Installation Guide - DOC. 5979A 10-Position RJ45 Panel Mount Interface: TPSBLOCK-10 •i

Crestron TPSBLOCK-10 10-Position RJ45 Panel Mount Interface

10-Position RJ45 Panel Mount

Interface: TPSBLOCK-10

Introduction

The TPSBLOCK-10 is a 10-position RJ45 panel mount interface for

Crestron Isys™ tilt touchpanels. The TPSBLOCK-10 is an electrically

and magnetically shielded 10-position, female RJ45 connector mounted

on a printed circuit board (PCB) and a 10-foot cable with a 10-position

RJ45 plug (male).

This interface is designed to provide a lengthy 10-foot connection

between the NET/VIDEO or RGB output from the TPS-IMC tucked

away in a cabinet or under a table to the Isys touchpanel, which is

available to the user. When installed into a panel or desktop pop-up/tilt-

up device, the TPSBLOCK-10 provides local access by extending the

touchpanel NET/VIDEO port and/or RGB port(s). The RGB port may be

interfaced only when the touchpanel is equipped with an optional

TPS-XVGA-BV RGB Computer Interface Card with Balanced Video. To

interface the touchpanel NET/VIDEO and RGB ports, two

TPSBLOCK-10s must be utilized.

Functional Summary

• Handy 10-pin male connector and 10-foot cable interface

solution for Isys™ TPS-Series advanced touchpanels

• Easy mounting into a standard Extron/Altinex/Inline type

interface plate

• Plug-in socket for the “ship-with” Net/Video or RGB cable

from a TPS-Series touchpanel

The touchpanel NET/VIDEO or RGB cable (supplied with the

touchpanel) is connected to the female connector of the TPSBLOCK-10

and the TPSBLOCK-10 plug is connected to the Cresnet control system

(via Crestron TPS interface module or optional TPS wall-mounted

Installation Guide - DOC. 5979A 10-Position RJ45 Panel Mount Interface: TPSBLOCK-10 •1

10-Position RJ45 Panel Mount Interface Crestron TPSBLOCK-10

interface module). Refer to the table below for touchpanel and interface

modules that are used with the TPSBLOCK-10.

TPSBLOCK-10 Interface Applications

INTERFACE MODULE MODULE TPSBLOCK-10

MODULE AVAILABILITY D

INTERFACE

TPS-4500IMC Supplied

w/touchpanel 5890 NET/VIDEO only

TPS-4500IMW Sold Separately 5913 NET/VIDEO only

TPS-IMC Supplied

w/touch

anel 5856 NET/VIDEO only

TPS-IMC-BV Sold Separately * 5921 NET/VIDEO or

RGB

TPS-IMW Sold Separately 5857 NET/VIDEO only

*The TPS-IMC-BV is supplied with the optional TPS-XVGA-BV card that can only be installed

into specific touchpanels. Refer to the TPS-XVGA-BV Operations & Installation Guide for

further information.

ISYSTM

TOUCHPANEL

TPS-4500

TPS-5000 &

TPS-6000

NOTE: For more information about the Crestron TPS interface or wall-

mounted interface module(s), refer to the latest revision of the

appropriate operations guide. The latest version can be obtained from the

Downloads | Product Manuals section of the Crestron website

(www.crestron.com).

Refer to the table below for the pinouts of the TPSBLOCK-10 connector

during NET/VIDEO and RGB applications. Pin 1 of the female

connector is wired to pin 1 of the plug.

Connector/Plug Pinouts

RGB

DESIGNATION DESCRIPTION DESCRIPTION

1 * +24V Power (Network) Vertical sync -

2 GND Ground (Network) Horizontal sync -

3 C+ Chrominance (Positive) RED video -

4 C- Chrominance (Negative) RED video +

5 YData (Network) GREEN video -

6 ZData (Network) GREEN video +

7 Y+ Luminance (Positive)/Composite BLUE video -

8 Y- Luminance (Negative)/Composite BLUE video +

9 GND Ground (Network) Horizontal sync +

10 +24V Power (Network) Vertical sync +

PIN NET/VIDEO

While facing the female connector of the TPSBLOCK-10, pin 1 is located at the upper-left of

the connector.

2 •10-Position RJ45 Panel Mount Interface: TPSBLOCK-10 Installation Guide - DOC. 5979A

Crestron TPSBLOCK-10 10-Position RJ45 Panel Mount Interface

Peel-and-stick NET/VIDEO and RGB labels are supplied with the

TPSBLOCK-10. If desired, a label may be affixed to the surface of the

panel or desktop pop-up/tilt-up device. A matching AUDIO label is also

supplied for use with non-Crestron 8-position RJ45 interface devices.

