Daewoo DTC Series Bedienungsanleitung

MODEL NO.

DTC-14Q1/14Q1T/20Q1/20Q1T/21Q1/21Q1T

14Q2/14Q2T/20Q2/20Q2T/21Q2/21Q2T

14Q3/14Q3T/20Q3/20Q3T/21Q4/21Q4T

14Q6/14Q6T/21Q8/21Q8T

14T1/14T1T/20T1/20T1T/21T1/21T1T

14T2/14T2T/20T2/20T2T/21T2/21T2T

14T3/14T3T/20T3/20T3T/21T5/21T5T/21T9/21T9T

Instruction

Manual

Instruction

Manual

IDENTITY OF FEATURES ON LOCALAND REMOTE CONTROL

LOCAL CONTROL

REMOTE CONTROL

VIDEO AUDIO

MAIN

POWER

BUTTON

VIDEO

INPUT AUDIO

INPUT HEAD

PHONE STAND-BY

INDICATOR REMOTE

SENSOR AV & MENU

BUTTON VOLUME

DOWN/UP

BUTTONS

PROGRAMME

DOWN/UP

BUTTONS

Front

SLEEP RECALL

SKIPMOVEDEL

TIME MODE

NORMAL

123

456

TELETEXT mode

POWER

NUMBER 0-9

TEXT MIX

PAGE UP

SUBPAGE

INDEX

PAGE DOWN

HOLD

MUTE

HALF TONE(MESH)

SIZE

CANCEL

G (VOLUME UP)

R (VOLUME DOWN)

TV/TEXT

C (BRIGHT UP)

Y (BRIGHT DOWN)

TV mode

POWER

NUMBER 0-9

PR (CURSOR)UP

VOLUME UP (CURSOR RIGHT)

OK(NORMAL)

PR(CURSOR) DOWN

VOLUME DOWN(CURSOR LEFT)

MUTE

RECALL

SLEEP

SKIP

MOVE

DELETE

TELETEXT

MODE

TIME

CONTENTS

* Identity of features on Local and Remote Control 1

* Important safeguards 2

* Installation 3

After moving the set 3

Inserting Batteries into the Remote Control Unit 3

Aerial connection 3

Mains connection 3

Switching the set on and off 3

Tuning the TV Channels 4

Edit 4

Manual Channel Setting 5

* Daily use 6

Selecting a Programme Number 6

Volume and Picture control 6

Timer 6

Sleep 7

Recall 7

Child Lock 7

Mode 7

OSD half tone (mesh) function 7

16:9 function 7

Local control key Mode 8

*Connecting the External Equipment 8

*TELETEXT 8

IMPORTANT SAFEGUARDS

Water / Moisture: Never install the set in the following places: in the bathroom, in a wet base-

ment.

Do not place any containers with liquid (e.g. flower vases) on the set.

Heat: Never place the set near heat sources (e.g. radiator).

Ventilation: Do not cover the ventilation openings in the cabinet.

Never place the set in a confined space such as a bookcase or built-in cab-

inet, unless proper ventilation is provided.

Object Entry: Do not insert foreign objects, such as needles and coins, into the ventila-

tion openings.

Lightning Striking: You should disconnect your set from the mains and the aerial system dur-

ing thunderstorms.

Cleaning: Unplug the set from the mains before cleaning.

INSTALLATION

AFTER MOVING THE SET

If the used set is moved or placed in a different direction, the

MAIN POWER button must be switched off for at least 15 min-

utes in order to take out a colour strain on the screen.

INSERTING BATTERIES INTO THE REMOTE CONTROL UNIT

Press down the battery compartment grip and slide the

cover.Insert the batteries supplied(two 1.5V, typeAA).

Make sure that the polarity matches with the (+) and (-) marks

inside of the battery compartment.

Used batteries should be disposed of properly.

AERIAL CONNECTION

For better picture and sound quality, an effective aerial installa-

tion is the most important.

If you are located in a relatively strong area, you will be able to

use the indoor aerial.

