Dell™ PowerConnect™

8132/8164/8132F/8164F/7024/7048/7024P/7048P/7024F/7048R/

7048R-RA/8024/8024F/M6220/M6348/M8024/M8024-k

PowerConnect

5.1.0.1 Firmware Release Notes

Date: April 2013

System Firmware Version 5.1.0.1

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc.is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo and PowerConnect are trademarks of Dell Inc; Intel and Pentium are registered trademarks and

Celeron is a trademark of Intel Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation.

Other trademarks and trade names may be used in this document to refer to either the entity claiming the marks and names or their products. Dell

in part, be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form without the prior written

consent of Dell. Dell reserves the right to make changes without further notice to any products or specifications referred to herein to improve

reliability, functionality or design.

Reproduction, adaptation or translation without prior written permission is prohibited, except as allowed under the copyright laws.

2 System Firmware Version 5.1.0.1

Table of Contents

Introduction 1

Global Support 1

Firmware Specifications 1

Firmware Upgrade 2

Firmware Downgrade 3

Boot Code Downgrade 4

Hardware Supported 4

Support Matrix 5

Supported Firmware Functionality 6

Added Functionality in this Release 7

Changed Functionality in this Release 14

Issues Resolved 21

CLI Reference Guide Updates 52

User’s Configuration Guide Updates 56

Known Issues 58

Known Restrictions and Limitations 67

System – 5.0.1.3 67

System – 5.0.0.4 68

Management – 4.2.1.3 68

Layer 2 – 4.2.0.4 69

Layer 3 – 4.2.0.4 70

Management – 4.2.0.4 71

Data Center – 4.2.0.4 72

End of Release Notes 72

PowerConnect 8132/8164/8132F/8164F/8024/8024F/M8024/M8024-k/

M6220/M6348/7024/7048/7024P/7048P/7024F/7048R/7048R-RA

Release Notes

System Firmware Version 5.1.0.1 Page 1

Introduction

This document provides specific information for the Dell PowerConnect

8132/8164/8132F/8164F/7024/7048/7024P/7048P/7024F/7048R/7048R-RA/8024/8024F/M6220/M6348/M8024/M8024-k

switches firmware version 5.1.0.1.

It is recommended that this release note be thoroughly reviewed prior to installing or upgrading of this product.

Global Support

For information regarding the latest available firmware, release note revisions, or additional assistance, please visit

support.dell.com.

Firmware Specifications

Firmware Version

Firmware Image Name Version Number Release Date

PC8100v5.1.0.1.stk

PCM6220v5.1.0.1.stk

PC7000_M6348v5.1.0.1.stk

PC8024v5.1.0.1.stk

PCM8024v5.1.0.1.stk

PCM8024kv5.1.0.1.stk

5.1.0.1

April 2013

Version Numbering Convention

Version number

Description

PowerConnect

Series

Four part version number



Denotes the build number.



Denotes an ad hoc release of the product software.



Denotes a scheduled maintenance release of the product software.



Denotes a major version number.

2 System Firmware Version 5.1.0.1

Firmware Upgrade

NOTE: Administrators upgrading PowerConnect 7024/7048/7024P/7048P/7024F/

7048R/7048R-RA/8024/8024F/M6220/M6348/M8024/M8024k switches from 2.x.x.x or

3.x.x.x or 4.x.x.x or 5.0.x.x versions of firmware MUST follow the instructions

documented in the Upgrading PowerConnect Switches from Version 2.x.x.x or 3.x.x.x

or 4.x.x.x or 5.0.x.x to 5.1.0.1 Firmware procedure. Failure to follow the procedures

described in that document when upgrading from 2.x.x.x or 3.x.x.x or 4.x.x.x or 5.0.x.x

firmware may result in an inoperable switch!

NOTE: After upgrading the switch firmware version to 5.1.0.1, the CPLD (Complex

Programmable Logic Device) code update is required on M8024-k and PC8024/PC8024F

switches via serial console if switch is running with the older CPLD version. The latest

CPLD version available for M8024k switch is Version 5 and for PC8024/PC8024F switch is

Version 6. Administrators upgrading PowerConnect 8024/8024F/M8024k switches MUST

follow the CPLD update instructions documented in the Upgrading PowerConnect

Switches from Version 2.x.x.x or 3.x.x.x or 4.x.x.x or 5.0.x.x to 5.1.0.1 Firmware

procedure.

