Definitive Technology ProCenter 1000 Bedienungsanleitung

efinitive Technology

is known for build-

ing innovative

loudspeakers that

deliver high-end performance at

modest prices, and historically

some of the firm’s most special

products have come in small

packages. One great example

would be the firm’snew $1649

ProCinema 1000 5.1-channel

speaker system.

The deluxe version of the

ProCinema 1000 system consists

of four ProMonitor 1000 mini-

monitors, a ProCenter

2000 center-

channel

speaker,

and a

ProSub

1000 sub-

woofer. At first, the ProCinema

speakers look like truncated,

jet-black versions of Definitive’s

Mythos speakers, though the

designs are different from a

technical standpoint. Sadly,

Definitive’s product styling has

been widely imitated, so that the

lovely ProCinema components

look well finished but not particu-

larly distinctive. From the outside,

the ProCinema system looks

much like any number of other

good, “generic” sat/sub systems

on the market. But once you

hear the ProCinema system,

you’ll know in an instant there is

nothing generic about its sound.

Big Dynamics

This compact system

plays big—verybig.

We trotted out our

favorite cinematic

blockbusters—the

“Echo Game” scene

from House of Flying

Daggers, “The Flying Boat” scene

from The Aviator,and the “Under

Attack” scene from Master and

Commander—and came away

impressed with the way the

system handled this dynamically

demanding material. Many small

systems can play fairly loudly,

but few do so gracefully.The

ProCinema system, however,

almost always kept its composure,

taking large-scale dynamic swells

in stride, even in TPV’s relatively

large audio lab. Only at loony

volume levels did the ProCinema

rig startto show traces of hard-

ness and compression.

Innovations that Work

Iattribute the system’sfine

dynamics to two design innova-

tions. First, its speakers introduce

spectacular new mid/bass drivers

whose diaphragms are supported

both by outer and inner suspen-

sion rings (traditional diaphragms

are supported at their outer rims

only), with cylindrical wave-

guides in the center.These might

be the finest mid/bass drivers

Definitive has ever produced;

they deliver terrific dynamic

punch with very low distortion.

Second, the ProCinema speakers

5.1-Channel Speaker System

AUDIO REVIEW

Chris

Martens

Definitive Technology ProCinema 1000

Innovative Technology

Pays Big Dividends

“This compact system

plays big—verybig.“

“The ProCinema 1000

system is a bargain,

pure and simple.”

“Value with a capital ‘V’”

incorporate small passive radiators

mounted in the tops (or ends) of their

cabinets; these give the speakers a

more full-bodied sound and

better mid and upper bass (areas

where other small monitors can

sound “thin”).

Killer Midrange

The ProCinema system serves up

clean, clear highs and midrange

that is shockingly detailed and

nuanced. Sophisticated midrange

sound is this system’scrowning

achievement, meaning these speak-

ers reveal small textures and details

that many small systems simply

cannot reproduce. For example, the

ProCinema system caught the eerie

ping and shimmer of percussion

instruments in the Reiner/Chicago

recording of Bartok’s Music for

Strings, Percussion and Celeste

[RCA Living Stereo, SACD], and

the almost subliminal inflections of

Valerie Joyce’s voice on New York

Blue [Chesky]. Lower down, the

speakers nailed the plucked string

sounds and earthy growl of Charlie

Haden’s acoustic bass in Nocturnes

[Verve]. These rich midrange details

pull you deep inside your favorite

music and films.

The only small criticism I would offer

is that Definitive’s aluminum dome

tweeters, though very good, are not

as good as the low-distortion

ProCinema mid/bass drivers

mentioned above. The drivers

generally integrate well, but the

tweeter sometimes shows a bright,

hard-edged quality inconsistent

with the speaker’s otherwise

smooth, open sound. Even so,

the ProCinema tweeter is arguably

as good or better than those used

in other systems at this price.

Bass Wallop

Completing the system is the 300-

watt ProSub 1000, which borrows

technology from Definitive’s award-

winning SuperCube subwoofers.

Not surprisingly,the ProSub goes

low, and produces energetic bass,

with dynamic capabilities well

matched to the rest of the system.

Pitch definition is good, though not

quite as good as the best I’ve heard

from other subs in this price range

(for example, Epos’ ELS sub).

Nevertheless, the ProSub 1000 offers

greater bass wallop than most com-

petitors, building a rock-solid mid-

bass foundation that supports music

and low frequency effects alike.

The ProCinema 1000 system

is a bargain, pure and simple. For

under $2000 the system looks small,

plays big, and gives you revealing

midrange qualities you’d expect to

find only in higher-end systems. TPV

The Last Word

•Clear highs, potent bass

•Midrange with true high-end

sophistication

•Big dynamics from small enclosures

•Value with a capital “V”

•Could use a smoother tweeter

•You’ll need great electronics

toget this system’s full measure

Specifications

2-way satellite speaker

•Driver complement: One 5.25" mid/bass

driver, one 5.25" passive radiator, one

1"aluminum dome tweeter.

•Frequency response: 47Hz–30kHz

•Sensitivity: 90dB (1W/1m)

•Impedance: 4–8ohms

•Recommended amplifier power:

10-200Wpc

•Dimensions: 10.875" x 6.5" x 6.25"

•Weight: 7 lbs.

2-way center-channel speaker

•Driver complement: Two 5.25" mid/bass

drivers, two 5.25" passive radiators, one

1” aluminum dome tweeter.

•Frequency response: 42Hz–30kHz

•Sensitivity: 91dB (1W/1m)

•Impedance: 4–8ohms

•Recommended amplifier power:

10-250Wpc

•Dimensions: 6.5” x 6.5” x 17”

• Weight: 12 lbs.

Powered subwoofer

•Driver complement: One 10" polymer-

cone woofer,one 10" infrasonic (passive)

radiator

•Integrated amplifier power: 300 watts

•Dimensions: 12" x 17.875" x 14.4375"

• Weight: Not specified

System Price: $1649

Definitive Technology [410] 363-7148 www.definitivetech.com

Satellites and Center Channel

01234567 8910

Transparency and Focus

Imaging and Soundstaging

Tonal Balance

Dynamics

Bass Extension

Value

▲

Poor Good Excellent

Subwoofer

012345678910

Bass Extension

Bass Pitch Definition

Bass Dynamics

Value

▲

Poor Good Excellent

“clean, clear highs

and midrange that

is shockingly detailed

and nuanced.”

“they deliver terrific

dynamic punch with

very low distortion.” “qualities you’d

expect to find only in

higher-end systems.“

“looks small, plays big...

high-end sophistication”

11433 Cronridge Dr.•Owings Mills, MD 21117 • (410)363-7148

Visit us at www.definitivetech.com

The Perfect Vision September 2006
