QUICK-START

GUIDE

Denon

MC6000MK

Installation and Setup

The Denon MC6000MK2 is a class compliant USB plug and play device for

Mac, however requires drivers for Windows. You will nd these on the installation

CD provided with your Denon MC6000MK2.

NOTE: Please ensure you have the latest available drivers AND rmware updates,

which may be required in order to be compatible with Serato DJ. Please go to

http://serato.com/dj/support

1. Download and install the latest version of Serato DJ from http://serato.com/

dj/downloads

2. After installing drivers, connect your Denon MC6000MK2 to an available

USB Port.

3. Open Serato DJ.

4. The Denon MC6000MK2 platters require a few touches by the user in

order to calibrate to their environment. After power up and start of Serato

DJ, tap the platters a few times to set their sensitivity.

Serato DJ Activation

To nd out how to activate Serato DJ by either starting your free 14 day trial, or

purchasing a license for Serato DJ, click here for the most up to date information.

# Denon MC6000MK2 Control

1 DV 12V Power input

2 Controller ON/OFF

3 USB 2.0 Input

4 USB Audio line select switch

5 Balanced Booth Output L/R

6 Balanced Master XLR Output

L/R

7 Mono/Stereo switch

8 Unbalanced RCA Master Output

9 Line 4 L/R Input

10 Phono/Line Switch

11 Line 3 L/R Input

12 Phono/Line Switch

13 Line 2 L/R Input

14 Line 1 L/R Input

15 MIC 2 TRS Input

1 2 3 4 5 6 7 8 9 10 11 121314 15 16

17 18 19 20 21 22 23 24 25 26 27 28

16 MIC 1 XLR Input

17 Headphones Input

18 Headphone volume

19 Cue/Master volume

20 Split Cue switch

21 MIC 1 EQ LOW/MID/HI

22 MIC 2 EQ LOW/MID/HI

23 MIC Echo

24 Fader Assignment CH3 L/Thur/R

25 Fader Assignment CH1 L/Thur/R

26 X Fader Curve Dial

27 Fader Assignment CH 2 L/

Thur/R

28 Fader Assignment CH 4 L/

Thur/R

Controller 321 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18

30 2829313233343536373839404142

# Denon MC6000MK2

Control

Function Shift Function

1 CH ASSIGN Applies FX to selected channels

2 FX KNOBS Adjust Slot 1-3 FX Parameter Turn Knob 1 (Select Effect in Slot 1),

Turn Knob 2 (Select Effect in Slot 2),

Turn Knob 3 (Select Effect in Slot 1)

3 FX BUTTONS (P1,2,3) Slot 1-3 Effect On/Off Button 1 (Select Effect in Slot 1), Button

2 (Select Effect in Slot 2), Button 3

(Select Effect in Slot 1)

4 TAP Tap to set desired BPM/hold to reset

5 BEATS Turn to adjust Beats Multiplier setting/ push down to reset to 1/1

6 EQ (knobs) Adjust HI, MID and LOW

7 INPUT SELECT Toggles between available Line channels LN3,LN1,LN2,LN4 and PC mode

8 CH LEVEL Toggles focus between library, crates and open panels

9 INPUT SELECT Toggles between available Line channel LN1 and PC mode

10 LOAD Load selected track to Deck 1 (Press twice to Instant Double)

11 FILTER LP/HP lter combo adjust for channel 1

12 FILTER ON Turn lter combo on/off for channel 1

13 BROWSER Browses through currently focused area (library/crates/open panels) Click to

move between library and crates

14 FILTER ON Turn lter combo on/off for channel 2

15 LOAD Load selected track to Deck 2 (Press twice to Instant Double)

16 FWD Toggles focus between library, crates and open panels

17 IN Set loop in point (Loop not active)/Adjust loop in point (Loop active)

18 OUT Set loop out point (Loop in point set)/Adjust loop out point (Loop active)

19 MASTER LEVEL Adjusts the master output’s audio level

NOTE: The SHIFT button is used with other buttons that have shift modier functions.

# Denon MC6000MK2

Control

Function Shift Function

20 AUTO LOOP Activates Auto Loop

21 - Halve Auto Loop length

22 BOOTH LEVEL Adjust Booth Output

23 + Double Auto Loop Length

24 HOT CUE/SAMPLE Set/Trigger Cue (1,2,3,4) / Sample trigger (1,2,3,4) Delete Cue 1,2,3,4/ Shift + Sample + 1,2,3,4

stops sample playback

25 BOOTH ASSIGN Set booth assign to channel output 1,2,3,4 or master output

26 CENSOR/SLIP Censors the playing track while pressed Enables Slip mode.

27 SHIFT SHIFT button is used with other buttons that have shift modier functions

28 CHANNEL FADERS Adjusts the Channel Output

29 PANEL/VIEW/AREA/LIST Switches through available view and display options. See Display Options

table for more information

30 VIDEO LED Links crossfader to video channels only

31 X-F LINK Links the crossfader to Serato Video and/or audio channels Scrolls through Video transitions

32 LED METER Monitors the audio levels of the assigned Output (see LED METER

ASSIGN for more detail)

33 CROSSFADER Crossfades the output sound between Deck 1 & 2

34 LED METER ASSIGN LED meter assigning for CH1/2, CH3/4 or MASTER outputs

35 AUDIO LED Links crossfader to audio channels only

36 BACK Toggles focus between library, crates and open panels

37 CUE Cue selected channel in headphones

38 PITCH BEND -/+ Press or hold down either of these buttons to temporarily adjust the

track’s playback speed. When released, the track playback will return to

the speed designated by the PITCH FADER.

