Cornelius Nordic CCU0300 Series Leitfaden

Nordic

Model CCU0300***1

Service Parts Manual

(Includes 50Hz. Units)

IMI CORNELIUS INC.

www.cornelius.com

Publication Number: 631806062

Revision Date: July 1, 2008

Revision: B

Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs.

CCU0300 1 Service Parts Manual Manual Number 631806062

CCU Series Service Parts Table Of Contents

This parts list contains the service parts available for the CCU series icemakers listed below.

CCU0300**1 1 Air and Water Cooled

CCU0300**5 1 Air and Water Cooled

Engineering Revision Level

Check the model number on the data plate and refer to the correct listing for the specific component.

Check carefully that the correct part is identified and ordered.

Table of Contents Page 1

Bin and Exterior Components Page 2 - 3

Refrigeration System Page 4 - 5

Harvest Assist Assembly Page 6

Control Box Page 7

Evaporator Page 8

Water Pump Page 9

E-Mail: tech.service @cornelius.com

Website: www.cornelius.com

Telephone Number

800-238-3600 All Departments

The CCU Series Service Manual is available seperately, Part Number 631806061

Note: Model Number Suffix Indicates Machine Voltage As Follows:

1=115/60/1

2=208-230/60/1

3=208-230/60/3

5=230/50/1

Page 1

CCU0300 1 Service Parts Bin and Exterior Components

Page 2

CCU0300 1 Service Parts Bin and Exterior Components

Item CCU0300 1 1 CCU0300 5 1 Description

1 620204400 620204400 Trim Strip RH

2 620204399 620204399 Trim Strip LH

3 620204333 620204333 Panel Rear Access

4 620204562 N/A Bushing, Strain Relief

5 620204561 N/A Power Cord 115 Volt Only

6 620204519 620204519 Front Grill Large

7 620204520 620204520 Front Grill Small

8 620204327 620204327 Bin Assembly (Includes Item 10)

9 620204446 620204446 Hex Head Machine Screw

10 620204538 620204538 Drain Elbow

11 620204420 620204420 Clamp

12 620204912 620204912 Bin Door Assembly

620204913 620204913 Bin Door

620204455 620204455 Thumb Screw

620204380 620204380 Door Stop

13 620204914 620204914 Bin Top Assembly Stainless Steel

620204915 620204915 Plastic Corner Cap Left Side

620204916 620204916 Plastic Corner Cap Right Side

620204444 620204444 Truss Head Sheet Metal Screw-Plastic Corner

14 620204440 620204440 Top Panel Screw

15 620204442 620204442 Screw

16 620204460 620204460 Bin Fastener Thumb Nut Three Prong

17 620204368 620204368 Control Box Cover

18 620204909 620204909 Leg Set (4 each)

19 620204485 620204485 Ice Scoop

20 620204288 620204288 Rear Panel

21 620204397 620204397 Left Side Panel

22 620204397 620204397 Right Side Panel

23 620204813 620204813 Plastic Drain Fitting

24 N/A 620204917 Water Pump Cover

25 N/A 620204918 Cover Base Panel

Page 3

CCU0300 1 Service Parts Refrigeration

Page 4

CCU0300 1 Service Parts Refrigeration

Item CCU0300 1 1 CCU0300 5 1 Description

1 620204699 620204700 Compressor

2 620204618 620204618 Expansion Valve

3 620204601 620204601 Drier-Air Cooled

620204604 620204604 Drier-Water Cooled

4 620204534 620204534 Service Valve Core

620204535 620204535 Service Valve Cap

5 620204615 620204615 Hot Gas Valve Body

6 620204613 620204614 Hot Gas Valve Coil

7 620204468 620204469 Purge Valve

8 620204428 620204428 Flat Washer

9 620204742 620204742 Grommet

10 620204448 620204448 Lock Nut

11 620204743 620204743 Sleeve Compressor Mounting

12 620204435 620204435 Lock Nut (Leg)

13 620204763 620204763 Base Assembly

14 620204595 620204595 Water Condenser

15 620204326 620204326 Water Trough Assembly

16 620204443 620204443 Water Trough Screws

620204429 620204429 Rubber Washer

620204919 620204919 Water Trough Support Bracket

17 620204764 620204764 Fan Bracket

18 620204644 620204645 Fan Motor

19 620204579 620204579 Fan Blade

20 620204367 620204367 Fan Shroud

21 620204599 620204599 Air Condenser

22 620204420 620204420 Hose Clamp

23 620204528 620204528 Barbed Tee

24 620204813 620204813 Drain Adapter

25 620204288 620204288 Rear Panel

26 620204465 620204465 Water Regulator

27 620204529 620204529 Drop Adapter Fitting

28 620204539 620204539 Water Inlet Fitting

29 620204450 620204450 Flanged Lock Nut

30 620204471 620204471 High Temperature Safety Control

31 620204397 620204397 Side Panel S/S

32 620204397 620204397 Side Panel S/S

33 620204560 620204560 Water Pump Connector

34 620204294 620204294 Water Distribution Tube

Compressor Components

CCU0300 1 1 CCU0300 5 1 Description

620204699 620204700 Compressor

620204663 620204664 Overload

620204656 620204657 Start Capacitor

620204660 620204680 Compressor Relay

N/A 620204667 Run Capacitor

Page 5

CCU0300 1 Service Parts Harvest Assist Assembly

Item CCU0300 1 1 CCU0300 5 1 Description

1 620204366 620204366 Bracket, Probe Motor

2 620204630 620204631 Gear Motor

3 620204570 620204570 Clutch Assembly, 60 Degree

4 620204483 620204483 Snap Bushing

5 620204481 620204481 Snap Bushing

6 620204439 620204439 #6-32 x 1/2 Screw

7 620204484 620204484 Connecting Rod

8 620204424 620204424 Probe, Single Length

9 620204427 620204427 Flat Washer

10 620204451 620204451 Shoulder Screw

11 620204516 620204516 Spacer, Cam Switch

12 620204556 620204556 Cam Switch

13 620204407 620204407 Insulator

14 620204434 620204434 Pan Head Screw

15 620204452 620204452 Speed Nut Plate

620204314 620204315 Harvest Assist Assembly

Page 6

CCU0300 1 Service Parts Control Box

Item CCU0300 1 1 CCU0300 5 1 Description

1 620204479 620204479 Thermostat-Bin Control

2 620204557 620204557 Ice/Off/Wash Switch

3 620204553 620204553 Switch-Purge

4 620204477 620204477 High Pressure Control

5 620204476 620204476 Low Pressure Control (Timer Initiate)

6 N/A 620204667 Run Capacitor

7 620204656 620204657 Start Capacitor

8 620204660 620204680 Relay

9 620204555 620204555 Timing Module

10 620204471 620204471 High Temperature Safety Control

11 620204548 620204548 Relay

12 620204550 620204551 Socket-Relay

13 620204549 620204549 Hold Down Spring - Relay

Page 7

CCU0300 1 Service Parts Evaporator

Item CCU0300 1 1 CCU0300 5 1 Description

1 620204766 620204766 Evaporator Assembly-Half Cube (Shown)

1 620204765 620204765 Evaporator Assembly-Full Cube

2 620204294 620204294 Water Distribution Tube

3 620204453 620204453 Thumbscrew

4 620204429 620204429 Rubber Washer

5 620204709 620204709 Spillway

6 620204489 620204489 Left Side Evaporator Mounting Panel

7 620204490 620204490 Right Side Evaporator Mounting Panel

8 620204486 620204486 Water Return

Page 8
