CyberView RKP115 Series Bedienungsanleitung

CyberView RKP115 / 117 / 119 Series A 1U rack mountable LCD, keyboard

and KVM drawer. Using the o tional integrated USB or PS/2 KVM allows you to connect to u to

16 servers, in addition to this the KVM drawer can be cascaded ‘or stacked’ with our CV series of KVM

switches to enable access to u to 128 servers. Remote or Two consoles KVM can either be, via the World Wide

Web using secure IP access or within the building using a secure hysical KVM extender connection via a Cat5 cable.

RKP115/117/119 SERIES

LCD Keyboard Drawer

And O tional Integrated KVM

(Keyboard, Video & Mouse) Switch

minimum rack s ace, maximum control.

CyberView offers its users a flexible, s ace saving, cost effective

method of managing multi le servers from a single unit,

either locally within the data centre, or remotely via the World

Wide Web using secure IP access.

CyberView is available in 1U and 2U height o tions, de ths

include 440mm for 600 dee racks or 650mm for 800 dee

racks, with com lete unit configuration flexibility of sim ly

LCD drawer, Keyboard drawer, LCD Keyboard Drawer or LCD

Keyboard Drawer with KVM (Keyboard, Video and Mouse) switch.

To cater for today’s ever demanding working environments and

a lications CyberView is available in 15, 17 or 19” LCD screens

with a wide selection of keyboard layouts and languages, including

vendor a lication s ecific units i.e. full SUN Microsystems Solaris

v10 com atibility when using our S Series solutions.

THE C BERVIEW SOLUTION...

1U LCD Screen/Keyboard Drawer

Space saving 1U design, incorporating

LCD screen & keyboard

15’’ / 17’’ / 19’’ TFT LCD Screen

Available in 3 LCD screen sizes, all in a 1U unit

Built in on screen display controlled by

integral membrane switches

Allows adjustment of color, contrast,

brightness, H Position, V position, Auto

Configure, OSD, etc

Unique modular mechanical design

Allows easy component level

replacement and provides a KVM

migration path

Extended Slide rails provide clearance

distance between rack panel mounts and

the rear of the LCD Screen

Allows protruding equipment i.e. servers

and patch panels to be mounted directly

above the drawer, without interference

Slide rails have two friction stops to

prevent movement of the keyboard

Allowing comfortable working on unit

while maintaining safety practices

A selection of keyboards and mouse options

Available with notebook keyboard and

either trackball or touchpad mouse

Full selection of keyboard languages

Available in European (UK), US, Spanish,

German, French, Italian & Norwegian

All mounting hardware included

Allows simple, quick and secure

installation

WITH KVM SWITCH:-

8 or 16 Port KVM

Available with PS/2 or USB KVM switch

options, cascade able up to 128 servers

Built in integral KVM membrane switch

Allows user to chose server selection via

membrane button or ‘hot’ keys via OSD

Multiplatform

Provides instant switching between PC’s,

SUN’s, IBM’s, HP’s, Compaq, and DELL

platforms

Stay Alive Feature

Safeguards server for power loss to switch

Access Password Security

Supports eight character password

protection and search feature for specific

PC or server name

Auto Scan Mode

Monitor your servers at intervals 5-99

seconds, set by user

Supplied with 8 x 6 C series KVM

connecting cables

Supports good rear cable management

via the use of 8 x 3 in 1 KVM Cables

PRODUCT FEATURES & BENEFITS

RKP115/117/119

Data Sheet (1)

LCD SPECIFICATION RKP115/117/119 SERIES

PANEL 15’’ LCD SERIES 17’’ LCD SERIES 19’’ LCD SERIES 20” LCD SERIES

DISPLAY TYPE Active matrix TFT colour LCD Active matrix TFT colour LCD Active matrix TFT colour LCD -------

MAX RESOLUTION 1024 x 768 XGA 1280 x 1024 SXGA 1280 x 1024 SXGA -------

PIXEL PITCH 0.297(H) x 0.297(W) mm 0.264(H) x 0.264(W) mm 0.294(H) x 0.294(W) mm -------

