Dacor EG366 Bedienungsanleitung

Grill Placement and Use

Grill Models: AEGR3648 and AGRG14 INSTRUCTIONS

Cooktop and Range Models:

ER30D, ER30G , EG366, ER36D, EG486 and ER48D

Part No. 102331 Rev. C

WARNING: Do not touch the grill when hot.

WARNING: Do not use water on grease res. A violent steam explosion may result. Smother any

ames with a lid, cookie sheet or at tray. Use baking soda or a foam extinguisher to extinguish am-

ing grease. Be careful to avoid getting burned.

WARNING: Non-stick coatings, when heated, can be harmful to birds. Remove birds to a separate,

well-ventilated room during cooking.

CAUTION: Place the grill only in the position shown below. Do not turn the burners under the grill

higher than the “MAX GRIDDLE” setting. Setting the burner ames too high or putting the grill in the

wrong position may damage it permanently.

Grill Placement and Use

Page 2

Instructions

STEP 1: Before using the grill for the rst time, wash it in hot soapy water. Rinse it and allow it to dry

thoroughly.

STEP 2: Make sure all burners are off and the cooktop or range is cool to the touch. Put the grill over the

top of the grates on the cooktop or range in the position shown. The grease trap goes toward the

back. Fit the tabs that stick out of the bottom of the feet into the inside corners of the grate. When

correctly installed, the grill will rest securely about 1/2” above the top surface of the grate. It may

rock back and forth slightly, which is normal.

STEP 3: Set one of the burners under the grill to the light (high) position. Once lit, turn the knob to the

MAX GRIDDLE position, or lower if desired. DO NOT keep the burner knobs higher than the MAX

GRIDDLE setting after they are lit!

STEP 4: Repeat Step 3 for the other burner under the grill.

STEP 5: During cooking be careful with metal utensils on the surface because they can scratch the non-

stick coating. See back for cleaning instructions.

After each use, wash the grill thoroughly in hot soapy water to avoid stains from grease build-up.

The grill is coated with a non-stick coating for easy cleaning. Warm water and liquid detergent are

all that are needed for cleaning. Remove stubborn spots with a non-abrasive plastic mesh pad.

To prevent scratching, do not use abrasives or abrasive cleaners.

Cleaning the Grill

Line up bottom of grill

with top of grate

EG366 and EG486

Grease trap

toward back

Put over center burners

Grill Placement and Use

Page 3

Line up bottom of grill

with top of grate

ER36D and ER48D Grease trap

toward back

Grease trap

toward back

Put over center burners

Line up bottom of grill

with top of grate

CAUTION: For grills used with model ER30G,

the kit comes with two extra knobs marked

with the words “MAX GRIDDLE” that must be

installed on the two right valve stems prior to grill

use:

Remove the two existing right knobs by grasping 1.

them and pulling straight back.

Put the new knobs with the words “MAX 2.

GRIDDLE” on the shafts. When installing them,

align the “D-shaped” opening on the back of the

knob with the end of the valve shaft. Carefully push

the knob on until it stops. The old knobs may be

discarded.

ER30D and ER30G

Put over right burners

Model ER30D shown.

Front panel style varies

with model.

Dacor ● 1440 Bridge Gate Drive, Diamond Bar, CA 91765 ● Tel: (800) 793-0093 ● FAX: (626) 403-3130 ● www.Dacor.com