Fast Forward/Rewind

NOTE: The SHIFT button is used with other buttons that have shift modier functions.

# Denon MC6000MK2

Control

Function Shift Function

39 VINYL Toggles between Vinyl/Jog Modes

40 PLAY/PAUSE Play/Pause track

41 CUE Add or Jump to Temporary Cue

42 SYNC Sync On Sync Off (Press twice to return to Absolute

Pitch when in Relative Mode)

43 PITCH FADER Adjust Pitch When in Sync mode, used to disable the Pitch

Fader temporarily and change the zero position

44 PLATTER Adjust/Scratch or Jog Search

45 KEYLOCK Enable Keylock Cycle through available Tempo Range

46 ECHO ON 1/2 Adjust Mic Echo Wet/Dry for Mic Channels

47 DECK LAYER ASSIGN Swap deck layer

48 DUCKING Lowers master signal when pressed down/will stop ducking on release Routes Mic input to the Booth output

49 MIC ON 1/2 Turn on/off MIC channel 1 or 2

50 HOT CUE MODE Activates Hot Cue (1-4)

51 MIC 2 LEVEL KNOB Turn to adjust MIC 2 level

52 MIC 1 LEVEL KNOB Turn to adjust MIC 1 level

NOTE: The SHIFT button is used with other buttons that have shift modier functions.

Looping

You have the choice of Auto or Manual looping within Serato DJ with the

Denon MC6000MK2.

Display Options

Denon MC6000MK2

Control

Manual Loop Mode

IN Set loop in point (Loop not active)

IN Edit start of loop point with platter (Loop active)

OUT Set end of loop point (If Loop in point set)

OUT Edit end of loop point (Loop active)

AUTO LOOP Exit Manual Loop

NOTE: The best way to edit the start and end points of a manual loop is with

the jog wheel/platter on your Denon MC6000MK2.

Denon MC6000MK2

Control

Manual Loop Mode

Panel Cycles through REC, FX and SP-6 panels

View Cycles through the available deck views

Area Navigates through the Files, Browse, Prepare and

History panels

List Switches between Simple List and Album Art list

library view modes

Denon MC6000MK2

Control

Auto Loop Mode

AUTO LOOP Start Auto Loop

- Halve Auto Loop length

+ Double Auto Loop length

DJ-FX

The DJ-FX in Serato DJ are powered by iZotope™. Click the FX tab

to open the FX panel. Select either 1, 2, 3, 4 or M to assign the selected effect

bank to a deck or Master Output.

There are two available modes in the DJ-FX. Single FX Mode allows you to

select one effect per FX bank, and has multiple parameters that can be

adjusted. Multi FX Mode allows you to select up to three effects per FX bank,

and adjust only one parameter, the FX Depth. The same effects available in

Single FX mode are available in Multi FX mode, as well some additional presets.

You can select between the two FX modes by clicking either the Single FX

mode button or Multi FX mode button

MC6000MK2

Control

Single FX Mode Multi FX Mode Shift

FX P1

BUTTON

Effect On/Off Slot 1 Effect On/

Off

Slot 1 Select

Effect

FX P2

BUTTON

Effect Modier 1

On/Off

Slot 2 Effect On/

Off

Slot 2 Select

Effect

FX P3

BUTTON

Effect Modier 2

On/Off

Slot 3 Effect On/

Off

Slot 3 Select

Effect

FX KNOBS Adjust FX

Parameter (1-3)

Adjust FX

Parameter (1-3)

Adjust Beats

Multiplier

Serato Video

Serato Video is an Expansion Pack for Serato Software which adds the ability to

playback and mix video les, use effects and fader transitions with your Serato

DJ hardware, an additional MIDI controller or your mouse/keyboard.

For more information on Serato Video go to http://serato.com/video

When using the MC6000MK2 with Serato Video, the following functions apply:

MIDI

The MIDI control feature in Serato DJ provides the ability to map Serato DJ

software functions to MIDI controller functions such as keyboards, triggers,

sliders, and knobs. Integrating MIDI controllers into your Serato DJ setup can

improve live performance usability, such as hitting pads on a MIDI controller to

trigger Loops and Cue Points.

For more information download the Serato DJ manual by going to http://serato.

com/dj/downloads

NOTE: You can not MIDI Map your Denon MC6000MK2, you will need to con-

nect an additional MIDI controller to use these MIDI functions.