Industry Compliance

As of the date of manufacture, the TPSBLOCK-10 have been tested and

found to comply with specifications for CE marking and standards per

EMC and Radiocommunications Compliance Labelling (N11785).

Installation

The items required for installation of the TPSBLOCK-10 are appropriate

cutting tools to create the rectangular cut-out area in the panel or desktop

pop-up/tilt-up device, a 0.136-inch (#29 or approximately 9/64-inch) drill

bit, electric drill and two #4-40 screws of adequate length with an

appropriate screwdriver. Refer to the following diagrams and perform the

procedure that begins on the next page.

Overhead View

1.408 in

(3.576 cm)

1.210 in

(3.073 cm)

MOUNTING

BRACKETS

10 ft

CABLE

MALE

RJ45 PLUG

0.162 in

(0.412 cm)

Front View

0.687 in

(1.745 cm)

FEMALE RJ45

CONNECTOR & PCB

Pin 1

(Reference Only)

Installation Guide - DOC. 5979A 10-Position RJ45 Panel Mount Interface: TPSBLOCK-10 •3

10-Position RJ45 Panel Mount Interface Crestron TPSBLOCK-10

NOTE: The recommended clearance on each side of the rectangular

cutout area is approximately 0.268 in (0.681 cm). The clearance at the

bottom of the cutout area should be approximately 0.180 in (0.457 cm).

The clearance above the cutout area is zero.

NOTE: If affixing a NET/VIDEO or RGB label near the TPSBLOCK-

10 (above or below is recommended), a 0.200 in (0.508 cm) by 0.700 in

(1.778 cm) area is required.

NOTE: Extron has made available Architectural Adapter Plates (AAPs)

for mounting the TPSBLOCK-10 for Cresnet touchpanel connection.

Refer to “Custom Adapter Plates” on page 5 for details. If using AAPs,

skip steps 2 and 3 in the subsequent procedure.

1. On the panel or desktop pop-up/tilt-up device, determine an

adequate location for the TPSBLOCK-10.

2. Refer to the diagram below. Using the proper tools, cut-out

and remove the rectangular area from the panel or desktop

pop-up/tilt-up device.

TPSBLOCK-10 Installation (1 of 3) - Cutout Diagram

0.675 in

(1.715 cm)

0.590 in

(1.500 cm)

3. Refer to the diagram below. Using an electric drill and

0.136-inch (#29 or approximately 9/64-inch) drill bit, drill

two TPSBLOCK-10 mounting holes.

TPSBLOCK-10 Installation (2 of 3) - Mounting Hole Diagram

0.143 in

(0.362 cm)

0.276 in

(0.701 cm) 0.136 in

DIAMETER

0.313 in

(0.795 cm)

4. At the inner surface of the panel or desktop pop-up/tilt-up

device, position the female connector of the TPSBLOCK-10

4 •10-Position RJ45 Panel Mount Interface: TPSBLOCK-10 Installation Guide - DOC. 5979A

Crestron TPSBLOCK-10 10-Position RJ45 Panel Mount Interface

into the cutout area and align the drilled mounting holes

with the TPSBLOCK-10 mounting brackets.

5. Refer to the diagram below. At the outer surface of the panel

or desktop pop-up/tilt-up device, loosely install two #4-40

screws of adequate length (not supplied) through the surface

into the TPSBLOCK-10 mounting brackets. Tighten screws

to finger-tight then, using an appropriate screwdriver,

tighten to a torque that is adequate for the surface material.

TPSBLOCK-10 Installation (3 of 3) - Secure TPSBLOCK-10

6. Connect the male RJ45 plug of the TPSBLOCK-10 cable to

the NET/VIDEO or RGB port of the TPS interface module

or TPS wall-mounted interface module.

7. If desired, peel the appropriate NET/VIDEO or RGB label

(supplied) from the paper backing and affix to the surface of

the panel or desktop pop-up/tilt-up device near (above or

below is recommended) the TPSBLOCK-10.

8. At the outer surface of the panel or desktop pop-up/tilt-up

device, connect the touchpanel NET/VIDEO or RGB cable

(supplied with touchpanel) to the female RJ45 connector of

the TPSBLOCK-10.

Custom Adapter Plates

Extron Architectural Adapter Plates (AAPs), shown on the next page, are

available for mounting Crestron TPSBLOCK-10 for touchpanel

connection. These two-space AAPs allow the mounting of one or two

TPSBLOCK-10 interfaces. The AAPs must be ordered separately from

Extron; consult the Extron website (www.extron.com) for specifications

and ordering details.

