Custom Audio Electronics S'print DPT100-B Bedienungsanleitung

DPT100-B

User Manual

Portable thermal printer

s’print

www.custom.it

DPT100-B

form, whether by printed or electronic means, is forbidden. While guarantee-

ing that the information contained in it has been carefully checked, CUSTOM

ENGINEERING SPA and other entities utilized in the realization of this manual

bear no responsibility for how the manual is used.

Information regarding any errors found in it or suggestions on how it could be

improved are appreciated. Since products are subject to continuous check

and improvement, CUSTOM ENGINEERING SPA reserves the right to make

changes in information contained in this manual without prior notification.

COD. DOME - DPT100-B VERS. 1.10

CUSTOM ENGINEERING SPA

Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy

Phone: +39 0521-680111 - Fax: +39 0521-610701

http:\\www.custom.it http:\\www.smice.com

Customer Service Dept.:

Phone: +39 0521-680163 - Fax: +39 0521-680146

E-mail: [email protected]

DPT100-B

PRINTER COMPONENTS

A. DPT100-B – Front external view

1- Printer base

2- Cover

3- Paper holder

4- Printing mechanism

5- Multi-function + ON key

6- Paper exit slot

7- Infrared device

DPT100-B

B. DPT100-B –Under view

1- Serial connector and battery recharger

2- Battery compartment

TABLE OF CONTENTS

iDPT100-B

INTRODUCTION

MANUAL CONTENTS ....................................................................................1

EXPLANATORY NOTES USED IN THIS MANUAL ......................................1

GENERAL SAFETY INFORMATION.............................................................1

UNPACKING THE PRINTER .........................................................................2

PRINTER FEATURES ...................................................................................3

PRINTER DESCRIPTION .............................................................................4

1. INSTALLATION AND USE

1.1 CONNECTIONS................................................................................... 1-1

1.1.1 Battery recharger ........................................................................... 1-1

1.1.2 Turning the printer On and Off ....................................................... 1-2

1.2 BATTERIES ......................................................................................... 1-3

1.2.1 Recharging batteries...................................................................... 1-3

1.2.2 Information regarding battery use.................................................. 1-4

1.2.3 Replacing batteries ........................................................................ 1-4

1.2.4 Disposing of batteries.................................................................... 1-6

1.3 CONFIGURATION ............................................................................... 1-6

1.4 HEXADECIMAL DUMP ........................................................................ 1-8

1.5 SIXLOAD.............................................................................................. 1-9

1.6 MAINTENANCE.................................................................................... 1-9

1.6.1 Changing the paper roll.................................................................. 1-9

1.6.2 Cleaning ........................................................................................1-11

2. INTERFACES

2.1 RS232 SERIAL .................................................................................... 2-1

2.2 INFRARED BIDIRECTIONAL SERIAL............................................... 2-4

2.2.1 Printing instructions ........................................................................ 2-4

3. PRINTER OPERATION

3.1 CONTROL CHARACTERS ................................................................. 3-1

3.1.1 ESC/POS emulation ..................................................................... 3-1

TABLE OF CONTENTS

iiDPT100-B

4. TECHNICAL SPECIFICATIONS

4.1 TECHNICAL SPECIFICATIONS......................................................... 4-1

4.2 ADAPTOR SPECIFICATIONS............................................................ 4-3

4.3 DIMENSIONS....................................................................................... 4-4

5. CHARACTER FONTS

5.1 CHARACTER SETS ............................................................................ 5-1

APPENDIX A - ACCESSORIES AND SPARE PARTS

A.1 ACCESSORIES................................................................................... A-1

A.1.1 Belt coupler.................................................................................... A-1

A.2 SPARE PARTS.................................................................................... A-2

INTRODUCTION

1DPT100-B

MANUAL ORGANIZATION

In addition to the Introduction which includes a description of the explanatory

notes used in the manual, general safety information, how to unpack the

printer and a brief description of the printer including its basic features, this

manual is organized as follows:

Chapter 1: Contains the information required for correct printer installation

and its proper use, as well as interface specifications

Chapter 2: Contains information on interface specifications

Chapter 3: Contains a description of the printer command set

Chapter 4: Contains Technical Specifications of the printer

Chapter 5: Contains the character sets (fonts) used by the printer

SYMBOL USED IN THIS MANUAL

NOTE

Gives important information or suggestions relative to the use of the

printer.

WARNING

Information marked with this symbol must be carefully followed to

guard against damaging the printer.

DANGER

Information marked with this symbol must be carefully followed to

guard against operator injury or damage.

GENERAL SAFETY INFORMATION

•Read and keep the instructions which follow.

•Before cleaning the printer, disconnect the power supply and make sure

that the printer is off.

•Clean the printer with a damp cloth. Do not use liquid or spray products.

•Do not operate the printer near water.

•Only use approved accessories and batteries. Do not connect to

products that are not compatible.

INTRODUCTION

DPT100-B 2

•Use the type of electrical power supply indicated on the printer label. If in

doubt, contact your retailer.

•When deciding where to place the printer, make sure it is positioned

where its cables will not be damaged.

•Do not introduce foreign objects of any kind into the printer as they could

cause a short circuit and could jeopardize printer functioning.

•Do not spill liquids onto the printer.

•Do not carry out technical operations on the printer, with the exception of

the scheduled maintenance procedures specifically indicated in the user

manual.

•Disconnect the printer from the electricity supply and have it repaired by a

specialized technician when:

A. The feed connector has been damaged.

B. Liquid has seeped inside of the printer.

C. The printer has been exposed to rain or water.

D. The printer is not functioning normally despite the fact that all

instructions in the users manual have been followed.

E. The printer has been dropped and its outer casing damaged.

F. Printer performance is poor.

G. The printer is not functioning.

UNPACKING THE PRINTER

Remove the printer from its carton being careful not to damage the packing

material so that it may be re-used if the printer is to be transported in the

future.

Make sure that all the components illustrated in fig. 1 are present and that

there are no signs of damage. If there are, contact Customer Service.

1. Warning sheet

2. Cable

3. Paper roll

4. Adaptor / Battery recharger

5. Batteries (5 pcs.)

6. Belt coupler

7. Printer

8. Box

INTRODUCTION

3DPT100-B

s’print

PRINTER FEATURES

The new s’ print portable thermal printer offers an innovative alternative to

impact-based systems, with a range of interface options (RS232

serial,R232+IRDA). The printer is powered using batteries.

(Fig. 1)

INTRODUCTION

DPT100-B 4

The battery version (with RS232+IRDA interface) is primarily intended for

the automatic identification and mobile telephony market, combined with

portable terminals without printer; the infrared bidirectional interface with

which it is equipped makes cable connection—so “inconvenient” for portable

devices—unnecessary.

It is important to note that s’ print is the first Custom printer designed with

“sixload” easy paper load, making it simpler and more convenient to use.

It has a 203 dpi thermal print mechanism that utilizes 57.5mm-wide paper

rolls and can print up to 24 o 40(1) charaters per line.

(1)NOTE

The 40 column version is downloadable on the Support/Download/

Firmware section from www.custom.it web site.

PRINTER DESCRIPTION

The printers consists of a ABS-V0 casing (1) equipped with a cover (2)

under which is housed the paper roll and print mechanism. On the front is the

multi-function key (3) and red LED (4).

(Fig. 2)
