Daewoo DTP-28B1 Bedienungsanleitung

Service Manual

S/M No. : TWP895BEF0

DAEWOO ELECTRONICS CO., LTD

http : //svc.dwe.co.kr AUG. 2001

Colour Television

CHASSIS: WP-895

MODEL: DTP-28B1

- 2 -

1- Main Features

1-1 Specifications

TV standard PAL - SECAM B/G D/K, PAL I/I, SECAM L/L’

Sound system NICAM B/G, I, D/K, L,

FM 2Carrier B/G, D/K

Power consumption

28” 4:3, FST : 69 W approx.

Sound Output Power

28”: 7W x 2 (at 1kHz, 60% mod, 10%THD)

Speaker

28” : 12W 8 ohm x2

Teletext system 10 pages memory FASTEXT (FLOF or TOP)

Aerial input 75 ohm unbalanced

Channel coverageOff-air channels, S-cable channels and hyperband

Tuning system frequency synthesiser tuning system

Visual screen

28” : 66 cm

Channel indication On Screen Display

Program Selection 100 programmes

Aux. terminal EURO-SCART 1 : Audio / Video In and Out, R/G/B In, Slow and

Fast switching.

EURO-SCART 2 : Audio / Video In and Out, SVHS In.

AV3 : Audio-Video Jack on front of cabinet.

Headphone jack (3.5 mm) on front of cabinet

SVHS3 (option) : Jack on front of cabinet - sound input common with AV3.

Remote Control Unit R-46G22

28” 16:9, WIDE : 69 W approx.

Monitor Out(option)

CHASSIS NAME WP895

VCT VERSION 3834

SOFTWARE VERSION A

REMOTE CONTROL R46G22

PCB SERIAL NUMBER 4859805093

TUBE 16:09

SVHS3

"PICTURE IMPROVE-

MENTS, COMB FILTER,

HORIZONTAL SCALER"

TELETEXT SPLIT SCREEN

FORMATS AVAILABLE IN

VIDEO MODE

AUTO / 4:3 / 14:9 / ZOOM 14:9 /

ZOOM 16:9 / FULL SCREEN

AV2 MONITOR OUTPUT

MSP VERSION (OPTION) 3410 3411

SOUND EFFECTS OFF / SPATIAL OFF / SPATIAL

/ PANORAMA /

VIRTUAL

DOLBY

GRAPHIC EQUALIZER

AV3 AUDIO INPUT DEDICATED DEDICATED

TELETEXT PAGE MEMORY 10 PAGE

TOP TELETEXT AVAILABLE : SELECTABLE IN FACTORY/SERVICE MODE BY OPTION BITS

FLOF TELETEXT AVAILABLE : SELECTABLE IN FACTORY/SERVICE MODE BY OPTION BITS

TEXT CHARACTER

SUPPORT

"Pan-European Latin, Cyrillic, Greek"

OSD LANGUAGES "English, French, German, Italian, Spanish, Dutch, Danish, Finnish, Norwegian, Swedish, Greek, Polish, Hungarian, Czech, Slovakian, Roma-

nian, Russian."

TUNER OPTIONS "Philips, ALPS"

Specification matrix

21 Pin EURO-SCART 1 :

Pin Signal Description Matching value

1Audio Output Right 0.5 Vrms, Impedance < 1 , ( RF 54% Mod )

2Audio Input Right 0.5 Vrms, Impedance > 10

3Audio Output Left 0.5 Vrms, Impedance < 1 , ( RF 54% Mod )

4Audio Earth

5Blue Earth

6Audio Input Left 0.5 Vrms, Impedance > 10

7Blue Input 0.7 Vpp ±0.1V, Impedance 75

8Slow Switching TV : 0 to 2V, AV 16/9 : 4.5 to 7V, AV 4/3 : 9.5 to 12V ,

Impedance > 10

9Green Earth

10 N.C.

11Green Input 0.7 Vpp 0.1V, Impedance 75

12 N.C.

13Red Earth

14Blanking Earth

15Red Input 0.7 Vpp 0.1V, Impedance 75

16Fast Switching 0 to 0.4V : Logic “0”, 1 to 3V : Logic “1”, Impedance 75

17Video Out Earth

18Video In Earth

19Video Output 1 Vpp 3dB, Impedance 75

20Video Input 1 Vpp 3dB, Impedance 75

21Common Earth

21 Pin EURO-SCART 2 :

Pin Signal Description Matching value

1Audio Output Right 0.5 Vrms, Impedance < 1 , ( RF 54% Mod ) - Not available for cp885

