Creative ZEN MICROPHOTO Bedienungsanleitung

English............................................ 1

Français........................................ 13

Deutsch ........................................ 27

Italiano.......................................... 39

Español......................................... 51

Nederlands................................... 63

Português..................................... 75

Svenska ........................................ 87

Norsk............................................ 99

Dansk ......................................... 111

Suomi ......................................... 123

Česky.......................................... 135

Polski.......................................... 147

Рyccкий ...................................... 159

CLE_Vegas QS.book Page i Thursday, July 21, 2005 11:04 AM

CLE_Vegas QS.book Page ii Thursday, July 21, 2005 11:04 AM

Getting Started 1 English

Getting Started

Congratulations on your purchase of Zen™ MicroPhoto! Follow the next few

steps to set up the software and your player to enjoy a new level in portable

digital entertainment.

51 32 4

78911 10

1. Power switch/

Screensaver LED

2. Lock

3. Headphone jack

4. USB 2.0 port

5. Microphone

6. Next/Fast-Forward

button

7. Options button

8. Play/Pause button

9. Vertical Touch Pad

10. Menu/Back button

11. Previous/Rewind button

CLE_Vegas QS.book Page 1 Thursday, July 21, 2005 11:04 AM

2 Using the Vertical Touch Pad

Using the Vertical Touch Pad

■Move your thumb up and down the Vertical Touch Pad to scroll

through menu items.

To rapidly scroll through menu items, hold down the top or bottom

portion of the Vertical Touch Pad with your thumb.

To select a menu item, firmly tap the Vertical Touch Pad.

■To adjust the sensitivity of the Vertical Touch Pad, press the Menu/

Back button, and select System Player Settings TouchPad

Sensitivity. Sensitivity can be set to low, medium or high.

■To turn the Vertical Touch Pad's clicking sound on and off, press

the Menu/Back button, and select System Player Settings

TouchPad Clicker.

■Slide the Power switch towards the Lock icon to disable

Zen MicroPhoto's Vertical Touch Pad and buttons. This is useful

when you do not want to activate controls accidentally when your

player is in your pocket or bag.

CLE_Vegas QS.book Page 2 Thursday, July 21, 2005 11:04 AM

Insert the battery 3

Step 1: Insert the battery

Step 2: Set up the software

1Turn on your computer.

You must log in as an administrator in Windows®before you can set up the

software. For more information, refer to your operating system’s online

Help.

2Insert the Installation and Applications CD into your CD-ROM/DVD-ROM

drive.

Your CD should start automatically. If it does not, follow the steps below:

i. Double-click the My Computer icon.

ii. Right-click the CD-ROM/DVD-ROM drive icon, and then click

Autoplay.

3Follow the instructions on the screen.

4When prompted, restart your computer.

WARNING DO NOT connect your player to your computer before setting up the

software.

1 2 3

CLE_Vegas QS.book Page 3 Thursday, July 21, 2005 11:04 AM

4 Charge the battery

Step 3: Charge the battery

1Connect your player to your computer’s USB port with the supplied USB

cable.

2When the battery is charging, the battery charging icon flashes on the

Organic Light Emitting Diode (OLED) display.

3Disconnect your player from your computer when the battery is fully

charged and you see on your player’s OLED display. Fully charging your

player takes approximately five hours. If your fully charged player remains

connected to your computer for a prolonged period, the OLED display

blanks out automatically to save battery power.

NOTE ■For continuous battery charging using the USB port, make sure

your computer is not in power conservation mode. For more

information on power conservation modes, refer to your

operating system's Help.

■Connect to a computer USB port only; avoid connecting to a USB

hub.

■For express battery charging without using your computer,

purchase the Zen MicroPhoto Power Adapter or Universal Travel

Adapter. For more information on this and other Zen MicroPhoto

accessories, visit www.creative.com.

CLE_Vegas QS.book Page 4 Thursday, July 21, 2005 11:04 AM

Turn on player 5

Step 4: Turn on player

1Slide the Power switch towards the power icon and hold it there until

the OLED display lights up.

2When you turn on Zen MicroPhoto for the first time, the default language is

in English. To change the language:

i. Press the Menu/Back button. The main menu appears.

ii. Use the Vertical Touch Pad to select System Language, and

then select the language that you want. For tips on using the

Vertical Touch Pad, see “Using the Vertical Touch Pad” on page 2,

or refer to the User’s Guide on the Installation and Applications

CD.

3Congratulations! You can now use your player. Zen MicroPhoto is preloaded

with some music and photos to get you started immediately.

To start listening to music, connect the earphones and press the Play/

Pause button.

To start viewing photos in a slideshow, press the Menu/Back button,

select Photos and press the Play/Pause button.

To listen to your own music or view your own photos, proceed to the next

step.

TIP During playback, move your thumb up and down the Vertical Touch

Pad to adjust the volume.

CLE_Vegas QS.book Page 5 Thursday, July 21, 2005 11:04 AM

6 Rip music and copy files

Step 5: Rip music and copy files

Rip music from your CD collection to your player, or copy audio files (such

as music you have purchased online) from your computer. Before ripping or

copying files, make sure your player is connected to your computer as

shown on page 4.

To rip music from your CD collection

1Double-click the My Computer icon on your desktop.

2Click the Zen MicroPhoto Media Explorer icon .

3Click the Rip Audio CDs button .

4Follow the instructions on the screen.

If you are connected to the Internet, album information is automatically

retrieved.

To copy audio files or photos from your computer

1Double-click the My Computer icon on your desktop.

2Click the Zen MicroPhoto Media Explorer icon .

3Click the Import Media button .

4Follow the instructions on the screen.

CLE_Vegas QS.book Page 6 Thursday, July 21, 2005 11:04 AM

Disconnect player 7

To copy data files using Creative Media Explorer

1Double-click the My Computer icon on your desktop.

2Click the Zen MicroPhoto Media Explorer icon .

3Click the Transfer Documents button .

Locate your data files and copy them to your player or computer using the

drag-and-drop method.

Step 6: Disconnect player

When you have finished transferring files, disconnect Zen MicroPhoto.

DO NOT disconnect your player if you see the left picture below on the OLED

display. Track or data file transfer is in progress and disconnecting your

player may damage the content being transferred.

Wait until you see the the right picture below on the OLED display before

disconnecting your player.

Docked Docked

CLE_Vegas QS.book Page 7 Thursday, July 21, 2005 11:04 AM

8 Managing Music and Data

Managing Music and Data

Creative Media Explorer, Creative MediaSource™ and Creative Media

Toolbox are included with your player. Install and try out the applications to

decide which one is more suitable for your needs.

Creative Media Explorer

Creative Media Explorer offers you the ease of managing music tracks and

data files in Zen MicroPhoto, in a Windows Explorer environment. Use

Creative Media Explorer, if you:

■are new to MP3 and WMA ripping and want to build up a library

■prefer to manage Zen MicroPhoto as a removable disk drive

To start Creative Media Explorer, click the Zen MicroPhoto Media Explorer

icon under My Computer.

Creative MediaSource

Creative MediaSource Player/Organizer is your digital music center for

playing, creating, organizing, synchronizing and transferring digital music.

Use Creative MediaSource Player/Organizer, if you:

■frequently need to playback or organize music in your computer

■require other features such as recording and audio conversion

CLE_Vegas QS.book Page 8 Thursday, July 21, 2005 11:04 AM
