S16SB/S16B-IR

Ultracompact printer

S16SB, S16B-IR

User Manual

www.custom.it

S16SB/S16B-IR

in any form whatsoever, whether it be on paper or through computer

processes, is strictly prohibited. Custom Engineering s.r.l. and the resource

teams employed in the making of this manual will not be held responsible for

any problems arising as a result of improper use of this manual, as they

guarantee that the information contained in it has been subjected to careful

inspection.

Any suggestions regarding errors in its contents or possible improvements

will, nonetheless, be greatly appreciated. The products are continuously

checked and improved. For this reason Custom Engineering s.r.l. reserves

the right to modify the information contained in this manual without prior

notice.

COD. DOME - S16SB VER. PRELIMINARY

Custom Engineering

Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy

Tel. : +39 0521-680111 Fax : +39 0521-610701

http: www.custom.it Email : [email protected]

S16SB/S16B-IR

PRINTER COMPONENTS

A. S16SB - front view

1- Printing mechanism

2- FEED key

3- LED

4- RS232 / TTL serial connector

5- Battery charger connector

6- Paper holder

7- Printer cover

S16SB/S16B-IR

PRINTER COMPONENTS

A. S16B-IR front view

1- Printing mechanism

2- FEED key

3- LED

4- INFRARED Sensor

5- Battery charger connector

6- Paper holder

7- Printer cover

TABLE OF CONTENTS

iS16SB/S16B-IR

INTRODUCTION

CONTENTS OF THE MANUAL......................................................................1

CONVENTIONS USED IN THE MANUAL .....................................................1

GENERAL INFORMATION REGARDING SAFETY .....................................1

UNPACKING THE PRINTER .........................................................................3

GENERAL FEATURES..................................................................................3

DESCRIPTION OF THE PRINTER...............................................................4

1. INSTALLATION AND USE

1.1 CONNECTIONS................................................................................... 1-1

1.1.1 Power supply ................................................................................. 1-1

1.1.2 Selection of character bit...................................................................................1-2

1.1.3 Carriage return selection ...................................................................................1-2

1.1.4 Selection of print direction ................................................................................1-2

1.1.5 Turning the printer ON and OFF..................................................... 1-3

1.2 MAINTENANCE.................................................................................... 1-4

1.2.1 Changing the paper roll.................................................................. 1-4

2. INTERFACES

2.1 RS232 SERIAL .................................................................................... 2-1

2.2 INFRARED ........................................................................................... 2-4

3. PRINTER FUNCTIONS

3.1 PRINT DIRECTION ............................................................................. 3-1

3.2 CONTROL CHARACTERS ................................................................. 3-2

4. TECHNICAL SPECIFICATIONS

4.1 TECHNICAL SPECIFICATIONS......................................................... 4-1

4.2 DIMENSIONS....................................................................................... 4-2

5. CHARACTER SETS

5.1 CHARACTER SETS ............................................................................ 5-1

ATTACHMENT A - ACCESSORIES AND SPARE PARTS

A.1 SPARE PARTS.................................................................................... A-1

INTRODUCTION

1S16SB/S16B-IR

CONTENTS OF THE MANUAL

In addition to the introduction which lists: the conventions used in the manual,

general information relative to safety, unpacking of the printer and a brief de-

scription of the printer itself, highlighting its main features, the manual is split

up into the following chapters:

Chapter 1: Containing the information required for installing and using the

printer correctly

Chapter 2: Containing the specifications of the interfaces

Chapter 3: Containing the description of the printer command set

Chapter 4: Containing the technical specifications of the printer

Chapter 5: Containing the character sets (fonts) used by the printer

CONVENTIONS USED IN THE MANUAL

N.B.

Gives important information or suggestions relative to the use of the

printer

WARNING

The information marked with this symbol must be carefully heeded

to safeguard against damaging the printer

DANGER

The information marked with this symbol must be carefully heeded

to safeguard against injury to the operator

GENERAL INFORMATION REGARDING SAFETY

• Read and keep the following instructions.

• Observe all warnings and follow all instructions attached to the printer.

• Before cleaning the printer, disconnect the feed cable.

• Clean the printer with a damp cloth. Do not use liquid or spray products.

• Do not operate the printer near to water.

• Do not place the printer on unsteady surfaces. It could fall and get seri

ously damaged.

INTRODUCTION

S16SB/S16B-IR

• Use the type of electricity supply marked on the printer label. In the

event of uncertainty, contact the seller.

• Position the printer in such a way as to ensure that the cables con

nected to it will not be damaged.

• Ensure that the maximum absorbed current of the printer does not ex

ceedthe maximum acceptable current for the type of feed cable used.

• Do not put objects of any kind inside the printer as they could cause a

short circuit or damage parts which could affect its performance.

• Do not spill liquids on the printer.

• Do not carry out technical operations on the printer with the exception

of the scheduled maintenance operations specifically indicated in the

user’s manual.

• Disconnect the printer from the electricity supply and have it repaired

by a specialized technician should any of the following conditions oc

cur:

A. The feed connector has been damaged.

B. Liquid has penetrated to the inside of the printer;

C. The printer has been exposed to rain or water;

D. The printer is not operating normally despite the instructions inthe

user’s manual having been followed.

E. The printer has been dropped and its case damaged.

F. The performance of the printer is poor.

G. The printer does not work.

INTRODUCTION

3S16SB/S16B-IR

UNPACKING THE PRINTER

Remove the printer from the carton, taking care not to damage the packing

materials which should be retained for future shipping/moving.

Make sure all components listed below are present and not damaged. If any

part is missing and/or damaged, contact customer service.

Printer

Manual (or CD-Rom)

Paper roll (inside printer)

Battery charger

GENERAL FEATURES

The S16SB (Fig.2) is an extremely practical, easy-to-use desk or panel

printer. It is the ideal solution for all those applications, whether they be

industrial, professional or laboratory-related, in which data has to be

immediately printed out in ticket form: measuring systems, receipts (not for

tax purposes), security, control, diagnosis purposes, vehicles (taxis, trucks),

portable version for measuring and reports of all kinds, and any other

circumstances in which high performance printing is required in tight spaces.

(Fig.1)

INTRODUCTION

S16SB/S16B-IR

The printer is equipped with a 4-pin impact mechanism which uses ordinary

44.5mm paper rolls with a maximum of 16 columns per line, and housed

inside it is a battery which means the printer can be operated without being

connected to an electrical outlet.

The S16SB is so compact, lightweight and economical that it can be

installed extremely easily on any type of equipment.

It has a standard RS232 serial interface.

PRINTER DESCRIPTION

The printer has an ABS casing with a cover which opens to allow access to

the paper roll and print head.

On the front of the panel there is a ON-OFF / FEED key and an LED.

(Fig.2)

1) ON-OFF / FEED key. If the printer is off (green LED off), when this key

is pressed briefly, power is turned on to the printer (green LED blinking).

To turn off the printer, press the key briefly (the LED starts to blink

faster) and if the key is not pressed again within a second the printer

shuts off, otherwise it returns to operational status.

INTRODUCTION

5S16SB/S16B-IR

(Fig.3)

If the key is held down during power up, a test receipt will be printed out

giving the default parameters and character font.

If the key is pressed when the printer is on, the paper can be fed

manually.

•GREEN LED: Intermittent blinking of the LED indicates that the printer is

functioning.

Keypressed

Key released

Off

Paper feed

Keypressed

Key released

Off

Print test receipt (Fig.4)

(Fig.5)

> 1 Sec.
