CY3270

PSoC® 1 FirstTouch™ Kit Guide

Document No. 001-15945 Rev. *D

Cypress Semiconductor

198 Champion Court

San Jose, CA 95134-1709

Phone (USA): 800.858.1810

Phone (Intnl): 408.943.2600

http://www.cypress.com

2 CY3270 PSoC® FirstTouch™ Kit Guide, Document No. 001-15945 Rev. *D

Copyrights

Cypress Semiconductor Corporation assumes no responsibility for the use of any circuitry other than circuitry embodied in a

Cypress product. Nor does it convey or imply any license under patent or other rights. Cypress products are not warranted

nor intended to be used for medical, life support, life saving, critical control or safety applications, unless pursuant to an

express written agreement with Cypress. Furthermore, Cypress does not authorize its products for use as critical components

in life-support systems where a malfunction or failure may reasonably be expected to result in significant injury to the user.

The inclusion of Cypress products in life-support systems application implies that the manufacturer assumes all risk of such

use and in doing so indemnifies Cypress against all charges.

PSoC Designer™ and Programmable System-on-Chip™ are trademarks and PSoC® is a registered trademark of Cypress

Semiconductor Corp. I²C is a registered trademark of Philips Electronics. All other trademarks or registered trademarks refer-

enced herein are property of the respective corporations.

Any Source Code (software and/or firmware) is owned by Cypress Semiconductor Corporation (Cypress) and is protected by

and subject to worldwide patent protection (United States and foreign), United States copyright laws and international treaty

provisions. Cypress hereby grants to licensee a personal, non-exclusive, non-transferable license to copy, use, modify, create

derivative works of and compile the Cypress Source Code and derivative works for the sole purpose of creating custom soft-

ware and or firmware in support of licensee product to be used only in conjunction with a Cypress integrated circuit as speci-

fied in the applicable agreement. Any reproduction, modification, translation, compilation or representation of this Source

Code except as specified above is prohibited without the express written permission of Cypress.

Disclaimer

CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THIS MATERIAL,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PAR-

TICULAR PURPOSE. Cypress reserves the right to make changes without further notice to the materials described herein.

Cypress does not assume any liability arising out of the application or use of any product or circuit described herein. Cypress

does not authorize its products for use as critical components in life-support systems where a malfunction or failure may rea-

sonably be expected to result in significant injury to the user. The inclusion of Cypress’ product in a life-support systems appli-

cation implies that the manufacturer assumes all risk of such use and in doing so indemnifies Cypress against all charges.

Use may be limited by and subject to the applicable Cypress software license agreement.

CY3270 PSoC® FirstTouch™ Kit Guide, Document No. 001-15945 Rev. *D 3

Contents

1. Introduction 5

1.1 Kit Contents..............................................................................................................................6

1.2 Additional Learning Resources.................................................................................................6

1.2.1 Reference Documents ..................................................................................................6

1.3 Document History.....................................................................................................................7

1.4 Document Conventions ............................................................................................................7

2. Getting Started 9

2.1 Introduction...............................................................................................................................9

2.2 CD Installation ..........................................................................................................................9

2.3 PSoC Designer.......................................................................................................................14

2.4 PSoC Programmer .................................................................................................................15

2.5 Install Hardware......................................................................................................................15

2.6 Run CapSense Touch Sensing Design ..................................................................................16

3. Kit Operation 17

3.1 Introduction.............................................................................................................................17

3.1.1 MultiFunction Expansion Card (FTMF).......................................................................17

3.2 FTMF Expansion Card Demonstrations .................................................................................17

3.2.1 CapSense Touch Sensing Demonstration (Default)....................................................18

3.2.2 Temperature Sensing Demonstration..........................................................................18

3.2.3 Light Sensing Demonstration......................................................................................18

3.2.4 CapSense Proximity Sensing Demonstration.............................................................18

4. Hardware 19

4.1 System Block Diagram ...........................................................................................................19

