DeLonghi CF08E Bedienungsanleitung
66126661
- 1 -
Features
Powerful dehumidifying capability
The dehumidifier powerfully removes excess
moisture from the air creating a drier,healthier
home environment.
Excellent drying laundry function
The dehumidifier dries laundry quickly. This can
prevent laundry and furniture from becoming damp
and musty in a rainy season.
Quiet operation
For overnight operation,the QUIET mode may be
selected.
Drainage tank with a large capacity
Large 6 litre capacity water tank means the
dehumidifier requires emptying less often.
Using refrigerant for protecting environment
The dehumidifier uses no CFC refrigerant
therefore protecting the environment.
Modern Design
The dehumidifier is compact with a streamlined
appearance and modem design.
The castors at the bottom allow easy mobility.
SAVE
Saving energy
The power consumption is low.
- 2 -
The dehumidification capacity is the value obtained after the dehumidifier was continuously run in the
room temperature of 30 with the relative humidity 80%.
The amount of dehumidification is the amount per day(24 hours).
The manufacturer reserves the right to change specifications without prior notification.
The work temperature is in the range 2 to 38 . If the room temperature is beyond the range, the unit
can not operate normally.
If you pour cold water into a cup, the air around the cup is cooled, and drops of water
form on the surface of the cup. The dehumidifiertakes advantage of this phenomenon to
remove moisture.
It draws in room air, cools it with a cooling unit,
and changes the humidity to drops of water.
The drops of water fall into a drainage tank.
The dehumidified air is re-heated by a heating
unit and discharged.
Steps ,,and are repeated to remove
humidity from the room.
After the air passes through the re-heating unit, its temperature will rise a little, so that the
temperature of the room will rise by 2 to 4 . This is normal operation.
How dehumidifying works
Specifications
Power Supply
Dehumidifying Capacity
Power Consumption
Drainage Tank Capacity
Weight
Dimension(height width depth)
Model CF08E
220 240V ~ 50Hz
6.0L
20L/day
400W
14kg
545mm 380mm 261.5mm
Cooling unit Re-heating unit
Moist air Dried air
Compressor Drainage tank
- 3 -
DrainageTank
Handle
Air Outlet
Louvre
Control Panel
Refer to next page
Sensor
Do not obstruct!
Float
Guard
Water Level
Gauge
When the unit is purchased,
there may be some water left in
the drainage tank. This is from
the dehumidifying test
conducted at the factory, and
does not indicate a problem.
Back panel
Continuous
Drainage Port
Refer to page 7
Air Filter
(Back panel air inlet)
do not obstruct!
Refer to page 8
Cord Hook
Cord Band
(undo on operation)
Power Supply Plug
Castors
Refer to page 7
Description
Front panel
- 4 -
Control Panel
4. “50%”, “60%”, “70%”:Humidity indicator light.
This indicates that the current humidity setting is “50%”,
“60%” or “70%” respctively.
5. The“Continuous”light indicates the unit is operating in
cotinuous mode.
Indicator lamp
1. Full : Tank full indicator lamp
It will light when the drainage tank is full or positioned incorrectly. Empty the water out of the drainage tank,
and make sure the tank is positioned properly.
2. On/Off” :Power indicator light.
It will light when the unit is plugged in.
3. Normal”, Hi”, Quiet”:mode indicator light.
Indicates mode of dehumidification selected.
Switch function
1. “On/Off” switch
Press the switch once to turn the dehumidifier on, press it again to turn it off.
2. “Mode” switch
Each time the switch is pressed, the mode changes in the order of “Normal”, “High” and “Quiet”
and the corresponding mode indicator lamp will change with the mode of operation.
3. “Humidity” switch
Press the switch to set the humidity of the room, which can be set in order of “50%”, “60%” “70%” and
“continuous”, and the corresponding humidity indicator lamp will light to display your setting humidity.
When the relative humidity of the room is lower than your humidity setting, the unit will turn off
automatically.
When the unit is initially started, the default operation is the continuous mode.
In this mode the unit will run until manually turned off,or the water tank is full.
- 5 -
Operation
1.Plug the power supply plug into the outlet and press the “ On/Off” switch
When the “ On/Off” switch is pressed during operation:
The unit turns off.
Do not turn the unit off by unplugging the power cord.
2.Setting the louvre angle
3.Switching the Unit On
4.Switching the Unit Off
Use single phase 220 240V AC power supply.
Wipe dust off of the power supply plug and insert the plug firmly,
all the way to the rubber section.
Do not use the appliance if the supply cord is damaged.
After the power supply plug is plugged into the outlet, the“On/
Off” indicator will light.