When using an outdoor aerial, it is usually connected to the set

by means of 75 ohm coaxial cable.

MAINS CONNECTION

Plug the mains cable into the power socket with

100~250V,50/60Hz AC.

SWITCHING THE SET ON AND OFF

Switching On

Switch the set on with the MAIN POWER button in front of the

receiver. The set will turn on.

If not, press either : - PR UP or DOWN button on the front of

set - or POWER button or the UP/DOWN button or one of the

NUMBER button 0..9 on the remote controller.

The STAND-BY INDICATOR will flicker during 5 times, after

then turn it off and a picture will appear on the screen.

Switching Off

Press POWER button on the remote controller to return the set

to its stand-by mode.

The STAND-BY INDICATOR will illuminate.

If you don't use the set for extended period of time, turn it off

with MAIN POWER button in front of the receiver.

AUTO SEARCH UHF >>

MAIN MANU


TIMER

LANGUAGE

PRESET

EDIT

PRESET

P01 P--

AUTOB/D

PRESET

P01 P--

AUTOB/D

EDIT

P SKIP P SKIP

00 ---- NO

01 ---- NO

02 ---- NO

03 ---- NO

04 ---- NO

05 ---- NO

06 ---- NO

07 ---- NO

08 ---- NO

09 ---- NO

EDIT

P SKIP P SKIP

00 ---- NO

01 ---- NO

02 ---- NO

03 ---- NO

04 ---- NO

05 ---- NO

06 ---- NO

07 ---- NO

08 ---- NO

09 ---- NO

DELETE 01

EDIT

P SKIP P SKIP

ARD

ZDF

BR3

SAT1

04 PR07 NO

05 RTL2 NO

06 ---- NO

07 ---- NO

08 ---- NO

09 ---- NO

MOVE 06

TUNING THE TV CHANNELS

MAIN MENU

Press the MENU button to call up the MAIN MENU.

The MAIN MENU is consist of 5 sub-menus:

PICTURE, TIMER, LANGUAGE, PRESET, EDIT menu.

LANGUAGE SELECTION

Select a LANGUAGE menu at the MAIN MENU by placing the

cursor on the LANGUAGE with UP/DOWN button and press-

ing the OK button. You can choose language you require with

UP/DOWN button.

Press the MENU button to return to the MAIN MENU.

AUTOMATIC TUNING SYSTEM

Select the PRESET menu at the MAIN MENU.

Place the cursor to ""with the RIGHT button.

Press and hold down OK button until the tuning screen appears

above the PRESET menu.

The cursor will move from left to right on the VHF-L line, then

VHF-H, then UHF

Please wait until the EDIT MENU appears.

EDIT

The EDIT menu shows you the programme position assignment.

You can change this programme position assignment accord-

ing to your personal preferences.

SKIPPING THE CHANNELS

You can select SKIP "YES" or "NO" with the SKIP button.

Aprogramme marked with SKIP "YES" is skipped when chang-

ing channel using the UP/DOWN button.Askipped programme

number selected by NUMBER button 0..9 will be displayed in

red.

DELETE PROGRAMME POSITION DATA

Position the cursor to programme number to delete with the

UP/DOWN, LEFT/RIGHT buttons.

Press the DEL button. While this is being carried out, the

"DELETE Prog. No." appear and the "deleted" programme is

moved to last programme number. And changed SKIP "YES".

The programme located in the last programme no. will move to

the upper programme no. automatically.

CHANGING THE ORDER OF THE CHANNELS

Position the cursor to programme number to move and press

the MOVE button. The "MOVE Prog. No." will appear.

Position the cursor to programme number to exchange and

press the MOVE button. Two programmes will be exchanged.

ENTER A STATION NAME, CHANGING THE PROGRAMME

NUMBER AND COPYING

A PROGRAMME

You can go to the PRESET menu directly for entering a station name

and changing the programme number and copying a programme to

another programme no. by pressing the OK button.

Refer to the MANUAL CHANNEL SETTING.