The MC6000MK2 also has a dedicated Video mode. To boot the unit up in

dedicated Video mode hold [SHIFT+ VIDEO ON (x2)] at the same time, then turn

on the MC6000MK2. Once the unit is turned on, press the BROWSER knob and

the controller will now be in Video mode.

In the dedicated Video mode, the following functions control Serato Video:

Denon MC6000MK2

Control

Function Shift

Video FX Knob 1 Highpass/Lowpass lter Adjust Video FX 1

Wet/Dry

Video FX Knob 2 Highpass/Lowpass lter Adjust Video FX 2

Wet/Dry

Video FX ON button N/A Turns Video FX 1 On

Video FX ON button N/A Turns Video FX 2 On

X-F Link Button Links crossfader to

Serato Video

Toggles Video

transition

Denon MC6000MK2 Control Function

Video FX Knob 1 Adjust Video FX parameter for Left Deck

Video FX Knob 2 Adjust Video FX parameter for Right Deck

Video FX ON button Switch to Filter Mode

Video FX ON button Switch to Video Mode

Pressing SHIFT will exit this mode and return to the original controller function.

Using the Tool Tips

Click on the icon to enable Tool Tips. This is located in next to the setup

button in the top right hand corner of the screen. Tool Tips provide a handy

way to learn the various features of Serato DJ.

Move the mouse over a section of the screen to bring up a context sensitive

tool tip. Holding the mouse over the button with Tool Tips turned on will

show you a list of all keyboard shortcuts.

For more information about how to use Serato DJ, please go to our website

www.serato.com or refer to the Serato DJ Software Manual.

For more information on your controller, please refer to the hardware manual.

For further help, please contact support@serato.com or go to www.serato.com/

dj/support

Andere Handbücher für MC6000MK2

Inhaltsverzeichnis

Andere Denon DJ-Equipment Handbücher

Denon

Denon X1850 Bedienungsanleitung

Denon

Denon DN-S700 - Compact Tabletop CD/MP3 Disc... Bedienungsanleitung

Denon

Denon MCX8000 Bedienungsanleitung

Denon

Denon MC7000 Bedienungsanleitung

Denon

Denon MC2000 Bedienungsanleitung

Denon

Denon PRIME 4 Bedienungsanleitung

Denon

Denon DN-HC5000 - Serato ITCH Hardware/Software... Bedienungsanleitung

Denon

Denon DN-X1500 Bedienungsanleitung

Denon

Denon PRIME 2 Bedienungsanleitung

Denon

Denon SC5000 PRIME Bedienungsanleitung

Denon

Denon DN-HC5000E2 Montageanleitung

Denon

Denon DN-X500 Bedienungsanleitung

Denon

Denon DN-X800 Bedienungsanleitung

Denon

Denon PRIME 4 Bedienungsanleitung

Denon

Denon SC5000 PRIME Bedienungsanleitung

Denon

Denon DN-X1500 Bedienungsanleitung

Denon

Denon DN-X400 Bedienungsanleitung

Denon

Denon MC7000 Bedienungsanleitung

Denon

Denon SC6000M PRIME Bedienungsanleitung

Denon

Denon PRIME 2 Bedienungsanleitung

Denon

Denon DN-MC6000 Bedienungsanleitung

Denon

Denon DN-X1500 Bedienungsanleitung

Denon

Denon DN-X1500 Bedienungsanleitung

Denon

Denon MCX8000 Bedienungsanleitung

Beliebte DJ-Equipment Handbücher anderer Marken

ALPHA LITE

ALPHA LITE ALPHA 1500 Betriebsanleitung

Chauvet

Chauvet OVATION E-930VW Bedienungsanleitung

Zumtobel

Zumtobel APHRODITE Home Bedienungsanleitung

Snow Masters

Snow Masters Zig Oscillator Bedienungsanleitung

EuroLite

EuroLite 50530554 Bedienungsanleitung

Beamz

Beamz BUV243 Bedienungsanleitung

thomann

thomann Stairville DJ Lase 40-G MK-III Bedienungsanleitung

Eagletone

Eagletone 6 Eyes Flower Bedienungsanleitung

EuroLite

EuroLite FLD-1508 Bedienungsanleitung

Technical Pro

Technical Pro LG8xSEA Bedienungsanleitung

JB Systems

JB Systems Lounge Laser DMX Bedienungsanleitung

Lightmaxx

Lightmaxx Vega Halo 90 Bedienungsanleitung

Elation

Elation FUZE WASH Z350 Bedienungsanleitung

Maverick

Maverick MK3 WASH Bedienungsanleitung

Infinity

Infinity TF-260C7 Fresnel Bedienungsanleitung

Chauvet

Chauvet EVE E-50Z Bedienungsanleitung

Eliminator Lighting

Eliminator Lighting E 138 Bedienungsanleitung

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Bedienungsanleitung
