Delta Electronics Exhaust Fan EFB Series Bedienungsanleitung

40 x 40 x 20 MM SERIES

EFB

DIMENSIONS DRAWING

MOUNTING PANEL CUTOUT

Bearing Type

Ball Bearings

Material

Impeller & Frame : Plastic (UL 94V-0)

Lead Wires :

UL 1007 AWG #24 O Equivalent

Red Wire Positive (+)

Black Wire Negative (-)

Weight : 33g (1.16 oz)

* Function type is optional.

* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.

* Noise is measured in anechoic chamber in free air, one meter from intake side.

* All readings are typical values at rated voltage.

* Specifications are subject to change without notice.

Operating

Voltage

Range

MODEL Rated

Voltage

Maximum

Air Flow

Speed

Maximum

Air Pressure

Noise

FUNCTION VDC VDC Amp Watt R.P.M. 3

m /min CFM mmH

2O IN H2

O dB-A

EFB0405LD 54

12 7

24 14

-R00 / -F00 .5 to 5.5 0.10 0.50

5000 0.157 5.54 3.45 0.136 22.0

EFB0412LD -R00 / -F00 .0 to 13.8 0.05 0.60

EFB0424LD -R00 / -F00 .0 to 27.6 0.04 0.96

EFB0405MD -R00 / -F00 5 4.5 to 5.5 0.15 0.75

6300 0.203 7.17 5.54 0.218 24.0

EFB0412MD -R00 / -F00 12 7.0 to 13.8 0.06 0.72

EFB0424MD -R00 / -F00 24 14.0 to 27.6 0.05 1.20

EFB0405HD -R00 / -F00 5 4.5 to 5.5 0.25 1.25

7600 0.242 8.54 7.69 0.303 28.5

EFB0412HD -R00 / -F00 12 7.0 to 13.8 0.08 0.96

EFB0424HD -R00 / -F00 24 14.0 to 27.6 0.06 1.44

EFB0405HHD -R00 / -F00 5 4.5 to 5.5 0.30 1.50

8200 0.267 9.43 9.00 0.354 30.5

EFB0412HHD -R00 / -F00 12 7.0 to 13.8 0.10 1.20

EFB0424HHD -R00 / -F00 24 14.0 to 27.6 0.07 1.68

EFB0405VHD -R00 / -F00 5 4.5 to 5.5 0.32 1.60

9000 0.286 10.10 10.57 0.416 32.5

EFB0412VHD -R00 / -F00 12 7.0 to 13.8 0.12 1.44

EFB0424VHD -R00 / -F00 24 14.0 to 27.6 0.09 2.16

(12.992 0.394)

330.0 10.0

(0.394)

10.0

(4- 0.138 0.008)

4- 3.5 0.2

(0.787 0.020)

20.0 0.5

(0.118 0.012)

3.0 0.3

(0.118 0.012)

3.0 0.3

(1.575 0.020)

(1.260 0.012)

(1.575 0.020)

40.0 0.5

32.0 0.3

LABEL

UNIT: (INCH)

32.0

37.6

(1.480)

(1.260)

(1.480)

37.6

(1.260)

32.0

( 1.555)

39.5

32.0

(1.260)

37.6

(1.480)

(1.260)

(1.480)

37.6

32.0

(4- 0.138) (4- 0.138)

4- 3.5 4- 3.5

P & Q CURVE (AT RATED VOLTAGE)

Rib Type Only

Air Pressure

0.08

0.16

0.24

0.32

0.40

(mm H O)

(IN H O)

0.48

(CFM)

12.89.66.43.20

Air Flow

(M /MIN)

EFB0405/12/24XD

0 .08 .16 .32.24 .40

12.0

10.0

8.0

4.0

2.0

6.0

(INCH)

UNIT:

OUTLET SIDE INLET SIDE

http://www.deltaww.com

PART NO.

Input

Power

Input

Current
