Dallmeier DF5200HD-IR-ANPR Leitfaden

005748 / 1.0.5 / 2018-12-17

DF5200HD-IR-ANPR

Commissioning

English

The reproducon, distribuon and ulizaon of this document as well as the communicaon

of its contents to others without express authorizaon is prohibited.

Oenders will be held liable for the payment of damages.

Figures in this document may dier from the actual product.

We reserve the right to make technical modicaons.

The manufacturer accepts no liability for damage to property or pecuniary damages arising

due to minor defects of the product or documentaon, e.g. print or spelling errors, and for

those not caused by intenon or gross negligence of the manufacturer.

All trademarks idened by ® are registered trademarks of Dallmeier electronic.

All trademarks idened by *) are trademarks or registered trademarks of the following owners:

Google and Google Chrome of Google Inc. headquartered in Mountain View, California, USA;

JavaScript of Oracle Corporaon (and/or its aliates) headquartered in Redwood Shores, California, USA;

Microso, Internet Explorer, Microso Edge and Windows of Microso Corporaon headquartered in Redmond,

Washington, USA;

Mozilla and Firefox of Mozilla Foundaon headquartered in Mountain View, California, USA.

Third-party trademarks are named for informaon purposes only.

Dallmeier electronic respects the intellectual property of third pares and always aempts to ensure the complete iden-

caon of third-party trademarks and indicaon of the respecve holder of rights.

In case that protected rights are not indicated separately, this circumstance is no reason to assume that the respecve

trademark is unprotected.

This product includes soware developed by the OpenSSL Project for use in the OpenSSL Toolkit (hp://www.openssl.org)

and cryptographic soware wrien by Eric Young (eay@cryptso.com).

1× 1×

1×

1× 1×

1× 4× 4× 4× 1×

DF5200HD-IR-ANPR

www.dallmeier.com 5

Contents

1 Validity 6

2 Documents 6

This Document 7

Other Applicable Documents 7

3 TypographicalConvenons 8

4 SafetyInstrucons 10

5 General Notes 13

Scope of Delivery 13

Transportaon and Packaging 14

Warranty 14

Appropriate Use 14

Approvals/Cercaons 16

6 Requirements 17

Ambient Condions 17

Power Supply 18

7 Maintenance 19

8 InstallaonandCommissioning 20

9 Front View of Camera 32

10 WireColorCodeforPre-assembledPatchCable 33

11 ConneconandLogin 34

System Requirements 34

Connecon 35

12 TechnicalSpecicaons 38

13 PresetsandMounng 40

14 Dimensions 42

DF5200HD-IR-ANPR

6www.dallmeier.com

1 Validity

This document applies to the following devices:

• DF5200HD-IR-ANPR

Figures in this document may dier from the actual product.

2 Documents

The product documentaon contains several documents which are

included in the scope of delivery in a printed form and/or on a digital

medium.

Read all documents included in the scope of delivery carefully and thor-

oughly before using the device.

Always follow the contained instrucons, notes and warnings and ob-

serve the technical specicaons in the product data sheet.

Keep all documents in legible condion and in a suitable locaon for

future reference.

Regularly check the website www.dallmeier.com for the latest updates on

product documentaon.

DF5200HD-IR-ANPR

www.dallmeier.com 7

This Document

Commissioning

The document “Commissioning” (this document) contains detailed de-

scripons on installaon, connecon and commissioning of the device as

well as safety instrucons and general notes.

The target audience of this document is trained system integrators.

OtherApplicableDocuments

Data Sheet

The document “Data Sheet” contains detailed technical specicaons,

features and characteriscs of the device.

The target audience of the document is trained system integrators.

Conguraon

The document “Conguraon” contains detailed descripons on the con-

guraon of the device.

The target audience of the document is trained system integrators.

DF5200HD-IR-ANPR

8www.dallmeier.com

3 TypographicalConvenons

This document may contain various warning words and symbols that

indicate potenal sources of danger:

DANGER

DANGER indicates a hazardous situaon which, if not avoided, will

result in death or serious injury.

WARNING

WARNING indicates a hazardous situaon which, if not avoided, could

result in death or serious injury.

CAUTION

CAUTION indicates a hazardous situaon which, if not avoided, could

result in minor or moderate injury.

NOTICE

NOTICE is used to address pracces not related to physical injury.

DF5200HD-IR-ANPR

www.dallmeier.com 9

For reasons of clarity and readability, various text formang elements

and types of emphasis are used in this documentaon:

Instrucons are indicated by arrows (➡).

➡Always carry out instrucons one aer the other in the sequence

described.

“Expressions” in quotaon marks generally indicate a control element

on the device (switches or labels) or on its user interface (buons, menu

items).

Paragraphs in italics provide informaon on basic principles, special

features and ecient procedures as well as general recommenda-

ons.

DF5200HD-IR-ANPR

10 www.dallmeier.com

4 SafetyInstrucons

Only use the device if it is technically in proper working condion and for

the intended purpose while keeping safety and potenal dangers in mind.

• QualiedPersonnel

The installaon, mounng, connecon, commissioning and congura-

on of the device may only be carried out by qualied personnel.

This also applies to the maintenance, tesng and repair, whereat the

regulaons of the DIN VDE 0701 series of standards (repair, modica-

on and inspecon of electrical appliances) must be followed.

• Regulaons

The use of video and audio surveillance systems is, in general, strictly

regulated.

Inform yourself about the currently valid laws and regulaons regarding

data, worker and environmental protecon before using the device and

ensure compliance with them.

• System Components

Only use internal components that have been tested and approved by

Dallmeier.

Inappropriate internal components may cause malfuncons, damages

and data loss and may result in the loss of warranty.

• Modicaons

Do not make any modicaons to the hardware or soware that have

not been tested and approved by Dallmeier.

Inappropriate modicaons may cause malfuncons, damages and

data loss and may result in the loss of warranty.
