Danfoss FP715 Montageanleitung
FP715 Electronic 2-channel
full programmer for
heating & hot water
Installation & User Instructions
2
Index
Installation
Product specification 3
Installation 4
Wiring 5
DIL switch settings 5
Wiring Conversion 6-13
User
Your programmer 14
Preset programmes 14
Resetting the unit 15
24hr or AM/PM display 15
Setting the Time and Day 15-16
Accepting the preset programmes 16
Changing the preset programmes 17
Programming heating - 5/2 day 18-19
Programming heating - 7 day 20-21
Programming heating - 24 hour 22
Programming hot water 23
Running the programme 24
Temporary overrides 25
Changing clocks forward/back 26
Troubleshooting 27
Contact details 28
Central Heating
1HR override
Central Heating
MAN override
RESET
Central Heating
Mode SELECT
+1HR
MAN
+1HR
MAN
Hot Water
1HR override
Hot Water
MAN override
Hot Water
Mode SELECT
INDEX
3
Installation & Specification
Please Note:
This product should only be installed by a qualified
electrician or competent heating installer, and
should be in accordance with the current edition of
the IEEE wiring regulations.
Specification
Power supply 230 Vac, ±10%, 50/60 Hz
Switching action
2 x SPDT internally linked, Type 1B
Switch rating 230 V ac, 3(1)A
Battery back-up 24 hours minimum
Programme resolution 1 minute
Dimensions, mm (W, H, D) 135 x 88 x 32
Design standard EN 60730-2-7
Control Pollution Situation Degree 2
Rated Impulse Voltage 2.5kV
Ball Pressure Test 75°C
Product specification
Installation Instructions
4
Installation
Remove wallplate from unit by unscrewing the two
screws on the bottom edge of the unit.
From the top left hand corner of the wallplate, there
must be clearances of at least 140 mm to the right,
15mm to the left, 30mm above and 100mm below in
order to mount the plug-on module.
The wallplate must be securely mounted either directly
to the wall using suitable wood screws or to a flush
mounted 1-gang electrical accessory box using M3.5
screws.
Cable access can either be from behind for concealed
cabling, or from below for surface cabling. If surface
cable is used, cut out cable access slot on plug-on
module prior to mounting the module.
For wiring connections refer to diagram on page 5.
FP715 models are double insulated and do not require
an earth connection, however a parking terminal is
provided on the wallplate. This is clearly marked with
an Earth symbol.
Prior to mounting the plug-on module, DIL switches
on the rear of the plug-on module must be set. See
diagram on page 5 for available options.
Mount plug-on module to wallplate by locating tabs on
top of wallplate in apertures on rear of module, hinge
down and press firmly to wallplate before tightening
securing screws on bottom of wallplate.
Installation
5
CP715 FP715 (3028 12/01)
2 ON/OFFs
PUMPED
7 DAY or 24 HOUR
24 HOUR
3 ON/OFFs
GRAVITY
5/2 DAY
7 DAY
SW.1
SW.2
SW.3
SW.4
Wiring & DIL switch settings
Wiring
Always switch off mains first and never fit
programmer to a live wallplate.
For Wiring Conversion tables see - pages 6-13
Remember to tick the
INSTALLER SETTING box on
the inside flap label to notify
user in which
mode their unit
is set (24hr, 5/2
day or 7 day).
DIL Switch Settings
Before mounting the unit, ensure
the 4 DIL switches on the rear of
the unit have been moved to the
required settings
!
