Datakom D-700 MK3 Bedienungsanleitung

D-700 MK3 User Manual Firmware V-16.8

D-700 MK3

ADVANCED

GENSET

CONTROLLER

D-700 MK3 is a next generation genset controller

combining multi-functionality and wide communication

capabilities together with a reliable and low-cost

design.

The same controller provides synchronization, load

share, AMF, DC Genset, ATS, Remote Start, Engine

Control and Remote Display Panel functionalities.

The module comes ready for remote monitoring over

GSM or Ethernet with plug-in communication modules.

Various plug-in modules provide unlimited expansion

capabilities allowing to meet any special requirement.

The unit complies and mostly exceeds world’s tightest

safety, vibration and environmental standards for the

industrial category.

Software features are complete with easy firmware

upgrade process through USB port.

The Windows based PC software allows monitoring

and programming through USB, RS-485, Ethernet and

GPRS. The Rainbow Scada web monitoring service

allows monitoring and control of an unlimited number

of gensets through any web browser.

Multi genset synchronizer and load share *

Multi genset mains synchronizer *

Single genset parallel with mains *

DC genset controller *

AMF unit with uninterrupted transfer

ATS unit with uninterrupted transfer

Remote start controller

Manual start controller

Engine controller

Remote display & control unit *

Waveform display of V & I

Harmonic analysis of V & I

*Optional with plug-in module

•Ethernet port (100Mbps) *

•GSM-GPRS *

•Embedded web server *

•Web monitoring *

•Web programming *

•Central Monitoring through internet *

•SMS message sending *

•E-mail sending *

•Central monitoring *

•Modbus RTU through RS-485 *

•Modbus TCP/IP *

•SNMP *

•USB Host *

•CANBUS-2 for inter- module comm. *

•USB Device

•PC software: Rainbow Plus

•J1939-CANBUS for electronic engines

*Optional with plug-in module

3 phases 4 wires, star

3 phases 4 wires, delta

3 phases 3 wires, delta, 3 CTs

3 phases 3 wires, delta, 2 CTs (L1-L2)

3 phases 3 wires, delta,2 CTs (L1-L3)

2 phases 3 wires, L1-L2

2 phases 3 wires, L1-L3

1 phase 2 wires

FUNCTIONALITIES

COMMUNICATIONS

TOPOLOGIES

DESCRIPTION

D-700 MK3 User Manual Firmware V-16.8

- 2 -

Any unauthorized use or copying of the contents or any part of this document is prohibited.

This applies in particular to trademarks, model denominations, part numbers and drawings.

This document describes minimum requirements and necessary steps for the successful installation of

the D-700 family units.

Follow carefully advices given in the document. These are often good practices for the installation of

genset control units which reduce future issues.

For all technical queries please contact Datakom at below e-mail address:

technical.support@datakom.com.tr

If additional information to this manual is required, please contact the manufacturer directly at below e-

mail address: technical.support@datakom.com.tr

Please provide following information in order to get answers to any question:

- Device model name (see the back panel of the unit),

- Complete serial number (see the back panel of the unit),

- Firmware version (read from the display screen),

- Measuring-circuit voltage and power supply voltage,

- Precise description of the query.

FILENAME

DESCRIPTION

700-Rainbow Installation

Rainbow Plus Installation Guide

700-Rainbow Usage

Rainbow Plus Usage Guide

700-DYNdns account setting

Dynamic DNS Account Setting

700-Ethernet Configuration

Ethernet Configuration Guide

700-GSM Configuration

GSM Configuration Guide

700-Firmware Update

Firmware Update Guide

700-MODBUS

Modbus Application Manual

700-snmp_E_34076

MIB file for SNMP Application

700-Rainbow Scada Installation

Rainbow Scada Installation Guide

700-Rainbow Scada Usage

Rainbow Scada Usage Guide

QUERRIES

RELATED DOCUMENTS

ABOUT THIS DOCUMENT

D-700 MK3 User Manual Firmware V-16.8

- 3 -

REVISION

DATE

AUTHOR

DESCRIPTION

01.06.2023

First release, firmware version 16.8

CAUTION: Potential risk of injury or death.

WARNING: Potential risk of malfunction or material damage.

ATTENTION: Useful hints for the understanding of device operation.

