Dell D3100 Bedienungsanleitung
Model: D3100
User Guide
Dell Docking Station – USB 3.0
NOTE: A NOTE indicates important information that helps you make
better use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss
of data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
© 2014 Dell Inc. All rights reserved.
Information in this document is subject to change without notice. Reproduction of these
materials in any manner whatsoever without the written permission of Dell Inc. is strictly
forbidden.
Trademarks used in this text: Dell and the Dell logo are trademarks of Dell Inc., Intel®,
Centrino®, Core™, and Atom™are either trademarks or registered trademarks of Intel
Corporation in the U.S. and other countries; Microsoft®, Windows®, and Windows start button
logo are either trademarks or registered trademarks of Microsoft Corporation in the United
States and/or other countries; Bluetooth®is a registered trademark owned by Bluetooth SIG,
Inc. and is used by Dell under license; Blu-ray Disc™is a trademark owned by the Blu-ray Disc
Association(BDA) and licensed for use on discs and players; Other trademarks and trade names
may be used in this document to refer to either the entities claiming the marks and names or
their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other
than its own.
2014 – 06 Rev. A00
3
Contents
a. Dell Docking Station – USB 3.0 (D3100)
b. USB 3.0 I/O cable (2 ft)
c. Power adapter & power cord
d. Installation CD
e. HDMI to DVI adapter
Specifications
Upstream Input
• 1 x USB 3.0 (Standard B Type)
Downstream Outputs
• 3 x USB 3.0
• 2 x USB 2.0
• 1 x DisplayPort
• 2 x HDMI
• Gigabit Ethernet
• Combo Audio (Headphone/Mic)
• Audio line out
• 2 High-powered ports ( ) for battery charging (BC 1.2).
Resolution/Refresh Rate
No. of video ports connected
Single
Single
Single
Dual Display
Dual Display
Dual Display
Triple Display
DP
3840 x 2160 / 30Hz
Not connected
Not connected
3840 x 2160 / 30Hz
3840 x 2160 / 30Hz
Not connected
3840 x 2160 / 30Hz
HDMI 1
Not connected
2560 x 1440 / 50Hz
Not connected
2560 x 1440 / 50Hz
Not connected
2048 x 1152 / 60Hz
2048 x 1152 / 60Hz
HDMI 2
Not connected
Not connected
2560 x 1440 / 50Hz
Not connected
2560 x 1440 / 50Hz
2048 x 1152 / 60Hz
2048 x 1152 / 60Hz
a b c d e
*Resolution supports also dependent on display EDID resolution
4
Power in
Audio Line out
USB 2.0
Ethernet
HDMI
DisplayPort
USB in
Product Overview
Front View
Audio Combo
USB 3.0
USB 3.0
USB 3.0
Kensington Lock
Back View
USB 2.0
5
Recommended System Requirements
Hardware
Processor: Intel Core i7 2+GHz or better
Memory: 8 GB
Video Card: Intel HD 4000, ATI Radeon
HD5/6xxx, NVidia GeForce 4xxM or better.
USB: USB 3.0
Disk: 7200 RPM or SSD
Operating System
• Wins OS (Win 7, 8, 8.1) 32/64 bits
Operating Temperature
Max. operating temperature is 40oC
6
Windows 7/8/8.1 Setup
Note: Setup with Bundled CD.
1. Double click on “Setup.exe” when CD is installed.
2. Once clicked on “Setup.exe”, it will run installation software end user license
agreement on the window.
3. Click "I Accept". DisplayLink Core software and DisplayLink Graphics will be installed.
4. Connect your docking station and peripherals to your PC.
IMPORTANT : DO NOT
connect the Docking Station
until you have installed the
drivers on your laptop.