2Audio Input Right 0.5 Vrms, Impedance > 10

3Audio Output Left 0.5 Vrms, Impedance < 1 , ( RF 54% Mod ) - Not available for cp885

4Audio Earth

5Earth

6Audio Input Left 0.5 Vrms, Impedance > 10

7N.C.

8Slow Switching TV: 0 to 2V, AV 16:9: 4.5V to 7V, AV 4:3: 9.5 to 12V

9N.C.

10 N.C.

11 N.C.

12 N.C.

13Earth

14Earth

15Chroma Input 3dB for a luminance signal of 1 Vpp

16 N.C.

17Earth

18Video In Earth

19Video Output 1 Vpp 3dB, Impedance 75 ( Monitor output ) - Not available for cp885

20Video Input,Y In. 1Vpp 3dB, Impedance 75

21Common Earth

CH EUROPE CCIR FRANCE GB(IRELAND) EAST OIRT

C01 46.25 - 47.75 49.75

C02 48.25 55.75 (L’) 53.75 59.25

C03 55.25 60.5 (L’) 61.75 77.25

C04 62.25 63.75 (L’) 175.25 85.25

C05 175.25 176.00 183.25 93.25

C06 182.25 184.00 191.25 175.25

C07 189.25 192.00 199.25 183.25

C08 196.25 200.00 207.25 191.25

C09 203.25 208.00 215.25 199.25

C10 210.25 216.00 223.25 207.25

C11 217.25 189.25 (LUX) 231.25 215.25

C12 224.25 69.25 (L’) 239.25 223.25

C13 53.75 76.25 (L’) 247.25 -

C14 - 83.25 (L’) 49.75 -

C15 82.25 90.25 57.75 -

C16 - 97.25 65.75 -

C17 183.75 - 77.75 -

C18 192.25 - 85.75 -

C19 201.25 - - -

C20 -- - -

C21 471.25 471.25 471.25 471.25

C22 479.25 479.25 479.25 479.25

C23 487.25 487.25 487.25 487.25

C24 495.25 495.25 495.25 495.25

C25 503.25 503.25 503.25 503.25

C26 511.25 511.25 511.25 511.25

C27 519.25 519.25 519.25 519.25

C28 527.25 527.25 527.25 527.25

C29 535.25 535.25 535.25 535.25

C30 543.25 543.25 543.25 543.25

C31 551.25 551.25 551.25 551.25

C32 559.25 559.25 559.25 559.25

C33 567.25 567.25 567.25 567.25

C34 575.25 575.25 575.25 575.25

C35 583.25 583.25 583.25 583.25

C36 591.25 591.25 591.25 591.25

C37 599.25 599.25 599.25 599.25

C38 607.25 607.25 607.25 607.25

C39 615.25 615.25 615.25 615.25

C40 623.25 623.25 623.25 623.25

C41 631.25 631.25 631.25 631.25

1-2 Channel table

FREQUENCY TABLE

CH EUROPE CCIR FRANCE GB(IRELAND) EAST OIRT

C42 639.25 639.25 639.25 639.25

C43 647.25 647.25 647.25 647.25

C44 655.25 655.25 655.25 655.25

C45 663.25 663.25 663.25 663.25

C46 671.25 671.25 671.25 671.25

C47 679.25 679.25 679.25 679.25

C48 687.25 687.25 687.25 687.25

C49 695.25 695.25 695.25 695.25

C50 703.25 703.25 703.25 703.25

C51 711.25 711.25 711.25 711.25

C52 719.25 719.25 719.25 719.25

C53 727.25 727.25 727.25 727.25

C54 735.25 735.25 735.25 735.25

C55 743.25 743.25 743.25 743.25

C56 751.25 751.25 751.25 751.25

C57 759.25 759.25 759.25 759.25

C58 767.25 767.25 767.25 767.25

C59 775.25 775.25 775.25 775.25

C60 783.25 783.25 783.25 783.25

C61 791.25 791.25 791.25 791.25

C62 799.25 799.25 799.25 799.25

C63 807.25 807.25 807.25 807.25

C64 815.25 815.25 815.25 815.25

C65 823.25 823.25 823.25 823.25

C66 831.25 831.25 831.25 831.25

C67 839.25 839.25 839.25 839.25

C68 847.25 847.25 847.25 847.25

