Dell™ PowerEdge™ R900
Systems
Information Update
Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better
use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data
if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
____________________
Information in this document is subject to change without notice.
© 2008–2009 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, and PowerEdge are trademarks of Dell Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks
and trade names other than its own.
June 2009 Rev. A05
Information Update 3
Information Update
Installing an Internal USB Memory Key
The USB memory key can be used as a boot device, security key, or mass
storage device. To use the internal USB connector, the Internal USB Port
option must be enabled in the Integrated Devices screen of the System Setup
program.
To boot from the USB memory key, you must configure the USB memory
key with a boot image and then specify the USB memory key in the boot
sequence in the System Setup program. See "Integrated Devices Screen"
in your
Hardware Owner’s Manual
.
For information on creating a bootable file
on the USB memory key, see the user documentation that accompanied
the USB memory key.
WARNING: Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team.
NOTE: To avoid interference with other components, the maximum allowable
dimensions of the USB key are 24 mm (0.94 in) wide x 79 mm (3.11 in) long x 8.6 mm
(0.33 in) high.
1
Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2
Open the system. See "Removing and Installing the Top Cover"
in your
Hardware Owner’s Manual
.
3
Locate the USB connector on the system board. See Figure 6-1
in your
Hardware Owner’s Manual
.
4
Insert the USB memory key into the USB connector.
5
Close the system. See "Removing and Installing the Top Cover"
in your
Hardware Owner’s Manual
.
6
Reconnect the system to power and restart the system.
4Information Update
2
1
Figure 1. Removing or Installing a USB Memory Key
Added Support for 8-GB Memory Modules
Your Dell™ PowerEdge™ R900 system now supports the following 8-GB
memory configurations:
• 32 GB — 4 x 8-GB quad-rank memory modules
• 64 GB — 8 x 8-GB quad-rank memory modules
NOTE: If 64 GB of memory is installed, the system will only recognize
and display 63.75 GB during POST.
• 128 GB — 16 x 8-GB quad-rank memory modules
• 256 GB — 32 x 8-GB quad-rank memory modules
NOTE: Prior to upgrading your system, verify that the latest system BIOS version is
on your system. Loading the latest BIOS version from support.dell.com will ensure
that your system is fully supported.
NOTE: Some operating systems cannot support more than 4 GB of physical
memory. For more information on memory support requirements and restrictions,
refer to the operating system documentation that ships with your system.
1 USB memory key 2 USB memory key connector
Information Update 5
BMC and DRAC5 Firmware Version Requirements
When upgrading either the BMC or the DRAC5, you must update the
firmware for both components to ensure full functionality and compatibility.
For example, the power reduction feature of the DRAC5 version 1.40
firmware works only when BMC 2.27 or higher is also installed. If the BMC
and DRAC firmware are incompatible—BMC 2.27 installed with DRAC5
version 1.33 or BMC 1.79 installed with DRAC5 version 1.40—the power
reduction feature may not function correctly.
Back Cooling Fans
Systems manufactured after September 2008 no longer include the four back
cooling fans installed in earlier systems. Therefore, BMC version 2.27 does
not recognize the presence of back fans. The back fans will still run in older
systems; however, from a system perspective, the fans do not exist and are
not monitored. As a result, if the back fans fail, the SEL, server management
software, and remote access card will not log the error. This change does not
compromise the standard hot plug and redundancy features of the front fans.
New LCD Error Codes
The following LCD error codes have been added for your system. For a
complete list of error codes, see "About Your System" in your Hardware
Owner’s Manual.
Table 1. LCD Status Messages
Code Test Causes Corrective Actions
EB107 Proc
Machine
Check Error
CPU detected an
unrecoverable hardware
error.
See error EB113 for specific
information on what
hardware failed.
EB113 PCIE Fatal
Error
Slot XX
CPU detected an
unrecoverable hardware
error.
"XX" indicates the slot
associated with the failed
hardware. If you are unable
to resolve the issue, see
"Getting Help" in your
Hardware Owner’s Manual.
6Information Update
E1A18 PDB Ctrl
Cable
PDB control cable is
missing, loose, or faulty.
Reseat the cable. If problem
persists, replace the cable.
See "Getting Help" in your
Hardware Owner’s Manual.
E1118 CPU Temp
Interface
Processor has exceeded
acceptable temperature
and has been disabled
to prevent damage.
See "Troubleshooting
System Cooling" in your
Hardware Owner’s Manual.
E1716 Chipset The BIOS has
determined that there
is a problem with the
chipset, but is unable
to determine its origin.
See "Getting Help" in your
Hardware Owner’s Manual.
E1717 IERR CPU is faulty. Applicable
only for BIOS 1.1.9 and
BMC 2.27 and later.
Replace the CPU.
See "Troubleshooting
Processors" in your Hardware
Owner’s Manual.
E1914 DRAC5 Conn
2 Cbl
DRAC5 cable is missing,
loose, or faulty.
Reseat the cable. If problem
persists, replace the cable.
See "Getting Help" in your
Hardware Owner’s Manual.
E2122 Fatal Mem
Reset
System memory failed. See "Troubleshooting
System Memory" in your
Hardware Owner’s Manual.
I1915 Video Off Local video is disabled. Information only.
I1916 Video Off
in XX
Remote disabling of
local video currently
in process.
Information only.
NOTE: For the full name of an abbreviation or acronym used in this table, see "Glossary"
in your Hardware Owner’s Manual.
Table 1. LCD Status Messages (continued)
Code Test Causes Corrective Actions
Information Update 7
New SEL Sensor Messages
The following SEL sensor messages have been added to the systems
management software and remote access card software.
System Board Replacement - Safeguarding
Encrypted Data
On systems using an operating system that supports the Trusted Platform
Module (TPM) and related encryption programs, you can use these features
to secure the contents of the hard drive(s).
If you are using the TPM with an encryption program, you may be prompted
to create a recovery key during system or program setup. Be sure to create and
safely store this recovery key. If you ever need to replace the system board, you
must supply the recovery key when you restart your system or program, before
you can access the encrypted data on your hard drive(s).
Table 2. Sensor Message Definitions
Sensor Number Message Definition
0x26 PCIE Non Fatal
error
A non-fatal error occurred. The system
will continue to operate normally.
0x27 Generic Fatal
I/O Error
A fatal I/O error occurred. The system
will no longer respond.
0x28 Processor
Machine Check
Error
A processor error occurred. The system
will no longer respond.
NOTE: For the full name of an abbreviation or acronym used in this table, see "Glossary"
in your Hardware Owner’s Manual.
8Information Update
Dell™ PowerEdge™
R900 系统
信息更新
注、小心和警告
注：“注”表示可以帮助您更好地使用计算机的重要信息。
小心：“小心”表示如果不遵循说明，就有可能损坏硬件或导
致数据丢失。
警告：
“ 告”表示可能会造成财产损失、人身伤害甚至死亡。
____________________
本说明文件中的信息如有更改，恕不另行通知。
© 2008-2009 Dell Inc. 版权所有，翻印必究。
未经 Dell Inc. 书面许可，严禁以任何形式复制这些材料。
本文中使用的商标：Dell DELL 徽标和 PowerEdge 是Dell Inc. 的商标。
本说明文件中述及的其它商标和产品名称是指拥有相应商标和产品名称的公司或其制造的
产品。 Dell Inc. 对本公司的商标和产品名称之外的其它商标和产品名称不拥有任何专有权。
2009 年6 月Rev. A05
