CTP301
OPERATION MANUAL
3 INCH CLEAR WATER PUMP
Pg. 2
Thank you for purchasing a Cromtech Pump.
This manual provides understanding of the operaon
and maintenance of your pump. Please read this
manual carefully before operang.
For any quesons regarding operaon or maintenance,
please consult your local service agent. Find your local
service agent at www.crommelins.com.au.
IMPORTANT ICONS
Important informaon is disnguished by the nocaons
below. The Safety Alarm Symbol ( !) alerts you to
potenal hazards. Please obey all safety informaon in the
symbol to avoid any possible injury or even death.
!DANGER: - Indicates a hazardous situaon which, if
not strictly complied with, will result in substanal property
damage, serious injury or DEATH.
!WARNING: Indicates a hazardous situaon which, if
not strictly complied with, may result in property damage,
!CAUTION: Indicates a hazardous situaon which, if
not strictly complied with, could result in property damage
or injury.
!NOTE: Indicates important informaon to simplify
operaon and understanding.
!WARNING: PLEASE READ AND UNDERSTAND THIS
MANUAL BEFORE OPERATING THE PUMP.
!NOTE: We connually seek advancements in product
design and quality. Therefore, there may be minor
discrepancies in actual machine and the printed manual.
INDEX:
Warranty ..................................................................... 4
Safety Warnings .......................................................... 5
CTP301 Features ......................................................... 7
Pump Specicaons .................................................... 8
Features ..................................................................... 8
Connecng hoses ........................................................ 9
Operang Checklist ..................................................... 10
Operang area ........................................................... 10
Operang condion ................................................... 10
Check engine oil .......................................................... 11
Check fuel levels .......................................................... 12
Priming the pump ........................................................ 13
Starng the pump ....................................................... 14
Stopping the pump .................................................... 15
Maintenance ............................................................... 16
Engine Maintenance ................................................. 16
Engine oil ................................................................ 18
Adding oil ............................................................... 18
Changing oil ........................................................... 18
Air lter ................................................................. 19
Oil bath lter ......................................................... 19
Spark plug .............................................................. 20
Spark arrestor ........................................................ 21
Adjustments .......................................................... 21
Troubleshoong ......................................................... 22
Storage and transport ................................................ 23
Storage ..................................................................... 23
Long term storage .................................................... 23
Transport .................................................................. 23
Pg. 3
WARRANTY
CROMTECH™and CROMMELINS™ are a registered trademark of The
Crommelin Group. Crommelins warrants their goods against defects in
materials and workmanship under normal use and service.
The Crommelin Group warranty does not cover fair wear commensurate
with the age of the product, any damage caused by accident, abuse, misuse,
neglect or failure to observe proper operang instrucons or proper
machinery maintenance as described in the instrucon manual.
It is the owner’s responsibility to regularly maintain a product in accordance
with the owner’s manual and only use the equipment for its designed
purpose.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entled to a replacement or refund for
a major failure and for compensaon for any other reasonably foreseeable
loss or damage. You are also entled to have goods repaired or replaced if
the goods fail to be of acceptable quality and the failure does not amount to
a major failure.
CONSUMER ADVICE
Any claim under these warranes must be made in the warranty period
from the date of purchase of the product.
There are over 185 naonal authorised service/repair agents available, visit
www.crommelins.com.au for their details and locaons.
To make a claim under the warranty, you must return the product (with
proof of purchase) to the closest warranty agent or to the place of purchase.
Where a failure does not amount to a major failure, Crommelins Machinery
is entled to choose between providing you with a repair, replacement or
refund. To obtain compensaon, you would need to provide documentary
evidence of the loss or damage suered, and documentary evidence that
such loss or damage was a reasonably foreseeable consequence of a failure
by The Crommelins Group to comply with a consumer guarantee under the
Australian Consumer Law.
Crommelins Operaons Pty Ltd trading as The Crommelin Group,
Crommelins Australia and Crommelins Machinery
THE CROMMELIN GROUP:
Ph: (08) 9350 5588 Fax: (08) 9451 6381
recepon@crommelins.com.au
www.crommelins.com.au
PO Box 352, BENTLEY WA 6982
ABN 11 008 889 656
Pg. 4
SAFETY WARNINGS
! WARNING: DO NOT Operate this pump unl you have
read ALL safety, operaon, and maintenance instrucons
listed in this manual.
• Failure to follow the instrucons may result in property
damage, INJURY or DEATH.
! WARNING: Modicaons to any part of the pump is
not allowed and may void your warranty.
!DANGER: FIRE OR EXPLOSION - Gasoline is highly
ammable and extremely explosive.
• Fire or explosion can cause severe burns or death.
• Keep ammable items away while handling gasoline.
• Fill fuel tank outdoors and in a well-venlated area with
the pump stopped.
• Always wipe o spilled fuel and wait unl the fuel has
dried before starng the pump.
• DO NOT operate the engine with known leaks in the fuel
system.
• Use proper fuel storage and handling procedures. DO
NOT store fuel or other ammable materials nearby.
• Empty the fuel tank before storing or transporng the
pump.
• Keep re exnguisher handy and be prepared if a re
starts.
!DANGER: TOXIC FUMES - The exhaust of the pump
engine contains carbon monoxide, an odorless, colorless,
poison gas. Using engine indoors CAN KILL YOU!
• NEVER use pump inside any building or any kind of
enclosure, EVEN IF doors and windows are open.
• Place the pump in a well-venlated area and consider
wind and air currents when posioning the pump
!DANGER: MOVING PARTS - Moving parts can cause
severe injury. Keep hands and feet away.