4.2 FTPC Bridge (First Touch PC Bridge)....................................................................................20

4.2.1 LED Usage..................................................................................................................21

4.3 Expansion Card Overview......................................................................................................23

4.4 Expansion Card Details..........................................................................................................23

4.4.1 FirstTouch MultiFunction Expansion (FTMF) Card......................................................23

5. Code Examples 29

5.1 My First Code Example ..........................................................................................................29

5.1.1 Project Objective.........................................................................................................29

5.1.2 Flowchart.....................................................................................................................30

5.1.3 Creating My First PSoC 1 Project...............................................................................31

5.2 MultiFunction Expansion Card Light Sensor...........................................................................51

5.2.1 Device Configuration...................................................................................................52

5.2.2 Firmware Architecture.................................................................................................53

5.3 MultiFunction Expansion Card Proximity Sensor....................................................................54

5.3.1 Device Configuration...................................................................................................55

4 CY3270 PSoC® FirstTouch™ Kit Guide, Document No. 001-15945 Rev. *D

Contents

5.3.2 Firmware Architecture.................................................................................................56

5.4 Multifunction Expansion Card Temperature Sensor...............................................................57

5.4.1 Device Configuration ..................................................................................................58

5.4.2 Firmware Architecture.................................................................................................59

A. Appendix 61

A.1 Schematic...............................................................................................................................61

A.1.1 First Touch PC Bridge Schematic...............................................................................61

A.1.2 First Touch Multifunction Card Schematic ..................................................................62

A.2 Board Layout..........................................................................................................................63

A.2.1 PDCR-9402 Primary side ...........................................................................................63

A.2.2 PDCR-9402 Secondary Side......................................................................................63

A.2.3 Assembly Drawing of First touch Multifunction Card (Primary side)...........................63

A.2.4 Assembly Drawing of First touch Multifunction Card (Secondary Side) .....................64

A.2.5 PDCR-9403 Primary Side...........................................................................................64

A.2.6 PDCR-9403 Secondary Side......................................................................................64

A.2.7 Assembly Drawing for FirstTouch PC Bridge..............................................................65

A.3 BOM .......................................................................................................................................66

A.3.1 FirstTouch Multifunction Board ...................................................................................66

A.3.2 FirstTouch PC Bridge..................................................................................................67

CY3270 PSoC® FirstTouch™ Kit Guide, Document No. 001-15945 Rev. *D 5

1. Introduction

Thank you for your interest in the CY3270 PSoC®1 FirstTouch™ Kit (FTK). You can design your

own projects with Cypress's easy-to-use Integrated Development Environment (IDE), PSoC

Designer™, or by altering sample projects provided along with this kit. The CY3270 PSoC 1 FTK is

described in the Help guides and examples projects that are available. The project “MF_CS_SLIDE”

is programmed on the CY3270 PSoC 1 FTK as the default project for demonstration purposes. For

more information on the default project, refer to Chapter 5.

The CY3270 PSoC 1 FTK includes a USB interface dongle, referred to as the FTPC bridge, and a

multifunction expansion card, referred to as the FTMF Expansion Card. The FTMF Expansion Card

demonstrates a variety of applications using ‘PSoC Powered Peripherals’. The FTMF Expansion

Card connects to the bridge through the bridge’s built-in 8×2 pin expansion port. As the name

implies, the FTPC bridge forms the connection between the FTMF Expansion Card and the various

PC applications that control and communicate with the FTMF Expansion Card.

The FTPC bridge portion of the kit contains a programmed Cypress CY8C24894 PSoC that

performs all of the USB and expansion card interface functions. The firmware that is run by this

PSoC performs the following primary functions:

■Functions as a USB physical and logical interface

■Provides PSoC MiniProg emulation for in system serial programming (ISSP) of the expansion

cards

■Provides communications with the PSoC programming utility

■Performs HID data channel communications

■Performs expansion card I2C communications

■Performs expansion card SPI communications

There are no other active components inside of the FTPC bridge. All of these interfaces run on a sin-

gle PSoC device. Future projects for the FirstTouch kit allow you to modify the FTPC firmware and

try some USB Interface designs of your own.