C69 855.25 855.25 855.25 855.25

C70 863.25 863.25 863.25 863.25

C71 69.25 - - -

C72 76.25 - - -

C73 83.25 - - -

C74 90.25 - - -

C75 97.25 - - -

C76 59.25 - - -

C77 93.25 - - -

S01 105.25 104.75 103.25 105.25

S02 112.25 116.75 111.25 112.25

S03 119.25 128.75 119.25 119.25

S04 126.25 140.75 127.25 126.25

S05 133.25 152.75 135.25 133.25

S06 140.25 164.75 143.25 140.25

S07 147.25 176.75 151.25 147.25

S08 154.25 188.75 159.25 154.25

S09 161.25 200.75 167.25 161.25

CH EUROPE CCIR FRANCE GB(IRELAND) EAST OIRT

S10 168.25 212.75 - 168.25

S11 231.25 224.75 - 231.25

S12 238.25 236.75 - 238.25

S13 245.25 248.75 255.25 245.25

S14 252.25 260.75 263.25 252.25

S15 259.25 272.75 271.25 259.25

S16 266.25 284.75 279.25 266.25

S17 273.25 296.75 287.25 273.25

S18 280.25 136.00 295.25 280.25

S19 287.25 160.00 303.25 287.25

S20 294.25 - - 294.25

S21 303.25 303.25 - 303.25

S22 311.25 311.25 311.25 311.25

S23 319.25 319.25 319.25 319.25

S24 327.25 327.25 327.25 327.25

S25 335.25 335.25 335.25 335.25

S26 343.25 343.25 343.25 343.25

S27 351.25 351.25 351.25 351.25

S28 359.25 359.25 359.25 359.25

S29 367.25 367.25 367.25 367.25

S30 375.25 375.25 375.25 375.25

S31 383.25 383.25 383.25 383.25

S32 391.25 391.25 391.25 391.25

S33 399.25 399.25 399.25 399.25

S34 407.25 407.25 407.25 407.25

S35 415.25 415.25 415.25 415.25

S36 423.25 423.25 423.25 423.25

S37 431.25 431.25 431.25 431.25

S38 439.25 439.25 439.25 439.25

S39 447.25 447.25 447.25 447.25

S40 455.25 455.25 455.25 455.25

S41 463.25 463.25 463.25 463.25

1-3 ATSS sorting method

The TV set sweeps all the TV bands from beginning of VHF to end of UHF.The TV controlling software for each

program checks if a VPS CNI code is transmitted ( this system exists for German, Swiss and Austrian transmissions).

If no VPS CNI code is found, then the system check if a CNI code is transmitted as part of the teletext transmission

( Packet 8/30 format 1 ). If such a code ( VPS or teletext ) is found and if this code is in theATSS list, the program is

automatically named.

If the transmission does not haveVPS CNI, and no teletext service is available, then there is no possibility of the

program being automatically named.

The programs found are then sorted in 4 groups :

Group I : It contains all the programs from the selected country and named by the TV controlling software. Within this

group the sorting order is fixed bythe ATSS list.

Group II : It contains all the programs with a strong signal strength which are not listed in group I.

Group III : It contains all the programs with a weak signal strength which are not listed in group I.

Group IV : If two or more programs with the same code are found, only the strongest ( or if they have the same level

the one with the lowest frequency) is listed in group I, II or III. The others are listed in group IV.

