Cydle T43H Bedienungsanleitung

4.3” Portable GPS car Navigation

Cydle T43H integrates enhanced functions such as Global Positioning System (GPS), HD

Radio Receiver, HD traffic update, music player, video player, and picture viewer

functions into a single, easy to use economical unit.

Our system allows you to listen to high quality FM channels that features multicasting

data service on FM band.

Real-time traffic service over HD Radio broadcasting is also available in North America.

T43H is Preloaded with a highly detailed city navigator for North America, including

Canada, US Puerto Rico and Hawaii.

There are countless POIs which will enable you to find hotels, restaurants, gas stations

and so much more at your convenience, anytime, anywhere.

Your T43H is suitable for daily use under any circumstances. Its functionalities will

simply take you beyond what you would normally expect from an ordinary GPS.

*HD Radio™ Technology is manufactured under license from iBiquity Digital Corporation.

U.S. and Foreign Patents. HD Radio™ and the HD and HD Radio logos are proprietary

trademarks of the iBiquity Digital Corporation.

All other trademarks, whether claimed or registered, are the exclusive property of their

respective owners.

T43H

Please contact Cydle if you have any inquires while using T43H.

Contact http://www.cydle.com or mail to cydle@cydle.com

Get further information and all contents for T43H at our official Cydle site:

- Get the latest software at the Cydle site for free

- Update your map via online Cydle store

- Please join us as a registered member for faster, enhanced tech support

by creating a personal account.

Contact

Introduction

Thank you for choosing our Cydle T43H as your portable navigation device. We are

committed to provide you with the very best. We hope you find the instructions in

this owner‟s manual clear and easy to follow. Please take a few minutes to read this

user manual and learn how to use all the features in your new Cydle T43H that

provide maximum driving enjoyment.

Introduction

1. Introduction

T43H

Contact

Contents

2. Before you start

Safety precaution

What‟s in the box

Name of Parts

Installation

Connecting to Ext. FM HD Radio antenna

Switching on and off

Volume on and Volume off

Reset

Speaker icon and Mute

Back Light off to save power

Battery saving mode

Battery notes

Charging the battery

3. Getting started with your GPS

Driving View

Menu page

4. Finding your destination

a. Where to?

Home

Favorites

Emergency

Recent Destination

Address

Intersection

Telephone No

Zip code

Point on Map

Itinerary

Cities

POI Name

POI in City

POI in Category

Start Travelling Guidance

Table of Contents

Introduction

5. Traffic information using HD Radio Technology

Real-time traffic information

Traffic service status

Traffic Menu

Traffic on Route

Traffic Map

Traffic Flow

Traffic Details

Traffic List

Traffic Classes

Traffic Setting

Traffic Station

6. Customizing Cydle XE

Settings

Color mode

Map view

Set Brightness

Map Colors

Auto Zoom

Home

Label on Map

Voice and Text Language

Routing Options

Units

Set Clock

Time Zone

Speed Limit

Fuel

Volume

Keyboard

About

Restore Settings

Introduction

b. Route options

Manage your route

Create Route

Edit Route

Detour

Route summary page

Introduction

8. Music

Sound settings

Display settings

Selecting System Language

Date & Time settings

Selecting Theme

Calibration

System Information

17. User information and Precautions

Introduction

7. GPS status

18. Copyright

14. Settings

9. Movie

10. Picture

11. Calculator

13. HD Radio Technology

Calendar

15. Update

OS update

Software update

App +Map update

App update

Map update

Introduction

12. Utility 72

Stopwatch 73

16. Specification 91

* EULA 95

Your unit contains a number of electronic components that can be

damaged permanently when exposed to shock or vibration. To protect

your unit from damage, please keep your unit in a stable environment

and avoid dropping your unit. Also, do not operate under high–shock

and high-vibration environments.

Clean the outer surface of your unit by gently wiping off with a mild

detergent-dampened cloth.

Avoid chemical cleaners that can damage to plastic components.

Clean the touch screen with a soft, clean cloth. You can use water or

an eyeglass cleaner to dampen the cloth. However, do not apply liquids

directly onto the touch screen. Dampen the cloth with liquid and then

gently wipe the touch screen.

A PDA stylus pen can be used to operate the touch screen. Never use

hard or sharp object to operate the touch screen as it might cause

damage.

Do not expose your unit to water. Contact with water can cause the

unit to malfunction.

Safety precaution

•Do not operate your device while driving. Please drive safely and pay attention

to the road and pedestrians. Always practice safe driving.

•To reduce the risk of traffic accidents, never use the video display function while

driving. This is a violation of federal law.

•Never disassemble or adjust the unit unless instructed to do so by this manual.

•To prevent injury from shock or fire, never expose the unit to moisture or water.

•Never use irregular software and data.

•To prevent internal damage of the unit, avoid direct impact to the TFT monitor.

•Using an improper fuse may cause damage to the unit and result in a fire.

Caution

Before you start

What‘s in the box

Cydle GPS Navigation Quick Start Manual

NOTE :

Go to the support section of the Cydle website to download the electronic manual with

detailed information available in multiple language formats for T43H.

Before you start

Cydle GPS Navigation

Quick Start Manual

Cydle Navigator Cradle

Super Suction Mount

DC Car adaptor

USB cable

Ext. FM Radio antenna

Cydle Navigator Cradle Super Suction Mount

DC Car adaptor USB Cable Ext. FM Radio antenna

e f g

AC adaptor Ext. GPS ANT Earphone

Charging and connecting

Installing in your automobile

Getting to know and start…

Sold separately

Name of parts

Before you start

Microphone(Applied only to the

Bluetooth model (T43HB))

Power Button

Volume Up

Volume Down

Reset Button

Name of parts

Earphone connector/

Ext. FM Radio antenna connector

Audio out connector

USB port /Car Battery Adaptor connector

External GPS Antenna connector

SD slot

1. Clean the area where your unit is to be installed with rubbing alcohol and soft

cloth. Allow to dry.

2. Push the pedestal suction cup firmly

onto the connector and then flip the A

lever down to secure the suction cup.

3. Use the Bknob to adjust

the angle and rotation of the

pedestal for maximum

visibility.

4. Attach the cradle onto the suction

cup.

5. Place your device in the cradle.

Press the front surface of the

cradle toward the mount until it

clicks. The unit is now fixed in the

cradle.

6. Insert the power adapter into the

cigarette jack and connect it to

the DC input of the navigation

cradle to turn on the power.

Installation

Before you start

Installing on Dashboard

This unit is designed to be installed on dashboard or windshield found in every

vehicle. Please install your unit in a safe manner.

NOTE: It is the end-users‟ responsibility to install and operate this unit in a manner

accordance to the local, state and federal laws.

DC Car Adaptor

1. Clean the area where your unit is to be installed with rubbing alcohol and soft

cloth. Allow to dry.

2. Push the pedestal suction cup firmly

onto the connector, then flip the A

lever down to secure the suction cup.

3. Use the Bknob to adjust

the angle and rotation of the pedestal

for maximum.

4. Attach the cradle onto the suction

cup.

5. Place your device in the cradle.

Press the front surface of the

cradle toward the mount until it clicks.

The unit is now fixed in the cradle.

6. Insert the power adapter into the

cigarette jack and connect it to the

DC input of the navigation cradle to

turn on the power.

Before you start

DC Car Adaptor

Installing onto the windshield

NOTE :

•Once the cradle is attached, the angle of the adhesive bracket can be adjusted by

applying gentle pressure to the top or bottom of the cradle.