7
Windows 7/8/8.1 Setup
Note: Setup without Bundled CD
1. Connect the dock to your laptop
Note: It is recommended to download the latest drivers from the DisplayLink support website at
www.displaylink.com/support
2. Windows will start installing the displaylink Driver Automatically.
3. Follow the screen instructions until the installation is complete.
For network/IT administrators, please visit
this link for a corporate installation software
package. (*User registration required)
http://www.displaylink.com/corporateinstall/
4. Connect your docking station and peripherals to your PC.
8
DisplayLink Manager Menu
Menu Option
DisplayLink Manager
Check for Updates
DisplayLink Devices
Audio Setup
Video Setup
Screen Resolution
Screen Rotation
Extend To
Extend
Set as Main Monitor
Notebook Monitor O
Mirror
O
Fit to TV
Description
Clicking on this item will show the version of DisplayLink
software installed.
Windows update checking.
Connected DisplayLink devices checking.
Opens the Windows Audio Configuration Window.
Opens the Windows Screen Resolution window.
Displays a list of available resolutions.
Rotates the screen in clockwise or counter-clockwise direction.
Extends the display to the right or left of the main display.
Extends the Windows desktop onto the display.
Sets this screen as the main display.
Switches o the display of the notebook and makes the
DisplayLink display the main display.
Copies what is on the main display and reproduces it on
this display.
Switches o the display.
Use this function to adjust the size of the windows to fit the
TV screen.
To set the display into extended mode
1. Click on the DisplayLink icon .
2. Select Extend.
The device is now extended in the direction it was the last time the display was in this
mode. For more control, use the Extend To submenu and select one of the options. This
puts the device into extend mode, and places it to the Left/Right/Above/Below the main
(primary) monitor.
To set the display into mirror mode
1. Click on the DisplayLink icon .
2. Select Mirror.
The resolution, colour depth and refresh rate of the primary screen are replicated on
the monitor connected to the DisplayLink USB Graphics device.
9
Fit to TV configuration
1. To configure Fit to TV, choose the option from the DisplayLink GUI.
The following interface appears
2. You will also see a red border on the DisplayLink screen
The red border shows the size of the new Windows desktop. Use the “+” and “-”
controls on the Fit to TV GUI to
change the size of the red border until it fits on the TV screen.
Note: Finer configuration of the size of the border can be achieved by holding down the
CTRL key and clicking the “+” and “-”.
3. Once the red border is at the edges of the TV screen, click “Apply” to resize the
Windows desktop.
10
The video on the attached monitor
is not displaying in extended mode
The audio jacks are not functioning
USB ports are not functioning on
the docking station
External USB 3.0 Media Card
Reader is not detected.
HDCP content is not able to
display on the attached monitor
Displaylink Driver not able to install
Laptop failed to boot with dock
connected
No CD drive and no Internet
access for getting the driver
Change the settings by either:
• Configuring under Control Panel Items\Display\
Change Display Setting.
• Switch by cycling the “Windows Key +P”.
Check the settings under Control Panel\All Control Panel
Items\Sound to make sure the USB Audio device is available
and set to default. Right click to show all available options.
Unplug from the power, wait 10 seconds, and then reconnect.
Update to the latest USB 3.0 host controller driver
Unplug from the power, wait 10 seconds, and then reconnect.
Update to the latest USB 3.0 host controller driver
HDCP content support is currently not available.
Get the driver by either:
• Downloading the latest driver from the Displaylink website.
• Connect to Windows Update with Docking station
(by using Wi-Fi or Ethernet port of the laptop).
Remove all USB devices connected to the dock; some
unqualified boot devices may cause lock up at boot screen.
Get an external CD drive to load the driver from CD
Download the driver from an Internet connected computer
and copy the driver over USB flash drive, and run the setup..
FAQs of Dell Docking Station - USB 3.0 (D3100)
Troubleshooting
There is no video on the monitor
attached to the dock
The video on the attached monitor
is distorted or corrupted.
Suggested Solutions
Check the video connection cables.
Unplug from the power, wait 10 seconds, and then reconnect.
Check video connection cables.
Check the video resolution under Control Panel Items\
Display\Change Display Setting.