Program

number

2Group I

...

n+1

... Group II

m+1

... Group III

p+1

... Group IV

q+1

.... not used

Group Skip Program

number

... Group II

m+1

... Group III

p+1

... Group IV

q+1

.... not used

Group Skip

Special case : Country selection = Others

Special case : France

Note :If two programs with the same name but a different code are found these two programs are listed in

group I, II or III ( e.g. Regional program SW3 in Germany ).

- 10 -

The sorting order within group II, III, and IV is based on the channel frequency.The Program with the lowest

frequency is allocated the first rank in its group, and so forth until the last program of the group which has the

highest frequency.

If France is selected, the TV controlling software first sweeps all TV bands with France system selected

( positive video modulation) and the a second time with Europe system selected ( negative video modulation).

Special case : Switzerland

If Switzerland is selected the TV controlling software first sweeps all TV bands with Europe system selected

(negative video modulation) and then a second time with France system selected ( positive video modulation).

Special case : GB

Note for satellite receiver users : Before starting ATSS turn On your satellite receiver and tune “ SKY NEWS ”.

If GB is selected the TV controlling software seeks for programs only in UHF ( C21 to C70 ).

The sorting order is :

1 - BBC1

2 - BBC2

3 - ITV

4 - CH4

5 - CH5

6 - NEWS

If two or more “ identical” programs ( same name but different code e.g. BBC1 and BBC1 Scotland ) are found

the following programs in the list will be shifted up. (1 - BBC1, 2 - BBC1, 3 - BBC2, 4 -ITV, 5 - CH4, 6 - CH5,

7 - NEWS, ..)

If one of the program above is not found, the associated program number remains empty

( freq.=467.25 Mhz - Skip selected - no name - system=GB).

example A : 1 - BBC1, 2 - BBC2, 3 - ITV, 4 - ----, 5 - CH5, 6 - NEW S, ...

example B ( if 2 BBC1 found ) : 1 - BBC1, 2 - BBC1, 3 - BBC2, 4 - IT V, 5 - -----, 6 - CH5, 7 -NEWS, ...

Special case : France

Inhaltsverzeichnis

Andere Daewoo Fernseher Handbücher

Daewoo

Daewoo DTQ-14V1FC Bedienungsanleitung

Daewoo

Daewoo DSC-3270E Bedienungsanleitung

Daewoo

Daewoo DTD-14D3 ME Bedienungsanleitung

Daewoo

Daewoo KR14E5/DTA-14V3VM Bedienungsanleitung

Daewoo

Daewoo DTH-211F Bedienungsanleitung

Daewoo

Daewoo KR29M5-MT Bedienungsanleitung

Daewoo

Daewoo DTK-28 Series Bedienungsanleitung

Daewoo

Daewoo DTH-21S7NAV Bedienungsanleitung

Daewoo

Daewoo DTQ-14P2FCM Bedienungsanleitung

Daewoo

Daewoo DTQ-14Q1 Bedienungsanleitung

Daewoo

Daewoo DTH-29M2FS Bedienungsanleitung

Daewoo

Daewoo DSC-3270E Bedienungsanleitung

Daewoo

Daewoo DTQ-29S5SC Bedienungsanleitung

Daewoo

Daewoo DTQ-20S1SSFV Bedienungsanleitung

Daewoo

Daewoo DDQ-9H1SC Bedienungsanleitung

Daewoo

Daewoo DTQ-29U1SC Bedienungsanleitung

Daewoo

Daewoo DTQ-29M2FS Bedienungsanleitung

Daewoo

Daewoo DTY-2896 TF Bedienungsanleitung

Daewoo

Daewoo DDT-21H9ZDF(21") Bedienungsanleitung

Daewoo

Daewoo DUA-3270GB Bedienungsanleitung

Daewoo

Daewoo DTC-29G1 Bedienungsanleitung

Daewoo

Daewoo DTU-14D3 Bedienungsanleitung

Daewoo

Daewoo DTE-29G3ZZR Bedienungsanleitung

Daewoo

Daewoo DDQ-20L6SCN Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