The FirstTouch expansion card connects to the FTPC bridge through the bridge’s 8×2 pin expansion

port. This expansion port provides all of the necessary signals to program the host PSoC on the

expansion card. The expansion port also provides power, ground, and I2C or SPI communications to

and from the expansion card host PSoC and PC.

The FirstTouch expansion card has a dedicated host PSoC. Therefore, when it is programmed with

your design, the expansion cards can operate either detached from the FTPC bridge in standalone

mode or connected to your system hardware. It is necessary to provide power and ground for the

expansion card to operate in either of these two arrangements.

There are four unused analog or digital GPIO pins on the FTPC port and four unused analog or

digital GPIO pins on the expansion card. This allows you to create custom designs and connect the

signals you want to the FTPC bridge or the FirstTouch expansion cards. These GPIO pins on the

PSoC are not connected to the header by default; zero ohm resistors (R9-R12) must be placed to

use these GPIOs.

6 CY3270 PSoC® FirstTouch™ Kit Guide, Document No. 001-15945 Rev. *D

Introduction

Chapter 2 describes the installation and configuration of the CY3270 PSoC 1 FTK. Chapter 3

describes the kit operation. It explains the programming of a PSoC 1 device with the PSoC

Programmer, and the usage of the kit with the help of an example project. Chapter 4 describes the

hardware operation. Chapter 5 provides information about the firmware and example project.

The Appendix A section provides the schematics and BOM associated with the PSoC Designer 5.1.

You can evaluate the included sample projects and then experiment with the included hardware and

software to create your own designs.

1.1 Kit Contents

The CY3270 PSoC 1 FTK contains:

■FirstTouch PC bridge.

■FirstTouch multifunction card

■CY8C21434-24LTXI sample

■Single strand wire (for proximity)

■CY3270-FTK Kit CD

❐PSoC Designer installation file

❐PSoC Programmer installation file

❐Bridge control panel installation file (packaged along with PSoC Programmer)

❐Code examples

❐Hardware files

❐Kit guide

❐Quick start guide

❐Release notes

Inspect the contents of the kit. If any parts are missing, contact your nearest Cypress sales office for

further assistance.

1.2 Additional Learning Resources

Visit www.cypress.com for additional learning resources in the form of data sheets, technical

reference manual, and application notes.

1.2.1 Reference Documents

■Application note - AN2216 - PSoC®1 - Estimating PSoC Power Consumption

http://www.cypress.com/?rID=2913

■PSoC CY8C21434 - Chip features and related documents:

http://www.cypress.com/?mpn=CY8C21434-24LQXI

■PSoC CY8C27443- Chip features and related documents:

http://www.cypress.com/?mpn=CY8C27443-24SXI

■FIRST TOUCH MF_Board Schematic.pdf

http://www.cypress.com/?docID=22557

■For more information regarding PSoC Designer functionality and releases:

www.cypress.com/go/psocdesigner

■For more information regarding PSoC Programmer, supported hardware and COM layer:

www.cypress.com/go/psocprogrammer

■For a list of PSoC Designer-related trainings, see http://www.cypress.com/?rID=40543

CY3270 PSoC® FirstTouch™ Kit Guide, Document No. 001-15945 Rev. *D 7

Introduction

1.3 Document History

1.4 Document Conventions

Revision PDF Creation

Date Origin of

Change Description of Change

** 08/17/2007 SXF New document

*A 02/08/2011 RKPM Updated template.

*B 02/16/2011 GNKK Formatted page layout in TOC.

*C 02/22/2011 RKPM

Updated link in CD Installation section.

Removed reference to PSoC Express from

Removed references to PSoC Designer version

in Chapter 2.

