SMART ENERGY CONTROL
CBT-STAT and CBT-STAT-H
USER GUIDE
2© Cylon Controls Ltd. MAN0120US rev 16
CBT-STAT and CBT-STAT-H
© Cylon Controls Ltd. 2019. All Rights Reserved.
CBT-STAT and CBT-STAT-H (MAN0120US rev 16)
Information in this document is subject to change without notice. The software described in this document is furnished under a
license agreement or nondisclosure agreement. The software may be used only in accordance with the terms of those agreements.
No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or any means electronic or
mechanical, including photocopying and recording for any purpose other than the purchaser’s personal use without the written
permission of Cylon Controls Ltd.
TRADEMARKS
All trademarks and trade names used in this document are acknowledged to be the copyright of their respective
holders.
UniPut™ technology is covered by UK Patent GB 2 400 991 and Irish Patent 84413
www.cylon.com
www.cylon-automatrix.com
MAN0120US rev 16 © Cylon Controls Ltd. 3
Contents
Style conventions used in this document:
UI Text: Text that represents elemets of the UI such as button names, menu
options etc is presented with a grey background and border, in
Tahoma font which is traditionally used in Windows UIs. For example:
Ok
Standard Terms (Jargon): Text that is not English Language but instead refers to
industry standard concepts such s Strategy, BACnet, or Analog Input
is represents in slightly condensed font. For example:
BACnet
Code: Text that represents File paths, Code snippets or text file
configuration settings is presented in fixed-width font, with a grey
background and border. For example:
$config_file = c:\CYLON\settings\config.txt
Parameter values: Text that represents values to be entered into UI fields, or
displayed in dialogs is represented in fixed-width font with a shaded
background. For example
10°C
Product Names: Text that represents a product name is represented in bold
coloured text. For example
CBX-8R8-H
PC Keyboard keys: Text representing an instruction to press a particular key on
the keyboard is enclosed in square brackets and in bold folt. For
example:
[Ctrl]+[1]
4© Cylon Controls Ltd. MAN0120US rev 16
CBT-STAT and CBT-STAT-H
CONTENTS
SECTION 1 : Introduction
What are CBT-STAT and CBT-STAT-H? 6
SECTION 2 : User Mode
User Mode 8
SECTION 3 : Engineering Mode
Engineering Mode 12
Using the Engineering Mode menus 13
Available parameters 14
Balancing Procedure - CBV-2U4-3T(-N) 18
Balancing Procedure –CBT12iVAV 19
SECTION 1 : INTRODUCTION
6© Cylon Controls Ltd. MAN0120US rev 16
CBT-STAT and CBT-STAT-H
WHAT ARE CBT-STAT AND CBT-STAT-H?
The CBT-STAT and CBT-STAT-H provide dedicated, visually
appealing Room Control displays for use with CBV and CBT
Unitary Controllers.
Both displays allow the user to view and adjust selected
7parameters within the controller to which they are connected,
and each has an integrated temperature sensor. The CBT-STAT-
Halso has an integrated humidity sensor.
While the display can be used for local control, the CBT12iVAV
and CBT14 Unitary Controllers can be easily integrated into the
Cylon Controls BACnet system architecture.
By default the CBT-STAT and CBT-STAT-H operate in User mode
–see User Mode on page 8 for details.
The CBT-STAT or CBT-STAT-H can be put into Engineering Mode,
allowing the display to be used as a commissioning tool,
adjusting preset points in the Unitary Controller’s default
strategy. See Engineering Mode on page 12.
SECTION 2 : USER MODE
8© Cylon Controls Ltd. MAN0120US rev 16
CBT-STAT and CBT-STAT-H
USER MODE
User mode is the default behavior for the CBT-STAT and CBT-STAT-H keypads.
Keypad and Display
1st line (large digits)
2nd line (small digits)
Operation Mode indicators
Keypad
Left button
No function
.
Up button
Increase setpoint
.
Right button
Toggle occupancy override (if Permit
Occupancy Override is enabled)
.
Down button
Decrease setpoint
.
c
a
b
d
Temperature
In User mode, the 1st line (large digits) on the display shows the current Temperature Sensor reading.
Humidity
On the CBT-STAT-H, the 2nd line (small digits) shows the current Humidity Sensor reading.
Temperature Setpoint
On the CBT-STAT, the 2nd line (small digits) shows the current value of the Temperature Setpoint.
On the CBT-STAT-H, pressing any of the buttons or changes the 2nd line (small digits) to show the
Temperature setpoint.
a
b
c
d
a
b
b
b
MAN0120US rev 16 © Cylon Controls Ltd. 9
How to adjust the Temperature Setpoint
If the Controller’s Strategy has been configured to permit it, the user can adjust the Temperature setpoint or occupancy status.
•Press any button so that the temperature setpoint is displayed on the second line, with a flashing unit symbol.
•Press the up button or down button to adjust the setpoint value by the span defined in the Controller’s configuration,
until the desired temperature setpoint is displayed.
•The right button can also be used to request the Strategy to override the schedule and force occupancy mode. Permit
Occupancy Override must be enabled in the controller configuration.
Operation Mode
At the bottom of the display there is a line of icons that give information about the current operation of the
CBT12iVAV or CBT14 Unitary Controller’s Strategy:
Indicates that the controller is operating in ‘heating’
mode.
Indicates that the controller is operating in ‘cooling’
mode.
Indicates that the controller strategy is currently
operating in ‘occupancy’ mode.
Indicates that functions of the Controller Strategy
are in manual override mode.
Indicates that an alarm state is detected in the
controller strategy.
Indicates that the fan is operating.
Indicates that the keypad is operating in
Engineering mode.
c