NOTE: Administrators upgrading PowerConnect 8132/8164/8132F/8164F switches

MUST follow the instructions documented in the Upgrading PowerConnect

8132_8164_8132F_8164F switches from Version 5.0.x.x to 5.1.0.1

Firmware procedure. Failure to follow the procedures described in that document when

upgrading firmware may result in an inoperable switch!

NOTE: OMNM (Open Manage Network Manager) v5.2 SP1 supports firmware

management of PowerConnect 7024/7048/7024P/7048P/7024F/7048R/7048R-

RA/8024/8024F/M6220/M6348/M8024/M8024-k to deploy the firmware version 4.1.x.x or

later. OMNM v5.2 SP1 supports PowerConnect 8132/8164/8132F/8164F to deploy the

firmware version 5.0.0.4

PowerConnect 8132/8164/8132F/8164F/8024/8024F/M8024/M8024-k/

M6220/M6348/7024/7048/7024P/7048P/7024F/7048R/7048R-RA

Release Notes

System Firmware Version 5.1.0.1 Page 3

Firmware Downgrade

Downgrading from 5.1.0.1 to an earlier release is supported on most PowerConnect series switches (except PC81xx series

with B1 CPU versions, see note below); however, migration of configuration information from a later release to an earlier

release is not supported. The existing configuration may or may not work with the earlier version of firmware, therefore, it is best

to be physically present at the switch site and to be prepared to access the switch over the serial port if necessary when

downgrading firmware.

Auto-downgrade of a stack is not enabled by default. If downgrading a stack, be sure to enable auto-downgrade before activating

the earlier versions of firmware on the stack master.

Recent versions of the PowerConnect 81xx series switches support newer versions of CPU (B1). The B1 version of CPU

requires Release 5.1.0.1 or later firmware and cannot be downgraded to earlier releases. In addition, if this unit is to be deployed

as a member within a stack, the entire stack will be required to run 5.1.0.1 or later firmware. Here are some steps to help

determine what CPU is in the PowerConnect 8100 Series switch:

1. Run show version from the CLI prompt.

2. If there is no CPU version line, then the stack is running 5.0.x.x firmware. Since 5.0.x.x can only run on

A1 CPU switches, then all switches in the stack (or a standalone) contain A1 CPUs.

3. If there is a CPU version line (like below):

CPU Version....................... XLP308H-A1

(It will display the CPU version in the last two characters - either A1 or B1).

4. On a stack, run show version mwhere mis the unit number assigned to the stack member to see each CPU

version for each member in the stack.

In addition here are the part numbers for reference:

Part Numbers for PowerConnect 81xx

A1 CPU

B1 CPU

PowerConnect 8132 (US, Canada, Mexico, South America)

TRJ78

PTM0F

PowerConnect 8132 (all other countries) 0C90P X20W5

PowerConnect 8132F

(US, Canada, Mexico, South America)

W0HV1

NWHGV

PowerConnect 8132F (all other countries)

7D1GN

KWHG3

PowerConnect 8164 (US, Canada, Mexico, South America)

H0F6C

N00C1

PowerConnect 8164 (all other countries)

P8RHX

Y2FJ0

PowerConnect 8164F (US, Canada, Mexico, South America)

VTWN8

4PHP2

PowerConnect 8164F

(all other countries)

1JWM5

8KHT1

Recent versions of the PowerConnect M8024-K modular switches have hardware changes that require firmware version 4.1.0.19

or higher. PowerConnect M8024-K with a new PPID label cannot be downgraded below 4.1.0.19. If a downgrade is attempted,

the firmware activation procedure will detect that earlier firmware is not compatible with the switch hardware and abort the

activation procedure. Any PowerConnect M8024-K with the old PPID label can accept any version of the switch firmware.

MODEL OLD PPID NEW PPID

M8024K 2F07F A00 2F07F A01

57821 A00 57821 A01

4 System Firmware Version 5.1.0.1

Boot Code Downgrade

Never downgrade the boot code! The 5.1.0.1 boot code supports all earlier versions of firmware and never needs downgrading.

