Daewoo FR-063 Bedienungsanleitung

S/M No. : FR06300010

✔ Caution :

In this Manual, some parts can be changed for improving, their

performance without notice in the parts list. So, if you need the

latest parts information,please refer to PPL(Parts Price List) in

Service Information Center (http://svc.dwe.co.kr).

DAEWOO ELECTRONICS Corp.

Mar. 2004

http : //svc.dwe.co.kr

Service Manual

Refrigerator

MODEL :

FR-063

FR-063R

FR-064

FR-064R

FR-065S

1. SPECIFICATION.......................................................................................................2

2. EXTERNAL VIEW .....................................................................................................3

3. WIRE DIAGRAM.......................................................................................................4

4. NAME OF PARTS......................................................................................................5

5. REFRIGERANT CYCLE DIAGRAM ...........................................................................6

6. MACHINE ROOM VIEW AND PARTS LIST................................................................7

7. MAIN COMPONENTS...............................................................................................8

8. DOOR COLOR SPECIFICATION...............................................................................9

9. EXPLODED VIEW AND PARTSLIST .......................................................................13

CONTENTS

SPECIFICATION

MODEL NAME FR-06

R12 50g

Refrigerant

R134a 55g

Cooling System Aluminum-embossedPlat ì Roll Bondî type

Refrigeration System Natural Cold-air Convention

Defrost System Natural

Defrost Operation Manual start & Stop

Cold Control Adjustable Dial

Freezer -

Refrigerator -

Capacity

Total 45

Height 511

Width 440

External Dimension

depth 452

Net Weight 16

EXTERNAL VIEW

861 370

101.5 208 30

440 400

440

511

182159

25 475 75

WIRE DIAGRAM

BROWN

THERMOSTAT

P-RELAY

COMPRESSOR

YELLOW

PLUG

L/BLUE

NAME OF PARTS

1 2 3 5 7 4 6

1 Evaporator

2 Control Box

3 Plastic Shelf

4 Magnetic Door Seals

5 Ice Tray

6 Bottle Rack

7 Usable Rack

REFRIGERANT CYCLE DIAGRAM

EVAPORATOR

DRYER

CAPI-TUBE

SUCTION PIPE

COMPRESSOR

SIDE PIPE

MACHINE ROOM VIEW AND PART LIST

5 4

14 13

NO PART NAME NO PART NAME NO PART NAME

1 CABINET 7 SUCTION PIPE 13 WASHER *T

2 REINFORCE *L 8 PIPE CON 14 ABSORBER

3 REINFORCE *R 9 BASE COMP 15 WASHER *U

4 COMPRESSOR 10 BOLT HEX 16 MACHINE SCREW

5 DRYER 11 P RELAY AS 17 TAPPING SCREW

6 CAPI TUBE 12 POWER CORD

MAIN COMPONENTS

1.COMPRESSOR

Refrigerant R12

Voltage

100V/50,60

E110V/60 115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50

Comp model DS22LCF1 DS22LCF1 DS22LCF1 DS22LCF1 DS22LCS8 DS22LCS8 DS22LCS8 DS22LCS8

Part Code

3951122X10 3951122X10 3951122X10 3951122X10 3954122X80 3954122X80 3954122X80 3954122X80

Start type RSIR RSIR RSIR RSIR RSIR RSIR RSIR RSIR

Refrigerant R134a

Voltage

100V/50,60

110V/60 115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50

Comp model DS25LHF0 DS22LHF1 DS22LHF1 DS25LHF2 DS22LCS8 DS22LCS8 DS22LCS8 DS22LCS8

Part Code

3951125Y00

3951125Y10

3954107F50

Start type RSIR RSIR RSIR RSIR RSIR RSIR RSIR RSIR

2. RELAY ASSEMBLY

Refrigerant R12

Voltage

100V/50,60 110V/60 115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50

Relay model

197SHB,S068

129RFB,S220

Part Code

3018101411

3018123030

Refrigerant R134a

Voltage 100V/50,60 110V/60 115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50

Relay model

734RFB,S068

174SHB,S068

213THB,S0

129SHB,S220

Part Code

3018122250

3018108140

3018102122 3018123121 3018123080

3018123080

3018122201 3018122201

3.CONTROL SWITCH

Refrigerant R12

Voltage

100V/50,60 110V/60 115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50

Relay model

PFN-110U-02A PFN-110U-02A PFN-110U-02A PFN-110U- 02A PFN-110U-02A PFN-110U-02A PFN-110U-02A PFN-110U-02A

Part Code 4004V70142 4004V70142 4004V70142 4004V70142

4004V70142 4004V70142 4004V70142 4004V70142

Refrigerant R134a

Voltage 100V/50,60 110V/60 115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50

Relay model

PFN-110U-02S PFN-110U-02D PFN-110U-02D PFN-110U-02D PFN-110U-02D PFN-110U-02D PFN-110U-02D PFN -110U-02D

Part Code 3018303120 3018303100 3018303100 3018303100 3018303100 3018303100 3018303100 3018303100

4. DRYER

Refrigerant R12 R134a

Spec. 10g 10g

Part code 3016801301 3016801301

Hz Hz Hz

HzHzHz Hz

HzHzHzHzHzHzHz

Hz HzHzHzHzHzHz

MAIN COMPONENTS

POWER CORD SPECIFICATION

NO SHAPE OF POWER CODE PART CODE DESCRIPTION REMARK

1 3011300321 CP-2PIN

2 4017J17101 CP-2PIN

4006D17101 KP-30

3011304520 DKP-301U

4 401PD17101 KP-211

5 3011316201 BP-3PIN

3011300971 FOR SWISS

3011303020

#267

FOR OTHER CONURTY

7 3011316101 FOR ISRAEL

3011303901 FOR EUROPEAN&SAUDI

3011303921 FOR SINGAPORE

3011303040

BS-1363A

FOR OTHER COUNTRY

9 3011301171