REVISION HISTORY

TERMINOLOGY

D-700 MK3 User Manual Firmware V-16.8

- 4 -

The D-700 family units are available in various options and peripheral features. Please use below

information for ordering the correct version:

D-700 MK3

-S

-E

-M

-C

-G

-T

-00

Screw type bracket

Stock Code=J10P01 (per unit)

Self-Retaining type bracket

Stock Code=K16P01 (per unit)

Sealing Gasket, Stock Code= K20P01

SPARE PARTS

ORDERING CODES

Family Code

GSM-GPRS

Modem module

USB-Host,

RS-485,

Ethernet module

With Sealing

gasket

With Conformal

Coating

Variant

00: standard unit

01...99: customer

specific products

Synchronization

module

I/O Expansion

module

D-700 MK3 User Manual Firmware V-16.8

- 5 -

▪Electrical equipment should be installed only by qualified

specialist. No responsibility is assured by the manufacturer or

any of its subsidiaries for any consequences resulting from the

non-compliance to these instructions.

▪Check the unit for cracks and damages due to transportation. Do

not install damaged equipment.

▪Do not open the unit. There are no serviceable parts inside.

▪Fuses of fast type with a maximum rating of 6A must be

connected to supply and AC voltage inputs of the controller.

▪Disconnect all power before working on equipment.

▪When the unit is connected to the network do not touch

terminals.

▪Short circuit terminals of unused current transformers.

▪Any electrical parameter applied to the device must be in the

range specified in the user manual. Although the unit is designed

with a wide safety margin, over-range parameters may reduce

lifetime, alter operational precision or even damage the unit.

▪Do not try to clean the device with solvent or the like. Only clean

with a dump cloth.

▪Verify correct terminal connections before applying power.

▪Only for front panel mounting.

SAFETY NOTICE

Failure to follow below instructions

will result in death or serious injury

Current Transformers must be used for current measurement.

No direct connection allowed.

D-700 MK3 User Manual Firmware V-16.8

- 6 -

1. INSTALLATION INSTRUCTIONS

2. MOUNTING

2.1 DIMENSIONS

2.2 SEALING, GASKET

2.3 ELECTRICAL INSTALLATION

3. TERMINAL DESCRIPTIONS

3.1. BATTERY VOLTAGE INPUT

3.2. AC VOLTAGE INPUTS

3.3. AC CURRENT INPUTS

3.4. DIGITAL INPUTS

3.5. ANALOG SENDER INPUTS AND SENDER GROUND

3.6. CHARGE INPUT TERMINAL

3.7. MAGNETIC PICKUP INPUT

3.8. DIGITAL OUTPUTS

3.9. -

3.10. -

3.11. INPUT/OUTPUT EXPANSION

3.12. J1939-CANBUS PORT

3.13. USB DEVICE PORT

4. PLUG-IN MODULES

4.1. MODEM PLUG-IN MODULE

4.1.1. GSM MODEM MODULE

4.1.2. Wi-Fi MODULE

4.1.3. ETHERNET MODULE

4.1.4. RS-485 MODULE

4.1.5. RS-232 MODULE

4.2. SYNCHRONIZATION PLUG-IN MODULE

4.2.1. ANALOG AVR CONTROL OUTPUT

4.2.2. ANALOG GOVERNOR CONTROL OUTPUT

4.2.3. DATALINK-CANBUS PORT

4.2.4. ANALOG LOAD SHARE SIGNAL

4.3. ANALOG PLUG-IN MODULE

4.3.1. ANALOG I/O EXPANSION MODULE

4.3.2. DC VOLTAGE & CURRENT MODULE

4.4. 3 X MAINS CT INPUTS MODULE

4.5. COMMUNICATION MODULE

4.5.1. ETHERNET PORT

4.5.2. USB HOST PORT

4.5.3. RS-485 PORT

TABLE OF CONTENTS

D-700 MK3 User Manual Firmware V-16.8

- 7 -

4.6. RS-232 PLUG-IN MODULE

4.6.1. RS-232 MODULE

4.6.2. GSM MODEM MODULE

4.6.3. Wi-Fi MODULE

4.6.4. ETHERNET MODULE

4.6.5. RS-485 MODULE

5. TOPOLOGIES

5.1. SELECTING THE TOPOLOGY

5.2. 3 PHASE, 4 WIRE, STAR

5.3. 3 PHASE, 3 WIRE, DELTA

5.4. 3 PHASE, 4 WIRE, DELTA

5.5. 3 PHASE, 3 WIRE, DELTA, 2 CT (L1-L2)

5.6. 3 PHASE, 3 WIRE, DELTA, 2 CT (L1-L3)

5.7. 2 PHASE, 3 WIRE, DELTA, 2 CTs (L1-L2)

5.8. 2 PHASE, 3 WIRE, DELTA, 2 CTs (L1-L3)

