Introduction
What is the…
DV-IP Decoder ?
As an integral part of Dedicated Micros Video Management System, the DV-IP Decoder is a
viewing and control client for multiple video images transmitted from the range of NetVu Connected
products.
Using an attached control solution such as the Pick-a-Point Digital Matrix System, the DV-IP
Decoder can view and control cameras attached to DVRs and servers from across the system,
regardless of geography – displaying the selected cameras on its monitor wall. A range of DV-IP
Decoder models are available with composite and Composite/HD outputs, allowing you to build
exible video walls combining any combination of analogue or digital screens.
The DV-IP Decoder, using its powerful codec architecture, is the ideal product to deliver and view,
high denition footage, live in real-time, all streamed seamlessly across a network
Part of a growing number of Dedicated Micros products with high denition capabilities, the DV-IP
Decoder is available with HDMI monitor outputs to provide greater denition and image quality. The
addition of composite outputs also allows scalable video walls that combine any combination of
analogue or digital screens.
With various composite and high denition models available the DV-IP Decoder can offer scalable
video wall solutions that suit any requirement, allowing analogue, IP and Megapixel images to be
viewed together seamlessly irrespective of the source devices location.
The DV-IP Decoder is equipped with a sophisticated digital matrix Video Management System that
enables cameras connected to any NetVu Connected device on the same network to be viewed and
controlled as if they were connected directly to the DV-IP Decoder.
The DV-IP Decoder includes both Gigabit and 10/100 Ethernet connections. By utilising the Gigabit
port to connect NetVu Connected video servers, encoders and cameras, including megapixel
cameras, the user is able to view and control images without having to transfer data across the
company network.
As part of Dedicated Micros range of next generation CCTV products, the DV-IP Decoder can offer
users remote access to the advanced viewing functions already within products such as DV-IP
Server, DV-IP RT, DV-IP Express, DV-IP HD and SD Advanced. Users can take advantage of
features to view, review and control cameras that are connected to remote DVRs and Video Servers.
For further information, please visit the website:
www.dedicatedmicros.com
or contact customer services in your region
Dedicated Micros ©2010
4
DV-IP DECODER
Features
The DV-IP Decoder from Dedicated Micros is equipped with an array of valuable features designed
to enhance the operator experience.
• Display JPEG or MPEG4 video streams on a CCTV Video Wall from any
connected device
• High denition and composite monitor outputs to allow scalable video wall solutions
• Includes Enhanced User Interface and control functionality
• Pick-a-Point and Pick-a-Point Icon Video Management System integration
• Gigabit Ethernet and Ethernet network connections
• Incorporated display of analogue, IP and megapixel cameras
• NetVu Connected for seamless interoperability with other NetVu Connected devices
• Embedded Operating System
• BS8418 compliant
The DV-IP Decoder has NetVu Connected technology built-in to ensure maximum compatibility
with future developments in networked security. NetVu Connected technology enables the DV-IP
Decoder to fully interact with other NetVu Connected compatible products from Dedicated Micros
including the Pick-a-Point Icon and NetVu ObserVer. Providing interoperability between the
worlds leading security companies, NetVu Connected uses industry standard networking protocols
supported by a wide range of third party integration products and SDKs to ensure future on-going
compatibility.
Design of the manual
For ease of use, this manual has two parts:
1. Installation Shows details of how to install the unit and connect external devices.
2. Conguration Shows details of the unit’s menus.
The order and layout of these pages has been designed to help the setup process. It is
recommended that the menus are edited in sequential order to enable accurate, easy and efcient
setup.
Dedicated Micros ©2010 5
DV-IP DECODER
Important Safeguards
Read Instructions
All the safety and operating instructions should be read before the unit is operated.
Power Sources
This unit should be operated only from the type of power source indicated on the manufacturer’s
label.
Servicing
Do not attempt to service this unit yourself as opening or removing covers may expose you to
dangerous voltage or other hazards.
Refer all servicing to qualied service personnel.
Ventilation
Ensure unit is properly ventilated to protect from overheating.
All the safety and operating instructions should be read before the unit is operated.
To prevent re or shock hazard, do not expose this equipment to rain or moisture. The lightning ash
with arrowhead symbol within an equilateral triangle is intended to alert the user of this equipment
that there are dangerous voltages within the enclosure which may be of sufcient magnitude to
constitute a risk of electric shock.
This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Lightning Strike
The unit has some in-built protection for lightning strike, however it is recommended that isolation
transformers be tted to the system in areas where lightning is a common occurrence.
Regulatory Notes and FCC and DOC Information
(USA and Canadian Models Only)
Warning: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at their own expense.
If necessary, the user should consult the dealer or an experienced radio/television technician for
corrective action. The user may nd the following booklet prepared by the Federal Communications
Commission helpful: “How to Identify and Resolve Radio-TV Interference Problems”.
This booklet is available from the US Government Printing Ofce, Washington, DC20402,
Stock No. 004-000-00345-4.
