AB-QM DN 10-32
DN 15 Low Flow Normal Flow High Flow
L/h L/s GPM L/h L/s GPM L/h L/s GPM
20% 55 0,015 0,24 90 0,025 0,40 227 0,063 1,00
25% 69 0,019 0,30 113 0,031 0,50 284 0,079 1,25
30% 83 0,023 0,36 135 0,038 0,59 341 0,095 1,50
35% 96 0,027 0,42 158 0,044 0,69 397 0,110 1,75
40% 110 0,031 0,48 180 0,050 0,79 454 0,126 2,00
45% 124 0,034 0,54 203 0,056 0,89 511 0,142 2,25
50% 138 0,038 0,61 225 0,063 0,99 568 0,158 2,50
55% 151 0,042 0,67 248 0,069 1,09 624 0,173 2,75
60% 165 0,046 0,73 270 0,075 1,19 681 0,189 3,00
65% 179 0,050 0,79 293 0,081 1,29 738 0,205 3,25
70% 193 0,053 0,85 315 0,088 1,39 795 0,221 3,50
75% 206 0,057 0,91 338 0,094 1,49 851 0,236 3,75
80% 220 0,061 0,97 360 0,100 1,58 908 0,252 4,00
85% 234 0,065 1,03 383 0,106 1,68 965 0,268 4,24
90% 248 0,069 1,09 405 0,113 1,78 1022 0,284 4,49
95% 261 0,073 1,15 428 0,119 1,88 1078 0,300 4,74
100% 275 0,076 1,21 450 0,125 1,98 1135 0,315 4,99
105% 289 0,080 1,27 473 0,131 2,08 1192 0,331 5,24
110% 303 0,084 1,33 495 0,138 2,18 1249 0,347 5,49
115% 316 0,088 1,39 518 0,144 2,28 - - -
120% 330 0,092 1,45 540 0,150 2,38 ---
DN 20 Normal Flow High Flow
L/h L/s GPM L/h L/s GPM
20% 180 0.050 0.79 340 0.094 1.50
25% 225 0.063 0.99 425 0.118 1.87
30% 270 0.075 1.19 510 0.142 2.24
35% 315 0.088 1.39 595 0.165 2.62
40% 360 0.100 1.58 680 0.189 2.99
45% 405 0.113 1.78 765 0.213 3.37
50% 450 0.125 1.98 850 0.236 3.74
55% 495 0.138 2.18 935 0.260 4.11
60% 540 0.150 2.38 1020 0.283 4.49
65% 585 0.163 2.57 1105 0.307 4.86
70% 630 0.175 2.77 1190 0.331 5.24
75% 675 0.188 2.97 1275 0.354 5.61
80% 720 0.200 3.17 1360 0.378 5.98
85% 765 0.213 3.37 1445 0.401 6.36
90% 810 0.225 3.56 1530 0.425 6.73
95% 855 0.238 3.76 1615 0.449 7.11
100% 900 0.250 3.96 1700 0.472 7.48
105% 945 0.263 4.16 1785 0.496 7.85
110% 990 0.275 4.36 1870 0.519 8.23
115% 1035 0.288 4.55 - - -
120% 1080 0.300 4.75 - - -
DN 25 Normal Flow High Flow
L/h L/s GPM L/h L/s GPM
20% 340 0.094 1.50 540 0.150 2.38
25% 425 0.118 1.87 675 0.188 2.97
30% 510 0.142 2.24 810 0.225 3.56
35% 595 0.165 2.62 945 0.263 4.16
40% 680 0.189 2.99 1080 0.300 4.75
45% 765 0.213 3.37 1215 0.338 5.35
50% 850 0.236 3.74 1350 0.375 5.94
55% 935 0.260 4.11 1485 0.413 6.53
60% 1020 0.283 4.49 1620 0.450 7.13
65% 1105 0.307 4.86 1755 0.488 7.72
70% 119 0 0.331 5.24 1890 0.525 8.32
75% 1275 0.354 5.61 2025 0.563 8.91
80% 1360 0.378 5.98 2160 0.600 9.50
85% 1445 0.401 6.36 2295 0.638 10.10
90% 1530 0.425 6.73 2430 0.675 10.69
95% 1615 0.449 7.11 2565 0.713 11. 29
100% 1700 0.472 7.48 2700 0.750 11.88
105% 1785 0.496 7.85 2835 0.788 12.47
110% 1870 0.519 8.23 2970 0.825 13.07
DN 32 Normal Flow High Flow
L/h L/s GPM L/h L/s GPM
20% 640 0.178 2.82 800 0.222 3.52
25% 800 0.222 3.52 1000 0.278 4.40
30% 960 0.267 4.22 1200 0.333 5.28
35% 1120 0. 311 4.93 1400 0.389 6.16
40% 1280 0.356 5.63 1600 0.444 7.04
45% 1440 0.400 6.34 1800 0.500 7.92
50% 1600 0.444 7.04 2000 0.556 8.80
55% 1760 0.489 7.74 2200 0.611 9.68
60% 1920 0.533 8.45 2400 0.667 10.56
65% 2080 0.578 9.15 2600 0.722 11.44
70% 2240 0.622 9.86 2800 0.778 12.32
75% 2400 0.667 10.56 3000 0.833 13.20
80% 2560 0.711 11. 26 3200 0.889 14.08
85% 2720 0.756 11.97 3400 0.944 14.96
90% 2880 0.800 12.67 3600 1.000 15.84
95% 3040 0.844 13.38 3800 1.056 16.72
100% 3200 0.889 14.08 4000 1.111 17.60
105% 3360 0.933 14.78 4200 1.167 18.48
110% 3520 0.978 15.49 4400 1.222 19.36
DN 10 Low Flow Normal Flow
L/h L/s GPM L/h L/s GPM
20% 30 0.008 0.13 55 0.015 0.24
25% 38 0.010 0.17 69 0.019 0.30
30% 45 0.013 0.20 83 0.023 0.36
35% 53 0.015 0.23 96 0.027 0.42
40% 60 0.017 0.26 110 0.031 0.48
45% 68 0.019 0.30 124 0.034 0.54
50% 75 0.021 0.33 138 0.038 0.61
55% 83 0.023 0.36 151 0.042 0.67
60% 90 0.025 0.40 165 0.046 0.73
65% 98 0.027 0.43 179 0.050 0.79
70% 105 0.029 0.46 193 0.053 0.85
75% 113 0.031 0.50 206 0.057 0.91
80% 120 0.033 0.53 220 0.061 0.97
85% 128 0.035 0.56 234 0.065 1.03
90% 135 0.038 0.59 248 0.069 1.09
95% 143 0.040 0.63 261 0.073 1.15
100% 150 0.042 0.66 275 0.076 1.21
105% 158 0.044 0.69 289 0.080 1.27
110% 165 0.046 0.73 303 0.084 1.33
115% 173 0.048 0.76 316 0.088 1.39
120% 180 0.050 0.79 330 0.092 1.45
