David Engineering & Mfg PDR MOUNTS SPM-100 Bedienungsanleitung
Model
Thank you for purchasing the PDR product
To ensure the correct usage, please read and follow the instructions
manual thoroughly. Please store the instructions in a safe place for future reference.
To ensure customer safety, be sure to decide the installation location so that the strength is sufficient to withstand the weight of both the panel
displays and the mount.
Always use at least two persons for all installations.
Fully tighten all of the mounting screws as specified in the installation instructions.
MODEL SPM-100 Features
Special techniques are necessary for installation of the panel display mount.
Do not attempt to perform this work by yourself.
Request an installation specialist to install this unit.
Manufacturer assumes absolutely no responsibility for injuries and damages that may occur due to improper installation and handling.
1
Mounts by
A division of David Engineering & Mfg. Inc.
SINGLE POLE MOUNT SPM-100
All PDR mounts and adapters carry a limited lifetime warranty from ship date against defects in material and workmanship.
Check the PDR website for details @ www.PDRmounts.com. We are not liable for improper installation that results in damage
to mounts, adapters or presentation equipment.
?Suitable for Vesa 100mm and 75mm or any PDR mount
?Mounts to standard 1 ½” pipe (not supplied)
?Display Mount hardware included
?Rotates 360 degrees
?Tilts down 30 degrees
?500 lb load capacity
?Heavy metal construction
?Made in the USA
not install in locations where there are excessive amounts of dust
Do not block the ventilation holes. Leave sufficient clearance in regard to the surroundings to avoid blocking the ventilation..
Do not install in locations where there is excessive vibration or impact. Injury and damage could result from the panel display
Use the specified bolts and screws in the specified places and tighten firmly. Failure to do this could cause injury if the panel
Always use at least two people to perform the installation work. Injury could result from dropping heavy objects.
be installed must be capable of long-term support of the total load of
be taken to ensure sufficient strength to
bration and other external forces.
display to fall and cause injury.
anel display + pole mount)
MAXIMUM WEIGHT - 500 Lbs. ( 226 Kg.)
INSTALLATION LOCATION
Do not install close to an air conditioner intake or outlet. Do
oily smoke or tobacco smoke. Fire could result.
falling.
display falls.
Do not alter any of the parts. Do not use broken parts.
The ceiling where the mount is to
the panel display and SPM-100 mount. Measures should also
withstand the force of earthquakes, vi
Note: Incorrect installation can cause the
Total load of the panel (p
2
CAUTION
WARNING
WARNING
Rev 081506
Caution: Installation o
location by checking the ceiling structure and durability for safety and accident prevention
f unit to be carried out by qualified technicians only. Install in an appropriate
3
6.780
30° 100mm
75mm
100mm
75mm
.265 dia
.325 dia
6.750
BOTTOM VIEW
1 ½”NPT
TOP VIEW
SIDE VIEW
LOCKING SCREW
FRONT VIEW
MOUNTING PATTERN
6.290
bottom screw
MODEL SPM-100 SPECIFICATIONS
Fig1
INSTLATION GUIDE
4
1: Install the SPM 100 onto the end of a threaded 1 ½” NPT (sold separably). See fig 2
2: Using the side locking screw, secure the pipe to the mount. See fig 3
3: To rotate the SPM100, loosen the bottom screws. See fig 1
Rotate to the desired viewing position and tighten the screws.
4: A repositioning of the bottom screws may be necessary to rotate to the best viewing angle
5: Using the 4 holes on the face of the mount, attach a PDR mount of your choice (sold separably)
6: Tilt the mount to the desired position and secure the side screws.
Fig 2
Fig 3
1 ½”NPT
PIPE SOLD SEPARATELY
SIDE LOCKING SCREW
Attach PDR mount here
Side screws