This reminder is provided to call the CCTV system installer’s attention to Art. 820-40 of the NEC that
provides guidelines for proper grounding and, in particular, species that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.
Dedicated Micros ©2010
6
DV-IP DECODER
CE Mark
If this product is marked with the CE symbol it indicates compliance with all applicable directives.
Directive 89/336/EEC.
A ‘Declaration of Conformity’ is held at Dedicated Micros Ltd.,
1200 Daresbury Park, Daresbury, Cheshire, WA4 4HS, UK.
Laser
The unit supports an integrated CD/DVD writer, the following are additional warnings associated with
installing and operating the CD/DVD writer, please pay particular attention to this information.
• Caution - Use of controls or adjustments or performance of procedures other than those
specied herein may result in hazardous radiation exposure.
• To prevent exposure to laser emanations (harmful to the eyes), do not attempt to
disassemble this unit.
Dedicated Micros ©2010 7
DV-IP DECODER
Installing the Unit
Before you start
Check the contents of the box
Remove all items from the packaging and check the items listed below are present:
• DV-IP Decoder (either 4 or 8 input)
• USB Mouse
• IR Remote Control
• IR Remote Control Extender
• Power Leads
• Rack mounting brackets
If any of these items are missing, please contact Dedicated Micros Technical Support team.
Note: Before installing the DV-IP Decoder, carefully read all Safety Instructions and the following
information on where the unit should be located.
Choosing a location for installation
• The DV-IP Decoder is designed to be desk, shelf or rack mounted.
• Ensure the DV-IP Decoder is properly ventilated to protect from overheating.
• Ensure there is a 3cm gap on both sides of the unit.
• Ensure the receiving end of the IR remote control extender faces the operator position
and is not more than 3 metres (10 feet) from the operator.
• Ensure the unit is not located anywhere it could be subject to mechanical shocks.
• The unit should be located in an area with low humidity and a minimum of dust. Avoid
places like damp basements or loft spaces.
• If the unit is to be installed in a closed assembly, the maximum operating temperature
must not exceed 40°C (104°F).
• Ensure there is reliable earthing of the mains outlet when tted to supply connections
(other than direct connection to the branch circuit).
• Any branch circuit supplying the unit must be rated at 15Amps.
• It is recommended that an uninterrupted power source be connected to the unit in case
of power failure (to ensure continuous operation of the unit).
Please ensure the following are available and have been tested prior to the installation:
• Mains point
• Network point
• Network cable
• Active video signals i.e. at least one working camera feed
• PC with CD ROM drive and connection to the same network as the DV-IP Decoder unit
(Recommended)
Dedicated Micros ©2010
8
DV-IP DECODER
Front Panel connections
Data
LED’s Power - The Power LED will be green to indicate power is connected to the unit
HDD (Hard Disk Drive) - This will ash when images are being stored to the hard disk
Network - The Network LED will be green to indicate a connection
Rear Panel connections
8 Input model
4 Input model
REARPANELDWGSERVER.EPS
Dedicated Micros ©2010 9
DV-IP DECODER
Monitors
8 & 4 output units
MON1 to MON4/MON8 75Ω BNC composite monitor output, 1V pk-pk
HDMI x2 High-Denition Multimedia Interface connectors (High Denition 8
output model only)
Audio (for future development)
Audio IN (Dual) RCA (phono) socket, 8KHz/16KHz/22KHz sampling 75Ω input
impedance, 1V pk-pk for future development
Audio OUT (Dual) RCA (phono) socket, line level <100Ω output impedance,
1V pk-pk amplication required for future development
Data
SERIAL 1 RS-232 (3 wire & 9 wire)
SERIAL 2 RS-232 (3 wire & 9 wire)
SERIAL 3 RS-485 (2 wire) or RS232 (5 wire)
SERIAL 4 RS-485 (2 wire) or RS232 (5 wire)
USB 2x USB2.0 connectors
IR Infra-Red Input connector for IR Remote Control Extender
NET1 RJ45 Ethernet network connector, 10/100 Mb/s Ethernet Network
NET2 RJ45 Ethernet network connector, 1 Gb/s Ethernet Network
KBD RJ12 expansion port for future development
EXP RJ12 expansion port for future development
Alarms and relays (for future development)
ALARMS IN 25-way (female) D Type port for future development
RELAYS 9-way (female) D Type port for future development
Power
POWER IEC mains power socket & switch
Dedicated Micros ©2010
10
DV-IP DECODER
This procedure shows the eight output version.
Step 1 Connecting Monitors
The DV-IP Decoder supports up to 4 or 8 connected Monitors (dependant on model) via the 75Ω
BNC connectors. Connect monitors to the outputs, starting from ‘Mon 1’.
5.12
Step 2 Monitor
The DV-IP Decoder also supports 2 High Dention monitor outputs via ports ‘HDMI 1’
and ‘HDMI 2 (High Denition 8 Output model only).
Andere Handbücher für DV-IP Decoder
1
Inhaltsverzeichnis
Andere Dedicated Micros Medienkonverter Handbücher