INSTALLER SETTING
24 Hour
5+2 Day
7 Day
6
WIRING CONVERSIONS
Wiring conversions can be used when replacing the following programmers
with the FP715. Some time controls are connected differently depending on
the type of system they are controlling. Consult the column headed “NOTE
Table A
DANFOSS RANDALL
FP715, CP715
(PUMPED)
MAINS DHW
OFF
HTG
OFF
DHW
ON
NL12 3
DANFOSS RANDALL 922/972 NL14 3
DANFOSS RANDALL 4033 7653 4
DANFOSS RANDALL SET 5 NL36 1
HORSTMANN 423, AMETHYST 7 & 10 2,3 1 4 6 5
HORSTMANN 424 GEM 2,3 1,10 6 9 4
HORSTMANN LEUCITE 423 & 424 2148 3
HORSTMANN 425 DIADEM NL36 1
HORSTMANN 525 & 527 NL36 1
HONEYWELL ST669 NL74 6
HONEYWELL ST6300 & ST6400 NL12 3
PEGLER SUNVIC SP50/SP100 NL14 2
POTTERTON EP2000, EP3000 NL12 3
RANDALL TSR3+3 3,6 7 2 5 1
RANDALL 3033 1,7 6 5 3 4
RANDALL 702 NL42 3
SANGAMO FORM 1 410 & 414 4,5 6 2 7 1
SANGAMO S409/1 N,1,3 L - - 2
7
This conversion ...” to determine whether Table A (pages 6-9) or Table B
(pages 10-13) should be used. If in any doubt, contact our Technical Services
Department before proceeding with the replacement. *Any wires connected
to switch COMMONS which are linked LIVE on existing wallplates must be
transferred to the LIVE terminal on the new wallplate.
HTG
ON
Wires other
than links
in these
terms got
to LIVE
NOTE
This conversion applies
only if....
An additional terminal
block may be required
where these discon-
nected leads (or pairs)
should be terminated
4LL
ABCD
625 Programmed
selectors UNLINKED
21-
425
7-- 8
7 5 8 Terminals 5,8 & 10 are LINKED
6 5 7 Terminals 5 & 7 are LINKED
425 Programme
selectors UNLINKED
425 Programme
selectors UNLINKED
385
4--
53- SS
4-5 Programme
selectors UNLINKED ABCD
4--
2--
165
83-
5--
8
Table A cont..
DANFOSS RANDALL
FP715, CP715
(PUMPED)
MAINS DHW
OFF
HTG
OFF
DHW
ON
NL12 3
SANGAMO S409/3 3,6 7 4 2 5
SATCHWELL LIBRA & DHP 2201 1285 6
SATCHWELL ET 1401 & 1451 1285 7
SMITHS IND. CENTROLLER 90 12- - 5
SMITHS IND. CENTROLLER 1000 NL12 3
SWITCHMASTER 800 & 805 NL42 3
SWITCHMASTER 900 & 9000 NL42 3
SWITCHMASTER SONATA NL36 1
VENNER CHC/W2 (WITH STAT) N,2,4 L - - 1
VENNER CHC/W2 (AIR STAT LINKED) N,2,4 L - - 1
VENNER VENOTROL 80M & 80PM
(WITH AIR STAT) N,3 L 1 4 2
VENNER VENOTROL 80M & 80PM
(AIR STAT LINKED) N,3 L 1 4 2
9
HTG
ON
Wires other
than links in
these terms
got to LIVE
NOTE
This conversion applies
only if....
An additional terminal
block may be required
where these discon-
nected leads (or pairs)
should be terminated
4LL
ABCD
1--
374
463
4-- 36
4-- Programme
selectors UNLINKED
1--
1-- Programme
selectors UNLINKED ABC
4--
A/S - - Used in a system having
independent control of water
and heating
A/S
3
3--
A/S - - A/S
5
5--
10
Table B
DANFOSS RANDALL
FP715, CP715
(PUMPED)
MAINS DHW
OFF
HTG
OFF
NL12
DANFOSS RANDALL 922/972 NL14
DANFOSS RANDALL 102/102E/102E7 5 3,6 - -
HORSTMANN 423 DIAMOND POTTERTON 423 N L,1,3 - -
HORSTMANN 424 DIAMOND N L,1,3 - -
HORSTMANN CORAL 423 & 424 2,3 1 - -
HORSTMANN 425 DIADEM NL36
HORSTMANN 525 & 527 NL36
HONEYWELL ST669 NL- -
POTTERTON EP2000, EP3000 NL12
RANDALL TSR2P 3 1,2 - -
RANDALL MKII R6 3 1,2 - -
DANFOSS RANDALL 3060 & 3020P 1,7 6 - -
RANDALL 701 NL42
DANFOSS RANDALL SET 2 NL36
SANGAMO M5 410 FORM 4 4,5 3 2 7
SANGAMO S409 FORMS 1 & 4 N,1,3 L - -
SANGAMO (EARLY MODEL) S410 FORM 4 N,2 L - -
SATCHWELL LIBRA 1285