5.9. 1 PHASE, 2 WIRE

6. FUNCTIONALITIES

6.1. CT LOCATION SELECTION

6.2. SYNCHRONIZATION FUNCTIONALITY

6.3. MAINS SYNCHRONIZATION FUNCTIONALITY

6.4. SINGLE GENSET PARALLEL WITH MAINS

6.5. DC GENSET FUNCTIONALITY

6.6. AMF FUNCTIONALITY

6.7. ATS FUNCTIONALITY

6.8. REMOTE START FUNCTIONALITY

6.9. ENGINE CONTROLLER FUNCTIONALITY

6.10. REMOTE DISPLAY UNIT FUNCTIONALITY

6.11. 400HZ OPERATION

7. CONNECTION DIAGRAMS

7.1. GENSET SYNCHRONIZATION FUNCTIONALITY

7.2. MAINS SYNCHRONIZATION FUNCTIONALITY

7.3. SINGLE GENSET PARALLEL WITH MAINS FUNCTIONALITY

7.4. DC GENSET FUNCTIONALITY

7.5. AMF FUNCTIONALITY

7.6. ATS FUNCTIONALITY

7.7. REMOTE START FUNCTIONALITY

7.8. ENGINE CONTROL FUNCTIONALITY

7.9. REMOTE DISPLAY PANEL FUNCTIONALITY

8. TERMINAL DESCRIPTION

9. TECHNICAL SPECIFICATIONS

D-700 MK3 User Manual Firmware V-16.8

- 8 -

10. DESCRIPTION OF CONTROLS

10.1. FRONT PANEL FUNCTIONALITY

10.2. PUSHBUTTON FUNCTIONS

10.3. DISPLAY SCREEN ORGANIZATION

10.4. AUTOMATIC DISPLAY SCROLL

10.5. MEASURED PARAMETERS

10.6. LED LAMPS

11. WAVEFORM DISPLAY & HARMONIC ANALYSIS

12. DISPLAYING EVENT LOGS

13. STATISTICAL COUNTERS

13.1. FUEL FILLING COUNTER

13.2. FUEL CONSUMPTION MONITORING

14. OPERATION OF THE UNIT

14.1. QUICK START GUIDE

14.2. STOP MODE

14.3. AUTO MODE

14.4. RUN MODE, MANUAL CONTROL

14.5. TEST MODE

15. PROTECTIONS AND ALARMS

15.1. DISABLING ALL PROTECTIONS

15.2. SERVICE REQUEST ALARM

15.3. SHUTDOWN ALARMS

15.4. LOADDUMP ALARMS

15.5. WARNINGS

15.6. NON-VISUAL WARNINGS

16. PROGRAMMING

16.1. RESETTING TO FACTORY DEFAULTS

16.2. ENTERING THE PROGRAMMING MODE

16.3. NAVIGATING BETWEEN MENUS

16.4. MODIFYING PARAMETER VALUE

16.5. PROGRAMMING MODE EXIT

17. PROGRAM PARAMETER LIST

17.1. CONTROLLER CONFIGURATION GROUP

17.2. ELECTRICAL PARAMETERS GROUP

17.3. ENGINE PARAMETERS GROUP

17.4. ADJUST DATE AND TIME

17.5. WEEKLY OPERATION SCHEDULE

17.6. EXERCISER SCHEDULE

17.7. SENDER CONFIGURATION

17.8. DIGITAL INPUT CONFIGURATION

17.9. OUTPUT CONFIGURATION

D-700 MK3 User Manual Firmware V-16.8

- 9 -

17.10. SITE ID STRING

17.11. ENGINE SERIAL NUMBER

17.12. MODEM1-2/SMS1-2-3-4 TELEPHONE NUMBERS

17.13. GSM MODEM PARAMETERS

17.14. TCP/IP PARAMETERS

17.15. SNTP PARAMETERS

17.16. Wi-Fi PARAMETERS

17.17. SYNCHRONIZATION PARAMETERS

17.18. DC GENSET PARAMETERS

17.19. SNMP PARAMETERS

18. ETHERNET CONFIGURATION

19. Wi-Fi CONFIGURATION

20. GSM CONFIGURATION

21. CRANK CUTTING

22. OVERCURRENT PROTECTION (IDMT)

23. MOTORIZED CIRCUIT BREAKER CONTROL

24. AUTO LEARNING

25. SPEED & VOLTAGE UP/DOWN RELAY OUTPUTS

25.1. SPEED UP/DOWN CONTROL

25.2. VOLTAGE UP/DOWN CONTROL

26. J1939 CANBUS ENGINE SUPPORT

27. DPF REGENERATION SUPPORT

28. DC GENSET OPERATION

28.1. OPTIMAL CHARGING WITH VARIABLE SPEED

28.2. UNCONTROLLED CHARGING WITH FIXED SPEED OPERATION

29. GPS SUPPORT

30. SMS COMMANDS

31. LOAD TRANSFER MODES

31.1. TRANSFER WITH INTERRUPTION

31.2. UNINTERRUPTED TRANSFER

31.3. SOFT TRANSFER