SEARCH UHF >>

PRESET

P01 P--

AUTOB/D

FINE TUNE UHF >>

PRESET

P01 P--

AUTOB/D

PRESET

P01 P--

AUTOB/D

PRESET

P01 P--

AUTOB/D

PRESET

P01 P02

AUTOB/D

----

BBC

STAR

SAU1

SAU2

MTV

B/D

I/M

SELECT PROGRAMME

You can also call up the PRESET menu at the MAIN MENU.

Press the NUMBER button 0..9 or UP/DOWN buttons to select a

programme number you want.

The screen will change according to the selected programme num-

ber.

SEARCHING A CHANNELS

At first, the sound and colour system have to be set according to

the broadcasting system.(ex, B/D,AUTO-----)

Locate a cursor to with LEFT/RIGHT button and then press

the UP or DOWN button.

The tuning screen will appear and the cursor will move from left to

right or from right to left.

Pressing and holding down the UP/DOWN button during 2 sec-

onds, the band will change as following:

VHF-L, VHF-H, UHF.

After searching a station, the tuning screen will disappear.

To stop searching, press the MENU button.

FINE TUNING

If you are unable to get a good picture or sound because of a poor

broadcasting signal, it is possible to adjust the fine tuning.

Move the cursor to and press UP or DOWN button to activate

fine tuning up or down.

It only operates while the UP or DOWN button is being pressed.

The changes is memorized automatically.

At this time, PR No will be changed from white to cyan.

ENTER A STATION NAME

Locate a cursor to with LEFT/RIGHT button, then station name

will be displayed on the screen.

Select station name in the station name list with UP/DOWN button

and press OK button.

If you Want to delete a station name, select “-----”.

If you can't find the desired name in the list, you can enter your

own.

To do so, move the cursor to the right and press OK button. Using

the UP/DOWN button, select the desired letter, number or blank.

Press the RIGHT button to select the next position.

Press the OK button to complete this procedure.

SELECT SOUND SYSTEM

If you heard strange sound or noise sound, then move the cursor

" with the LEFT/RIGHT button, sound system

table will be displayed on the screen. Select the sound system

" with the UP/DOWN button, then automatically

sound will be changed.

TO STORE PROGRAMME IN MEMORY

Move the cursor to the right end with the LEFT/RIGHT button.

Select the programme number that you want to store current dis-

playing programme with station name and system in memory using

the UP/DOWN button or NUMBER 0..9.

Press the OK button.

MANUAL CHANNEL SETTING

B/D I/M

TIMER

In the MAIN MENU, Select TIMER menu.

SETTING THE CLOCK

Press the button on the CLOCK line.

Set the hours and minutes with the NUMBER button 0..9. Press the OK

button to complete. The clock will start.

Note that if you turn the TV off with MAIN POWER button, the clock setting

is lost and must be reset if necessary.

SETTING THE WAKE UP TIME

Set WAKE UP TIME in a same way to the above for CLOCK.

Set ACTIVATE "YES" or "NO" with the LEFT/RIGHT button.

When ACTIVATE is "YES", the function is enabled.

Set WAKE UP PROG using the NUMBER button 0..9 or UP/DOWN but-

ton.

When WAKE UP TIME is operate, the set will switch on to this programme

number.


TIMER

CLOCK 12:20

WAKE UP TIME --:--

ACTIVATE YES

WAKE UP PROG P 45

TIMER

CLOCK 12:20

WAKE UP TIME 7:00

ACTIVATE YES

WAKE UP PROG P 45

DAILY USE

SELECTING A PROGRAMME NUMBER

The NUMBER button 0..9 are used for direct programme selection.

In order to select two-digit programme, press the second numbered

button within two seconds.

Switch through the programme number step by step with the

UP/DOWN button.

VOLUME AND PICTURE CONTROL

VOLUME CONTROL

Adjust the volume with the VOLUME DOWN/UP buttons on the

front of the set, or with the LEFT/RIGHT button on the remote con-

trol.

MUTE

Pressing the MUTE button once turns the sound off.

The sound returns if the button is pressed once more or the pro-

gramme no. is changed.