Hardware Supported

•Dell PowerConnect 8132 Ethernet Switch

•Dell PowerConnect 8164 Ethernet Switch

•Dell PowerConnect 8132F Ethernet Switch

•Dell PowerConnect 8164F Ethernet Switch

•Dell PowerConnect M6220 Ethernet Switch

•Dell PowerConnect M6348 Ethernet Switch

•Dell PowerConnect 7024 Ethernet Switch

•Dell PowerConnect 7048 Ethernet Switch

•Dell PowerConnect 7024P Ethernet Switch

•Dell PowerConnect 7048P Ethernet Switch

•Dell PowerConnect 7024F Ethernet Switch

•Dell PowerConnect 7048R Ethernet Switch

•Dell PowerConnect 7048R-RA Ethernet Switch

•Dell PowerConnect 8024 Ethernet Switch

•Dell PowerConnect 8024F Ethernet Switch

•Dell PowerConnect M8024 Ethernet Switch

•Dell PowerConnect M8024-k Ethernet Switch

PowerConnect 8132/8164/8132F/8164F/8024/8024F/M8024/M8024-k/

M6220/M6348/7024/7048/7024P/7048P/7024F/7048R/7048R-RA

Release Notes

System Firmware Version 5.1.0.1 Page 5

Support Matrix

Since not all functionality is supported on all switches, the following matrix identifies the major differences among the

PowerConnect switch models. A check mark indicates support for the feature. All other features listed in the release notes are

supported on all switches.

Feature/Switch Priority

Flow

Control

DCBx ETS PoE+ iSCSI

Optimization USB grEEEn

Ethernet Hot

Swap

Cards

WRED

Dell PowerConnect

M6220 Ethernet

Switch

Dell PowerConnect

M6348 Ethernet

Switch



Dell PowerConnect

7024 Ethernet

Switch



Dell PowerConnect

7048 Ethernet

Switch



Dell PowerConnect

7024P Ethernet

Switch



Dell PowerConnect

7048P Ethernet

Switch



Dell PowerConnect

7024F Ethernet

Switch



Dell PowerConnect

7048R Ethernet

Switch



Dell PowerConnect

7048R-RA Ethernet

Switch



Dell PowerConnect

8024 Ethernet

Switch 



Dell PowerConnect

8024F Ethernet

Switch 



Dell PowerConnect

M8024 Ethernet

Switch



Dell PowerConnect

M8024-k Ethernet

Switch 



Dell PowerConnect

8132 Ethernet

Switch 



Dell PowerConnect

8164 Ethernet

Switch 



Dell PowerConnect

8132F/8164F

Ethernet Switch 



6 System Firmware Version 5.1.0.1

Supported Firmware Functionality

For more details regarding all the supported firmware features and functionality, please refer to the Dell PowerConnect Series

CLI Reference Guide and the Dell PowerConnect Series User’s Configuration Guide.

PowerConnect 8132/8164/8132F/8164F/8024/8024F/M8024/M8024-k/

M6220/M6348/7024/7048/7024P/7048P/7024F/7048R/7048R-RA

Release Notes

System Firmware Version 5.1.0.1 Page 7

Added Functionality in this Release

This section contains a list of features added in this release that are new for at least one switch listed in the Hardware Supported

section above.

Release 5.1.0.1

IGMP Snooping Improvements

IP Multicast Enhancements

Support for B1 CPU – only on PC8100 series

New Browser Support

•Mozilla Firefox 14

•Internet Explorer 9

•Google Chrome 21

Static Route Maximum Increased to 512 (for all switches except for M6220 series)

USB Auto-configuration expanded for multiple MAC Address support

Ability to reset stack port counters

Increased Maximum number of dot1x clients per port to 24

Commands to remove signed certificates/Keys

Support for Additional transceivers/optics

Release 5.0.1.3

Added PoE DC Disconnect HW support – on PC7000 series

Release 5.0.0.4

Added Native EEE Support for the PC8100 10GBaseT Ports

802.1Qaz (ETS) – on 8100 series

Support for 40 Gig (QSFP+) interfaces

Support for Bootcode upgrade from pre-4.x image to 5.x image without manual system reset.

