Dell Studio 0KWJH0A01 Bedienungsanleitung
SETUP GUIDE
SETUP GUIDE
Regulatory Model P03G series Regulatory Type P03G001
Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of your
computer.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells
you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
If you purchased a Dell™ n Series computer, any references in this document to Microsoft®Windows®operating systems
are not applicable.
__________________
Information in this document is subject to change without notice.
© 2009 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text:
Dell
, the
DELL
logo,
YOURS IS HERE,
and
DellConnect
are trademarks of Dell Inc.;
Intel
is a
registered trademark and
Core
is a trademark of Intel Corporation in the U.S. and other countries;
Microsoft
,
Windows
,
Windows Vista,
and
Windows Vista
start button logo are either trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries;
Bluetooth
is a registered trademark owned by Bluetooth SIG, Inc.
and is used by Dell under license;
SRS Premium Sound
,
SRS
, and the symbol are trademarks of SRS Labs, Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and
names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
October 2009 P/N KWJH0 Rev. A01
3
Setting Up Your Studio Laptop . . . . . . . . . . .5
Before Setting Up Your Computer . . . . . . . . . 5
Connect the AC Adapter . . . . . . . . . . . . . . . . 6
Connect the Network Cable (Optional) . . . . . 7
Press the Power Button . . . . . . . . . . . . . . . . . 8
Set Up Microsoft Windows. . . . . . . . . . . . . . . 9
Install the SIM Card (Optional). . . . . . . . . . . 10
Enable or Disable Wireless (Optional). . . . . 12
Connect to the Internet (Optional) . . . . . . . . 14
Using Your Studio Laptop . . . . . . . . . . . . . .18
Right Side Features . . . . . . . . . . . . . . . . . . . . 18
Left Side Features . . . . . . . . . . . . . . . . . . . . . 22
Computer Base and Keyboard Features . . . 26
Touch Pad Gestures. . . . . . . . . . . . . . . . . . . . 28
Multimedia Control Keys. . . . . . . . . . . . . . . . 32
Display Features . . . . . . . . . . . . . . . . . . . . . . 34
Removing and Replacing the Battery . . . . . 36
Using the Optical Drive . . . . . . . . . . . . . . . . . 38
Software Features . . . . . . . . . . . . . . . . . . . . . 39
Free Fall Sensor . . . . . . . . . . . . . . . . . . . . . . . 42
Dell Dock . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Solving Problems . . . . . . . . . . . . . . . . . . . . .44
Beep Codes . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Network Problems . . . . . . . . . . . . . . . . . . . . . 45
Power Problems. . . . . . . . . . . . . . . . . . . . . . . 46
Memory Problems . . . . . . . . . . . . . . . . . . . . . 47
Lockups and Software Problems . . . . . . . . . 48
Using Support Tools. . . . . . . . . . . . . . . . . . .50
Dell Support Center . . . . . . . . . . . . . . . . . . . . 50
System Messages . . . . . . . . . . . . . . . . . . . . . 51
Hardware Troubleshooter. . . . . . . . . . . . . . . 53
Dell Diagnostics . . . . . . . . . . . . . . . . . . . . . . 54
Contents
4
Contents
Restoring Your Operating System . . . . . . .58
System Restore . . . . . . . . . . . . . . . . . . . . . . . 59
Dell DataSafe Local Backup. . . . . . . . . . . . . 60
Operating System Reinstallation . . . . . . . . . 62
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . .64
Technical Support and Customer
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
DellConnect . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Online Services . . . . . . . . . . . . . . . . . . . . . . . 66
Automated Order-Status Service . . . . . . . . . 67
Product Information. . . . . . . . . . . . . . . . . . . . 67
Returning Items for Repair Under
Warranty or for Credit . . . . . . . . . . . . . . . . . . 68
Before You Call. . . . . . . . . . . . . . . . . . . . . . . . 69
Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . . 71
Finding More Information and
Resources . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Specifications . . . . . . . . . . . . . . . . . . . . . . .74
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Information for NOM, or Official Mexican
Standard (only for Mexico) . . . . . . . . . . . . . . 87
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
5
This section provides information about setting
up your Studio laptop.
Before Setting Up Your
Computer
When positioning your computer, ensure that
you allow easy access to a power source,
adequate ventilation, and a level surface to
place your computer.
Restricting airflow around your Studio laptop
may cause it to overheat. To prevent
overheating ensure that you leave at least
10.2 cm (4 inches) at the back of the computer
and a minimum of 5.1 cm (2 inches) on all other
sides. You should never place your computer in
an enclosed space, such as a cabinet or drawer
when it is powered on.
WARNING: Do not block, push objects
into, or allow dust to accumulate in the
air vents. Do not store your Dell™computer
in a low-airflow environment, such as a
closed briefcase, while it is powered on.
Restricting the airflow can damage the
computer or cause a fire. The computer
turns on the fan when the computer gets
hot. Fan noise is normal and does not
indicate a problem with the fan or the
computer.
CAUTION: Placing or stacking heavy or
sharp objects on the computer may result
in permanent damage to the computer.
Setting Up Your Studio Laptop
6
Setting Up Your Studio Laptop
Connect the AC Adapter
Connect the AC adapter to the computer and then plug it into an electrical outlet or surge protector.
WARNING: The AC adapter works with electrical outlets worldwide. However, power
connectors and power strips vary among countries. Using an incompatible cable or
improperly connecting the cable to a power strip or electrical outlet may cause fire or
permanent damage to your computer.
NOTE: Use only Dell AC adapter family PA-10, PA-2E, PA-3E, or PA-12 with your computer.
For more information, see “Specifications” on page 74, or the system regulatory label on the
bottom of your computer.
7
Setting Up Your Studio Laptop
Connect the Network Cable (Optional)
To use a wired network connection, connect the network cable.
8
Setting Up Your Studio Laptop
Press the Power Button