CONTRAST RATIO 300:1 500:1 700:1 -------

BRIGHTNESS 450 cd/ m2 300 cd / m2 300 cd / m2 -------

RESPONSE TIME Tr=5 / Tf=20 ms Tr=3 / Tf=10 ms Tr=15 / Tf=10ms -------

DISPLAY COLOURS 16.2M 16.2M 16.7M -------

VIEWING ANGLE (TYPICAL) 140 (Horiz.) / 115 (Vert.) 150 (Horiz.) / 135 (Vert.) 150 (Horiz.) / 135 (Vert.) -------

OPERATING TEMP (OC) 0 to 50 0 to 50 0 to 50 -------

STORAGE TEMP (OC) -25 to 60 -25 to 60 -25 to 60 -------

SIZE SPECIFICATION

UNIT TYPE 15’’ UNIT 17’’ UNIT 19’’ UNIT 20” UNIT

UNIT DIMENSIONS (CM) 43.9 x 4.45 x 60 43.9 x 4.45 x 60 44.2 x 4.45 x 65 -------

PACKAGED DIMENSIONS (CM) 73.5 x 18 x 57.5 73.5 x 18 x 57.5 78.5 x 18 x 57.5 -------

UNIT WEIGHT (KG) 10 12 14 -------

PACKAGED WEIGHT (KG) 18 21 23 -------

KVM SPECIFICATION

MODEL NUMBER -801 / -S801 / -1601 / -S1601 -802 / -S802 / - 1602 / -S1602 -IP802 / -IP1602 / -IPS802 / -IPS1602

Local Console CAT.5 Remote Console -------

PC PORTS 8 / 16 8 / 16 N/A 8 / 16

CONSOLE PORTS 1111

PC SELECTION On Screen Disp. / Hot Keys / Push Button On Screen Display Menu / Hot Keys / Push Button On Screen Display Menu

LED 1 Bank LED 1 Bank LED 1 Power LED Green 1 Bank LED

8/16 Online LED Green 8/16 Online LED Green 1 Status LED Red 8/16 Online LED Green

8/16 Selected LED Red 8/16SelectedLEDRed ------- 8/16 Selected LED Red

OSD CONTROL Yes Yes Yes

SCAN INTERVALS 5 - 99 Seconds 5 – 99 Seconds 5 – 99 Seconds

KEYBOARD & MOUSE EM. PS/2 or USB PS/2 or USB PS/2 or USB

VGA RESOLUTION (MAX.) 1920 x 1440 1920 x 1440 1600 x 1200 Local 1600x1200, Remote 1280x1024

CAT.5 CABLE LENGTH (MAX) N/A N/A 1000 feet -------

BANDWIDTH 200MHz 200MHz 150MHz 200MHz

CASCADE LEVEL 8 levels 8 levels 8 Levels

PC CONNECTIONS (MAX) 120/128 120/128 120/128

LOCAL CONSOLE PORTS ------- ------- ------- 1

REMOTE CONSOLE PORTS ------- ------- ------- 1

REM. CONSOLE CONNECTOR ------- ------- ------- RJ45 8P8C

SERIAL PORT ------- ------- ------- 1

REMOTE WEB BASED ACCESS ------- ------- ------- Internet, LAN/WAN, Dial Up Modem

REMOTE BROWSER SUPPORT ------- ------- ------- Microsoft IE, Netscape Navigator, Mozilla

DATA ENCRYPTED ------- ------- ------- Secure Socket layer SSL v2 / 23

POWER SUPPL

REMOTE ADAPTER 110V-220V AC Input - 12V 5A Output

ADAPTER SIZE 10.8(L) x 6.1 (W) x 3(H) cm

CABLE LENGTH (MAINS TO ADAPTER) 182cm

CABLE LENGTH (ADAPTER TO UNIT) 180cm

SAFETY APPROVAL UL / CE

OPTIONS AVAILABLE:

AV INPUT DC INPUT TOUCHSCREEN

KE BOARDS Supporting Layouts

‘E’TYPE KEYBOARD ‘B’TYPE KEYBOARD ‘D’TYPE KEYBOARD ‘T’TYPE KEYBOARD

Notebook With Touch Pad Mouse Notebook With Trackball Mouse Compact With Integrated Trackball Compact With Integrated Touch-pad Mouse

NOT AVAILABLE NOT AVAILABLE

NOTE: Technical Information.

All information contained in this

information sheet was correct at

the time of going to press.

Images are used for illustration

purposes and are subject to

change at the manufacturers

discretion. E&OE.
