2D-Link DHP-347AV User Manual
Table of Contents
Product Overview.............................................................. 3
Package Contents......................................................................... 3
System Requirements................................................................. 3
Introduction ................................................................................... 4
Features............................................................................................ 4
DHP-306AV Hardware Overview.............................................5
LEDs ........................................................................................... 5
Connection ............................................................................. 6
DHP-346AV Hardware Overview.............................................7
LEDs ........................................................................................... 7
Connection ............................................................................. 8
DHP-346AV Ethernet Port Trac Priority ............................. 9
Hardware Installation .....................................................10
Push Button Security.......................................................11
Using the Setup Wizard...................................................12
Conguration...............................................................................13
Security ..........................................................................................15
Troubleshooting ..............................................................17
DHP-346AV Technical Specications .............................18
DHP-306AV Technical Specications .............................19
Contacting Technical Support ........................................20
Warranty...........................................................................21
Registration .....................................................................26
Table of Contents
3D-Link DHP-347AV User Manual
Section 1 - Product Overview
One D-Link DHP-306AV PowerLine AV Network Adapter
One D-Link DHP-346AV PowerLine AV 4-Port Switch
Two CAT5 Ethernet Cable
CD-ROM with Software and User Manual
Power Cord
Quick Install Guide
System Requirements
Product Overview
Package Contents
• Windows® 7, Windows Vista®, XP (with Service Pack 3)
• PC with 233MHz Processor, 64MB Memory
• Ethernet Adapter (100Mbit/s)
4D-Link DHP-347AV User Manual
Section 1 - Product Overview
Introduction
Features
• Provides Ethernet to PowerLine Connection
• Fast Data Transfer Rate of up to 200Mbps*
• Four 10/100 Ethernet Ports (DHP-346AV)
• One 10/100 Ethernet Port (DHP-306AV)
• Plug & Play, Easy Installation
• Easy to use Management Utility
• Firmware Upgrade Support
• Push Button Security
• Power Saving mode
* Maximum throughput based on theoretical transmission PHY rate. Actual data throughput will vary. Network conditions and environmental factors, including volume of trac and network
overhead, may lower actual data throughput rate. Interference from devices that emit electrical noise, such as vacuum cleaners and hair dryers, may adversely aect the performance of this
product. This product may interfere with devices such as lighting systems that have a dimmer switch, short wave radios, or other PowerLine devices that do not follow the HomePlug AV standard.
D-Link announces the PowerLine AV 4-Port Switch Starter Kit which uses the electrical wiring that’s already in your house to provide fast, reliable
speeds of up to 200Mbps* to any room in the house. Simply connect one adapter into an existing power outlet, connect it to your home network
router, and plug another adapter into any other room in your house to get instant shared network connections. With 4 Ports, you can connect more
devices per room and get blazing speeds in each room without tripping over tangled, messy wires. It’s cable management at its best.
5D-Link DHP-347AV User Manual
Section 1 - Product Overview
DHP-306AV Hardware Overview
LEDs
1Power LED
• Solid - Indicates that the device is receiving electrical power.
• Blinking - Indicates that the device is setting itself up after reset or when the security
button was pressed or power saving mode enabled.
• O - The device is not receiving electrical power.
2Home Plug
• Solid - The device is connected to a PowerLine network.
• Blinking - The device is transmitting data.
• O - The device has not found any other compatible PowerLine devices using the
same encryption key.
The color indicates the PowerLine link rate:
• Green - The PowerLine link rate is faster than 80 Mbps.
• Amber - The PowerLine link rate is between 50 Mbps and 80 Mbps.
• Red - The PowerLine link rate is less than 50 Mbps.
3Ethernet LED
• Solid - The Ethernet port is linked but there is no data trac.
• Blinking - The device is transmitting data.
• O - There is no Ethernet connection.
1
123
6D-Link DHP-347AV User Manual
Section 1 - Product Overview
DHP-306AV Hardware Overview
Connection
3
1Security Button Press to secure your network. Refer to page 8 for more information.
2Reset Button Press and hold the button for one second to reset to factory default.
3Ethernet Port Connect the CAT5 Ethernet cable to the DHP-306AV Ethernet port.
2
1
7D-Link DHP-347AV User Manual
Section 1 - Product Overview
DHP-346AV Hardware Overview
LEDs
1Power LED
• Solid - Indicates that the device is receiving electrical power.
• Blinking - Indicates that the device is setting itself up after reset or security button
was pressed or power saving mode enabled.
• O - The device is not receiving electrical power.
2PowerLine LED
• Solid - The device is connected to a PowerLine network.
• Blinking - The device is transmitting data.
• O - The device has not found any other compatible PowerLine devices using the
same encryption key.
The color indicates the PowerLine link rate:
• Green - The PowerLine link rate is faster than 80 Mbps.
• Amber - The PowerLine link rate is between 50 Mbps and 80 Mbps.
• Red - The PowerLine link rate is less than 50 Mbps.
3LAN LEDs (1-4)
• Solid - The Ethernet port is linked but there is no data trac.
• Blinking - The device is transmitting data.
• O - There is no Ethernet connection.
123
8D-Link DHP-347AV User Manual
Section 1 - Product Overview
DHP-346AV Hardware Overview
Connection
1Ethernet Ports (1-4) Connect the CAT5 Ethernet cable to the selected Ethernet port in accordance to priority.
2Security Button Press to secure your network. Refer to page 8 for more information.
3Reset Button Press and hold the button for one second to reset to factory default.
4Power Receptor Receptor for the supplied power cord.
3
1
2
4
9D-Link DHP-347AV User Manual
Section 2 - Installation
DHP-346AV Ethernet Port Trac Priority
When connecting devices to your ethernet ports, be aware of the Quality of Service (QoS) priorities assigned to each port.
1
2
43
Port Color Description
1 & 2 Yellow Both ports have medium priority and are best for networking data devices such as printers.
3Purple Has a high priority. You can connect devices such as game consoles to this port.
4Light Green Has the highest priority and gives uninterrupted service to the connected devices such as media
players or Internet TV.
10D-Link DHP-347AV User Manual
Section 2 - Installation
5V---3A
1 2 LAN 3 4 INTERNET USB
RESET
INTERNET
Hardware Installation
Step 1
Plug the PowerLine AV Network Adapter (DHP-306AV) into an AC Wall outlet. Connect the included Ethernet cable to the network cable connector
located on the PowerLine AV Network Adapter and attach the other end of the Ethernet cable to the network devices (e.g. Router).
Step 2
Connect the supplied power cord into the power receptor located on the back of the PowerLine AV 4-Port Switch.
Note: Power source is conrmed when the green LED Power Indicator on both the PowerLine AV 4-Port Switch and the PowerLine AV Network
Adapter are illuminated.
Step 3
Connect the included Ethernet cable to the network cable connector located on the PowerLine AV 4-Port Switch (DHP-346AV) and attach the other
end of the Ethernet cable to the game console, media player, Internet TV or Computer.
Note: Network Connectivity is conrmed when the PowerLine and Ethernet LED indicators on the PowerLine AV 4-Port Switch are illuminated.
Wireless Router Cable/ DSL
Modem
TV
Blu-ray DVD Player
Game Console
NAS Storage
DHP-346AV
Network Diagram
DHP-306AV
