°C (-4 to 185°F)

Operating Humidity: 5 to 95% RH

CG-U31iS4PH – Product Manual 7

www.coolgear.com

2. Notes, Tips, Warnings, and Safety

Note For Systems with USB3.1 Gen 1, USB2.0, or USB1.1 Ports

Tip N/A

Warning N/A

Safety

•Read the entire Product Manual before implementing this product for

your application. This manual contains important information about

electrical connections that must be followed for safe and proper

operation.

•Inspect the product closely for visual defects before putting it to use.

•Keep away from areas where moisture builds, this product contains

electrical components that can be damaged by moisture build up, this

can adversely affect your equipment connected to it.

•Do not disassemble the product. Handling the product’s internal

components can expose it to ESD (Electro-Static Discharge) hazards

that can affect the function of the device.

•If this product is not functioning properly, email our support team at

[email protected].

8 CG-U31iS4PH – Product Manual

www.coolgear.com

3. Supporting References

Document Link

Website Product Page https://www.coolgear.com/product/4-port-

usb-3-gen1-isolated-hub-15kv-esd-surge-

protection

and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject

to change without notice.