• DO NOT operate pump with covers, shrouds, or guards
removed.
• DO NOT wear loose-ng clothing, dangling drawstrings
or items that could become caught. Tie up long hair and
remove jewelry.
• NEVER place ngers, hands, or body near the engine
when it is running.
Pg. 5
!DANGER: KICKBACK - Rapid retracon of the starter
cord will pull hand and arm towards the engine faster than
you can let go.
• Unintenonal startup could result in an injury.
!WARNING: CLEAR WATER ONLY - Do not use the pump
for ammable or corrosive liquids, chemical solvents, or
alkali liquids. For example; Gasoline, alcohol, seawater, oil,
wine or milk.
• Keep hands and body far away from discharge outlet of
the pump.
• Never secure the sucon hose with clamps to the pump
during operaon.
• Never put hand or body into an operang pump or
sucon hose.
!WARNING: OPERATION - Operate the pump on rm
dry ground and ensure it is not in mud or water, especially
when used next to ponds, ditches or water source.
• Never place hoses where they can be run over. If the
hose does lay across a road, place a specially made
metal plate over the hose to protect it from damage or
kinks.
• Never block the inlet or outlet ports.
• Never start the pump without the lter aached to the
sucon hose.
• ALWAYS Prime the pump upon inial start. Keep enough
water in the pump. DO NOT run pump without water in
it.
• DO NOT operate pump without reading the instrucons
• Children and pets must keep away from the area of
operaon at all mes.
• DO NOT operate while intoxicated or distracted
Pg. 6
CTP301 FEATURES
① Throttle control ② Choke lever
③ Fuel switch ④ Recoil starter
⑤ Muffler ⑥ Fuel cap
⑦ Outlet ⑧ Frame
⑨ Oil dipstick ⑩ Oil drain
⑪ Inlet ⑫ Outlet drain plug
⑬ Inlet water plug ⑭ Air filter
Pg. 7
PUMP SPECIFICATIONS
Model CTP301
Max. Water Flow (L/min) 900L/min
Max. Total Head (m) 30m
Max. Sucon Depth 7m
Engine Cromtech
Max. Power 4.5kW
Max. Speed (rpm) 3800rpm
Fuel Tank 2.6L
Oil Capacity 0.6L
Outlet 3” (with 2” hose
tail supplied)
Weight (kg) 26kg
Packaging (LxWxH) 530x415x445mm
FEATURES
• 3” to 2” Reducon hose tail supplied
• Mechanical seal (ceramic carbon)
• Petrol powered
• Recoil start
• 1 Year Cromtech warranty
• Emptying ponds, dams and large water tanks
• Agricultural and general purpose
Pg. 8
CONNECTING THE HOSES
! NOTE: DO NOT Operate this pump unl you have read
ALL safety, operaon, and maintenance Instrucons listed
in this manual.
1. Pump connecons - Check you have been provided with
all the following parts (Parts may vary from dierent
models). Connect them as follows;
1.1 Connect the lter to the sucon hose.
! CAUTION: Ensure that the lter is securely
connected so it can prevent debris being passed
into the pump. Keep the sucon hose at least
200mm below depth ensuring it is fully submerged
and there are no obstrucons.
1.2 Connect the sucon hose to the inlet port
! CAUTION: It is recommended that the sucon
hose be made of hardened pipe and it is short in
length (7m maximum based on sucon depth).
1.3 Connect the outlet hose to the outlet port
! CAUTION: The maximum water ow for the
pump is based on rpm, outlet size and hose size.
It is recommended to use a 3” hose for maximum
water ow. Fasten all hoses to the pump so they
cannot loosen under high pressure.
Suction hose
❶ Inlet port
❷ Rubber sealing gasket
❸ Hose tail
❹ Hose nut
❺ Clamp
❻ Sucon hose
Pg. 9
❶ Outlet port
❷ Rubber sealing gasket
❸ Hose tail
❹ Hose nut
❺ Clamp
❻ Outlet pipe
OPERATING CHECKLIST
1. OPERATING AREA - This pump is for outdoor use only.
Always keep the area around the water pump clear.
Place the pump in a well-vented area and carefully note
the wind and air currents. Place the water pump on rm
horizontal surface before running. The pump should not
exceed a height more than its maximum sucon depth
as it may not pump or could overheat.
! DANGER: TOXIC FUMES - The exhaust of the
pump engine contains carbon monoxide, an odorless,
colorless, poison gas. Using pump indoors CAN KILL
YOU! NEVER use inside any building or any kind of
enclosure, EVEN IF doors and windows are open.
2. OPERATING CONDITION - Check for loose or damaged
parts, signs of oil or fuel leaks, and any other condion
that may aect proper operaon. Repair or replace all
damaged or defecve parts immediately.
Remove any excessive dirt or debris, especially around
the muer and recoil starter.
! DANGER: Failing to correct problem(s) before
operaon could result in property damage, serious
injury or DEATH.
Pg. 10
Inhaltsverzeichnis
Andere Cromtech Wasserpumpe Handbücher
Beliebte Wasserpumpe Handbücher anderer Marken
Sykes AmeriPumps
Sykes AmeriPumps GP100M Fehlerbehebungshandbuch
DUROMAX
DUROMAX XP WX Series Bedienungsanleitung
BRINKMANN PUMPS
BRINKMANN PUMPS SBF550 Bedienungsanleitung
Franklin Electric
Franklin Electric IPS Bedienungsanleitung
Xylem
Xylem e-1532 Series Bedienungsanleitung
Milton Roy
Milton Roy PRIMEROYAL Bedienungsanleitung
