Dell™Studio1735/1737ServiceManual

Notes, Notices, and Cautions

Information in this document is subject to change without notice.

©2008DellInc.Allrightsreserved.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.;Bluetooth is a registered trademark owned by Bluetooth SIG, Inc. and is used by Dell under

license. Microsoft, Windows, and Windows Vista are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

Model PP31L

October2008Rev.A01

Before You Begin

Base Cover

Hard Drive

Memory

Coin-Cell Battery

Processor Heat Sink

Processor

Center Control Cover

Keyboard

Display

Camera (optional)

Palm Rest

Optical Drive

Speakers

System Board

Fan

Charger Board

Communication Cards

Audio Board

Microphone

Battery Latch Assembly

Flashing the BIOS

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Back to Contents Page

Audio Board

Dell™Studio1735/1737ServiceManual

Removing the Audio Board

Replacing the Audio Board



Removing the Audio Board



1. Follow the instructions in Before You Begin.



2. Press and eject any installed cards from the ExpressCard slot and the 8-in-1 memory card reader.



3. Remove any installed memory modules and Mini-Cards (see Memory and Communication Cards).



4. Follow the instructions in Removing the Palm Rest.



5. Remove the screw that secures the audio board and disconnect the audio board cable from the connector on the system board.



6. Lift the audio board and the cable out of the computer base.

Replacing the Audio Board



1. Place the audio board in the computer base and replace the screw that secures it.



2. Connect the audio board cable to the connector on the system board.



3. Follow the instructions in Replacing the Palm Rest.



4. Reinstall the memory modules and Mini-Cards, if any.



5. Reinstall any removed cards in the ExpressCard and 8-in-1 card slots.



CAUTION: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best

practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.

NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface

(such as the back panel) on the computer.

audio cable connector

audio board

screw

audio cable

system board



NOTICE: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may

result in damage to the computer.

Back to Contents Page



Back to Contents Page

Base Cover

Dell™Studio1735/1737ServiceManual

Removing the Base Cover

Replacing the Base Cover



Removing the Base Cover



1. Ensure that the computer is turned off.



2. Remove the battery (see Before Working Inside Your Computer).



3. Loosen the eight captive screws on the base cover and lift the cover off the computer at an angle as shown in the figure.



Replacing the Base Cover



1. Align the tabs on the base cover to the bottom of the computer.



2. Replace and tighten the eight captive screws on the base cover.



3. Slide the battery into the battery bay until it clicks into place.

Back to Contents Page



CAUTION: Before working inside your computer, follow the safety instructions that shipped with your computer.

CAUTION: Before performing this procedures, turn off the computer, disconnect the AC adapter from the electrical outlet and the computer,

disconnect the modem from the wall connector and the computer, and remove any other external cables from the computer.

NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface

(such as a connector on the back of the computer).

CAUTION: Do not touch the processor heat sink. Processor components should be removed only by trained support personnel.

base cover

captive screw (8)

Back to Contents Page

Battery Latch Assembly

Dell™Studio1735/1737ServiceManual

Removing the Battery Latch Assembly

Replacing the Battery Latch Assembly



Removing the Battery Latch Assembly



1. Follow the instructions in Before Working Inside Your Computer.



2. Remove the center control cover (see Removing the Center Control Cover).



3. Remove the keyboard (see Removing the Keyboard).



4. Remove the display assembly (see Display Assembly).



5. Remove the hard drive (see Removing the Hard Drive).



6. Remove the palm rest (see Removing the Palm Rest).



7. Remove the system board (see Removing the System Board).



8. Remove the charger board (see Removing the Charger Board).



9. Remove the three screws that secure the battery latch assembly to the computer base.



10. Remove the spring from the hook that holds it in place.



11. Lift the assembly out of the computer base.

Replacing the Battery Latch Assembly

CAUTION: Before you begin the following procedure, follow the safety instructions that shipped with your computer.

NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface

(such as the back panel) on the computer.

NOTICE: To help prevent damage to the system board, remove the main battery (see Before Working Inside Your Computer) before working

inside the computer.

screw (3)

battery latch assembly

spring

battery release latch



1. Place the latch assembly in the channel on the computer base.



2. Using a small screwdriver, place the spring over the hook on the computer base.



3. Replace the three screws.

Ensure that the newly installed latch moves smoothly and freely when pushed and released.