Before operation please check and make sure the louver has been
opened to ensure adequate air flow.
Set louvre to desired angle (when room temperature is above
32 set louvre to vertical position to allow maximum air flow.)
Press the “On/Off” switch, the unit operates in CONTINUOUS
mode automatically.
Normal Mode: Press the mode button until the “ Normal” mode is
selected.This setting allows medium air flow.
Hi Mode:Press the mode button until the “Hi” mode is selected.
This setting allows maximum air flow,and is ideal for enhanced
dehumification,drying clothes etc.
(When the indoor temperature is below 15 or above 35 , the
inbuilt protection device will allow operation in “Hi” mode only.)
Quiet mode: Press the mode switch until the “Quiet”mode is
selected.This setting allows minimum air flow,and is ideal for over-
night operation.
230-240VAC
220-240V AC
- 6 -
Abstergent
Gasoline
Thinner
Operation
Draining the water
The drainage tank is full
When the drainage tank becomes full (approx, 6 Litres), the full indicator lights to alert the user, and the
unit turns off automatically. Empty the water from the tank and discard it.
Drainage steps Notation for drainage
1. Remove the drainage tank
Lightly pressing on the sides of the tank with
both hands, pull it gently out.
Do not remove the bubble packing from the float
on the unit. The float on the unit will no longer be
able to detect without the bubble packing when the
water level is full, and water may leak from the
tank.
If the drainage tank is dirty, wash it with cold or
lukewarm water. Do not use detergent, scouring
pads, chemically treated cloths, or other cleaning
solutions as it may damage the drainage tank.
When replacing the drainage tank, press the tank
firmly into place with both hands. If the tank is not
positioned properly, the “ Tank Full” sensor will
activate, and the dehumidifier will not operate.
Check to make sure the guards are firmly attached
to the tank. If they are not, the drainage tank will
be harder to remove.
If the drainage tank is removed while the unit is in
operation, or immediately after operation has
stopped, water which is still in the cooling unit may
drip out on the base plate. Wait at least 30 minutes
before removing the drainage tank.(If water has
dripped, wipe it up.)
Take hold of the handle, and then remove the tank.
2. Discard the water
3. Place the drainage tank back in it’s
compartment.
Drain water
from this point
Guard
- 7 -
The unit has an optional continuous drainage port. Water can be continually drained by connecting a rubber
hose (15mm I.D), to this drainage port.When setting up the dehumidifier for continuous drainage, always
turn the unit off and unplug the supply plug.
2. Push the hose into the continuous drainage port
Pass a rubber hose (15mm I.D) through the continuous
drainage port, and press it firmly into the drainage port in
the main unit, making sure water does not leak.
The height of drain piping should always be lower than the
height of the drainage port.
Make sure there are no kinks or obstructions in the rubber
hose which may prevent the water draining out.
3.Return the drainage tank to its original position
Check the hose periodically to make sure it is still connected
and has not been obstructed.
1. Disconnect the drainage tank and open the
continuous drainage port.
Use sidecutters or similar tool to cut away the continuous
drainage port in the side of the main unit.
Operation
Draining the water
Continuous drainage of water
1.Drain the water.
2.Lift up the handle.
3.Move the unit.
1.If the floor is made of a material that scratches easily, or if the floor is uneven, lift up the unit and move
it. Also avoid rolling the unit on castors if the floor has shagpile carpet.
2.Tilt it within range of 20 to 30 degrees, as a rule (if you tip it too far, you may scratch the floor or water
may leak.)
3.Be careful that the power supply cord doesn't get pinched under the unit.
Moving the dehumidifier (using castors)
Note:
At least 50 cm At least 20 cm
At least 20 cm
At least 20 cm
At least 20 cm
Ensurethedehumidifierhas adequateclearance
between the unit and nearby walls as shown
below.
- 8 -
Wipe it with a soft cloth
Use a soft,clean cloth to wipe the surface.
(Do not use volatile chemicals detergents,chemically treated cloths
or other cleaning solutions.These could possibly damage the unit.)
Cleaning the air filter
The air filter should be cleaned approximately once every two
weeks.
1.Remove the air filter
Press downward on the tabs on the air filter to remove it.
3.Attach the air filter
Insert the lower tabs of the air filter into the main unit and
press the air filter until you hear the tabs click into place.
2.Clean the air filter
Run a vacuum cleaner lightly over the surface of the air
filter to remove dirt. If the air filter is very dirty, wash it with
warm water and a neutral cleaning solvent and dry it
throughly.
Caring for the dehumidifier
Maintenance
Cleaning the Unit
weeks.