*D 05/25/2011 RKPM

Changed document title to CY3270 PSoC®1

FirstTouch™ Kit Guide.

Code Examples chapter: Added ‘My First Code

Example’ section; updated all flowcharts.

Table 1-1. Document Conventions for Guides

Convention Usage

Courier New Displays file locations, User entered text, and source code:

C:\ ...cd\icc\

Italics Displays file names and reference documentation:

Read about the sourcefile.hex file in the PSoC Designer User Guide.

[Bracketed,Bold]Displays keyboard commands in procedures:

[Enter] or [Ctrl][C]

File > Open Represents menu paths:

File > Open >New Project

Bold Displays commands, menu paths, and icon names in procedures:

Click the File icon and then click Open.

Times New Roman Displays an equation:

2 + 2 = 4

Text in gray boxes Describes cautions or uniwue functionality of the product.

8 CY3270 PSoC® FirstTouch™ Kit Guide, Document No. 001-15945 Rev. *D

Introduction

CY3270 PSoC® FirstTouch™ Kit Guide, Document No. 001-15945 Rev. *D 9

2. Getting Started

2.1 Introduction

This chapter describes how to install and configure the CY3270 PSoC 1 FTK.

2.2 CD Installation

To install the CY3270 PSoC 1 FTK, follow these steps:

1. Insert the kit CD into the CD drive of your PC. The CD is designed to auto-run and the kit installer

menu appears.

Note You can also download the latest kit installer from http://www.cypress.com/go/CY3270-FTK.

Three different types of installers are available for download.

■CY3270-FTK_ISO: This file (ISO image) is an archive file of the optical disc provided with the kit.

You can use this to create an installer CD or extract information using WinRar or similar tools.

■CY3270-FTK_ Single Package: This executable file installs the contents of the kit CD, which

includes PSoC Programmer, PSoC Designer, kit code examples, kit hardware files, and user doc-

uments.

■CY3270-FTK_Single Package (without prerequisites): This executable file installs only the kit

contents, which includes kit code examples, hardware files, and user documents.

Download the kit installer ISO file and create an installer CD, or extract the ISO using WinRar and

install the executables.

2. Click Install CY3270-FTK to start the installation as shown in Figure 2-1.

10 CY3270 PSoC® FirstTouch™ Kit Guide, Document No. 001-15945 Rev. *D

Getting Started

Figure 2-1. Kit Installer Menu

Note If auto-run does not execute, double-click cyautorun.exe file on the root directory of the CD as

shown in Figure 2-2.

Figure 2-2. Root Directory of the CD

3. The InstallShield Wizard screen appears. On this screen, choose the folder location to install

the setup files. You can change the location of the folder for the setup files using Change as

shown in Figure 2-3.

4. Click Next to launch the kit installer.

Inhaltsverzeichnis

Andere Cypress Semiconductor Computerhardware Handbücher

Cypress Semiconductor

Cypress Semiconductor AutoStore STK14CA8 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor PSoC CapSense CY8CKIT-031 Handbuch

Cypress Semiconductor

Cypress Semiconductor CY7C1345G Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor CY7C1007BN Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor FM0+ S6E1C Series Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor Perform STK16C88-3 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor MoBL CY62128E Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor CY8C23533 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor CY7C1218H Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor CY7C1217H Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor STK12C68-5 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor NoBL CY7C1352G Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor CY7C1410AV18 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor STK11C68 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor Perform STK12C68 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor FLEx36 CY7C0850AV Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor CY7C1411JV18 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor CY7C2563KV18 Kurzanleitung

Cypress Semiconductor

Cypress Semiconductor Perform CY7C1380D Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor CY7C1510KV18 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor MoBL CY62157EV30 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor CY7C1241V18 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor Perform CY7C1561V18 Bedienungsanleitung

Cypress Semiconductor

Cypress Semiconductor NoBL CY7C1471V25 Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