NORMAL PICTURE SELECTION

When you press the NORMAL button repeatedly you can call up

three picture settings;

for NORMAL I(hard picture), NORMALII(soft picture), FAVOURITE

(adjustable picture).

PICTURE CONTROL

Press the MENU button to call up the MAIN MENU.

Press the OK button to call up the PICTURE MENU.

You can select each function with the UP/DOWN buttons.

Use the LEFT/RIGHT button adjust each function:

BRIGHTNESS( )-COLOUR ( )-CONTRAST

( )-SHARPNESS( )-TINT( ).

*The TINT is active only in NTSC system.

The last set value is automatically stored in FAVOURITE mode.

Note that if you set the brightness and contrast values too low, the

On-screen-display become dark.

SLEEP

By pressing the SLEEP button repeatedly, you can select one of the fol-

lowing setting:

0->30min. ->60min.->90min.->120min.

The set will turn off after time you select.

Automatic Switch-Off in No broadcast Signal

If a broadcasting signal is not present for about 30 minutes, the set will be

automatically turned off.

In AV mode, however, this function dose not operate.

RECALL

The RECALL button is used to display the current status: programme

number, station name and clock.

This display appear for 5 seconds unless any button is pressed.

CHILD LOCK

You can prevent the use of the TV set without the remote control.

The set is child-locked after switching off the set by pressing the TIME,

MODE, , POWER button in sequence on the remote control within 5

seconds.

The child-lock function is indicated by flashing the STAND-BY INDICATOR.

The set can only be switched back on using the remote control.

Note that even though “WAKE UP TIME” is set to ACTIVATE : YES, TV

won’t be turned on while “CHILD LOCK” function is working.

MODE

Pressing the MODE button on the remote control, the current system of the

set will be displayed on the screen.

Whenever you press the MODE button, the system will changed as fol-

lowing

AUTO → PAL → SEC → N3 → N4 → N5

the red colour of OSD means that the colour system of TV set is in

“AUTO” mode.

OSD HALF TONE (MESH) FUNCTION

If you push the Recall key in menu, OSD SCREEN is toggled with OSD half

tone (mesh).

And then, menu is memoried at the last state.

16 :9 FUNCTION

If you push “SKIP” key except “TEXT” and “EDIT” mode, picture is toggled

16:9 or 4:3.

LOCAL CONTROL KEY MODE

You can call up the MAIN MENU, not only by using the Remote

Control but also by pressing the TV/VIDEO key during 3 sec-

onds at the local key.

Then MAIN MENU will be displayed on the screen.

In this mode Move the cursor to SUB MENU you want, and

press the TV/VIDEO key during 3 seconds, then SUB MENU

will be displayed on the screen, you can set the SUB MENU

you want by using the VOL UP DOWN key or CH UP DOWN

key.

If you want to return to last MENU state, Press the TV/VIDEO

key.

HEADPHONE JACK

Insert the headphone plug (3.5mm∅) into the headphone socket. The

sound from the speaker will be cut off.

AV MODE

Select AV mode by pressing the AV button.

Press the AV button to return to the TV mode.

CONNECTING THE EXTERNAL EQUIPMENT

NOTE

The front AV terminal and the backAV ter-

minal are common.

If you use the frontAV terminal, disconnect

the back AV terminal with the external

equipment.

TELETEXT

SWITCHING TELETEXT ON/OFF

Press the TELETEXT button ( ). The index page viewed last

will appear.

Press the TELETEXT button to return to the TV mode.

COLOUR BUTTONS IN TOP/FLOF TELETEXT

Ared, green, yellow and blue field is shown at the bottom of the

screen.

If TOP or FLOF teletext (FASTEXT) is transmitted by the sta-

tion, pressing the corresponding colour button on the remote

controller, you can select the desired page easily.

SELECTING PAGES

The NUMBER button 0..9 are used to enter a page number.

The selected page number appears at the top of the screen and

the page appears after a short time.

The UP/DOWN buttons increase or decrease the current page

number by 1.