Installation Guide - DOC. 5979A 10-Position RJ45 Panel Mount Interface: TPSBLOCK-10 •5

10-Position RJ45 Panel Mount Interface Crestron TPSBLOCK-10

Extron Architectural Adapter Plates (AAPs)

Further Inquiries

If after reviewing this Installation Guide, you cannot locate specific

information or have questions, please take advantage of Crestron's award

winning customer service team by calling:

• In the US and Canada, call Crestron’s corporate headquarters at

1-888-CRESTRON [1-888-273-7876] or 1-201-767-3400.

• In Europe, call Crestron International at +32-15-50-99-50.

• In Asia, call Crestron Asia at +852-2341-2016.

• In Latin America, call Crestron Latin America at

+5255-5093-2160.

• In Australia and New Zealand, call Creston Pacific at

+613-9480-2999.

6 •10-Position RJ45 Panel Mount Interface: TPSBLOCK-10 Installation Guide - DOC. 5979A

Inhaltsverzeichnis

Andere Crestron Kabel und Steckverbinder Handbücher

Crestron

Crestron FlipTop FT2 Series Bedienungsanleitung

Crestron

Crestron C2N-TXM-C50 Bedienungsanleitung

Crestron

Crestron FlipTop CBLR2 Series Maßzeichnung

Crestron

Crestron SP-CBL Bedienungsanleitung

Crestron

Crestron SmartPresenter SPC-124 Bedienungsanleitung

Crestron

Crestron Four-Way Amplified Splitter SRD-SPL-4 Bedienungsanleitung

Crestron

Crestron SR9600 Konfigurationshandbuch

Crestron

Crestron ZUMLINK-CONV-CN Bedienungsanleitung

Crestron

Crestron QM-FTCMK Bedienungsanleitung

Crestron

Crestron SmartPresenter SPC-121 Bedienungsanleitung

Crestron

Crestron SR5500 Konfigurationshandbuch

Crestron

Crestron SmartPresenter SPC-550 Bedienungsanleitung

Crestron

Crestron FT2A-CP-USBA Bedienungsanleitung

Crestron

Crestron DM-8G-CONN-100 Bedienungsanleitung

Crestron

Crestron Connect It TT-100 Series Bedienungsanleitung

Crestron

Crestron CBL-USB-RS232KM-6 Bedienungsanleitung

Crestron

Crestron SmarTouch ST-112 Bedienungsanleitung

Crestron

Crestron TPS-CBL Bedienungsanleitung

Crestron

Crestron FlipTop CBLR2 Series Bedienungsanleitung

Crestron

Crestron CBL-MULTI-HD-6 Bedienungsanleitung

Crestron

Crestron TPS-CBL-S Bedienungsanleitung

Crestron

Crestron TPMC-CBL-T Bedienungsanleitung

Crestron

Crestron UC-B-ACCY Bedienungsanleitung

Crestron

Crestron FT-PWR Anleitung zur Verwendung

Beliebte Kabel und Steckverbinder Handbücher anderer Marken

Philips

Philips SWA6310 Bedienungsanleitung

StarTech.com

StarTech.com CRJ4550PK Bedienungsanleitung

Nohau

Nohau EMUL-IP2K-PC Bedienungsanleitung

Foxun

Foxun SX-SP144E-HD4K2K Bedienungsanleitung

Philips

Philips SWA3305W Bedienungsanleitung

opticis

opticis Stretch DVIM1-1P0x Bedienungsanleitung

Volkswagen

Volkswagen VAS 6558A Bedienungsanleitung

NEXIBO

NEXIBO N-13 Bedienungsanleitung

CYP

CYP PU-1H3HBTL Bedienungsanleitung

Allen-Bradley

Allen-Bradley 1784-u2dhp Bedienungsanleitung

Global Caché

Global Caché Flex Link Blaster Bedienungsanleitung

Hauppauge

Hauppauge USB-Live2 Bedienungsanleitung

Fenix

Fenix MPSV 15 Bedienungsanleitung

BEGA

BEGA 71 085 Bedienungsanleitung

Tesla

Tesla HPWC Bedienungsanleitung

GAMERON

GAMERON LUXURY TV CABLE Bedienungsanleitung

molex

molex Milli-Grid Dual row 87568 Series Bedienungsanleitung

Burndy

Burndy Continental Industries thermOweld CRE-7 Bedienungsanleitung