4. Replace the charger board (see Replacing the Charger Board).



5. Replace the system board (see Replacing the System Board).



6. Replace the palm rest (see Replacing the Palm Rest).



7. Replace the hard drive (see Replacing the Hard Drive).



8. Replace the display assembly (see Replacing the Display Assembly).



9. Replace the base cover (see Replacing the Base Cover).



10. Replace the keyboard (see Replacing the Keyboard).



11. Replace the center control cover (see Replacing the Center Control Cover).



12. Slide the battery into the bay until it clicks into place.

Back to Contents Page



NOTICE: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may

result in damage to the computer.

Back to Contents Page

Before You Begin

Dell™Studio1735/1737ServiceManual

Recommended Tools

Turning Off Your Computer

Before Working Inside Your Computer

This section provides procedures for removing and installing the components in your computer. Unless otherwise noted, each procedure assumes that the

following conditions exist:

lYou have performed the steps in Turning Off Your Computer and Before Working Inside Your Computer.

lYou have read the safety information that shipped with your computer.

lA component can be replaced or—if purchased separately—installed by performing the removal procedure in reverse order.

Recommended Tools

The procedures in this document may require the following tools:

lSmall flat-blade screwdriver

lPhillips screwdriver

lHex nut driver

lFlash BIOS update program CD

Turning Off Your Computer



1. Save and close all open files and exit all open programs.



2. In Windows Vista®, click Start , click the arrow , and then click Shut Down.

The computer turns off after the operating system shutdown process finishes.



3. Ensure that the computer and any attached devices are turned off. If your computer and attached devices did not automatically turn off when you shut

down your operating system, press and hold the power button for at least 8 to 10 seconds until the computer turns off.

Before Working Inside Your Computer

Use the following safety guidelines to help protect your computer from potential damage and to help to ensure your own personal safety.



1. Ensure that the work surface is flat and clean to prevent the computer cover from being scratched.



2. Turn off your computer (see Turning Off Your Computer).



NOTICE: To avoid losing data, save and close all open files and exit all open programs before you turn off your computer.

CAUTION: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best

practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.

NOTICE: Handle components and cards with care. Do not touch the components or contacts on a card. Hold a card by its edges or by its metal

mounting bracket. Hold a component such as a processor by its edges, not by its pins.

NOTICE: Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell is

not covered by your warranty.

NOTICE: When you disconnect a cable, pull on its connector or on its pull-tab, not on the cable itself. Some cables have connectors with locking

tabs; if you are disconnecting this type of cable, press in on the locking tabs before you disconnect the cable. As you pull connectors apart, keep

them evenly aligned to avoid bending any connector pins. Also, before you connect a cable, ensure that both connectors are correctly oriented

and aligned.

NOTICE: To avoid damaging the computer, perform the following steps before you begin working inside the computer.



3. If the computer is connected to a docking device (docked), undock it. See the documentation that came with your docking device for instructions.



4. Disconnect all telephone or network cables from the computer.



5. Press and eject any installed cards from the ExpressCard slot and the 8-in--1 memory card reader.



6. Disconnect your computer and all attached devices from their electrical outlets.



7. Turn the computer over.



8. Slide and click the battery latch release.



9. Slide the battery out of the battery bay.



10. Press the power button to ground the system board.

Back to Contents Page



NOTICE: To disconnect a network cable, first unplug the cable from your computer and then unplug the cable from the network device.

NOTICE: To help prevent damage to the system board, you must remove the battery from the battery bay before you service the computer.

NOTICE: To avoid damage to the computer, use only the battery designed for this particular Dell computer. Do not use batteries designed for

other Dell computers.

battery

battery latch release

Back to Contents Page

Flashing the BIOS

Dell™Studio1735/1737ServiceManual

Flashing the BIOS From a CD

Flashing the BIOS From the Hard Drive

If a BIOS-update program CD is provided with the new system board, flash the BIOS from the CD. If you do not have a BIOS-update program CD, flash the

BIOS from the hard drive.

Flashing the BIOS From a CD



1. Ensure that the AC adapter is plugged in and that the main battery is installed properly.



2. Insert the BIOS-update program CD, and restart the computer.

Follow the instructions that appear on the screen. The computer continues to boot and updates the new BIOS. When the flash update is complete, the

computer will automatically reboot.



3. Press <F2> during POST to enter the system setup program.



4. Press <Alt> and <F> to reset the computer defaults.



5. Press <Esc>, select Save changes and reboot, and press <Enter> to save configuration changes.



6. Remove the flash BIOS-update program CD from the drive and restart the computer.

Flashing the BIOS From the Hard Drive



1. Ensure that the AC adapter is plugged in, the main battery is properly installed, and a network cable is attached.



2. Turn on the computer.



3. Locate the latest BIOS update file for your computer at support.dell.com.



4. Click Download Now to download the file.



5. If the Export Compliance Disclaimer window appears, click Yes, I Accept this Agreement.

The File Download window appears.