INDEX PAGE

You can switch directly to the programme preview (with TOP

text) or the overview page of the station you are currently view-

ing by pressing the INDEX ( ) button.

PAGE HOLD

Several sub pages can be combined under a page number and

are scrolled at an interval determined by the television station.

The presence of sub pages is indicated by, for example, 3/6

beneath the time, which means that you are looking at the 3rd

page of a total of 6 pages.

If you want to look at a subpage for a longer period of time,

press the HOLD ( ) button.

The contents of the subpage shown are kept on the screen and

no longer updated or switched to other subpages.

Pressing the HOLD button again, the current subpage appear.

CALLING UP SUBPAGE DIRECTLY

Pressing the SUBPAGE ( ) button, "Page no./--"

appears at the bottom of the screen.

Enter the subpage number that you want to call up with the

NUMBER button 0..9, for example, the 2nd page, sequence

0002. The desired subpage is sought and displayed. To exit,

press SUBPAGE ( ) button again.

WATCHING TELEVISION DURING TELETEXT MODE

Some pages are continually update, for example, stock market

reports, sports announcements, and the latest news.

If you want to watch television and stay informed at the same

time, press CANCEL ( ) button.

The regular programme is still visible and the teletext symbol (

) appears at the top of the screen.

Pressing the CANCEL button again, the teletext page appears

with the update information.

REVEAL ANSWER

This function can be used on certain pages to reveal the solution

of riddles.

Press the REVEAL button ( ) to reveal a hidden answer and

press again to hide it.

DOUBLING CHARACTER SIZE

Repeatedly pressing the SIZE button ( ) doubles the character

size in the following order: Upper half of the page-> Lower half of

the page-> Return to normal size.

VOLUME AND BRIGHTNESS CONTROL IN TELETEXT MODE

ONLY IN MIX MODE

Pressing the MENU button in teletext mode, the volume and

brightness control menu will be displayed in the bottom of the

screen.

You can adjust volume and brightness using the corresponding

colour button on the remote controller.

TEXT MIX

Pressing theA/V ( ) button in teletext Mode , will be MIX/TEXT

TOGGLE.

Andere Handbücher für DTC Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Daewoo Fernseher Handbücher

Daewoo

Daewoo DTE-29G3ZZR Bedienungsanleitung

Daewoo

Daewoo DTC-14Q1TX Bedienungsanleitung

Daewoo

Daewoo DLP-2612 Bedienungsanleitung

Daewoo

Daewoo DTE-29 Series Benutzerhandbuch

Daewoo

Daewoo DTD-21H9 Bedienungsanleitung

Daewoo

Daewoo 2594ST Bedienungsanleitung

Daewoo

Daewoo CP-885 Bedienungsanleitung

Daewoo

Daewoo TVZ 1341X Bedienungsanleitung

Daewoo

Daewoo Super Vision 14A5 Bedienungsanleitung

Daewoo

Daewoo DTT-3250-100D Bedienungsanleitung

Daewoo

Daewoo DTQ-29M2FS Bedienungsanleitung

Daewoo

Daewoo DTB-21U6 Bedienungsanleitung

Daewoo

Daewoo DTQ 20D4AS Bedienungsanleitung

Daewoo

Daewoo DTQ-20J5FC Bedienungsanleitung

Daewoo

Daewoo CHASSIS : SC-150 Model : DSC-3220E Bedienungsanleitung

Daewoo

Daewoo DUA-3291GB Bedienungsanleitung

Daewoo

Daewoo DTQ 25G1TS Bedienungsanleitung

Daewoo

Daewoo DSC-3210E Bedienungsanleitung

Daewoo

Daewoo KR29M5-MT Bedienungsanleitung

Daewoo

Daewoo DTA-14C4TFF Bedienungsanleitung

Daewoo

Daewoo DTQ-29U1SC Bedienungsanleitung

Daewoo

Daewoo DTJ-28G8F Bedienungsanleitung

Daewoo

Daewoo DTH-29U3 Bedienungsanleitung

Daewoo

Daewoo DTD-14D3 ME Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
