2 D-Link DPH-50U Quick Install Guide

Package Contents

System Requirements

DPH-50U

D-Link USB VoIP Adapter for Skype™

RJ-11 Phone Cable USB 2.0 Cable

CD-ROM with User Guide

* If Skype™is not already installed on your computer, please insert the CD and click “Install

Skype” or visit http://www.skype.com to download latest version and follow the instructions

there to install Skype™. Verify that Skype™is working before installing the DPH-50U adapter.

An available Broadband connection

400MHz processor or higher

At least 128MB RAM

10MB Available Hard Drive Space

CD-ROM Drive

A valid Skype™account*

If any of the above items are missing, please contact your reseller.

3D-Link DPH-50U Quick Install Guide

Front Panel

Rear Panel

Power

A solid blue light indicates that

the device is receiving power.

USB Connection

Connect the supplied USB cable into this slot and the

other into an available USB port on your computer.

VoIP

A solid light indicates a

VoIP call.

PSTN

A solid light indicates a

PSTN call.

4 D-Link DPH-50U Quick Install Guide

Installation

Do not connect the DPH-50U to your computer until

instructed to do so by the DPH-50U installation wizard.

Insert the supplied CD into your PC CD-ROM drive. The installation should

start automatically. If you do not have Skype™installed, click Install Skype

before installing the phone adapter driver.

Click Install Driver.

• For Windows®2000 installation instructions,

continue to page 5.

• For Windows®XP installation instructions,

continue to page 13.

• For Windows®Vista installation instructions,

continue to page 18.

5D-Link DPH-50U Quick Install Guide

Click Next to continue

Windows®2000 Installation

Click Accept to continue

Click Next

Select the application target folder

by clicking the Browse button.

You will see the End User License

Agreement.

6 D-Link DPH-50U Quick Install Guide

Click Finish

Click Install

Connect the USB cable to the

DPH-50U adapter USB port.

7D-Link DPH-50U Quick Install Guide

The other end of the USB cable must be connected to a USB port on your

computer as shown or to a powered USB hub.

If the Found New Hardware Wizard window appears, click Next.

Click Next

Select Search for a suitable

driver for my device

(recommended)

Click Next

8 D-Link DPH-50U Quick Install Guide

Select Specify a location

Click Next

Click OK

Leave the default value intact, do

not select the Browse button.

Click Next

9D-Link DPH-50U Quick Install Guide

Click Finish

Click Next

Select Search for a suitable

driver for my device

(recommended)

Click Next

10 D-Link DPH-50U Quick Install Guide

Select Specify a location

Click Next

Click OK

Leave the default value intact, do

not select the Browse button.

Click Next