32. LOAD SHARING

32.1. DIGITAL LOAD SHARING (DATALINK)

32.2. ANALOG LOAD SHARING

32.3. DROOP MODE OPERATION

33. PARALLELING WITH MAINS OPERATION

33.1. PEAK LOPPING

33.2. POWER EXPORT TO MAINS

33.3. DISTRIBUTED POWER EXPORT TO MAINS

33.4. PEAK LOPPING WITH GENSET PRIORITY

D-700 MK3 User Manual Firmware V-16.8

- 10 -

34. PROTECTION FUNCTIONS PARALLELING WITH MAINS

34.1. ROCOF FUNCTION (rate of change of frequency)

34.2. VECTOR SHIFT FUNCTION

34.3. OVER/UNDER FREQUENCY FUNCTION

34.4. OVER/UNDER VOLTAGE FUNCTION

34.5. MAINS REVERSE POWER FUNCTION

34.6. NO FREQUENCY FUNCTION

35. DATA RECORDING

35.1. DATA RECORDING MEDIA

35.2. DIRECTORY STRUCTURE

35.3. UNDERSTANDING THE CSV FORMAT

35.4. RECORDED DATA LIST, RECORD PERIOD

36. SOFTWARE FEATURES

36.1. LOAD SHEDDING / DUMMY LOAD

36.2. LOAD ADD / SUBSTRACT

36.3. FIVE STEP LOAD MANAGEMENT

36.4. REMOTE START OPERATION

36.5. DISABLE AUTO START, SIMULATE MAINS

36.6. BATTERY CHARGING OPERATION, DELAYED SIMULATE MAINS

36.7. DUAL GENSET MUTUAL STANDBY OPERATION

36.8. MULTIPLE VOLTAGE AND FREQUENCY

36.9. SINGLE PHASE OPERATION

36.10. EXTERNAL CONTROL OF THE UNIT

36.11. AUTOMATIC EXERCISER

36.12. WEEKLY OPERATION SCHEDULER

36.13. ENGINE HEATING OPERATION

36.14. ENGİNE IDLE SPEED OPERATİON

36.15. ENGINE BLOCK HEATER

36.16. FUEL PUMP CONTROL

36.17. GAS ENGINE FUEL SOLENOID CONTROL

36.18. PRE-TRANSFER SIGNAL

36.19. CHARGING THE ENGINE BATTERY

36.20. EXTERNALLY CONTROLLED DIGITAL OUTPUTS

36.21. COMBAT MODE

36.22. RESETTING THE CONTROLLER

36.23. AUTOMATIC CONNECTION TOPOLOGY DETERMINATION

36.24. ZERO POWER AT REST

37. MODBUS COMMUNICATIONS

37.1. PARAMETERS REQUIRED FOR RS-485 MODBUS OPERATION

37.2. PARAMETERS REQUIRED FOR MODBUS-TCP/IP VIA ETHERNET

37.3. DATA FORMATS

Inhaltsverzeichnis

Andere Datakom Controller Handbücher

Datakom

Datakom D-500 MK2 Bedienungsanleitung

Datakom

Datakom DKG-225 Bedienungsanleitung

Datakom

Datakom DKG-205 Bedienungsanleitung

Datakom

Datakom D-100 MK2 Bedienungsanleitung

Datakom

Datakom DKG-255 Bedienungsanleitung

Datakom

Datakom D-200 MK2 Bedienungsanleitung

Datakom

Datakom D-500 MK3 Bedienungsanleitung

Datakom

Datakom DKG-379 Bedienungsanleitung

Datakom

Datakom DKG-509 Bedienungsanleitung

Datakom

Datakom DKG-319 Bedienungsanleitung

Datakom

Datakom DKM-046 Bedienungsanleitung

Datakom

Datakom DK-70 Bedienungsanleitung

Datakom

Datakom DKG-116 Bedienungsanleitung

Datakom

Datakom DK-45 MK2 Bedienungsanleitung

Datakom

Datakom D Series Bedienungsanleitung

Datakom

Datakom DK-40 Bedienungsanleitung

Datakom

Datakom DKG-329 Bedienungsanleitung

Datakom

Datakom DFC-0108 Bedienungsanleitung

Datakom

Datakom D-300 MK2 Bedienungsanleitung

Datakom

Datakom D-500 Bedienungsanleitung

Datakom

Datakom D-500 MK3 Bedienungsanleitung

Datakom

Datakom DK-45 Bedienungsanleitung

Datakom

Datakom DKG-119 Bedienungsanleitung

Datakom

Datakom DKG-108 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
