Introduction

User's Notice

described in it may be reproduced, transmitted or translated into any language in any form or by any means

without written permission of the manufacturer.

This manual contains all the information required for the use of this product to meet the userʼs requirements. It

may change or be corrected at any time without notice.

The manufacturer provides this manual “as is” without warranty of any kind, and will not be liable for any indirect,

special, incidental or consequential damages (including damages for loss of profit, loss of business, loss of use

of data, interruption of business and the like).

Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights

of their respective companies. They are used only for identification or explanation and to the ownerʼs benefit,

without intent to infringe.

Caution Safety Protections

Operate the device according to the correct installation steps and with great care to guarantee safety and comfort

using experience. Please refer to the following safety instruction guide to avoid the danger of electric shock or

fire. Please observe the previous safety instruction guide to use and maintain the product and the hard disk to

make sure of a safe operating environment.

·Please follow the instruction manual for the operation guide.

·The appropriate operating temperature range is -10°C...+60°C.

·The operation humidity for this product is 5%...80%RH.

·To avoid high temperature, please DO NOT overload the maximum power of the external power supply while

the system is consuming high voltage. Be aware of the maximum temperature allowance of the power

supply.

·Always unplug the power cable and other hardware cables from the system before cleaning.

·Use only a dry cloth to clean the product.

·Make sure that there is no heat source nearby when the product is working.

·Make sure that the thermal louver of the product is not blocked.

·Make sure to set up or use the product on a stable surface.

·Make sure not to drop the product or strike it in any way.

·Make sure not to move the product when the power is on.

·Disconnect the power cord from the i4Gen unit prior to any installation. Be sure both the system and all

external devices are turned off. A sudden surge of power could ruin sensitive components. Make sure

i4Gen is properly grounded.

·Do not open the system's back cover.

TECHNICALDOCUMENTATION

A56V0_90020-E-EN

Package Contents

-1x i4Gen

-1xDC-DC Adapter 9 to 36VDC input for 12VDC output

-1x Power cord

-2x WIFI antenna

-1x Cabinet fixed parts

-1x Quick-start

Environmental Protection Announcement

Do not dispose of this electronic device into the trash while discarding. To minimize pollution and ensure utmost

protection for the global environment, please recycle.

TECHNICALDOCUMENTATION

A56V0_90020-E-EN

General Description

·10-point capacitive multi-touch

·Edge-to-edge narrow bezel design and fan-less cooling system

·Designed for easy wall mount, panel mount, and VESA mount installation

·A truly flat, easy-to-clean front surface with an edge-to-edge design

·USB 3.0 ports support lock device

·9 to 36VDC support using the DC-DC converter provided with the unit (i4Gen touchscreen DC voltage input

only accepts 12VDC)

·On-board Intel® Braswell series SoC processor, with low power consumption never denies the high

performance

·On-board 4GB DDR3L 1333Mhz SO-DIMM

·On-board 1 x full-size Mini-PCIE slot

·On-board 1 x M.2 slot (M-key), type-2242 SATA interface for SSD device

·Support 2 xRJ-45 Gigabit LAN port and 1*external RJ-45 COM port

·COM port male DE-9 connector (D-Sub DB-9)

·1x2.4G WIFI module with support for 802.11 b/g/n WIFI communication

Additional Functions

·WiFi: The Mini PCI-E on-board socket in the board is integrated with a WIFI card (802.11 b/g/n) that can act

as a mini wireless modem when external antennas are connected.

·Giga LAN: The system is integrated with Gigabit LAN network controller with ACPI (Advanced Configuration

and Power Interface) management realizing efficient power management for the operating system.

·USB 3.0: Experience fastest data transfers at 5Gb/s with USB 3.0 the new latest connectivity standard. Built

connect easily with next-generation components and peripherals, USB 3.0 transfers data 10 times faster and

backward compatible with previous USB2.0 components.

·dB value: The system design features the low noise operation normally required in a living-room. The average

is below 26 dB under normal operation.

TECHNICALDOCUMENTATION

A56V0_90020-E-EN

Specifications

Display

Front bezel IP65, NEMA 4 rugged protection, Full planar metal

border

Display type 10.1'' with LED back-light

Brightness (cd/m²) 400 nits

Display color 16.2M

Resolution 1280x800 at 60Hz

Viewing angle (H/V) 170°/170°

Pixel pitch 0,1695x0,1695mm

Aspect ratio 16:10

Contrast ratio 800:1

Response time 30ms

Touch Screen

Type Projected capacitive type

Active range 257,1x159,66mm +0,2mm (10,1x6,29in)

Transparency > 87%

Surface hardness > 6H (JIS-5400)

Glass haze value > 3%

Main CPU Board

CPU Intel® Braswell series SoC CPU

System memory On-board 4GB DDR3L 1333MHz SO-DIMM

BIOS AMI 64Mb Flash ROM

I/O System

TECHNICALDOCUMENTATION

A56V0_90020-E-EN

Icon Name Quantity Description

Power button 1 Press to turn On/Off the system.

DC-in power

connector 1 12VDC power supply input (9 to 36VDC support using the DC-DC

converter provided with the unit) .

HDMI port 1 To connect a display device that supports HDMI specification (not

used).

USB 3.0 port 4 To connect devices compatible with the USB specification. USB 3.0

port supports up to 5Gbps data transfer rate.