6. Click Save this program to disk and then click OK.

The Save In window appears.



7. Click the down arrow to view the Save In menu, select Desktop, and then click Save.

The file downloads to your desktop.



8. Click Close if the Download Complete window appears.

The file icon appears on your desktop and is titled the same as the downloaded BIOS update file.



9. Double-click the file icon on the desktop and follow the instructions on the screen.

Back to Contents Page



NOTE: If you use a BIOS-update program CD to flash the BIOS, set up the computer to boot from a CD before inserting the CD.

Back to Contents Page

Camera (optional)

Dell™Studio1735/1737ServiceManual

Removing the Camera

Replacing the Camera



Removing the Camera



1. Follow the instructions in Before You Begin.



2. Follow the instructions in Display Assembly.



3. Remove the display bezel (see Display Bezel).



4. Pull the camera cable pull-tab to disconnect it from the connector on the camera board.



5. Remove the two screws securing the camera board.



6. Remove the camera board.

Replacing the Camera



1. Align the camera board over the screw holes.



2. Replace the two screws that secure the camera board to the display.



3. Connect the camera cable to the connector on the display board.



4. Replace the display bezel (see Replacing the Display Bezel).



5. Follow the instructions inReplacing the Display Assembly.

Back to Contents Page



CAUTION: Before working inside your computer, follow the safety instructions that shipped with your computer.

NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface

(such as a connector on the back of the computer).

camera

camera cable pull-tab

screw (2)

Andere Handbücher für Studio 1735

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Dell Laptop Handbücher

Dell

Dell Inspiron 15 3000 Series Bedienungsanleitung

Dell

Dell P121G001 Bedienungsanleitung

Dell

Dell Inspiron 17-5767 Bedienungs- und Wartungshandbuch

Dell

Dell Inspiron 1521 Bedienungsanleitung

Dell

Dell Alienware 13 Bedienungsanleitung

Dell

Dell Inspiron 14 5000 Series Bedienungsanleitung

Dell

Dell Alienware 17 R5 Bedienungsanleitung

Dell

Dell Inspiron 7720 Bedienungsanleitung

Dell

Dell Inspiron 13 5000 Bedienungs- und Wartungshandbuch

Dell

Dell Latitude MD991 Bedienungsanleitung

Dell

Dell Latitude E6440 Bedienungsanleitung

Dell

Dell Inspiron 14 3000 Series Bedienungsanleitung

Dell

Dell Inspiron 17R 5737 Bedienungsanleitung

Dell

Dell Inspiron 15 5000 Series Bedienungs- und Wartungshandbuch

Dell

Dell Latitude XPi CD Bedienungsanleitung

Dell

Dell Inspirion Bedienungsanleitung

Dell

Dell PowerEdge 6400 Bedienungsanleitung

Dell

Dell Latitude 5511 Bedienungsanleitung

Dell

Dell Inspiron 15 3000 Series Bedienungsanleitung

Dell

Dell Latitude JF854 Bedienungsanleitung

Dell

Dell Precision M65 Bedienungsanleitung

Dell

Dell Inspiron 1300 Bedienungsanleitung

Dell

Dell Inspiron 20-3045 Bedienungsanleitung

Dell

Dell XPS /Dimension Gen 2 Bedienungsanleitung

Beliebte Laptop Handbücher anderer Marken

HP ze2401xt - Pavilion Notebook PC Bedienungsanleitung

Velocity

Velocity NoteMagix M10 Bedienungsanleitung

Toshiba

Toshiba A105-S2236 Bedienungsanleitung

HP ENVY 17 Handbuch

Winbook

Winbook LM Bedienungsanleitung

HP PROBOOK 4520S Handbuch

Sony

Sony VAIO PCG-FX270 Bedienungsanleitung

Sony

Sony VAIO PCG-R505JLK Bedienungsanleitung

Lenovo

Lenovo THINKPAD X32 Bedienungsanleitung

HP Compaq tc4200 Kurzanleitung

Toshiba

Toshiba mini NB300 Bedienungsanleitung

Lenovo

Lenovo ThinkPad X201 Tablet Handbuch

Lenovo

Lenovo THINKPAD X31 Handbuch

Sony

Sony VGN-T240P VAIO Bedienungsanleitung

Compaq

Compaq Armada E700 Series Bedienungsanleitung

Fujitsu

Fujitsu Lifebook A6230 Bedienungsanleitung

Acer

Acer Aspire ONE 722 Bedienungsanleitung

Toshiba

Toshiba L300-EZ1524 Bedienungsanleitung
