Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
4
Hardware connection
Physical appearance
Front board
Back board
Power Socket
PoE or Ethernet Device
(switch, router, etc.)
Powered Device (PD)
Router
Internet
NVR
Monitor
IP Camera
Wireless AP
Smart VoIP
Gigabit Ethernet Port
10/100 Mbps PoE Port
SFP Port
Power Input Port
AC Input 100 V-240 V
5
Specifications
Network Protocol:
IEEE802.3/IEEE802.3u/IEEE802.3z
IEEE802.3x/IEEE802.3ab/IEEE802.3af/at
PoE Standard:
IEEE802.3at (30 W) and IEEE802.3af (15.4 w)
PoE Voltage:
DC 48-55 V
Power Pin:
Power over spare pairs 1/2 (+), 3/6 (-)
AC Input Voltage:
AC 100 240 V
Output:
52 V 2.3 A
Total Power:
120 W
Dimension (L x W x H):
320 mm x 210 mm x 46 mm
Bandwidth:
9.2 Gbps (non-blocking)
MAC Address:
2K MAC address table
Pocket Buffer Memory:
6.8 Mpps
Forwarding Mode:
Store-and-forward
Working Temperature:
-20 50˚C
Storage Temperature:
-40 80˚C
Working humidity:
Max relative humidity 90 %, non-condensing
Storage humidity:
Max relative humidity 95 %, non-condensing
Working hight:
Max 10 000 feet (3 000 meters)
Storage hight:
Max 10 000 feet (3 000 meters)
DIP explanation
VLAN
Port Isolation
Downlink designated ports are isolated from each
other, only transmit data with the uplink port.
Default
Standard Switch
All ports communicate freely.
Extend
Link Extension
The specified port speed drops to 100 Mbps/s, max
PoE transmission is 250 meters.
6
LED and Interface Explanation
PWR
Power LED
ON
Powered
OFF
No power
SW Mode
DIP LED
ON
VLAN mode
OFF
Default mode
Flashing
Extend mode
Link ACT
Link LED
ON
OFF
Flashing
Link connected
Link disconnected
Link data transmitted
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
7
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
CIN: 27082440
Subject of the declaration:
Title: PoE or Ethernet Device
Model / Type: Cudy-FS1018PS1
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. 2014/35/EU
Directive No. 2014/30/EU
Directive No. 2009/125/EC
Directive No. 2011/65/EU as amended 2015/863/EU
Prague
8
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
9
Vážený zákazníku,
děkujeme vám za zakoupení našeho produktu. Před prvním použitím si prosím pečlivě
přečtěte následující pokyny a uschovejte si tento návod k použití pro budoucí potřebu.
Zvláštní pozornost věnujte bezpečnostním pokynům. Pokud máte k přístroji jakékoli
dotazy nebo připomínky, obraťte se na zákaznickou linku.
✉www.alza.cz/kontakt
✆+420 255 340 111
Dovozce Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
10
Hardwarové připojení
Fyzický vzhled
Přední deska
Zadní deska
Napájecí zásuvka
Zařízení PoE nebo
Ethernet
(přepínač, směrovač
Napájené zařízení
Směrovač
Internet
NVR
Monitor
IP kamera
Bezdrátový
přístupový
Inteligent
ní VoIP
Gigabitový port
Port PoE 10/100 Mb/s
Port SFP
Vstupní port
Vstup AC 100 V-240 V
