D-Link DAP-1665 Bedienungsanleitung

Wireless AC1200 DuAl BAnD ACCess Point

DAP-1665

QUICK

INSTALLATION

GUIDE

GUIDE D’INSTALLATION

DAP-1665

ENGLISH

CONTENTS OF

PACKAGING

WIrElESS AC1200 DuAl BAND ACCESS POINT

DAP-1665

Note: With two detachable antennas.

12V 1A POWEr ADAPTEr (INCluDING 2 ADAPTErS)

SUPPLIES POWER TO THE DAP-1665

ETHErNET CABlE (CAT5 uTP)

use to ConneCt to Your CoMPuter

If any of the above items are missing, please contact

your reseller.

WI-FI CONFIGurATION NOTE

CONTAINS THE AP's DEFAULT WI-FI INFORMATION

PrODuCT MANuAl ON CD

Wi-Fi Conguration Note

DAP-1665 3

ENGLISH

PrODuCT

SETuP

ProDuCt instAllAtion

CONNECT THE DAP-1665

Using the included Ethernet cable, plug one end into the LAN port on

the back of the DAP-1665, and plug the other end into the Ethernet

port on your computer. Alternatively, you can connect to the DAP-1665

using Wi-Fi. Go to your computer's WiFi settings. Select the network

name (SSID) that is printed on the included Wi-Fi Conguration Note

(e.g. dlink-A8FA), then enter the Wi-Fi password also printed on the

Wi-Fi Conguration Note (e.g. akbdj19368).

TurN ON THE POWEr

Plug the supplied power adapter into the back of the DAP-1665 and

connect it to a power outlet. Press the power switch at the back of

the access point to turn on the power. Wait about 30 seconds for the

device to complete startup processes.

POSITION THE ACCESS POINT (AP)

Place the access point in an open area of your intended work area for

better wireless coverage. If you are using it as a repeater, you should

ensure that the access point is within wireless range of the network

which you wish to repeat.

ProDuCt ConFiGurAtion (WeB-BAseD utilitY)

To congure, open a web browser (such as Internet Explorer) from a PC or Notebook. and enter http://

dlinkap.local. in the address bar. This will direct you to the web-based configuration utility. The default

username is Admin and the password field should be left blank. Click Log In to continue. Once logged

in, click Launch Wireless Setup Wizard to commence the setup process. For further information on

conguring your access point, please refer to the included user manual.

USERNAME: Admin

PASSWORD: (blank by default)

If you have more than one access point, enter http://dlinkapxxxx, or http://dlinkapxxxx.local.

(where xxxx represents the last four digits of the access point’s MAC address, which is located on

the label on the bottom of the device).

DAP-1665

ENGLISH

TrOuBlESHOOTING

setuP AnD ConFiGurAtion ProBleMs

1. WHY CAN'T I ACCESS THE WEB-BASED CONFIGurATION uTIlITY?

- Check the physical connection between your computer and the access point. The LAN LED

on the access point should be illuminated, indicating that a connection is present. You should

also ensure that your computer's Ethernet port is enabled and functioning correctly.

- If you are using Wi-Fi to connect to the access point, ensure that you are connected to the

correct wireless network, and that there are no connectivity problems. If you are still unable to

access the conguration utility, try connecting to the access point using the included Ethernet

cable.

2. HOW DO I rESET MY DAP-1665 AP TO FACTOrY DEFAulT SETTINGS?

- Ensure the access point is powered on.

- Press and hold the reset button on the rear of the device for 10 seconds.

Note: Resetting the AP to the factory default will erase the current conguration settings. You

should repeat the setup process described in the installation guide above to recongure your

access point.

3. HOW DO I ADD A NEW WIrElESS ClIENT Or PC IF I HAVE FOrGOTTEN MY

WIrElESS NETWOrK NAME (SSID) Or WIrElESS ENCrYPTION KEY?

- If you have not changed your Wi-Fi settings from the factory defaults, you can use the

information listed on the provided Wi-Fi Conguration Card to connect to the access point.

- If you have changed your Wi-Fi settings, you should access the web-based conguration utility

as described on the previous page, and complete the setup wizard again to renew your wireless

settings.

- Make sure you write down these settings so that you can enter them into each wirelessly

connected device.

teCHniCAl suPPort

United Kingdom (Mon-Fri) , Website: http://www.dlink.com

Home Wireless/Broadband 0871 873 3000 (9.00am–06.00pm, Sat 10.00am-02.00pm)

Managed, Smart, & Wireless Switches, or Firewalls 0871 873 0909 (09.00am- 05.30pm)

(BT 10ppm, other carriers may vary.)

Ireland (Mon-Fri), Website: http://www.dlink.com

All Products 1890 886 899 (09.00am-06.00pm, Sat 10.00am-02.00pm)

Phone rates: €0.05ppm peak, €0.045ppm off peak times

TECHNICAL SUPPORT

UK www.dlink.com

IRELAND www.dlink.com

GERMANY www.dlink.com

FRANCE www.dlink.com

SPAIN www.dlink.com

ITALY www.dlink.com

NETHERLANDS www.dlink.com

BELGIUM www.dlink.com

LUXEMBURG www.dlink.com

POLAND www.dlink.com

CZECH www.dlink.com

HUNGARY www.dlink.com

NORWAY www.dlink.com

DENMARK www.dlink.com

FINLAND www.dlink.com

SWEDEN www.dlink.com

GREECE www.dlink.com

PORTUGAL www.dlink.com

Ver. 1.02(EU)_90x130 2014/08/28 290726001665A18

WIRELESS NETWORK REMINDER

Wireless Network Name (SSID)

Wireless Network Password