RJ-45 LAN port 2 This connector is standard RJ-45 LAN jack for network connection.

Both ports are set as a bridge, acting like a switch. WARNING:

Pluging both ports on a same network will result in a network loop,

causing a network failure.

RJ-45 COM port 1 This connector is standard RJ-45 jack used as a COM serial port.

If needed, use a link which convert RJ-45 jack to a male DE-9

connector (D-Sub DB-9).

COM port 1 This connector is a male DE-9 connector (D-Sub DB-9).

Environment

Operating temperature range -10°C...+60°C

Humidity 5%...80% RH (relative humidity)

TECHNICALDOCUMENTATION

A56V0_90020-E-EN

Presentation

The i4Gen.10” is a user interface made by CRE TECHNOLOGY to offer users a complete monitoring of new

CRE TECHNOLOGY controllers.

The unit hardware is a multi-touch screen color display developped for harsh environment and industrial areas,

providing access to all controllersʼ data for control and measurement.

With our advanced touch screen panel, it is possible to manage remote control and monitoring, through an

internet access (Wi – LAN connection), with ZOHO assist© platform, and to use e-mail services, for alarms/faults

management.

Control and Management

Direct display

The i4Gen is able to display information from 1 to 32 controllers using the Ethernet connection and shows a

basic overview of the power plant by using controller CANbus data when applicable.

Easy Connect

This function permit to quickly switch the connection between controllers. Automatically detects CRE

TECHNOLOGY controllers on an Ethernet network.It allows to automatically configure CRE TECHNOLOGY

controllers IP address to be able to access them with the current network configuration.

Multi user display

Several i4Gen can be securely connected by an Ethernet hub to a single controller (or a group of controllers). An

i4Gen display has two Ethernet communication ports. Easy to use for redundancy application multi-level access

or long-distance monitoring panel. One i4Gen display can also be connected to different and several COMPACT

platforms.

Internet connection

With WIFI connection, or LAN cable connexion, the i4Gen can be easily connected on internet, to manage

remote monitoring or remote control, and emails management.

Events displayed/recorded

An innovative feature turns major alarms and faults into 3D graphical object display, to warn the operator about

an important event and facilitate immediate diagnosis (ex: coolant tank lights up in red in case of coolant temp

fault or in orange in case of coolant temp alarm).

An event alarm/fault recorder is also available on a dedicated display page, indicating timestamps, status,

acknowledgment, and corresponding variable; the event page can be filtered for diagnosis and investigation of

selected variables.

Compatibility

i4Gen is compatible with these controller versions:

- GENSYS COMPACT PRIME: v2.10 or later

- GENSYS COMPACT MAINS: v2.10 or later

- AMF COMPACT: v2.10 or later

- SYNCHRO COMPACT: v2.10 or later

- MASTER COMPACT: v2.10 or later

- MASTER COMPACT 1B: v2.10 or later

- BTB COMPACT: v2.10 or later

TECHNICALDOCUMENTATION

A56V0_90020-E-EN

Installation

Mechanical Mounting

Install i4Gen position at eye level and at a brightness-less location.

Frame cut-out (hxl): 160x242mm (6.3x9.5in).

Chassis Fixed Parts

1. Insert the corresponding edges of the fixed part into the slots until they match.

Make sure that the fixed part is installed as shown in the picture, with protruding tips

upwards.

2. The models that support this fixing mode have pairs of slots reserved on both

sides of the module. The user can choose the height or position of the installation

spot.

3. Tighten the screw so that the fixed part can be fitted into the slots tightly. Install

other fixed parts to the system in the same way.

WIFI Antenna Installation (Optional)

Screw the two antennas on the antenna heads connectors:

Andere Handbücher für i4GEN

Inhaltsverzeichnis

Andere CRE Technology Bedienfeld Handbücher

CRE Technology

CRE Technology GENSYS 2.0 Leitfaden

Beliebte Bedienfeld Handbücher anderer Marken

RDZ

RDZ PC-HRX Bedienungsanleitung

STG-BEIKIRCH

STG-BEIKIRCH MZ3 Technisches Handbuch

Efka

Efka Variocontrol V810 Bedienungsanleitung

Cebora

Cebora 208-10 Bedienungsanleitung

AMX

AMX AutoPatch CP-15 Bedienungsanleitung

Satel

Satel CA-6 KLED-S Bedienungsanleitung

Evolution

Evolution IQ plus 800 Bedienungsanleitung

Fagor

Fagor 8040 TCO CNC Bedienungsanleitung

Trane

Trane ComfortLink II XL950 Control Bedienungsanleitung

AKO

AKO PROCool AKO-17635-2 Bedienungsanleitung

ABB

ABB 6136/30M-101 Bedienungsanleitung

Telikou

Telikou BK-603 Belt Pack Bedienungsanleitung

Mapei

Mapei Mapeheat Thermo Touch Bedienungsanleitung

Bosch

Bosch D9412GV4 Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries SC-SL4-AE2/1 Bedienungsanleitung

Sminn

Sminn BOX L VF1L EI Bedienungsanleitung

Balboa

Balboa TP600 Bedienungsanleitung

Nice

Nice HSCU1 Technische Daten

CRE Technology i4GEN Leitfaden

Beliebte Bedienfeld Handbücher anderer Marken