Local Preference for LAG

Private VLAN

CLI output filtering

Routing Improvements for OSPF

UDLD

Administrative Profiles

AAA Authorization

TACACS+ Accounting

Stacking over QSFP+ ports

QSFP+ diagnostics

sFlow Support on Port Channels

Release 4.2.2.3

No Added Functionality in this Release

8 System Firmware Version 5.1.0.1

Release 4.2.1.3

No Added Functionality in this Release

Release 4.2.0.4

DCBx on M8024-k/8024/8024F

FIP Snooping Bridge on M8024-k/8024/8024F

Add EEE Support for the PC7000 10GBaseT Ports

GUI EEE Power Savings Charts

RP Failover Performance Improvement

Flexible Dynamic LAG Limits

CLI Help Usability Improvements

Ability to Show Static Route Entries

CMC XML Support

Stacking Over Ethernet Ports

Change Dell EqualLogic iSCSI Auto Detect to default

Add CLI Macro (Port Profile) for Dell Compellent Storage Equipment

Provide Dell EqualLogic DCBx TLV Auto Detect and Configuration on M8024-k/8024/8024F

Release 4.1.1.9

No Added Functionality in this Release

Release 4.1.0.19

Media-type CLI command

Added new command "media-type" to configure an interface to select the specified media on a combo port. It is

recommended the administrators select the specific media type for the particular type of network connection they

expect to use. Users may observe a single port flap when the media type is changed from RJ45 to auto-select RJ45 and

only the corresponding SFP port is enabled. Refer to the CLI Reference Guide Updates section below for the complete

syntax.

Release 4.1.0.6

IPv4-Only Mode Optimization

PowerConnect switches allocate the maximum sizes for routing tables (and others, as applicable) for both IPv4 and

IPv6. Switch Performance Optimization allows the operator to optimize the allocation of switch silicon tables for

either IPv4 only or mixed IPv4/IPv6 operation. The template specified limits are enforced by routing components

when routes are being learned. When IPv4 only mode is selected, the following capabilities are disabled:

•DHCPv6 relay

•DHCPv6 server

•IPv6 routing/forwarding

•OSPFv3

•IPv6 Neighbor Discovery

•Configured v6-over-v4 tunnels

•Automatic (6to4) tunnels

•IPv6 Multicast

A reboot is required when changing to or from IPv4 mode.

Andere Handbücher für Networking 7048

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Dell Schalten Handbücher

Dell

Dell PowerConnect 3024 Benutzerhandbuch

Dell

Dell PowerVault 56F Bedienungsanleitung

Dell

Dell N2000 Series Bedienungsanleitung

Dell

Dell PowerConnect 8024 Gebrauchs- und Pflegehandbuch

Dell

Dell N1108T-ON Bedienungsanleitung

Dell

Dell Networking S4048 Bedienungsanleitung

Dell

Dell PowerConnect B-RX Bedienungsanleitung

Dell

Dell PowerConnect 5316M Bedienungsanleitung

Dell

Dell S6100 Anleitung zur Verwendung

Dell

Dell Networking Z9500 Bedienungsanleitung

Dell

Dell Powerconnect W-ClearPass Hardware Appliances Handbuch

Dell

Dell Broadcom NetXtreme Family of Adapters Bedienungsanleitung

Dell

Dell EMC N2200-ON Series Bedienungsanleitung

Dell

Dell PowerEdge 180AS Bedienungsanleitung

Dell

Dell PowerConnect B-RX Bedienungsanleitung

Dell

Dell Broadcom NetXtreme Family of Adapters Bedienungsanleitung

Dell

Dell PowerConnect 5316M Bedienungsanleitung

Dell

Dell PowerConnect 3248 Bedienungsanleitung

Dell

Dell PowerConnect 6024 Bedienungsanleitung

Dell

Dell PowerConnect 5424 Bedienungsanleitung

Dell

Dell PowerConnect B-DCX-4S Backbone Kurzanleitung

Dell

Dell Wyse R Class Bedienungsanleitung

Dell

Dell C7008 Bedienungsanleitung

Dell

Dell POWERCONNECT J SERIES Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
